FT-7715
Fan Free Touch Control
Desktop POS Terminal
User's Manual
Rev.: Original
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex Technology, Inc. has made every effort for the accuracy of the content in this
manual. However, Posiflex will assume no liability for any technical inaccuracies or
editorial or other errors or omissions contained herein, nor for direct, indirect,
incidental, consequential or otherwise damages, including without limitation loss of
data or profits, resulting from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex expressly disclaims any warranties,
expressed, implied or statutory, including without limitation implied warranties of
merchantability or fitness for particular purpose, good title and against infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex Technology, Inc. reserves the
right to alter product designs, layouts or drivers without notification. The system
integrator shall provide applicative notices and arrangement for special options utilizing
this product. The user may find the most up to date information of the hardware from
web sites: http://www.posiflex.com or http://www.posiflex.com.tw or
http://www.posiflexusa.com
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex Technology, Inc. will not be responsible for any loss of data
resulting from the use, disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Technology, Inc. the publisher of this documentation.
© Copyright Posiflex Technology, Inc. 2012
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 16620900010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT-7715 and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX FT-7715

  • Page 1 About This Manual: Posiflex Technology, Inc. has made every effort for the accuracy of the content in this manual. However, Posiflex will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. This product contains a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Product Pictures

    INTRODUCTION PRODUCT PICTURES Front Views Detail inside front cover Side Views Rear Views Part 3...
  • Page 4: Parts Identification

    Detail inside back cover Please note that the picture for inside front and back cover is for reference only. The actual layout may disagree from this picture if there is any difference in model or options selected or in the system revision. Please follow the actual layout for cable connections in this case.
  • Page 5: Product Features

    18. External power connector for power adaptor 19. VGA port 20. LAN port 21. Standard serial COM1 port 22. Standard serial COM3 port 23. 12V Bat 24. Line Out 25. USB1 port 26. USB2 port 27. USB3 port 28. USB4 port 29.
  • Page 6 Spill proof water resistant structure allowing easy cleaning i ) i ) i ) i ) Support MTC IR Touch j ) j ) j ) j ) Easy maintenance construction k ) k ) k ) k ) Various I/O ports supported, including: l ) l ) l ) l ) 1.
  • Page 7 NON-USER-INSTALLABLE OPTIONS When the FT-7715 system is ordered with options like expanded system memory or side mount upgrade kit, the option(s) is (are) already installed in the system delivered. Therefore, no more installation is required.
  • Page 8 The user shall be responsible for such kind of damage. INSTALLING UPS BATTERY (OPTION) When the FT-7715 system is the optional UPS model and is ordered with the UPS battery, the UPS battery is separately stored in the carton at delivery while the connector area inside back cover shows some deviation from the standard as in the right picture.
  • Page 9 SIDE MOUNT UPGRADE KIT When a side-mount upgrade kit option such as FA-200 is ordered with the FT-7715 system, this option is already installed in the delivery. No matter the kit itself contains MSR only, finger print sensor only or...
  • Page 10: Connecting Interface Cables

    Use the cable supplied with the cash drawer (Part No. 21863018010) for connection to the CR port in FT-7715 system. This cable has a 6-pole plug at one end and an 8-pole plug at the other. The 8-pole plug should be inserted into the connector marked: “signal cable from POS Printer”...
  • Page 11: Connecting Ac Power

    PC veterans to accomplish such a task. Therefore, OS installation into a system without preloaded OS is highly discouraged. Posiflex shall not be responsible for any technical support to questions arisen due to non-preloaded...
  • Page 12 Wake on LAN or select the “Resume by Alarm” for Alarm Clock Wake Up. Save the configuration and exit the CMOS setup program. The Preset Power On Control will then be ready after a normal power off. When the FT system is turned off after a successful boot up, the preset automatic power on functions will keep monitoring for the preset conditions and turn on the system when the preset conditions are met.
  • Page 13: Application Environment

    USING THE TOUCH TERMINAL APPLICATION ENVIRONMENT It is very important that you check the following operational guidelines: Ventilation This terminal must NOT be operated in an environment with restricted ventilation. There must be at least 25 mm air clearance around any top or side ventilation holes with a free flow of air around the unit at ALL time for the installation.
  • Page 14: Power On/Off

    connected there but found inoperable by such messages. Emergency treatment: The battery is constructed maintenance free and leak proof. It is well protected in FT system as long as the ambient temperature remains below 30°C and the ventilation of the FT system remains free. However, should any accident happen and the sulfuric acid from the battery spills on skin or clothing, wash immediately with water.
  • Page 15 When using this feature, please make sure that the software application has the ability to power off the machine. In preloaded Windows, “Posiflex Power Switch Manager” in “Posiflex Tools” in the Program Files helps managing these functions.
  • Page 16: Display Issues

    Posiflex monitor, use the DC adaptor to connect into the monitor or use Posiflex VGA + power cable and set an internal jumper in FT main board to supply the required power through the VGA connector. Do not connect other monitor to this port before the power in this port is disabled.
  • Page 17: Customer Display

    Display Utility Driver The end user of the FT-7715 terminals is not supposed to install the utility drivers personally. If an optional preloaded OS is ordered, the required driver will be already installed in the preloaded OS. However, the driver will always be available over our web site: http://www.posiflex.com...
  • Page 18 Posiflex USB Touch Manager A program named “Posiflex USB Touch Manager” and a right-click sticky button tool in the program group “Posiflex USB Touch Tools” is installed in the preloaded Windows system with a USB interface touch panel controller. This program can also be obtained by downloading from the POSIFLEX web site.
