- Page 1 Achat 110 M passive full-range speaker user manual...
- Page 2 Musikhaus Thomann Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 26.05.2015, ID: 230510, 277965 (V2)
-
Page 3: Table Of Contents
1.3 Symbols and signal words....................... 6 Safety instructions............................. 8 Features............................... 10 Installation..............................11 4.1 Tips on handling speakers......................12 4.2 Mounting............................13 4.3 Connections............................17 Technical specifications........................19 Plug and connection assignment....................21 Protecting the environment......................22 Achat 110 M... -
Page 4: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 5: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 7 NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. Achat 110 M...
-
Page 8: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed as a PA system. This device is designed for professional and not house‐ hold use. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 9 If this is not possible, keep a greater distance or use suffi‐ cient ear protectors. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Achat 110 M...
-
Page 10: Features
Features Features Special features of this powerful and compact full-range speaker: Connections: 2 lockable NL4 sockets (1+/1–) M10 rigging points Speaker stand flange Textured paint (item no. 230510: black, item no. 277965: white) Optionally available accessories: – Vertical bracket the box pro Achat 110M U-bracket (item no. 258813: black, item no. 296830: white) –... -
Page 11: Installation
Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Achat 110 M... -
Page 12: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 13: Mounting
NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field. Achat 110 M... - Page 14 Installation Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. In Germany: BGV C1 "Staging and Production Facilities for the Entertainment Industry". Only trained, qualified personnel may hang up speakers. Mounting options You can install the device standing or hanging upside down.
- Page 15 We recommend that the speaker be set up so that the lower edge is located 175 cm above the floor. Achat 110 M...
- Page 16 Installation Suspended mounting WARNING! Risk of injury caused by falling objects Portable PM systems should be secured from falling using two independently working devices, for example, safety ropes. The load capacity of trusses or other fixtures must be sufficient for the intended number of devices.
-
Page 17: Connections
Installation 4.3 Connections Installation methods Achat 110 M... - Page 18 Installation 1 [INPUT] Lockable NL4 connector for signal input (1+/1–). 2 [THRU] Lockable NL4 output connector (1+/1–) to connect another speaker. passive full-range speaker...
-
Page 19: Technical Specifications
Frequency range 70 Hz … 20 kHz Dispersion angle (H × V) 90° × 60° Dimensions (W × H × D) 300 mm × 450 mm × 285 mm (15.35in. × 15.55in. × 5.31in.) Weight 11 kg Achat 110 M... - Page 20 Technical specifications passive full-range speaker...
-
Page 21: Plug And Connection Assignment
‘just’ in poor transmission quality! NL4 mounting connectors 1, + Signal 1 (in phase) 1, – Signal 1 (180 degree phase shift) 2, + Signal 2 (in phase) 2, – Signal 2 (180 degree phase shift) Achat 110 M... -
Page 22: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 24 Musikhaus Thomann · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
