ZA-101/103/104/304/305
Side Attachment
Quick Installation Guide
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告
為避免電磁干擾,本產品不應安裝或使用於住宅環境。
SAFETY INSTRUCTIONS
This equipment is not suitable for use in locations where children are likely to be present.
CONSIGNES DE SÉ CURITÉ
Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des
enfants.
ZA Series Ver. B0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZA-101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX ZA-101

  • Page 1 ZA-101/103/104/304/305 Side Attachment Quick Installation Guide FCC NOTES This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2: Revision History

    Revision History Date Version Description 2023/11/21 For Preliminary Release 2024/04/18 Add ZA-103/104/304/305 Overview ZA-101 (MSR) ZA-103 (iButton) 3-track Magnetic Stripe Reader iButton Sensor USB I/O Cable USB I/O Cable ZA-104 (2D Scanner Engine) USB I/O Cable Trigger Button Scan Window...
  • Page 3 Note1: The scanner of ZA-104 is auto trigger mode by default. The manual trigger button is for advanced setup. It is highly recommended that the scanner setup is implemented by professional technicians. If you need to use the manual trigger button, you can use a needle to insert into the hole to press the button.
  • Page 4: Hardware Installation

    Hardware Installation During Installation of the ZA series, do NOT power ON your terminal and monitor. Installation of ZA series onto the ZT Series Terminals Start to install ZA series attachment onto ZT series terminals according to the following steps. Rotate the screen to the horizontal position like the below picture, and there is a base cover latch on the front side of the base stand.
  • Page 5 There is a latch inside cable exit on the rear side of the POS terminal. Push the latch with the thumb of the left hand, and then the touch monitor will release automatically. Open the touch monitor with two hands, and then you can do the maintenance work.
  • Page 6 Remove the side attachment cover by pressing the inner hook on both sides. Press. Fix the ZA series to the ZT POS terminal with two thumbscrews, and then connect the cable to the cable connector from the main board like below picture. ZA-103 ZA-101 ZA-3xx Series ZA-104...
  • Page 7 There is a plastic cable cover on ZA series attachment. Please remove the plastic cable cover. Remove the side attachment cover on the rear cover. TM/LM-5011 TM/LM-5x15/5x16 Connect the cable to the cable connector from the display control board like below picture. ZA-101 ZA-103...
  • Page 8 ZA-3xx Series ZA-104 Install the ZA series attachment to the monitor with two M3 screws. ZA-103 ZA-101 ZA-104 ZA-3xx Series...
  • Page 9 Before installing the drivers of the ZA series attachment, after installing the ZA series attachment, power on your POS terminal. Installing and Starting the Posiflex USB MSR Manager Before installing the USB MSR Manager, please visit Posiflex official website (https://download.posiflex.com/en- global/Download/index/driver/Attachment/ZA-101) to download the utility.
  • Page 10 8. After completion of the driver installation, restart your terminal. Installing the RFID Setup Tool If you purchase the attachment having the RFID module of which the interface is Virtual COM, please visit Posiflex official website (https://download.posiflex.com/en- global/Download/index/driver/Attachment/ZA-101) to download the virtual COM driver.
  • Page 11 2D imager based on personal preferences, two options are offered to achieve the purpose: the advanced user manual, which contains a complete set of barcode labels, and the quick setup guide with most frequently used barcode labels. Please visit Posiflex Global Website ( https://download.posiflex.com/en- ) to download the global/Download/index/manualUinstall_guide/Attachment/ZA-104 related documents.
  • Page 12 Operation of the Fingerprint Sensor (Optional) Keep your thumb close to the fingerprint reading area to allow the fingerprint sensor to read your thumb fingerprint. Reading Area Using iButton Sensor (Default for ZA-103, Optional for ZA-304) iButton sensor, an item located on the front side of ZA- 103/304, mainly functions to verify an individual’s identity for enhanced access control to your computer.
  • Page 13 Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey, etc. ≧4mil Resolution* Typical Depth of Field* EAN-13 (13mil): 40mm-360mm PDF417 (6.67mil): 30mm-200mm Data Matrix (10mil): 30mm-220mm Code 39 (5mil): 40mm-180mm...
  • Page 14 Temperature Operating: 0℃~ +40℃ Non-operating: -20℃~ +60℃ (storage) Relative Humidity Operating: 95% RH, non-condensing at 50° C Storage: 85% RH, non-condensing at 60° C Ambient Light 0~107,639 lux (direct sunlight) ZA-104 with MDI-4100 Scanner Engine (Option) Power source 5VDC Scan method CMOS area sensor (black and white) Number of effective pixel 752 (H) ×...
  • Page 15 ZA-104 with NLS-N1 Scanner Engine (Option) Performance Image Sensor 640*480 CMOS Illumination White LED Aiming Red LED (625nm) Symbologies PDF417, QR Cord, Micro QR, Data Matrix Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, ISSN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of ,...
  • Page 16 Outline Dimension ZA-101 ZA-103...
  • Page 17 ZA-104 A-304...
  • Page 18 ZA-305 ※ The product information and specifications are subject to change without prior notice.
