Specifications - Lectrosonics AM16/12 Operating Instructions Manual

Mic/Line Input
Type:
Impedance:
Input Gain Settings:
Input Gain Range:
EIN , 20-20KHz:
Maximum Input Level:
Tone Controls:
Line Outputs
Impedance:
Output Gain Range:
Max output level:
Matrix Crosspoints
Matrix Crosspoint Gain Settings
Programmable Inputs
Programmable Input Range:
Analog Control:
Logic Control:
Programmable Outputs
Logic Control:
Max sink current:
Max supply voltage:
Serial Communication (RS-232):
Default LecNet address:
Maximum System Gain:
System Frequency Response (0dBu in/out): 20Hz to 20kHz, +/– 1dB
System THD:
System IMD:
Phantom Power:
Power Consumption:
Weight:
Dimensions:
Optional accessories:
This product meets the CE Compliance Standards - EN55022 and
EN50082-1:1998. A copy of the Declaration of Conformity may be
requested from your dealer or by contacting the factory directly:
Lectrosonics, Inc.
Marketing Department
581 Laser Rd. NE, Rio Rancho, NM 87124 USA
tel: 505-892-4501 fax: 505-892-6243 e-mail: marketing@lectrosonics.com
34

SPECIFICATIONS

Electronically balanced and RF filtered
Greater than 2.5K, any gain setting
0dB, +30dB, +50dB
+15dB to -63dB, plus mute
–126dBu (+50dB gain)
+20dBu at 0dB gain
–10dBu at +30dB gain
–30dBu at +50dB gain
Lo-cut 6dB/octave @75 Hz, 90 Hz, 110Hz, 130 Hz, 190 Hz, 280Hz, 600 Hz
Shelving high frequency control:
Turnover frequency 1kHz
+/– 3dB, +/– 6dB, +/– 8dB at 10 kHz
Outputs 1-8: 200 ohms balanced, 100 ohms unbalanced;
Outputs 9-12: Line mode - 520 ohms balanced, 260 ohms unbalanced.
+10dB to –68dB, 1dB steps, plus mute
+26dBu, 10k load in Line mode; –16dBu, 10k load in Mic mode
Versions 1.x: –15dB, –10dB, –5dB, 0dB, +3dB, +6dB, of f
Versions 2.0 & higher: Channels: –15dB, –10dB, –5dB, 0dB, +3dB, +6dB, off
Exp. In/Noise: –10dB, 0dB, +3dB, off
0VDC - 5VDC
0dB to –30dB plus off control range; 156mV/dB control sensitivity
Active Low
Active low
100 mA
40VDC
9600 baud, 8 data bits, no parity, 1 stop bit
139
81dB (Input to Main Out)
Less than 0.1%, any gain setting, 0dBu out
Less than 0.1%, any gain setting, 0dBu out
Selectable by channel, +15V, short circuit current 6.5mA each from the "+" and "–" inputs
25 Watts max at 16.5VAC (1.7A max.)
7 lbs.
19"wide x 3.5"high x 8"deep
- TA1 Line Level Adapter
- RCW-VLS Remote Volume Control
Specifications subject to change without notice.
Mic mode - 125 ohms balanced or unbalanced
