Master Section Controls

The fuzz, overdrive and distortion sections are summed
together in the master section. The master controls apply
to the combined signal and can be used to tailor the nal
sound that leaves the pedal.
mid freq: this switch allows you to select the center
frequency of the mid band of the master EQ.
hi: controls the amount of high frequency content in the
output signal. It is a gentle high shelf lter starting around
3 kHz. The 12 o'clock setting is 0 dB, no boost or cut, and
the extreme boost and cut is about 10 dB.
mid: allows you to add or subtract the frequency selected
with the mid freq switch. The 12 o'clock setting is 0 dB, no
boost or cut, and the extreme boost and cut is about 10 dB.
low: controls the amount of low frequency content in the
output signal. It is a low shelf lter starting around 150 Hz.
The 12 o'clock setting is 0 dB, no boost or cut, and the
extreme boost and cut is about 10 dB.
output: controls the output gain. The point
where unity gain is achieved varies and
depends on the individual section volumes.
