HARDWARE GUIDE
BIGTOUCH INF5711
009-1555-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIGTOUCH INF5711 and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus BIGTOUCH INF5711

Summary of Contents for InFocus BIGTOUCH INF5711

  • Page 1 HARDWARE GUIDE BIGTOUCH INF5711 009-1555-02...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 安全資訊 ....................................6 What’s Included ..................................8 Setup ....................................9 General mounting information ............................9 Stand assembly ................................10 Attach monitor to stand ..............................11 Connecting to other devices ............................12 Connecting AC power ..............................14 External PC touchscreen control setup ........................14 Turning the Monitor On/Off ...............................14 Setting up the Wireless Mouse and Keyboard ........................15 Wireless mouse ................................15...

  • Page 5: Declaration Of Conformity

    Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.

  • Page 6: Safety Considerations

    Input ratings: 100-240V~ 50-60Hz, 3.5A Output ratings:100-240V~ 50-60Hz 1A max InFocus reserves the right to alter product offerings and specifications at any time without notice. SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source.
  • Page 7 • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.

  • Page 8: 安全資訊

    安全資訊 在將本產品連接到電源前，請仔細閱讀並遵守以下列出以及產品上的所有安全指示。未遵守安全指示可能會導致火災、電擊 或人身傷害，並可 能破壞或損壞設備所提供的保護。請保存所有安全指示。 • 此顯示器非常重，至少需要兩個人移動並完成安裝。請勿自己嘗試移動或安裝顯示器，否則會造成傷害和/或損壞。 • 移動顯示器時，請務必使用手柄和側外框或底部外框牢牢托住顯示器。請勿抓握頂部外框。 • 移動顯示器包裝箱時，請勿傾斜或倒置包裝箱。始終保持直立。 • 移動顯示器前，請斷開所有配件和線纜。 • 如果將顯示器裝在牆上，請在顯示器和牆壁之間保留最少 1.98 英寸（5 釐米）的距離，以保持足夠通風。 • 有關正確開機和關機流程，請參閱本指南。 • 請遵循本手冊中以及顯示器上的所有警告和注意事項。 • 顯示器的擺放位置應與加熱和冷卻通風孔保留至少 4 英尺（1.2 米）的距離。 • 請勿堵塞通風口。將顯示器置於通風良好的區域，且進氣口或排氣口無阻塞。 • 請勿在散熱器、電熱器、火爐或其他產生熱量的設備（包括放大器）等熱源附近安裝或使用顯示器或條形音箱。 • 請勿將顯示器放在陽光直射、潮濕、油膩或積塵，或顯示幕可能接觸到雨水、煙霧或蒸汽的區域。 • 請勿在電源線靠近浴缸、洗臉盆、廚房水槽、游泳池附近等有水的區域使用顯示器。 • 請勿在靠近水的區域使用顯示器的任何元件，包括條形音箱。警告：要降低火災或電擊風險，請勿使本設備或其元件淋 雨或受潮。 • 請勿拋擲顯示器。 • 請勿將液體濺灑在顯示器上。濺落的液體可能會損壞顯示器。 •...
  • Page 9 • 請向專業維修人員諮詢所有維修資訊。請勿卸下封蓋或封底。自行維修顯示器不僅會對您造成傷害，而且也會使保修失 效。 • 僅使用 InFocus 指定的更換零件。未經授權進行更換可能會造成火災、電擊或人身傷害，並可能使保修失效。 • 將顯示器安裝到牆上時，必須使用 8 枚公制（12 毫米）螺絲。此外，安裝介面應符合北美地區的 UL1678 標準。安裝方 法應結實牢固，足以承受顯 示器的重量（參見產品技術規格）。 • 遵守這些指示有助於確保使用壽命內顯示器的圖像品質。不遵守這些指示可能會影響保修。 • 鋰電池注意事項（僅適用于發運時配有內嵌 PC 箱的型號）：如果更換的電池類型不正確，可能會有爆炸的風險。應按 照製造商的建議，使用相同或同類型的電池進行更換。按照當地廢棄物品處理法規處理廢舊電池。 INF5711 Hardware Guide Page 7...

  • Page 10: What's Included

    (Batteries not included) *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. Page 8...

  • Page 11: Setup

    SETUP General mounting information This product ships with a table stand. It does not ship with any other mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • The table stand is for use on desk and table surface only. Do not use the table stand as a floor stand. Injury or product damage could occur.

  • Page 12: Stand Assembly

    Stand assembly Place base feet flat on a table or other surface. Insert support legs into base feet. Using the provided M16 screws, secure the support legs to the base feet. (Two screws attach from the bottom of the feet and two from the back of the base feet for a total of four screws per foot/leg.) Insert caps into the top of the support legs.

  • Page 13: Attach Monitor To Stand

    Attach monitor to stand If you have not already done so, carefully place your monitor face-down on a cushioned, clean surface to protect the screen from damages and scratches. Align the support legs to the back of the monitor with the longer side of the feet pointing towards the front of the monitor.

  • Page 14: Connecting To Other Devices

    Connecting to other devices A full range of digital and analog video inputs and audio source devices can be connected to the connection panels on the back and side of the monitor. Available jacks include: HDMI In (2), PC In (1), Composite Video (1), Component RCA (1), RS232 (1), Audio In 3.5mm (1), Audio In RCA (1-R/L), Microphone In (1), RJ45 (2), USB-B for touch control (1), USB 2.0-A (4), USB 3.0-A (3), Audio Out RCA (1-R/L), and HDMI Out (1).
  • Page 15 Connect the camera or another USB device to this USB Type A 3.0 USB-A connector. ANTENNAS Receive and transmit wireless data. Antennas POWER Press to turn on/off the embedded computer. HDMI OUT Connect an HDMI cable from the embedded computer to another monitor.

  • Page 16: Connecting Ac Power

    Connecting AC power Connect one end of the AC power cord to the AC In jack on the back of the monitor. Connect the other end of the AC power cord to an AC outlet. Press the power switch. (The LED on the front of the monitor turns on.) NOTES: • Your monitor should only be operated from the power source indicated on the label.

  • Page 17: Setting Up The Wireless Mouse And Keyboard

    SETTING UP THE WIRELESS MOUSE AND KEYBOARD NOTE: The wireless mouse and keyboard is not included as a standard accessory for some countries. For initial setup and/or configuration, it may be easier to use a mouse and keyboard. Any standard wired or wireless mouse or keyboard can be connected through the monitor's USB ports.

  • Page 18: Using The Remote

    USING THE REMOTE The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor.
  • Page 19 Remote buttons Power: Switches the power on or puts the monitor into Standby. POWER POWER Home: Changes the active source back to the embedded PC. HOME HOME INPUT MENU RESIZE Input: Toggles the Input Source menu on and off, which allows the user to INPUT change sources.

  • Page 20: Using The Keypad

    USING THE KEYPAD The keypad, located on the side of the monitor, has the following buttons: Power button: Switches the power on or puts the monitor into Standby. Input button: Turns the Source menu on allowing the user to change sources. Saves changes/selections if the OSD menu is on.

  • Page 21: Osd (On-Screen Display) Menu System

    OSD (ON-SCREEN DISPLAY) MENU SYSTEM The OSD provides the user the ability to control the monitor display. This is different than the Mondopad software described in the Mondopad Software Guide. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.

  • Page 22: Picture Menu

    Picture menu PICTURE BRIGHTNESS CONTRAST SHARPNESS NATIVE COLOR TEMPERATURE COLOR CONTROL BLUE GREEN STANDARD PICTURE MODE PICTURE RESET < > Adjust Enter Back Quit Brightness: changes the intensity of the image. Range: 0-100. (Default 70.) Contrast: controls the degree of difference between the lightest and darkest parts of the picture and changes the amount of black and white in the image.

  • Page 23: Screen Menu

    Screen menu SCREEN H POSITION V POSITION CLOCK CLOCK PHASE ASPECT RATIO WIDE SCREEN RESET < > Adjust Enter Back Quit H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only).

  • Page 24: Audio Menu

    Audio menu AUDIO SPEAKER INTERNAL AUDIO SOURCE MONDOPAD AUDIO RESET < > Adjust Enter Back Quit Speaker: controls whether both the internal and external speakers (sound bar, etc.) or just external speakers are used. Options include: Internal (both internal and external speakers operate) and External (only external speakers operate). Default Internal.

  • Page 25: Pip Menu

    PIP menu PIP SIZE SMALL PIP AUDIO MAIN PIP RESET < > Adjust Enter Back Quit PIP Size: changes the size of the PiP window used in the Corner-to-Corner configuration. Options include: Small (default), Middle and Large. PIP Audio: switches the audio source from the main source to the PiP source. Options include: Main (default) and Sub. PIP Reset: resets all PIP menu items to factory default settings.

  • Page 26: Configuration 1 Menu

    Configuration 1 menu CONFIGURATION 1 LANGUAGE ENGLISH AUTO SOURCE OPERATION MODE CONFIGURATION RESET FACTORY RESET < > Adjust Enter Back Quit Language: switches the OSD menu language. Auto Source: When enabled, automatically searches for an active source. Options: On (default) and Off. Operation Mode: When Monitor is enabled, the monitor acts like a simple monitor and only displays external source devices.

  • Page 27: Configuration 2 Menu

    Configuration 2 menu CONFIGURATION 2 OSD TURN OFF OSD H POSITION OSD V POSITION MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 45) OSD H Position: adjusts the horizontal position of the OSD menu.

  • Page 28: Advanced Option Menu

    Advanced option menu ADVANCED OPTION INPUT RESOLUTION MODE1 GAMMA SELECTION OVER SCAN SCAN CONVERSION NORMAL IR CONTROL UNLOCK KEYBOARD CONTROL MONITOR ID DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit Input Resolution: sets the resolution of the VGA input. This is only required when the monitor is unable to detect the VGA input resolution correctly.

  • Page 29: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be on). • Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage.
  • Page 30 • The monitor is in standby mode. Press the Power button on the remote or keypad. White Green • The monitor is powered on. Orange • Contact InFocus Support at www.infocus.com/support For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...

  • Page 31: Specifications

    SPECIFICATIONS To read the latest product specifications, be sure to visit our support website at www.infocus.com/support, as specifications are subject to change. Size (viewable) 57.51"(1460.68mm) diagonal Dimensions (without stand) 54.65" W x 33.71H x 3.59" D (1388.1 x 856.4 x 91.2 mm) Weight (without stand) 116.88lbs (53.015 kg)
  • Page 32 Mouse Dimension 59.2 x 103.6 x 34.8mm Weight ~68g excluding batteries Batteries Two (2) AAA alkaline Operating Voltage 2.0V~3.2VDC Power Consumption <8.5mA @3V Battery Life 150 working hours continuous operation Operating Distance 10M without signal disturbance and no direction limit Page 30...

  • Page 33: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 34 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 35 InFocus will provide it. You must assist in diagnosing issues with your product and follow InFocus’s warranty processes. InFocus may restrict service to the country where InFocus or its Authorized Distributors originally sold the hardware product. InFocus will provide warranty service either (i) at an ASP location, where service is performed at the INF5711 Hardware Guide...
  • Page 36 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 37 InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, OR 97223-8368 USA © 2015 InFocus Corp. All rights reserved. InFocus and the InFocus logo are trademarks of InFocus Corp., registered in the U.S. and other countries.
