STEP 1
a) Attach the Left and Right Bar Assembly together by first sliding the Left Bar
Assembly into the Right Bar Assembly.
b) Next, align the holes at the center where
the 2 Bars slide together. Securely
attach the 2 Bars together with
Right Bar Assembly
2 Washers, 2 Spring Washers and
Washer
2 Phillips Bolts. Tighten with Tool
Phillips Bolt
Left Bar Assembly
Spring
provided. When assembled, this is
Washer
referred to as the Crossbar.
Note: Make sure the Foam Grip around the Holes does
not interfere with tightening the Phillips Bolts.
STEP 2
Long
Carriage
a) Locate the 2 Square Holes on the Left and
Bolt
Right U Shaped Tube Assemblies. Lay on top
of the Crossbar and line up the holes. Insert
2 Long Carriage Bolts into the Square Holes
Square
Right
Holes
and through the Left and Right U Shaped
U Shaped
Tube
Left
Tube Assemblies.
U Shaped
Note: Make sure the Square on the
Tube
Washer
Carriage Bolt seats into the Square Hole.
Spring
Washer
b) While holding the Carriage Bolt in
Acorn Nut
the Square Hole, insert the end of the
Carriage Bolt through the Holes in the
Crossbar. Secure with Washer, Spring
Washer and Acorn Nut. Hand-tighten only
at this time. Repeat for other U Shaped
Phillips Bolt
Curved
Tube Assembly.
Spring
Frame
Washer
Tubes
Washer
STEP 3
a) Attach the Left and Right Curved Frame
Tubes to the U Shaped Tubes.
b) Next, align holes and insert 2 Washers,
2 Spring Washers and 2 Phillips Bolts per
Crossbar
side.
(Left and Right
Bar Assembly)
Right
Handlebar
Long
STEP 4
Carriage
Curve
Bolt
a) Place the Left and Right Handlebars
Down
on the Left and Right U Shaped Tubes
as shown. Curve faces down.
b) Align holes of the Handlebars and
the U Shaped Tubes and insert 2
Left
Long Carriage Bolts per side. Place
Handlebar
Washers and Spring Washers on
the bottom and tighten with Acorn Nuts.
Washer
Spring Washer
Acorn Nut
