Dolphin Bio Suction | User Instructions Manual

4. POOL CLEANER PARTS

Dolphin Bio
Suction
Filteration
Cartridge with
Spring net filters
X4 X4
Coarse net filter Ultra-fine filter
Internal suction
Swivel to pipe
adaptor connector
Pipe (optional)*
* The pipe for the external pump is a standard pipe and can be purchased from your Dolphin dealer.
Dolphin Bio Suction | User Instructions Manual
Caddy
Remote Control Unit
Weekly timer
Power Supply
X10
Suction inlet Cable to pipe
plug clip connector
3
