Rayburn Cookmaster 300W User Instructions

BS EN 12815
Consumer Protection Act 1987
As responsible manufacturers, we take care to make sure that our
products are designed and constructed to meet the required safety
standards when properly installed and used.
IMPORTANT NOTICE: PLEASE READ THE ACCOMPANYING
WARRANTY: Any alteration that is not approved by Aga, could
invalidate the approval of the appliance, operation of the warranty
and could also affect your statutory rights. Use only authorised
replacement parts.
All local regulations including those referring to national and
European standards need to be complied with when installing
the appliance.
Control of Substances - Health and Safety
Important
This appliance may contain some of the materials that are indicated.
It is the Users/Installers responsibility to ensure that the necessary
INTRODUCTION
The Rayburn 300W has been designed to burn wood
logs only. The grate baffle plates must be in place before
using the appliance. THIS APPLIANCE IS NOT
APPROVED TO BURN SOLID MINERAL FUELS.
Under normal use it is not necessary to riddle the grate.
The correct setting of the spinwheel and flue damper will
be found after having some experience with the
appliance and will alter according to day-to-day
requirements.
Secondary Air Slide.
On opening the firedoor the secondary air slide is seen
on the base of the opening and should be set according
to the type of wood used.
Air Slide Open - most wood types
Air Slide Closed - some hard woods such as oak or when
first starting the fire.
WARNING: HOT SURFACES, use the tool supplied to
operate this appliance. It is recommended to use the
heatproof glove supplied when raising the dome lids to
use the hotplate. Replacement gloves can be obtained
from the Aga Shop.
WARNING
THE ASHPIT AND FIREBOX DOORS MUST BE LOCKED
CLOSED AT ALL TIMES DURING NORMAL USE, EXCEPT
WHEN LIGHTING OR RE-FUELLING.
raywarranty@aga-web.co.uk
Users Instructions.
Rayburn Cookmaster 300W
Wood Burning Cooker
personal protective clothing is worn when handling, where
applicable, the pertinent parts that contain any of the listed materials
that could be interpreted as being injurious to health and safety, see
below for information.
Firebricks, Fuel beds, Fuels - when handling use disposable
gloves.
Fire Cement - when handling use disposable gloves.
Glues and Sealants - exercise caution - if these are still in liquid
form use face mask and disposable gloves.
Glass Yarn, Mineral Wool, Insulation Pads, Ceramic Fibre,
Kerosene Oil - may be harmful if inhaled, may be irritating to skin,
eyes, nose and throat. When handling avoid inhaling and contact
with skin or eyes. Use disposable gloves, face-masks and eye
protection. After handling wash hands and other exposed parts.
When disposing of the product, reduce dust with water spray,
ensure that parts are securely wrapped.
Grate Restriction Plate
The appliance comes supplied with three rectangular air
restriction plates on the bottomgrate. These should
always be in place during operation to control the amount
of air into the firebox. They should be removed to clean
the bottomgrate and to use the riddling rod on the left
hand side of the unit, but must be replaced after
cleaning.
Fig. 1
1
06/07 EOPI 515185
