- Page 1 Sprinter@ ADSL W422G ser’s Manual (3.0)---------- User’s Manual Sprinter@ ADSL2+ WiFi ROUTER W422G (3.0) Version 1.0 en...
-
Page 2: Table Of Contents
Contents Introduction .............................. 5 System Overview ............................. 5 Specifications.......................... 5 2.1.1 ADSL Standard....................... 5 2.1.2 Wireless Features ......................5 2.1.3 Software Features......................6 2.1.4 Management ........................6 Hardware Installation ..........................7 Hardware Requirements......................7 Hardware Setup Procedures ....................7 Software Configuration..........................8 LAN Configuration ........................ - Page 3 4.4.5.6 Domain blocking....................41 4.4.6 IGMP Proxy Configuration ................... 43 4.4.7 UPnP Configuration ..................... 45 4.4.8 RIP Configuration......................46 Advance Configuration ......................47 4.5.1 Bridging ........................47 4.5.2 Routing......................... 48 4.5.3 SNMP Configuration ....................51 4.5.4 Port Mapping........................ 52 4.5.5 IP QoS..........................
- Page 4 5.5.3 A.3 PPPoE Model ......................78 5.5.4 A.4 PPPoA Model......................79 5.5.5 A.5 1483 Routed Model ....................80 Appendix B: Mapping PVCs to VLANs....................80...
-
Page 5: Introduction
1 Introduction W422G is a high-speed ADSL2+ Ethernet/Wireless router that is specifically designed (3.0) to connect to the Internet and to directly connect to your local area network (LAN) via high-speed 10/100 Mbps Ethernet, or wireless LAN (WLAN). The ADSL2+ modem is compatible with the latest ADSL standards, including ADSL2 and ADSL2+, and supports up to 24 Mbps downstream and 1.5 Mbps upstream to deliver true broadband speed and throughput. -
Page 6: Software Features
2.1.3 Software Features RFC-1483/2684 LLC/VC-Mux bridged/routed mode RFC-1577 Classical IP over ATM RFC-2516 PPPoE RFC-2364 PPPoA ITU-T 1.610 F4/F5 OAM send and receive loop-back 802.1d Spanning-Tree Protocol DHCP Client/Server/Relay RIP v1/v2 DNS Relay Agent DMZ support IGMP Proxy/Snooping Stateful Packet Inspection Protection against Denial of Service attacks IP Packet Filtering Dynamic DNS... -
Page 7: Hardware Installation
3 Hardware Installation 3.1 Hardware Requirements A RTL867x demo board with RTL8185 WLAN card 12V DC power RJ-45 Ethernet cable RJ-11 ADSL line COM Port cable (Optional) 3.2 Hardware Setup Procedures 1. Connect RJ-11 line from RTL867x to DSLAM. 2. Connect RJ-45 line from your PC to RTL867x Ethernet port. 3. -
Page 8: Software Configuration
4 Software Configuration The W422G(3.0) is an ADSL2+ wireless router. When you power on the device, the system will boot up and connect to ADSL automatically. The system provides a PVC for bridge test by default. The default configurations for the system are listed below. LAN IP address: 192.168.1.1, NetMask:255.255.255.0 UART setting: 115200bps, 8 bits, no parity, 1 stop bit, no flow control. - Page 9 This page displays the ADSL modem/router’s current status and settings. This information is read-only except for the PPPoE/PPPoA channel for which user can connect/disconnect the channel on demand. Click the “Refresh” button to update the status Function buttons in this page: Connect / Disonnect The two buttons take effect only when PVC is configured as PPPoE/PPPoA mode.
-
Page 10: Lan Configuration
4.1 LAN Configuration This page shows the current setting of LAN interface. You can set IP address, subnet mask, and IGMP Snooping for LAN interface in this page. Fields in this page: Field Description IP Address The IP address your LAN hosts use to identify the device’s LAN port. Subnet Mask LAN subnet mask. -
Page 11: Wireless Configuration
4.2 Wireless Configuration This section provides the wireless network settings for your WLAN interface. The wireless interface enables the wireless AP function for ADSL modem. 4.2.1 Basic Setting This page contains all of the wireless basic settings. Most users will be able to configure the wireless portion and get it working properly using the setting on this screen. -
Page 12: Advanced Settings
modem (or AP). Channel Number Select the appropriate channel from the list provided to correspond with your network settings. You shall assign a different channel for each AP to avoid signal interference. Radio Power (mW) The maximum output power: 15mW, 30mW or 60mW. Function buttons in this page: Associated Clients Click it will show the clients currently associated with the ADSL modem. - Page 13 Fields in this page: Field Description Authentication Type Open System: Open System authentication is not required to be successful while a client may decline to authenticate with any particular other client. Shared Key: Shared Key is only available if the WEP option is implemented. Shared Key authentication supports authentication of clients as either a member of those who know a shared secret key or a member of those who do not.
-
Page 14: Apply Changes
inconsistent data flow, only minor modifications are recommended. If a network packet is smaller than the preset “RTS threshold” size, the RTS/CTS mechanism will not be enabled. The ADSL modem (or AP) sends Request to Send (RTS) frames to a particular receiving station and negotiates the sending of a data frame. After receiving an RTS, the wireless station responds with a Clear to Send (CTS) frame to acknowledge the right to begin transmission. -
Page 15: Security
Discard your changes and reload all settings from flash memory. 4.2.3 Security This screen allows you to setup the wireless security. Turn on WEP or WPA by using encryption keys could prevent any unauthorized access to your WLAN. Fields in this page: Field Description Encryption... -
Page 16: Access Control
Use 802.1x Check it to enable 802.1x authentication. This option is selectable only when the Authentication “Encryption” is choose to either None or WEP. If the “Encryption” is WEP, you need to further select the WEP key length to be either WEP 64bits or WEP 128bits. WPA Authentication There are 2 types of authentication mode for WPA. - Page 17 Fields in this page: Field Description Wireless Access The Selections are: Control Mode Disable Disable the wireless ACL feature. Allow Listed When this option is selected, no wireless clients except those whose MAC addresses are in the current access control list will be able to connect (to this device).
-
Page 18: Wds
Click to add this entry into the Current Access Control List. The Current Access Control List lists the client MAC addresses. Any wireless client with its MAC address listed in this access control list will be able to connect to the device. You can select the entries at the Select column and apply to the following function buttons. -
Page 19: Wps
Enable WDS Check to enable the WDS function. Add WDS AP This is where you enter the MAC address of the peer AP’s wireless interface that you are connecting to. Function buttons for this setting block: Apply Changes Click to add this entry into the Current WDS AP List. The Current WDS AP List lists the peer MAC addresses of the WDS link. - Page 20 Fields in this page: Field Description Disable WPS Check to disable the Wi-Fi protected Setup. WPS Status When AP’s settings are factory default (out of box), it is set to open security and un-configured state. “WPS Status” will display it as “UnConfigured”. If it already shows “Configured”, some registrars such as Vista WCN will not configure AP.
-
Page 21: Wan Configuration
Click to regenerate the Self-PIN Number. Start PBC Click to start the Push Button method of WPS. Apply Changes Click to commit changes. Reset It restores the original values. Start PIN Click to start the PIN method of WPS. 4.3 WAN Configuration There are three sub-menu for WAN configuration: [Channel Config], [ATM Settings], and [ADSL Settings]. - Page 23 Function buttons in this page: Click Add to complete the channel setup and add this PVC channel into configuration. Modify Select an existing PVC channel by clicking the radio button at the Select column of the Current ATM VC Table before we can modify the PVC channel. After selecting an PVC channel, we can modify the channel configuration at this page.
-
Page 24: Atm Setting
4.3.2 ATM Setting The page is for ATM PVC QoS parameters setting. The DSL device support 4 QoS mode —CBR/rt-VBR/nrt-VBR/UBR. Fields in this page: Field Description Virtual Path Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table. -
Page 25: Adsl Setting
selected, the SCR and MBS fields are enabled. − rt-VBR (real-time Variable Bit Rate): When rt-VBR is selected, the SCR and MBS fields are enabled. Peak Cell Rate, measured in cells/sec., is the cell rate which the source may never exceed. - Page 26 Fields in this page: Field Description ADSL modulation Choose prefered xdsl standard protocols. G.lite : G.992.2 Annex A G.dmt : G.992.1 Annex A T1.413 : T1.413 issue #2 ADSL2 : G.992.3 Annex A ADSL2+ : G.992.5 Annex A AnnexL Option Enable/Disable ADSL2/ADSL2+ Annex L capability.
-
Page 27: Services Configuration
Apply Changes Click to save the setting to the configuration and the modem will be retrained. 4.4 Services Configuration 4.4.1 DHCP Mode You can configure your network and DSL device to use the Dynamic Host Configuration Protocol (DHCP). This page provides DHCP instructions for implementing it on your network by selecting the role of DHCP protocol that this device wants to play. -
Page 28: Dhcp Relay Configuration
Field Description IP Pool Range Specify the lowest and highest addresses in the pool. Max Lease Time The Lease Time is the amount of time that a network user is allowed to maintain a network connection to the device using the current dynamic IP address. At the end of the Lease Time, the lease is either renewed or a new IP is issued by the DHCP server. -
Page 29: Dns Configuration
network. In this case, you can configure this device to act as a DHCP relay agent. When a host on your network requests Internet access, the device contacts your ISP to obtain the IP configuration, and then forward that information to the host. You should set the DHCP mode after you configure the DHCP relay. -
Page 30: Dynamic Dns
Field Description Attain DNS Select this item if you want to use the DNS servers obtained by the WAN Automatically interface via the auto-configuration mechanism. Set DNS Manually Select this item to configure up to three DNS IP addresses. Function buttons in this page: Apply Changes Set new DNS relay configuration. - Page 31 host name. The Dynamic DNS page allows you to enable/disable the Dynamic DNS feature. On the Dynamic DNS page, configure the following fields: Field Description Enable Check this item to enable this registration account for the DNS server. DDNS provider There are two DDNS providers to be selected in order to register your device with: DynDNS and TZO.
- Page 32 from the configuration.
-
Page 33: Firewall Configuration
4.4.5 Firewall Configuration Firewall contains several features that are used to deny or allow traffic from passing through the device. 4.4.5.1 IP/Port Filtering The IP/Port filtering feature allows you to deny/allow specific services or applications in the forwarding path. Fields on the first setting block: Field Description Outgoing Default Action Specify the default action on the LAN to WAN forwarding path. - Page 34 Click to save the setting of default actions to the configuration. Fields on the second setting block: Field Description Rule Action Deny or allow traffic when matching this rule. Direction Traffic forwarding direction. Protocol There are 3 options available: TCP, UDP and ICMP. Src IP Address The source IP address assigned to the traffic on which filtering is applied.
-
Page 35: Mac Filtering
4.4.5.2 MAC Filtering The MAC filtering feature allows you to define rules to allow or deny frames through the device based on source MAC address, destination MAC address, and traffic direction. Fields on the first setting block: Field Description Outgoing Default Action Specify the default action on the LAN to WAN bridging/forwarding path. Incoming Default Action Specify the default action on the WAN to LAN bridging/forwarding path. - Page 36 Direction Traffic bridging/forwarding direction. Src MAC Address he source MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in the MAC address space and are considered as don’t care. Dst MAC Address The destination MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in the MAC address space and are considered as don’t care.
-
Page 37: Port Forwarding
4.4.5.3 Port Forwarding Firewall keeps unwanted traffic from the Internet away from your LAN computers. Add a Port Forwarding entry will create a tunnel through your firewall so that the computers on the Internet can communicate to one of the computers on your LAN on a single port. Fields in this page: Field Description... -
Page 38: Dmz
Function buttons for the setting block: Apply Changes Click to save the rule entry to the configuration. Function buttons for the Current Port Forwarding Table: Delete Selected Delete the selected port forwarding rules from the forwarding table. You can click the checkbox at the Select column to select the forwarding rule. -
Page 39: Url Blocking
Enable DMZ Check this item to enable the DMZ feature. DMZ Host IP Address IP address of the local host. This feature sets a local host to be exposed to the Internet. Function buttons in this page: Apply Changes Click to save the setting to the configuration. 4.4.5.5 URL Blocking The URL Blocking is the web filtering solution. - Page 40 Fields in this page: Field Description URL Blocking capability Check this item to enable the URL Blocking feature. FQDN A fully qualified domain name (or FQDN) is an unambiguous domain name that specifies the node's position in the tree hierarchy absolutely, such as tw.yahoo.com.
-
Page 41: Domain Blocking
4.4.5.6 Domain blocking The firewall includes the ability to block access to specific domain based on string matches. For example, if the URL of Taiwan Yahoo web site is “tw.yahoo.com” and you enter “yahoo.com”, the firewall will block all the DNS queries with “yahoo.com” string. So the Host will be blocked to access all the URLs belong to “yahoo.com”... - Page 42 Function buttons in this page: Apply Changes Click to disable/enable the Domain Block capability Add Domain Add domain into Domain Block table. Delete Selected Domain Delete the selected domain from the Domain Block table. You can click the checkbox at the Select column to select the Blocked domain.
-
Page 43: Igmp Proxy Configuration
4.4.6 IGMP Proxy Configuration Multicasting is useful when the same data needs to be sent to more than one hosts. Using multicasting as opposed to sending the same data to the individual hosts uses less network bandwidth. The multicast feature also enables you to receive multicast video stream from multicast servers. - Page 44 Fields in this page: Field Description IGMP Proxy Enable/disable IGMP proxy feature Proxy Interface The upstream WAN interface is selected here. Function buttons in this page: Apply Changes Click to save the setting to the configuration. Undo Discard your settings.
-
Page 45: Upnp Configuration
4.4.7 UPnP Configuration The DSL device supports a control point for Universal Plug and Play (UPnP) version 1.0, and supports two key features: NAT Traversal and Device Identification. This feature requires one active WAN interface. In addition, the host should support this feature. In the presence of multiple WAN interfaces, select an interface on which the incoming traffic is present. -
Page 46: Rip Configuration
4.4.8 RIP Configuration RIP is an Internet protocol you can set up to share routing table information with other routing devices on your LAN, at your ISP’s location, or on remote networks connected to your network via the ADSL line. Most small home or office networks do not need to use RIP;... -
Page 47: Advance Configuration
Field Description Enable/disable RIP feature. Function buttons for the second setting block in this page: Apply Changes Click to save the setting of this setting block to the system configuration Fields on the second setting block: Field Description Interface The name of the interface on which you want to enable RIP. Receive Mode Indicate the RIP version in which information must be passed to the DSL device in order for it to be accepted into its routing table. -
Page 48: Routing
Fields in this page: Field Description Ageing Time Set the Ethernet address ageing time, in seconds. After [Ageing Time] seconds of not having seen a frame coming from a certain address, the bridge will time out (delete) that address from Forwarding DataBase (fdb). 802.1d Spanning Tree Enable/disable the spanning tree protocol Function buttons in this page: Apply Changes... - Page 49 device. Your LAN hosts know their default gateway either because you assigned it to them when you modified your TCP/IP properties, or because you configured them to receive the information dynamically from a server whenever they access the Internet. − On the DSL device itself, a default gateway is defined to direct all outbound Internet traffic to a route at your ISP.
-
Page 50: Show Routes
Next Hop The IP address of the next hop through which traffic will flow towards the destination subnet. Metric Defines the number of hops between network nodes that data packets travel. The default value is 0, which means that the subnet is directly one hop away on the local LAN network. -
Page 51: Snmp Configuration
4.5.3 SNMP Configuration Simple Network Management Protocol (SNMP) is a troubleshooting and management protocol that uses the UDP protocol on port 161 to communicate between clients and servers. The DSL device can be managed locally or remotely by SNMP protocol. Fields in this page: Field Description... -
Page 52: Port Mapping
Community name Name of the write-only community. This write-only community allows write operation (write-only) to the objects defines as read-writable in the MIB. Function buttons in this page: Apply Changes Save SNMP configuration. New configuration will take effect after saving into flash memory and rebooting the system. - Page 53 Fields in this page: Field Description Enabled/Disabled Radio buttons to enable/disable the interface group feature. If disabled, all interfaces belong to the default group. “Interface groups To manipulate a mapping group: 1. Select a group from the table. 2. Select interfaces from the available/grouped interface list and add it to the grouped/available interface list using the arrow buttons to manipulate the required mapping of the ports.
-
Page 54: Ip Qos
memory and rebooting the system. See section “Admin” for details. 4.5.5 IP QoS The DSL device provides a control mechanism that can provide different priority to different users or data flows. The QoS is enforced by the QoS rules in the QoS table. A QoS rule contains two configuration blocks: Traffic Classification and Action. -
Page 55: Remote Access
Destination IP The IP address of the traffic destination. Destination Netmask The destination IP netmask. This field is required if the destination IP has been entered. Protocol The selections are TCP, UDP, ICMP and the blank for none. This field is required if the source port or destination port has been entered. -
Page 56: Diagnostic
The Remote Access function can secure remote host access to your DSL device from LAN and WLAN interfaces for some services provided by the DSL device. Fields in this page: Field Description Check/un-check the services on the LAN column to allow/un-allow the services access from LAN side;... -
Page 57: Atm Loopback
receives the message, it sends messages in reply. To use it, you must know the IP address of the host you are trying to communicate with and enter the IP address in the Host Address field. Click Go! To start the ping command, the ping result will then be shown in this page. -
Page 58: Adsl
This page allows you to use ATM ping, which generates F5 segment and end-to-end loop-back cells to test the reachability of a segment endpoint or a connection endpoint. Fields in this page: Field Description Select PVC Select the PVC channel you want to do the loop-back diagnostic. Flow Type The ATM OAM flow type. -
Page 59: Diagnostic Test
4.6.4 Diagnostic Test The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. -
Page 60: Admin
Fields in this page: Field Description Select the Internet The available WAN side interfaces are listed. You have to select one for the WAN Connection side diagnostic. 4.7 Admin 4.7.1 Commit/Reboot Whenever you use the Web configuration to change system settings, the changes are initially placed in temporary storage. -
Page 61: Backup/Restore
Function buttons in this page: Commit and Reboot Whenever you use the web console to change system settings, the changes are initially placed in temporary storage. To save your changes for future use, you can use the Commit/Reboot function. This function saves your changes from RAM to flash memory and reboot the system. IMPORTANT! Do not turn off your modem or press the Reset button while this procedure is in progress. -
Page 63: System Log
4.7.3 System Log This page shows the system log. 4.7.4 Password The first time you log into the system, you use the default password. There are two-level logins: admin and user. The admin and user password configuration allows you to change the password for administrator and user. -
Page 64: Upgrade Firmware
Fields in this page: Field Description User Name Selection of user levels are: admin and user. Old Password Enter the old password for this selected login. New Password Enter the new password here. Confirmed Password Enter the new password here again to confirm. 4.7.5 Upgrade Firmware To upgrade the firmware for the DSL device: −... -
Page 65: Acl
4.7.6 ACL The Access Control List (ACL) is a list of permissions attached to the DSL device. The list specifies who is allowed to access this device. If ACL is enabled, all hosts cannot access this device except for the hosts with IP address in the ACL table. -
Page 66: Time Zone
Fields in this page: Field Description ACL Capability Enable/disable the ACL function Enable Check to enable this ACL entry Interface Select the interface domain: LAN or WAN IP Address Enter the IP address that allow access to this device. 4.7.7 Time Zone Simple Network Timing Protocol (SNTP) is a protocol used to synchronize the system time to the public SNTP servers. -
Page 67: Tr-069 Config
Fields in this page: Field Description Current Time The current time of the specified time zone. You can set the current time by yourself or configured by SNTP. Time Zone Select The time zone in which the DSL device resides. Enable SNTP client Enable the SNTP client to update the system clock. - Page 68 Fields in this page: ACS Field Description ACS URL. For example, http://10.0.0.1:80 https://10.0.0.1:443 User Name The username the DSL device should use when connecting to the ACS. Password The password the DSL device should use when connecting to the ACS. Periodic Inform Enable When this field is enabled, the DSL device will send an Inform RPC to the ACS server at the system startup, and will continue to send it periodically at an interval defined in Periodic Inform Interval field;...
-
Page 69: Statistics
http://Device_IP:Port/Path Port The port of the device ConnectionRequestURL. 4.8 Statistics The DSL device shows the different layer of network statistics information. 4.8.1 Interfaces You can view statistics on the processing of IP packets on the networking interfaces. You will not typically need to view this data, but you may find it helpful when working with your ISP to diagnose network and Internet data transmission problems. -
Page 71: Channel Mode Configuration
5 Channel Mode Configuration ADSL router supports multiple channel operation modes. This section will show procedures to configure the router. 5.1 Bridge Mode ADSL modem/router is bridge mode enabled by factory default. There is a 1483-bridged mode PVC 5/35 in system. 1. -
Page 72: Mer(Mac Encapsulating Routing) Mode
5.2 MER(Mac Encapsulating Routing) Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “1483 MER”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting. 3. Set “Local IP Address:” according to the IP that ISP assign for your router. Set “Remote IP Address”... -
Page 73: Pppoe Mode
5.3 PPPoE Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “PPPoE”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting. 3. Enter user/password from your ISP. 4. Click “Add” button to add this channel. 5. -
Page 74: Pppoa Mode
5.4 PPPoA Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “PPPoA”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting. 3. Enter user/password from your ISP. 4. Click “Add” button to add this channel. 5. -
Page 75: 1483 Routed Mode
5.5 1483 Routed Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “1483 Routed”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM’s setting. 3. In WAN IP settings, give the local and remote IP address from your ISP or use DHCP to get them automatically if your ISP support it. -
Page 76: Appendices
Appendices Appendix A: Protocol Stacks 5.5.1 A.1 1483 Bridged Model Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 Bridged Channel Mode Scenario... -
Page 77: 1483 Mer Model
5.5.2 A.2 1483 MER Model Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 MER Channel Mode Scenario... -
Page 78: Pppoe Model
5.5.3 A.3 PPPoE Model PPPoE PPPoE Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS PPPoE Channel Mode Scenario... -
Page 79: Pppoa Model
5.5.4 A.4 PPPoA Model Ethernet Ethernet AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS PPPoA Channel Mode Scenario... -
Page 80: 1483 Routed Model
5.5.5 A.5 1483 Routed Model Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-R) (1483-R) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 Routed Channel Mode Scenerio Appendix B: Mapping PVCs to VLANs RTL867x device supports mapping ATM Permanent Virtual Circuits (PVCs) to VLANs, based on the ATM bridging standards of RFC 2684. - Page 81 ATM Network Ethern DATA Header Header RTL8670 device 10 Vc3 mapped to VLAN 20 RTL867x Ethern VLAN ID Tag Type DATA Header Header 0x8100 RTL8305S Ethern DATA Header Header VLAN 20 VLAN 10 Figure B.1 Adding a VLAN ID and tag to packets from a...
