Fuzz, Overdrive and Distortion Controls

Each section has a dedicated volume, gain and lter control.
This allows for an extremely wide range of sonic possibilities.
lter: engages a high pass lter (hp) or a low pass lter (lp)
for this section. This switch allows you to use only the high
frequencies of one section with only the low frequencies from
another section. For example: you could combine the tight
lows of the distortion section with the classic, high frequency,
sustain of the fuzz section. The cuto frequency is 500 Hz for
both the high-pass and low-pass lter settings.
+
Power:
gain: controls the amount of break-up in each section.
volume: controls the amount of signal from each
section that gets added to the output. Think of this
as the volume fader on a mixer.
select: used to toggle between 2 preset combinations of
fuzz, overdrive and distortion. Choose which channels
are active in each preset using the dip switch located
inside the multidrive. LEDs indicate which channels are
active at any given time.
-
9V DC negative tip 2.1mm jack.
110mA or greater
Controls a
distortion type: choos
available in the distortio
bypass: When the LED is
is applied to the signal. W
being bypassed (true byp
