- Page 1 ™ AquaSpot OPERATOR MANUAL Advance MODEL 56220000 10/98 revised 3/02 Form Number 56041422...
-
Page 2: Table Of Contents
TABLE OF CONTENTS _________________________________________________________________________________________________________________ Page Introduction ......................2 Parts and Service ....................2 Nameplate ......................2 Uncrating the Machine ..................2 Cautions and Warnings ..................3 Importantes Mesures de Sécurité ..............4 Grounding Instructions ..................5 Instructions Visant La Mise à La Terre ..............6 Know Your Machine ................... -
Page 3: Introduction
Repairs, when required, should be performed by your Authorized Nilfisk-Advance Service Center, who employs factory trained service personnel, and maintains an inventory of Nilfisk-Advance original replacement parts and accessories. Call the NILFISK-ADVANCE DEALER named below for repair parts or service. Please specify the Model and Serial Number when discussing your machine. -
Page 4: Cautions And Warnings
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this appliance. WARNING ! To reduce the risk of fire, electric shock, or injury: Do not leave the appliance when it is plugged in. Unplug the unit from the outlet when not in use and before servicing. To avoid electric shock, do not expose to rain. -
Page 5: Importantes Mesures De Sécurité
IMPORTANTES MESURES DE SÉCURITÉ L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER CET APPAREIL AVERTISSEMENT ! Pour réduire les risques d’incendie, de choc électrique ou de blessure: Ne pas laisser l’appareil sans surveillance lorsqu’il est branché. Débrancher lorsque l’appareil n’est pas utilisé et avant l’entretien. Pour réduire les risques de choc électrique, utiliser à... -
Page 6: Grounding Instructions
GROUNDING INSTRUCTIONS ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 7: Instructions Visant La Mise À La Terre
INSTRUCTIONS VISANT LA MISE À LA TERRE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Cet appareil doit être mis à la terre. En cas de défaillance ou de panne éventuelles, la mise a la terre fournit au courant un chemin de moindre résistance qui réduit le risque de choc électrique. Cet appareil est pourvu d’un cordon muni d’un conducteur de terre et d’une fiche avec broche de terre. -
Page 8: Know Your Machine
KNOW YOUR MACHINE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ Solution Tank Recovery Tank Latch Recovery Tank Lid Recovery Tank Optional Cart Hose Assembly Hand Tool Vacuum Motor Exhaust Filter Vacuum Motor Intake Filter Recovery Tank Full Indicator Solution Strainer Pigtail Cord Power Cord Solution Hose Coupler Power Switch Vacuum Gasket 7 - FORM NO. -
Page 9: Preparing For Use And Operating The Machine
PREPARING FOR USE AND OPERATING THE MACHINE ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ WARNING! Use only nonflammable commercial chemicals intended for machine application. Unsnap the Recovery Tank Latches (2) and remove the Recovery Tank (4) from the machine. Pour up to 2 gallons (9 liters) of hot water into the Solution Tank (1). NOTE: Liquid cleaning chemical can be added to water if desired. -
Page 10: After Use
Once a month, check the vacuum motor to make sure the airways are not blocked. Clear hose of debris and keep the vacuum motor exhaust area clean. Have Nilfisk-Advance check the carbon motor brushes once a year or after 500 operating hours. Replace the carbon brushes if they are worn to 3/8” (9.5 mm) or less. -
Page 11: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Remedy Poor water pick-up Vacuum hose cuff is not firmly pushed Push hose cuff onto fitting. onto recovery tank fitting. Vacuum Motor Intake Filter (9) is clogged Remove and clean filter Recovery Tank (4) is not firmly latched Check Latches (2) and re-latch. - Page 12 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©2002 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
