LCD Monitor
User Manual
E2200HDP
Welcome
Downloaded from ManualMonitor.com Manuals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2200HDP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BenQ E2200HDP

Summary of Contents for BenQ E2200HDP

  • Page 1 LCD Monitor User Manual E2200HDP Welcome Downloaded from ManualMonitor.com Manuals...

  • Page 2: Copyright

    Copyright Copyright © 2009 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

  • Page 3: Table Of Contents

    How to assemble your monitor hardware ................7 How to detach the stand base ...................10 Getting the most from your BenQ monitor ..............11 How to install the monitor on a new computer ............12 How to upgrade the monitor on an existing computer ..........13 How to install on Windows Vista systems ...............14...

  • Page 4: Getting Started

    1. Getting started When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. BenQ LCD Monitor Monitor Base Quick Start Guide CD-ROM Power Cord (Picture may differ from product supplied for your region.)
  • Page 5 Video Cable: DVI-D (Optional accessory for models with DVI inputs, sold separately) Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor. The fitted foam packing is ideal for protecting the monitor during transport. Getting started Downloaded from ManualMonitor.com Manuals...

  • Page 6: Getting To Know Your Monitor

    2. Getting to know your monitor Front view Back view 1. AC Power Input jack 2. DVI-D socket 3. D-Sub socket 4. Lock switch Getting to know your monitor Downloaded from ManualMonitor.com Manuals...

  • Page 7: How To Assemble Your Monitor Hardware

    3. How to assemble your monitor hardware If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. 1. Attach the monitor base. Please be careful to prevent damage to the monitor.
  • Page 8 2. Connect the PC video cable To Connect the D-Sub Cable Connect the plug of the D-Sub cable (at the end without the ferrite filter) to the monitor video socket. Connect the other end of the cable (at the end with the ferrite filter) to the computer video socket.
  • Page 9 Turn on the monitor by pressing the power button on the front of the monitor. Turn on the computer too, and follow the instructions in Section 4: Getting the most from your BenQ monitor on page 11 to install the monitor software. How to assemble your monitor hardware...

  • Page 10: How To Detach The Stand Base

    How to detach the stand base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like a towel on the desk for padding, before laying the screen face down on a flat clean padded surface.

  • Page 11: Getting The Most From Your Benq Monitor

    4. Getting the most from your BenQ monitor To gain the most benefit from your new BenQ color LCD flat screen monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM.

  • Page 12: How To Install The Monitor On A New Computer

    BenQ LCD Monitor is the first ever monitor to be connected to it. If you are adding the BenQ LCD Monitor to an existing computer that has already had another monitor connected to it (and has monitor driver software installed), you should not be following these instructions.

  • Page 13: How To Upgrade The Monitor On An Existing Computer

    The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems.

  • Page 14: How To Install On Windows Vista Systems

    This will copy and install the appropriate monitor driver files to your computer. 10. Click Close. You do not need to restart Windows Vista, as the BenQ LCD monitor drivers will operate immediately with no further action required by you.

  • Page 15: How To Install On Windows Xp System

    The Monitor Properties window will display. If the driver provider is listed as BenQ, and the model matches that of your new monitor, the proper drivers are already installed, and you need do nothing further. Cancel out of these property windows.

  • Page 16: Picture Optimization

    If you wish, you can always adjust the screen geometric settings manually using geometry menu items. To assist you in this endeavour, BenQ has provided a screen test image utility which you can use to check for screen color, grayscale and line gradient display.

  • Page 17: How To Adjust Your Monitor

    6. How to adjust your monitor The control panel 1. “AUTO”: Adjust vertical position, phase, horizontal position and pixel clock automatically. 2. “MENU” key: Activate OSD main menu and return to the previous menu or exit OSD. /Contrast/Brightness key: For Up/Increase adjustment. The key is the hot key for Brightness and Contrast.

  • Page 18: Hot Key Mode

    Hot key mode The monitor keys perform as hot keys to provide direct access to particular functions whenever the menu isn't currently displaying on-screen. Brightness and Contrast hot key Press the key to display the Brightness and Contrast indicators. Further press the keys, then the ENTER key to select Brightness or Contrast.

  • Page 19: Main Menu Mode

    Main menu mode You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor. Press the MENU key to display the following main OSD menu. There are four main OSD menus: 1. Display 2. Picture 3.
  • Page 20 Display menu 1. Press the MENU key to display the main menu. 2. Press the keys to select DISPLAY and then press the ENTER key to enter the menu. 3. Press the keys to move the highlight to a menu item and then press the ENTER key to select that item.
  • Page 21 H. Position Adjusts the horizontal 0 to 100 position of the screen image. V. Position Adjusts the vertical 0 to 100 position of the screen image. Pixel Clock Adjusts the pixel clock 0 to 100 frequency timing to synchronize with the analog input video signal.
  • Page 22 Picture menu 1. Press the MENU key to display the main menu. 2. Press the keys to select PICTURE and then press the ENTER key to enter the menu. 3. Press the keys to move the highlight to a menu item and then press the ENTER key to select that item.
  • Page 23 Normal Allows video and still photographs to be viewed with natural coloring. This is the factory default color. Bluish Applies a cool tint to the Press the keys image and is factory to select this option. pre-set to the PC industry standard white color.
  • Page 24 Picture Advanced menu 1. Press the MENU key to display the main menu. 2. Press the keys to select PICTURE ADVANCED and then press the ENTER key to enter the menu. 3. Press the keys to move the highlight to a menu item and then press the ENTER key to select that item.
  • Page 25 • Full Display Mode This feature is provided to Press the keys allow aspect ratio’s other • Aspect to change the settings. than 16:9 to be displayed without geometric distortion. • Full - Scales the input image to fill the screen. Ideal for 16:9 aspect images.
  • Page 26 System menu 1. Press the MENU key to display the main menu. 2. Press the keys to select SYSTEM and then press the ENTER key to enter the menu. 3. Press the keys to move the highlight to a menu item and then press the ENTER key to select that item.
  • Page 27 H. Position Adjusts the horizontal 0 to 100 position of the OSD menu. V. Position Adjusts the vertical 0 to 100 position of the OSD menu. • 5 Sec. Display Time Adjusts the display time of Press the keys to the OSD menu.

  • Page 28: Troubleshooting

    7. Troubleshooting Frequently asked questions (FAQ) The image is blurred: Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions. How do you use a VGA extension cable? Remove the extension cable for the test.

  • Page 29: Need More Help

    “OSD Settings” menu (under SYSTEM), and all OSD controls will be accessible. Need more help? If your problems remain after checking this manual, please contact your place of purchase or e-mail us at: Support@BenQ.com Troubleshooting Downloaded from ManualMonitor.com Manuals...
