- Page 1 AO520/AO620 OUTDOOR SPEAKERS I n s t a l l a t i o n & O p e r a t i o n M a n u a l...
- Page 2 This manual contains features, setup recommendations and specifications for the AO520 and AO620 outdoor speakers. We recommend you thoroughly read through the material contained in this manual before connecting your speakers.
- Page 3 The bracket for the AO520 and AO620 allows the speaker to be hung either horizontally or vertically, and can be mounted several different ways and swivels for optimum placement.
- Page 4 The hole in the center of the bracket allows speaker wire through so it may be properly attached to the speaker. It is best to consult your local Destination Audio dealer or installer with any further questions.
- Page 5 E. Use the bracket knobs to attach the speaker to the bracket, being careful to not tighten the knobs; this will allow the speaker to be angled slightly so the rear binding posts are accessible (see Parts Guide). F. Connect one wire to the black terminal and one to the red terminal, paying close attention to the markings on the wires for proper polarity.
- Page 6 Specifications Model AO520 AO620 70 Hz - 20kHz ± 3 dB 60 Hz - 20kHz ± 3 dB Frequency Response: 87 dB (2.83V @ 1 Meter) 88 dB (2.83V @ 1 Meter)
- Page 7 Limited Warranty Information Your Destination Audio AO520 or AO620 outdoor speaker is covered by a limited warranty against defects in materials and workmanship for a period of five (5) years from the original date of purchase. This warranty is provided by the authorized Destination Audio dealer where the speaker was purchased.
- Page 8 382 Marshall Way, Layton, Utah • USA • 84041 Toll Free: (800) 543-2205 • Fax: (801) 543-3300 www.destinationaudio.com It is Destination Audio policy to continuously incorporate improvements into our products; all specifications are subject to change without notice. Copyright © 2006-2009 Destination Audio. All Rights Reserved.
