Electric Cooker
Two-Oven
Instructions for Use,
Installation and Servicing
For use in GB, IE (Great Britain and Eire)
IMPORTANT
The front and top of this appliance will become hot during operation ; it is therefore recommended that a suitable guard should be
used for protection of young children, the elderly or infirm.
This appliance is guaranteed for 3 years Parts & 1 year Labour (subject to the conditions on page 3 of this Instruction manual).
These Instructions must be left with the appliance for future reference and for consultation when servicing the appliance. Please
make the customer aware of the correct operation of the appliance before leaving these instructions with them.
The commissioning sheet found on Page 3 of this Instruction manual must be completed by the Installer prior to leaving the
premises.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rayburn Two-Oven
Summary of Contents for Rayburn Two-Oven
-
Page 1: Instructions For Use
Electric Cooker Two-Oven Instructions for Use, Installation and Servicing For use in GB, IE (Great Britain and Eire) IMPORTANT The front and top of this appliance will become hot during operation ; it is therefore recommended that a suitable guard should be used for protection of young children, the elderly or infirm. -
Page 2: Table Of Contents
CONTENTS SERVICING INSTRUCTIONS Appliance Commissioning Checklist Dealer and Installer Information REPLACING PARTS USER INSTRUCTIONS General Description Fan Motor General Overheat Switches Ovens and Warm Front Fan Oven Element Using the Radiant Hob Grill Element Introduction to Induction Lower Oven Element Using the Induction Hob Fan Oven Thermostat Care of Cooker... -
Page 3: Appliance Commissioning Checklist
This product is guaranteed for 3 years Parts & 1 year Labour from the date of installation, as set out in the terms and conditions of sale between AGA and your local Rayburn dealer. This guarantee will be invalid, to the extent permitted by law, if the above Appliance Commissioning Checklist is not fully completed by the installer and available for inspection by a Rayburn engineer. -
Page 4: User Instructions
2.12 Do not place knives, forks, spoons and lids on the hob surface since these can get hot. The Rayburn Electric Traditional Cooker has enamel lined multifunctional fan oven, grill and multifunctional 3. THE OVENS & WARM FRONT conventional oven combining the classic look of the... - Page 5 USER INSTRUCTIONS 3.4 REPLACING SHELVES • Place shelf onto the stainless steel runner, Diagram 2 AR2024 3.6 WARM FRONT The Warm Front can either be switched ON or OFF. AR2022 When you turn the dial to the ON position, the front and its edge are brought to a warm temperature (warm to •...
-
Page 6: Using The Radiant Hob
USER INSTRUCTIONS 3.10 FAN-ASSISTED OVEN 3.12 LOWER OVEN This oven option has greater speed than the The Lower Oven can be run as a conventional oven with optional traditional oven but can be used in the features: same way, offering every baking or cooking mode. -
Page 7: Introduction To Induction
USER INSTRUCTIONS 4.2.2 Zones 4.1 TURNING THE HOB ON When the hob is first switched on, only the inner • Touch the On/Off key to turn the Hob on. You zone is heated. For faster heating, touch the 'zone' hear a short beep. The display shows ‘0’. key to turn on the other zones. -
Page 8: Using The Induction Hob
USER INSTRUCTIONS contents are, in fact, heated by the pan. The pan rapidly reaches 6. USING THE INDUCTION HOB the chosen temperature and quickly stops any cooking when lifted away from the hob surface. It is this flexibility, speed and control that many cooks find attractive. - Page 9 USER INSTRUCTIONS 6.3 WARNING between “A” and the power level selected. After the pre-heat time has elapsed the power level will reduce to the level selected The display shows ‘H’ if the hob remains hot after use. The heat and the display will no longer flash “A” and will display the power is producted by pans resting on the hob and is not induced heat.
-
Page 10: Care Of Cooker
11. RUNNING IN ceramic hobs. Use clean water to rinse off the cleaner and rub to finish with a dry cloth. 11.1 The new surface coating on your Rayburn cooker will “burn • Remove stubborn splashes with a glass scraper: off”... -
Page 11: Fault Finding
USER INSTRUCTIONS Step 2: 14.2 HOBS H - WARNING - the hob's surface remains hot If your cooker has developed a fault during the guarantee period, your installer should contact the AGA • Correct zone has been switched ON and temperature Rangemaster Service Centre for assistance. -
Page 12: Installation Instructions
INSTALLATION INSTRUCTIONS TECHNICAL INFORMATION GENERAL Connection Voltage 230V 50HZ Maximum Power Rating 52 amp (Induction Hob Model) 40 amp (Radiant Hob Model) Cooker Weight 214 Kilos INDUCTION HOB POWER Right Hand Hob Variable, depending on pan size up to 3.7kW Left Hand Hob Variable, depending on pan size up to 3.7kW RADIANT HOB... -
Page 13: Site Requirements
INSTALLATION INSTRUCTIONS SITE REQUIREMENTS 10mm clearance to Work top Work top Square lid option Position of Position of door lid when when open raised 10mm clearance to Wall Services duct Important - Electrical connections are left hand side only AR2008 Dimensions in Millimetres 1. -
Page 14: Installation
INSTALLATION INSTRUCTIONS INSTALLATION IMPORTANT 1. STANDARDS The wires in the mains lead are coloured in accordance This appliance should be installed according to with the following code: regulations in force and only used in a well-ventilated space. Read these instructions before installing or - green/yellow Earth operating. -
Page 15: Location
INSTALLATION INSTRUCTIONS INSTALLATION 4. LOCATION • Decide on where the cooker is to be located, see Site Requirements • Install the electrical supply up to the cooker switch, see YOUR COOKER SHOULD REMAIN ON THE PALLET. AR2030 • Slide off the pallet onto the plinth •... -
Page 16: Final Assembly
INSTALLATION INSTRUCTIONS INSTALLATION • Fit the two towel rail cast iron ends to the rail • Lock with the hex grub screw, Diagram 9 Mains cable clamp AR2035 • Feed the 10mm mains cooker cable through the channel and into the cooker, Diagram 6 AR2031 •... -
Page 17: Commissioning
INSTALLATION INSTRUCTIONS COMMISSIONING 7. COMMISSIONING ON COMPLETION, THE INSTALLATION MUST BE CHECKED FOR SAFETY. THE TESTS MUST INCLUDE: • POLARITY CHECK • EARTH BOND CONTINUITY • INSULATION RESISTANCE CHECK IMPORTANT IF THERE IS NO MAINS SUPPLY OR THE ABOVE TESTS CANNOT BE CARRIED OUT, ENSURE THAT A WARNING LABEL IS ATTACHED TO THE APPLIANCE STATING THAT IT SHOULD NOT BE USED UNTIL ELECTRICALLY TESTED BY A SUITABLY QUALIFIED... -
Page 18: Wiring Diagram
SERVICING INSTRUCTIONS WIRING DIAGRAM... -
Page 19: Servicing Instructions
SERVICING INSTRUCTIONS REPLACING PARTS IMPORTANT The work must be carried out by trained service engineers. 1. GENERAL IMPORTANT – The glass panel on this appliance should be checked for any signs of damage on the front face of the glass panel (scratches, scores, cracks or other surface defects). -
Page 20: Overheat Switches
SERVICING INSTRUCTIONS REPLACING PARTS • Remove the three screws (Arrow B) and the fan motor Remove the three screws retaining the oven element and from the panel, Diagram 4. carefully pull forward the element to expose the connections. See diagram 7, Arrow C. •... -
Page 21: Fan Oven Thermostat
SERVICING INSTRUCTIONS REPLACING PARTS To change the top element: • Remove the single fixing screw and carefully pull forward the element to expose the connections. See diagram 9, Arrow A. AR2028 • Remove the two screws securing the control to the panel, Diagram 12 AR1559 •... -
Page 22: Lower Oven Thermostat
In the unlikely event that a problem occurs with any of the following features: - Induction Hob - Radiant Hob - Neon Indicators - Warm Front The parts are serviceable only by an authorised Rayburn Service engineer; contact your local Rayburn agent. - Page 23 SERVICE RECORDS 1ST SERVICE 2ND SERVICE Date of Service:................Date of Service:................Next Service Due:............... Next Service Due:............... Signed:..................Signed:..................Dealer's Stamp Registration Number Dealer's Stamp Registration Number 3RD SERVICE 4TH SERVICE Date of Service:................Date of Service:................Next Service Due:................ Next Service Due:...............
- Page 24 Manufactured by AGA Rangemaster Station Road, Ketley, Telford, Shropshire, England TF1 5AQ England, Scotland & Wales Tel: 0845 6010398 Northern Ireland Tel: 02891 270233 www.agaliving.com www.agacookshop.co.uk www.rayburn-web.co.uk N00532AXX...
