HARDWARE GUIDE
MONDOPAD INF5720 & INF5722
009-1553-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MONDOPAD INF5720 and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus MONDOPAD INF5720

Summary of Contents for InFocus MONDOPAD INF5720

  • Page 1 HARDWARE GUIDE MONDOPAD INF5720 & INF5722 009-1553-00...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 Information about this Hardware Guide ..........................5 What’s Included ..................................6 Setup ....................................7 General mounting information ............................7 Stand assembly ................................8 Attach monitor to stand ..............................9 Attach the speakers ..............................10 Attach the HD video conferencing camera .........................11 Connect to other devices ............................12 Connect AC power ..............................14 External PC touchscreen control setup ........................14...

  • Page 5: Declaration Of Conformity

    Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.

  • Page 6: Safety Considerations

    Input ratings: 100-240V~ 50-60Hz, 5A Output ratings:100-240V~ 50-60Hz 1A max InFocus reserves the right to alter product offerings and specifications at any time without notice. SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source.

  • Page 7: Information About This Hardware Guide

    • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.

  • Page 8: What's Included

    Table stand kit Speaker kit *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. Page 6...

  • Page 9: Setup

    SETUP General mounting information This product ships with a table stand. It does not ship with any other mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • The table stand is for use on desk and table surface only. Do not use the table stand as a floor stand. Injury or product damage could occur.

  • Page 10: Stand Assembly

    Stand assembly Place base feet flat on a table or other surface. Insert support legs into base feet. Using the provided M16 screws, secure the support legs to the base feet. (Two screws attach from the bottom of the feet and two from the back of the base feet for a total of four screws per foot/leg.) Insert caps into the top of the support legs.

  • Page 11: Attach Monitor To Stand

    Attach monitor to stand If you have not already done so, carefully place your monitor face-down on a cushioned, clean surface to protect the screen from damages and scratches. Align the support legs to the back of the monitor with the longer side of the feet pointing towards the front of the monitor.

  • Page 12: Attach The Speakers

    The speakers can be installed as desired around the perimeter of the monitor using the supplied brackets, however NOTE: InFocus recommends installing the speakers across the bottom of the monitor. If you are not attaching the speakers, proceed to the next section, "Attach the HD video conferencing camera" on page 11.

  • Page 13: Attach The Hd Video Conferencing Camera

    Connect one end of the AC power cord to the Power jack on the back of the speaker. Connect the other end of the AC power cord to the Power Out jack on the bottom connector panel of the monitor. ON/OFF POWER INPUT...

  • Page 14: Connect To Other Devices

    Connect to other devices A full range of digital and analog video inputs and audio source devices can be connected to the connection panels on the back and side of the monitor. Available jacks include: HDMI In (2), PC In (1), Composite Video (1), Component RCA (1), RS232 (1), Audio In 3.5mm (1), Audio In RCA (1-R/L), Microphone In (1), RJ45 (2), USB-B for touch control (1), USB 2.0-A (4), USB 3.0-A (3), Audio Out RCA (1-R/L), and HDMI Out (1).
  • Page 15 Connect the camera or another USB device to this USB Type A 3.0 USB-A connector. ANTENNAS Receive and transmit wireless data. Antennas POWER Press to turn on/off the embedded computer. USB-A Connect a USB device to one of the USB Type A 3.0 connectors (e.g. a USB 3.0 / 2.0 hard drive).

  • Page 16: Connect Ac Power

    Connect AC power Connect one end of the AC power cord to the AC In jack on the back of the monitor. Connect the other end of the AC power cord to an AC outlet. Press the power switch. (The LED on the front of the monitor turns on.) NOTES: • Your monitor should only be operated from the power source indicated on the label.

  • Page 17: Set Up The Wireless Mouse And Keyboard

    SET UP THE WIRELESS MOUSE AND KEYBOARD NOTE: The wireless mouse and keyboard is not included as a standard accessory for some countries. For initial setup and/or configuration, it may be easier to use a mouse and keyboard. Any standard wired or wireless mouse or keyboard can be connected through the monitor's USB ports.

  • Page 18: Use The Remote

    USE THE REMOTE The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor.
  • Page 19 Remote buttons Power: Switches the power on or puts the monitor into Standby. POWER POWER Home: Changes the active source back to the embedded PC. HOME HOME INPUT MENU RESIZE Input: Toggles the Input Source menu on and off, which allows the user to INPUT change sources.

  • Page 20: Use The Keypad

    USE THE KEYPAD The keypad, located on the side of the monitor, has the following buttons: Power button: Switches the power on or puts the monitor into Standby. Input button: Turns the Source menu on allowing the user to change sources. Saves changes/selections if the OSD menu is on.

  • Page 21: Osd (On-Screen Display) Menu System

    OSD (ON-SCREEN DISPLAY) MENU SYSTEM The OSD provides the user the ability to control the monitor display. This is different than the Mondopad software described in the Mondopad Software Guide. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.

  • Page 22: Picture Menu

    Picture menu PICTURE BRIGHTNESS CONTRAST SHARPNESS NATIVE COLOR TEMPERATURE COLOR CONTROL BLUE GREEN STANDARD PICTURE MODE PICTURE RESET < > Adjust Enter Back Quit Brightness: changes the intensity of the image. Range: 0-100. (Default 70.) Contrast: controls the degree of difference between the lightest and darkest parts of the picture and changes the amount of black and white in the image.

  • Page 23: Screen Menu

    Screen menu SCREEN H POSITION V POSITION CLOCK CLOCK PHASE ASPECT RATIO WIDE SCREEN RESET < > Adjust Enter Back Quit H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only).

  • Page 24: Audio Menu

    Audio menu AUDIO SPEAKER INTERNAL AUDIO SOURCE MONDOPAD AUDIO RESET < > Adjust Enter Back Quit Speaker: controls whether both the internal and external speakers (sound bar, etc.) or just external speakers are used. Options include: Internal (both internal and external speakers operate) and External (only external speakers operate). Default Internal.

  • Page 25: Pip Menu

    PIP menu PIP SIZE SMALL PIP AUDIO MAIN PIP RESET < > Adjust Enter Back Quit PIP Size: changes the size of the PiP window used in the Corner-to-Corner configuration. Options include: Small (default), Middle and Large. PIP Audio: switches the audio source from the main source to the PiP source. Options include: Main (default) and Sub. PIP Reset: resets all PIP menu items to factory default settings.

  • Page 26: Configuration 1 Menu

    Configuration 1 menu CONFIGURATION 1 LANGUAGE ENGLISH AUTO SOURCE OPERATION MODE CONFIGURATION RESET FACTORY RESET < > Adjust Enter Back Quit Language: switches the OSD menu language. Auto Source: When enabled, automatically searches for an active source. Options: On (default) and Off. Operation Mode: When Monitor is enabled, the monitor acts like a simple monitor and only displays external source devices.

  • Page 27: Configuration 2 Menu

    Configuration 2 menu CONFIGURATION 2 OSD TURN OFF OSD H POSITION OSD V POSITION MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 45) OSD H Position: adjusts the horizontal position of the OSD menu.

  • Page 28: Advanced Option Menu

    Advanced option menu ADVANCED OPTION INPUT RESOLUTION MODE1 GAMMA SELECTION OVER SCAN SCAN CONVERSION NORMAL IR CONTROL UNLOCK KEYBOARD CONTROL MONITOR ID DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit Input Resolution: sets the resolution of the VGA input. This is only required when the monitor is unable to detect the VGA input resolution correctly.

  • Page 29: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be on). • Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage.
  • Page 30 • The monitor is in standby mode. Press the Power button on the remote or keypad. White Green • The monitor is powered on. Orange • Contact InFocus Support at www.infocus.com/support. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...

  • Page 31: Specifications

    SPECIFICATIONS To read the latest product specifications, be sure to visit our support website at www.infocus.com/support, as specifications are subject to change. Size (viewable) 57.51"(1460.68mm) diagonal Dimensions (without stand) 54.65" W x 33.71H x 3.59" D (1388.1 x 856.4 x 91.2 mm) Weight (without stand) 116.88lbs (53.015 kg)
  • Page 32 Speakers Power 120-240VAC, 50-60Hz Speaker Drivers Two 3” and one ¾” Aluminum Neodymium Tweeter (per side) Left and Right Channels Enclosure Type Sealed Speakers Frequency Response 90Hz to 20kHz Sound Pressure Level 98dB SPL (max vol@1m, pink noise) Signal to Noise Ratio (SNR) 110dB Amplifier Type High efficiency Class D amplifier...

  • Page 33: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 34 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 35 InFocus will provide warranty service either (i) at an ASP location, where service is performed at the location, or the ASP may send the product to an InFocus repair service location for service, (ii) by sending you prepaid way bills (and if you no longer have the original packaging, InFocus may send you packaging material at your cost) to INF5720 &...
  • Page 36 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 37 InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, OR 97223-8368 USA © 2014 InFocus Corp. All rights reserved. InFocus and the InFocus logo are trademarks of InFocus Corp., registered in the U.S. and other countries.

This manual is also suitable for:

Mondopad inf5722
