Summary of Contents for Lectrosonics AM6
- Page 1 AM6 AUTOMATIC MIXER OPERATING INSTRUCTIONS and trouble-shooting guide LECTROSONICS, INC. Rio Rancho, NM...
-
Page 2: Table Of Contents
Although the AM6 is an affordable unit, performance is equivalent to much more expensive separates. The AM6 has 6 input channels which will accept either mic or line level signals. The AM6 will be an ideal choice for small churches, conference rooms, or anywhere a state of the art integrated automatic mixer is desirable. -
Page 3: General Technical Description
The AM6 has two modes of operation for each channel; Auto and Direct. The operational mode is selected via the front panel Auto/Direct switch on each channel. In the Direct mode, the channel is always on. The Direct mode is analogous to a standard channel in a non-automatic mixer. - Page 4 In the Auto mode, the ambient level is continuously monitored, and the minimum level at which channels begin to come on is set a few dB above ambient. With the AM6 set in the Auto Threshold mode, the chances of misadjustment are considerably less.
-
Page 5: Front Panel Description
Output Level control. THRESHOLD MANUAL/AUTO SWITCH - Determines the mode of the fixed Threshold for the AM6. In Manual mode, the Threshold Level pot determines the Threshold. In Auto mode, the ambient noise is monitored and the Threshold is set relative to the ambient noise. -
Page 6: Rear Panel Description
MAIN OUT REMOTE REMOTE REMOTE REMOTE REMOTE REMOTE LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL GAIN GAIN GAIN GAIN GAIN GAIN 100/120 VOLTS AC 50/60 HZ 30 WATTS MAX TIP-HI RING-LO SLEEVE-GND MADE IN USA Figure 3 - AM6 Rear Panel... -
Page 7: Installation
Channels 1-6 are factory jumpered for tone control and notch filtering. If these functions need to be disabled, set the jumpers to BYPASS as shown in Figure 4. To gain access to these jumpers the top cover of the AM6 should be temporarily removed*. -
Page 8: Operating Instructions
6) With all Channel Level controls fully open clockwise and the Output Level control fully counterclockwise, turn on the power for the AM6 and the amplifier. If Auto Threshold was selected in step 5, wait about 10 seconds after turning the power on before proceeding. This will allow the Auto Threshold to initialize its sampling of the ambient noise. -
Page 9: Specifications
SPECIFICATIONS Mic/Line Input: Type: Electronically balanced RF filtered Impedance: 10K balanced, for standard 200 Ohm mics Trim Gain Range: 6dB-55dB EIN, 20-20KHz -127dBu Nominal Attenuation: 15dB Maximum Input Level: +12dBu (Gain set at 6dB) Phantom Power: +15 Volts, internal jumper Notch/tone controls Section: Notch Filters: Variable 500Hz to 5KHz,... -
Page 10: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS service department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out of warranty repairs are charged at a modest flat rate plus parts and shipping. -
Page 11: Warranty
This warranty applies only to items returned to us, shipping costs prepaid, within one year from the date of purchase. This warranty gives you specific legal rights. You may have additional legal rights which vary from state to state. LECTROSONICS, INC. 581 LASER ROAD RIO RANCHO, NM 87124 USA July 6, 1999...
