Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 21.3″ LCD • Applicable to the resolution of 1600 × 1200. • 89° horizontal and vertical viewing angles • Dimming down to the low brightness The mode allows the user to turn off the backlight.
1-2. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes adjustment software, touch panel software, and user’s manuals. Refer to Readme.txt file on the disk for software startup procedures or file access procedures.
1-3. Basic Operations and Functions ● Basic Adjustment menu operations Displaying Adjustment Menu 1. Press for two seconds or more. The Adjustment menu appears. Menutitle Currentmode Item Settings Menu Adjusting/Setting 1. Choose a menu to adjust/set with , and then press 2.
● Showing button guide Press the front buttons other than , and the button guide appears above the button. Note • The Button Guide will continue to appear while the Adjustment menu is showing. • The Button Guide is displayed differently depending on the selected menu or status. Chapter1Introduction...
● Functions The following table shows all the Adjustment menu’s adjustment and setting menus. Main menu Setting Reference Color “2-3.AdjustingColor”(page15) Brightness Contrast Temperature Gamma Advanced Settings Saturation ContrastEnhancer OutlineEnhancer Gain “3-8.ReturnToDefaultSetting”(page22) ColorReset Screen “2-4.SelectingScreenSize”(page19) ScreenSize “2-2.DisplayingScreenCorrectly”(page12) Analog AutoAdjustment Adjustment RangeAdjustment Clock Phase Hor.Position...
Chapter 2 Adjusting Screens 2-1. Setting the Resolution ● Display resolution For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual. ● Setting resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below.
2-2. Displaying Screen Correctly ● Digital Signal Input When digital signals are input, images are displayed correctly based on the preset data of the monitor. When performing advanced adjustment, see “2-3. Adjusting Color” (page 15) and subsequent pages. ● Analog Signal Input Attention •...
Page 13
Prepare to use analog screen adjustment patterns. Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen adjustment pattern files”. Note • For details and instructions on opening the “Screen adjustment pattern files”, refer to the Readme.txt file.
Page 14
Perform advanced adjustments for the following using “Analog Adjustment” of “Screen”. Adjust the clock, phase and position, in this order. ● To eliminate vertical bars Procedure 1. Choose “Clock” from the “Analog Adjustment” menu, and press 2. Adjust the clock with to eliminate vertical bars.
Adjusting color gradation. ● To adjust color gradation automatically Every color gradation (0 to 255) can be displayed by adjusting the signal output level. Procedure 1. Display Pattern 2 in full screen on the monitor using the “Screen adjustment pattern files”. 2.
● To adjust contrast The light and dark setting of the screen is adjusted by varying the video signal level. Adjustable range 0 to 100% Procedure 1. Choose “Color” from the Adjustment menu, and press 2. Choose “Contrast” from “Color”, and press 3.
● To adjust hue This function allows you to adjust the hue. Adjustable range -100 to 100 Procedure 1. Choose “Color” from the Adjustment menu, and press 2. Choose “Advanced Settings” from “Color”, and press 3. Choose “Hue”, and press 4.
● To enhance outline of image OutlineEnhancer functions to emphasize outline of the images by emphasizing the color difference between pixels composing the images. This may improve the texture of the material and its feel of the images. On the contrary, it also functions to reproduce the images smoothly by gradating its outline.
2-4. Selecting Screen Size ● To change screen size The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using the “Screen Size” function from “Screen”. Setting Function Full Displaysanimageinfullscreen.Imagesaredistortedinsomecasesbecausethevertical...
Chapter 3 Setting Monitor 3-1. Setting Brightness of Front Button/Power Indicator The brightness of the front buttons (control button and power button) and power indicator can be set. Attention • They are set to light up under the following condition, and are set to “4” by default. - Power button: When the power cord is connected to the power outlet.
3-4. Setting the EIZO Logo Display This function allows you to display, or not, the EIZO logo. Procedure 1. Press for two seconds or more to turn off the monitor. 2. Holding down, press for at least two seconds to turn on the monitor.
3-7. Setting Backlight Off Mode This function allows you to set the condition when “Brightness” is set to the lower limit value. Setting Function When“Brightness”issettothelowerlimitvalue,thebacklightisturnedofftodarkenthe screen.(However,thisexcludeswhentheAdjustmentmenu,“SignalError”,ortheEIZO logoaredisplayed) Evenwhen“Brightness”issettothelowerlimitvalue,thescreenisnotdarkened. Procedure 1. Press for two seconds or more to turn off the monitor.
Chapter 4 Power Saving Functions 4-1. Setting Power Saving This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •...
4-2. Enabling/Disabling Automatic Brightness Adjustment The sensor on the front side of the monitor detects the environmental brightness to adjust the screen brightness automatically and comfortably by using the Auto EcoView function. Attention • Be careful not to block the sensor on the lower side of the monitor when using the Auto EcoView function. Procedure 1.
Chapter 5 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. 5-1. No picture Problem Possible cause and remedy 1. No picture • Checkwhetherthepowercordisconnectedproperly. • Powerindicatordoesnotlight. • Press . • Powerindicatorislightinggreen. • Increase“Brightness”,“Contrast”,and/or“Gain”inthe Adjustmentmenu(see“2-3.AdjustingColor”(page15)). •...
5-2. Imaging problems (for both digital and analog) Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use“Brightness”or“Contrast”intheAdjustmentmenu toadjustit.(TheLCDmonitorbacklighthasalimitedlife span.Whenthescreenbecomesdarkorbeginstoflicker, contactyourlocaldealer.) • Turnonthe“AutoEcoView”functionintheAdjustment menu.Themonitordetectstheenvironmentalbrightness toadjustthescreenbrightnessautomatically(see“4- 2.Enabling/DisablingAutomaticBrightnessAdjustment” (page24)). 2. The screen suddenly became dark. / The •...
5-3. Imaging problems (for analog only) Problem Possible cause and remedy 1. Display position is incorrect. • Use“Position”intheAdjustmentmenutocorrectthe imageposition(see“Tocorrectthescreenposition”(page 14)). • Iftheproblempersists,usethegraphicsboard’sutilityif availabletochangethedisplayposition. 2. Vertical bars appear on the screen or a • Use“Clock”intheAdjustmentmenutoadjustit(see“To part of the image is flickering. eliminateverticalbars”(page14)).
5-5. Touch panel problems (for FDU2101T only) Attention • For information on how to install or use the touch panel driver, see the Touch Panel Driver User’s Manual (on the CD-ROM). Problem Possible cause and remedy 1. Cursor position is not correct. / Cursor •...
Chapter 6 Reference 6-1. Connecting Multiple PCs The product has multiple connections to PCs and allows you to switch to one of the connections for display. Attention • It is assumed the touch panel monitor will be used with one computer. When the monitor is to be connected to multiple computers, connect a RS-232C cable to the computer used for touch operation (one unit only).
● To switch among input signals Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Input” from “Tools”, and press 3. Select “D-SUB” or “DVI” with 4. Press to exit. When the signal is switched, the active input port name appears at the top right corner of the screen. ●...
6-2. Displaying monitor information ● Displaying signal information This function displays the information about the current input signals displayed. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Signal Info” from “Tools”, and press The “Signal Info” appears. (Example) ●...
6-4. Glossary Clock The analog signal input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog signal is converted to a digital signal for image display. This is called clock adjustment.
Range Adjustment Range adjustment controls the signal output levels to display every color gradation. It is recommended that range adjustment be made before color adjustment. Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of horizontal 1600 pixels and 1200 vertical pixels.
6-5. Preset Timing The following table shows factory preset analog signal timing: Attention • Display position may be deviated depending on the PC connected, which may require screen adjustment using Adjustment menu. • If a signal other than those listed in the table is input, adjust the screen using the Adjustment menu. However, screen display may still be incorrect even after the adjustment.
