Digi XBee ZigBee Quick Start Manual

1 Verify Kit Components
Thank you for purchasing the XBee ZigBee Cloud Kit. This kit is designed to
make it easy to set up your XBee ZigBee hardware and configure the online
application. You will be able to see sensor data from your hardware kit on
a web page and send data from the web down to your device. The components in this
kit allow you to create highly customized solutions.
XBee Gateway
Ethernet + Wi-Fi Model
Development Board
2 Write Down the Serial Numbers
Write down the serial number located on the back of your XBee Gateway and XBee RF module. You will use these serial numbers later when accessing
the gateway and adding the devices to Device Cloud by Etherios™. Some digits of the serial number are the same for all models and are pre-filled below.
XBee Gateway Serial Number:
3 Connect Hardware
Connect XBee Gateway Hardware
a
Connect the power supply.
b
Optional: If using an Ethernet network connection in addition to Wi-Fi, connect
one end of the Ethernet cable to your gateway and the other to a live Ethernet jack.
c
Startup Sequence - After power is applied:
- The Power LED turns solid green.
- The XBee LED turns to blinking green if it has started a ZigBee network.
- The Network LED gradually turns solid green if the XBee Gateway
can connect to Device Cloud.
More on these LED states is in LEDs and Startup States on the next page.
c
Connect XBee Module and Development Board Hardware
a
Place the XBee module onto the development board, seating the pins
on the connectors noted on the diagram.
Connect one end of the USB cable to the development board and
b
the other end to your computer.
c
Startup Sequence - Locate the LED labeled Associate on the
development board. The Associate LED will blink green when the
XBee module joins a ZigBee network. Later in the setup process,
you will verify that the XBee module joins the ZigBee network started
by the XBee Gateway. This step is covered in Getting Started with Your
XBee ZigBee Cloud Kit in the XBee User's Guide.
