- Page 1 Robotic Pool Cleaner POOL UP Operating Instructions Robotic Pool Cleaner POOL UP POOL UP 8151705...
-
Page 3: Table Of Contents
Robotic Pool Cleaner POOL UP Operating Instructions Contents 1. INTRODUCTION ................2 2. SPECIFICATIONS ................2 3. WARNINGS AND CAUTIONS ............2 3.1. Warnings ................2 3.2. Cautions .................2 4. POOL CLEANER PARTS ..............3 5. USING THE POOL CLEANER ............4 5.1. Setup ..................4 5.2. Putting the Pool Cleaner into the pool .......4 5.3. -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing a Maytronics Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable filtration in all pool conditions and all-surface climbing brush enhance maximum pool hygiene. -
Page 5: Pool Cleaner Parts
4. POOL CLEANER PARTS Robotic Pool Cleaner POOL UP Brushes There are three types of optional brushes, each designed to provide optimal traction on different pool surfaces. Only one type set is provided with your robot Pool Cleaner. PVC Brush Wonder (foam) Brush Combined Brush For concrete, PVC,... -
Page 6: Using The Pool Cleaner
5. USING THE POOL CLEANER 5.1. Set Up 40°C Max 104°F Max Position the power supply so GFI/ELI that it is approximately in the middle of the long side of the pool at a distance of 3m / 10ft. Attach the floating cable to the power supply by inserting it with the notch on the connector (1) lined up with... -
Page 7: Removing The Pool Cleaner From The Pool
Turn the power supply ON. 5.3. Removing the Pool Cleaner from the pool The Pool Cleaner will perform automatic shut-off at the end of the cleaning cycle. Turn Off and unplug the power supply. CAUTION Using the floating cable, bring the Pool Cleaner to the pool’s edge. -
Page 8: Maintenance
5.4. Maintenance Click 5.4.1. Cleaning the filtration system: Cleaning the filter bag Unplug the power supply. CAUTION Turn the Pool Cleaner upside-down. Open the bottom lid. Remove the filter bag. Clean the filter bag with a hose. We recommend that you periodically wash the filter bag in a washing machine using the gentle cycle program. - Page 9 Cleaning the cartridge filters Note: Don’t let the cartridge filters dry out before cleaning. Click Unplug the power supply. CAUTION With the pool cleaner upside down open the bottom lid and pull it out. Open the clips and remove the filters. Clean the filters with a hose.
-
Page 10: Cleaning The Impeller
Insert the filters with the plastic backing facing out. Insert the cartridge unit. 5.4.2. Cleaning the impeller Unplug the power supply. If you notice debris trapped in the impeller open the impeller and remove the debris. Robotic Pool Cleaner POOL UP | Operating Instructions... -
Page 11: Off-Season Storage
Cable To remove the kinks, stretch the cable out completely and let it sit for at least a day in the sun. 5.5. Off-season storage If the pool cleaner will not be in use for an extended period, perform the following storage steps: • Make sure that no water is left in the pool cleaner.
