Liebert Interceptor H2120Y444R-03 Technical Specification

H2120Y444R-03
Example Part Number:
H __ __ __ __
SAD
Surge
Energy
1 250J
2 500J
Voltage
120 120V
208 208V
230 230V
240 240V
277 277V
480 480V

Phase Configuration

N Single Phase L-N
L Single Phase L-L
S Split Phase
Y 3 Phase Wye
D 3 Phase Delta
H
3 Phase Hi-Leg
111
222
333
444
Job Name____________________________
Model # _____________________________
Date ________________________________
Qty _________________________________
Quote # _____________________________
Liebert Corporation • 1050 Dearborn Drive • PO Box 29186 • Columbus, OH 43229
Phone 607-724-2484 • Fax 607-722-8713 • US & Canada 800-288-6169
EMAIL: info@control-concepts.com • Web Site: www.Liebert.com
Operating Frequency Range .....47 - 63 Hz
Fault Current Rating (AIC) .........200 kAIC
Capacity .....................................(Continuous) Parallel
Modes of Protection...................L - N, L - L, L - G, N - G
Response Time...........................MOVs= <0.5 nanoseconds / SADs= <250 picoseconds
Operating Temperature .............-40ϒC TO 60ϒC
Operating Humidity....................0% TO 95% Non-condensing
Certifications ..............................UL 1449, UL 1283, CSA, ISO 9001
Warranty .....................................5 Years Labor / 10 Years Parts
= 500Joules,120/208V 3-Phase Wye, 750 kA per phase,
Rotary Disconnect, LED's, Alarm & Dual Counters
__ __ __ __ __ - __ __
"blank"
R
Surge Current Rating
250kA Per Phase
320kA Per Phase
400kA Per Phase
750kA Per Phase
Liebert Interceptor Hybrid
TVSS Technical Specification
Option Codes
01 LED
04 LED, Alarm
05 LED, Surge Counter
06 LED, Alarm,
Surge Counter
03 LED, Alarm, Dual
Surge Counters
Connection Type
Compression Lugs
Rotary Disconnect
Life Cycle Surge Testing
10kA, 20kV, IEEE Cat. C3
Unit Per Mode
250kA 15,000
320kA 30,000
400kA 45,000
750kA 60,000
UL 1449 second edition
Voltage Modes
L-N
L-G
120/208
N-G
L-L
L-N
L-G
277/480
N-G
L-L
L-G
240
L-L
L-G
480
L-L
Case Size
..S111
..Y111
..D110
..S222
..Y222
..D220
..S333
..Y333
..D330
..S444
..Y444
..D440
82244 Rev 0
Per Phase
30,000
60,000
90,000
120,000
Clamping
330
400
400
700
700
800
800
1500
700
700
1500
1500
A = 16"
B = 20"
C = 10"
A = 20"
B = 24"
C = 10"
A = 24"
B = 24"
C = 10"
A = 24"
B = 30"
C = 10"
