Installation Manual
Color LCD Monitor
Software Version 4.3
Thank you for purchasing our Color LCD Monitor.
Important
Please read this "Installation Manual", the "Instruction Manual" and
the "Setup Manual" carefully to familiarize yourself with safe and
effective usage.
• For the latest product information including the "Installation Manual",
refer to our web site:
http://www.eizoglobal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DuraVision FDF4627W-IP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo DuraVision FDF4627W-IP

Summary of Contents for Eizo DuraVision FDF4627W-IP

  • Page 1 Installation Manual Color LCD Monitor Software Version 4.3 Thank you for purchasing our Color LCD Monitor. Important Please read this “Installation Manual”, the “Instruction Manual” and the “Setup Manual” carefully to familiarize yourself with safe and effective usage. • For the latest product information including the “Installation Manual”, refer to our web site: http://www.eizoglobal.com...
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Notice For This Monitor

    The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc.

  • Page 4: Disclaimer

    Instruction Manual.). Disclaimer EIZO shall not be liable in any way to any person whatsoever for the occurrences described below. 1. Any incidental, special or consequential disruption or damage directly or indirectly arising in connection with this product.

  • Page 5: Table Of Contents

    CONTENTS ● Notice for this monitor ......... 3 Camera and Display Position / Date and TimeSettings / Network Settings / Disclaimer ..............4 Communication Settings ....... 46 Cautions for Network Use ........4 3-4. Setting Network Cameras ......47 CONTENTS ............. 5 ●...

  • Page 6: Chapter 1 Product Overview

    Camera Images • Provides display modes (DAY / NIGHT) suitable for surveillance camera images • Equipped with EIZO original “Visibility Optimizer” technology - Outline Enhancer function This function adjusts the perceived resolution of the images so that the blurs are reduced and images are displayed vividly and clearly.

  • Page 7: System Control

    ● System Control • You can register a network camera and configure the live image screen using your web browser • Possible to save and load the settings data You can save the settings data to a USB storage device or to a PC and load the data. ●...

  • Page 8: Supported Network Cameras

    1-3. Supported Network Cameras This product supports the following network cameras: • Panasonic i-pro series network cameras • AXIS network camera • ONVIF Profile S-compatible network cameras Attention • Supported network cameras vary depending on the monitor’s software version. Check the software version of the monitor you are using, then check our website (http://www.eizoglobal.com) for details on supported network cameras.

  • Page 9: Chapter 2 Configuring From The Monitor Screen

    Chapter 2 Configuring from the monitor screen You can configure and operate network cameras from the monitor screen. To configure from your web browser, see “Chapter 3 Configuring from a Web Browser” (page 43). Operating and setting the monitor can be implemented by using either the Remote Control, or a USB mouse. To use a USB mouse, connect the mouse to the USB downstream port at the back of the monitor.

  • Page 10: Setting Screen

    Attention • When the monitor power is turned off while the user is logged in, the user is logged out from the system automatically. In such a case, you cannot display the web interface in your web browser. 2-2. Setting Screen The setting screen is used for various settings such as network camera registration and monitor system settings.
  • Page 11 Entering characters 1. Press The text field is highlighted in green. 2. Press the number buttons ( 0 to 9 ). Press a button consecutively to change over to the character next in order. For the order of character entry, refer to the table shown below.

  • Page 12: Setting Network Cameras

    2-3. Setting Network Cameras ● To automatically discover network cameras Discover network cameras on the network automatically and register them to the system. This procedure is for setting network cameras connected after performing “Easy Setup” upon initial startup of the monitor. Attention •...
  • Page 13 6. Select “OK” and press Automatic discovery is started and a “Searching” message is displayed. When the search is completed, the discovered network cameras are added to the list. A subsequent result is displayed in the detection results for camera discovery. Discovery Results Description When there is no information update for the registered network cameras,...
  • Page 14 7. Select “Apply”. The setting complete screen is displayed. Select “OK”. Note Panasonic network camera • The settings of the newly detected network camera can be changed. Select the network camera whose settings you want to change at “Camera Name” and then select “Settings”.

  • Page 15: To Manually Register Network Cameras

    ● To manually register network cameras Register network cameras manually for cases described below. • When a network camera is installed in a subnet differing from the subnet of the monitor • When settings such as network settings of a registered network camera have been changed •...
  • Page 16 4. Configure the items. For setting details, contact your system administrator. Item Detail Setting range Camera Name Enter the camera name. When selecting ‘Execute’ Alphanumeric characters for ‘Obtain Camera Name,’ the camera name is (up to 24 characters) automatically obtained from the network camera. •...

  • Page 17: To Set Network Camera Functions

    5. Select “Apply”. The setting complete screen is displayed. Select “OK”. Attention • If you want to change the set values using the remote control, press the button, then enter the values (for details see “Entering characters” (page 11)). • Depending on the network camera type, the “Model No.” displayed on the setting screen may differ from when the camera is discovered automatically and when it is registered manually.
  • Page 18 Camera Information Display Select to display or not display the camera information and time of the network camera settings on the camera images. Attention • It is not possible to configure the network camera when its “Protocol” is set to “ONVIF”,“AXIS”, or “DirectUri”. 1.
  • Page 19 When using a Panasonic network camera 1. Configure the items. Item Detail Setting range Aspect Ratio Set the H.264 aspect ratio. Network camera imaging mode Resolution Set the H.264 resolution. According to the network camera specification Refresh Interval Set the refresh interval of H.264 images. 0.2s / 0.33s / 0.5s / 1s / 2s / 3s / 4s / 5s Transmission Priority Set the transmission mode of H.264 Constant Bit Rate / Frame Rate / Best...
  • Page 20 When using an AXIS network camera 1. Configure the items. Item Detail Setting range Video Stream Select the display mode for screens that display According to the camera network camera images. specification Stream Profile Select the profile that the network camera has. According to the camera specification Compression Format Select the compression format.
  • Page 21 ONVIF Profile S-compatible network cameras 1. Configure the items. Item Detail Setting range Media Profile Select the ONVIF image profile. EIZO_Profile / camera profile Encoder Select the encoder settings of ONVIF images. According to the camera specification Compression Format Select compression format of ONVIF images. H.264 / MJPEG Resolution Set the resolution of ONVIF images.
  • Page 22 Preset Preset the shooting position and adjustment status of the network camera. Displays images of the selected network camera. 1. Select the number (1 to 256) to set for “Preset No”. 2. Configure the items. Item Detail Setting range Brightness Adjust the network camera brightness.
  • Page 23 Other Attention • It is not possible to configure the network camera when its “Protocol” is set to “ONVIF”,“AXIS”, or “DirectUri”. 1. Configure the items. Item Detail Setting range Pan / Tilt-flip Turn on / off the pan / tilt-flip function On / Off Upside-down Turn on / off the network camera upside down...

  • Page 24: Setting Display Positions Of Camera Images

    2-4. Setting Display Positions of Camera Images Set the display position for images from the network camera. Procedure 1. Select “Position”. Indicates the display positions on the monitor screen. 2. Configure the items. Item Detail Setting range Position Select a position to display a camera image. Set the network camera to the number of the desired position for display.

  • Page 25: Setting Visibility Optimizer Function

    2-5. Setting Visibility Optimizer Function Set Visibility Optimizer function for images from each camera. Procedure 1. Select “Visibility Optimizer”. Displays images of the selected network camera. Displays current settings. 2. Select the network camera to configure at “Camera Name”. Attention •...

  • Page 26: Configuring System Settings

    2-6. Configuring System Settings Set the date, time and network information for this product. Procedure 1. Select “System”. Displays current settings. (e.g. software version) 2. Select a setting. The setting screen for the selected setting is displayed. Date and Time Settings Set the current date and time. 1.
  • Page 27 3. Select “Apply”. The setting complete screen is displayed. Select “OK”. Attention • Time zones differ according to the sales region. This needs to be set. • If the time zone has been changed, daylight saving time will be turned off. (For details, refer to “Summer Time (DST)”...
  • Page 28 Network Set network information. 1. Select “Network Settings”, “DNS Settings” or “NTP Settings”. 2. Configure the items. Item Detail Setting range Network Settings Select the IP address setting method. IP Setting Method DHCP / Manual Setting If “Manual Setting” is selected, set the IP IP Address, 0.0.0.0 to address, subnet mask and gateway.
  • Page 29 Communication Settings The communication settings are used to configure the web interface function, detection of communication errors, and so on. 1. Configure the items. Item Detail Setting range Communication speed Sets the communication speed between the monitor 100Mbps Half duplex / and network hub.
  • Page 30 Key Lock Locks operations by the buttons on the front of the monitor. On / Off Logo Set whether to display / hide the EIZO logo when the power On / Off is turned on Power Indicator Set whether to turn of or off the power indicator (blue) while On / Off the monitor is on.
  • Page 31 Restart Restart the system. 1. Select “Execute” at “Restart”. Settings Data Migration You can save the settings data to a USB storage device and load the data. Load Settings Data 1. Connect a USB storage device to the USB downstream port of the monitor. 2.
  • Page 32 Save Settings Data 1. Connect a USB storage device to the USB downstream port of the monitor. 2. Enter the password. The password is blank by default. Set the password as necessary. 3. Select “Execute”. The settings data are saved. 4.
  • Page 33 You can select update files from the File Selection screen, and can both upgrade or downgrade software. 1. Download the update file from the EIZO website (http://www.eizoglobal.com), and save it to a USB storage device. 2. Connect a USB storage device to the USB downstream port of the monitor.
  • Page 34 Troubleshooting Use this function when this product does not operate normally, such as when a connection cannot be established with a network camera or a communication error occurs. The network status can be checked using communication commands and past error contents can be checked by displaying the system log.
  • Page 35 Saving system log data 1. Connect a USB storage device to the USB downstream port on the back of the monitor. USB downstream port Displays the data storage status. 2. Select “System Log”. 3. Select the date (year / month / day) of the log data to display. 4.

  • Page 36: Setting User Information

    2-7. Setting User Information Register, change or delete information (username, user level and password) on users that access this product, and configure Auto Login settings. Attention • User information can be registered for up to 10 users. User information for a new user cannot be registered when there are already 10 users registered.

  • Page 37: To Register New User Information

    ● To register new user information Procedure 1. Select “User”. 2. Select “Settings” on the “User Info. Settings” screen. 3. Select “New User Registration”. 4. Set user information. 5. Select “Register”. The registration completion screen is displayed. Select “OK”. Chapter 2 Configuring from the monitor screen...

  • Page 38: To Change User Information

    ● To change user information Procedure 1. Select “User”. 2. Select “Settings” on the “User Info. Settings” screen. 3. Select “Change / Delete User Information”. 4. Set user information. 5. Select “Change”. The registration completion screen is displayed. Select “OK”. Chapter 2 Configuring from the monitor screen...

  • Page 39: To Delete User Information

    ● To delete user information Procedure 1. Select “User”. 2. Select “Settings” on the “User Info. Settings” screen. 3. Select “Change / Delete User Information”. 4. Select the user to delete at “Username”. 5. Select “Delete”. The deletion completion screen is displayed. Select “OK”. Chapter 2 Configuring from the monitor screen...

  • Page 40: Configuring Auto Login Settings

    ● Configuring Auto Login Settings Attention • Once the Auto Login settings are configured, unauthorized operation becomes easy for a malicious third party. Restrict the configuration to the application in an environment where sufficient security is ensured. Procedure 1. Select “User”. 2. Select “Settings” on the “Auto Login Settings” screen. 3.

  • Page 41: Displaying Operation Logs

    2-8. Displaying Operation Logs Operations of this product are recorded on logs. Past operation results can be checked by displaying the log. Also, log data can be saved to a USB storage device. Note • The following data are recorded on the log: - Login information: The names of users who logged in to the system - Camera operation results: Name of operated camera, operation details, operation results - Date, time and details of changes confirmed by selecting “Apply”...

  • Page 42: To Save Log Data

    ● To save log data Procedure 1. Connect a USB storage device to the USB downstream port on the back of the monitor. USB downstream port 2. Select “Log Display”. Displays the data storage status. 3. Select the date (year / month / day) of the data to save. 4.

  • Page 43: Chapter 3 Configuring From A Web Browser

    Chapter 3 Configuring from a Web Browser This product allows you to configure and operate network cameras from your web browser. Basic Information, Monitor Settings, and the Live Image Screen Settings are located on the Web control screen. Note • To configure from the monitor screen, see ”Chapter 2 Configuring from the monitor screen”...

  • Page 44: Web Control Screen

    3-2. Web Control Screen Basic Information, Monitor Settings, and the Live Image Screen Settings are located on the Web control screen. Basic Information display lists of the various settings acquired from the monitor. The Monitor Settings are used for various settings such as network camera registration and monitor system settings. Live Image Screen Settings are used for displaying live image screen layout changes and the like.

  • Page 45: Basic Information

    3-3. Basic Information Display lists of the various settings acquired from the monitor. To make various settings, click to item tab at the top of the screen. This moves you to the setting items page. ● System Information Displays the current status of the monitor system. •...

  • Page 46: Camera And Display Position / Date And Timesettings / Network Settings / Communication Settings

    ● Camera and Display Position / Date and TimeSettings / Network Settings / Communication Settings Displays the current settings status of the monitor. To configure settings, click the link for the item name under an item, or click on the setting items tab at the top of the screen.

  • Page 47: Setting Network Cameras

    3-4. Setting Network Cameras “Camera Registration” is used to display a list of the network cameras currently registered for a monitor. You can add or change network cameras, and reflect network camera information, etc., onto the monitor. Attention • You can only change network cameras that are registered. •...
  • Page 48 2. Select “Auto Discovery”. A “Camera detection will start” dialog box appears. 3. Select the “Protocol” from the list. Enter the “Username” and “Password” registered in the network camera. 4. Select “OK”. A “Searching...” dialog box appears, and the detected network cameras are displayed in the list of additional candidates.

  • Page 49: Load Camera Information

    ● Load camera information Importing a CSV file with the additional candidates for cameras, they can be the candidates for the network cameras discovery. Procedure 1. Select “Camera Registration”. A list of camera registration information appears. 2. Select “Load camera information”. A file dialog box opens 3.

  • Page 50: Manual Registration Of Cameras / Changing Camera Information

    6. Select “OK”. Note • Up to 255 candidate cameras can be read. • The CSV files that can be read are as follows. - CSV files that are exported from the monitor or browser - CSV files created by the user •...
  • Page 51 3. Select “Manual Registration”. A “Camera Information Settings” dialog box appears. When a registered camera is selected, a dialog box describing the applicable camera information appears. Item Detail Setting range Alphanumerics, kana, and Camera Name Enter the camera name. When “Obtain Camera Name”...
  • Page 52 Stream Profile Select the profile that the network camera has. According to the camera When “Obtain Profile” is selected, the profile is specification automatically selected from the network camera. Media Profile Select the ONVIF image profile. When “Obtain EIZO_Profile / camera profile Profile”...

  • Page 53: Deleting Camera Information

    ● Deleting Camera Information You can delete the contents of the registered information for cameras. Procedure 1. Select “Camera Registration”. A screen displaying a list of the camera registration information appears. 2. Check the number of the camera to be deleted. 3.

  • Page 54: Setting Display Positions Of Camera Images

    3-5. Setting Display Positions of Camera Images You can configure settings such as the display positions of network cameras, and displaying camera names in the live image screen. 1. Select “Display” in the “Monitor Settings”. A screen for display position settings is displayed. A link for each setting item that can be configured in “Display”...

  • Page 55: Setting Display Positions

    ● Setting Display Positions Set the positions for displaying network camera images. You can switch the display positions of the source and destination camera images by dragging and dropping the camera within the page. Attention • All of the display positions of registered network cameras can be set. Procedure 1.

  • Page 56: Other Display Settings

    3. Drag a camera name and drop it on the position number where you want to display it. The display positions of the source and destination camera images are switched. e.g.) 4 screen layout 1. Drag display position 1 on Page 1 and drop it at display position 5 on page 2. 2.

  • Page 57: Setting Visibility Optimizer Function

    ● Setting Visibility Optimizer function Set Visibility Optimizer function for images from each camera. Attention • Information such as camera name will be displayed as a blank row for display positions that have not been allocated a camera. Each list box becomes invalid and will not be displayed. Procedure 1.

  • Page 58: Custom Screen Settings

    ● Custom Screen Settings This section describes the procedure for screen settings when the Custom Screen is selected for the image layout. Procedure 1. Select “Custom Scr. Settings”. The “Custom Scr. Settings” screen is displayed. 2. Select the number of columns and rows from the list box. The screen will change to a layout with the number of columns and rows you selected.

  • Page 59: Configuring System Settings

    3-6. Configuring System Settings Configure settings such as the date and time of this product, network settings, and maintenance. Procedure 1. In the “Monitor Settings”, select “System”. A link for each setting item that can be configured in the system settings is located at the top of the screen. 2.
  • Page 60 1. Select “Date and Time”. The “Date and Time” screen is displayed. Date/Time Display Settings Set the current date and time. 1. Configure the items. Item Detail Setting range Date / Time Display Set the date display format, time display yyyy/mm/dd, Mmm/dd/yyyy, Settings format, and time zone (time difference...
  • Page 61 2. Select “Apply”. The setting complete screen is displayed. Select “OK”. Note • When “Synchronize with PC” is selected in “Procedure”, the current date and time setting information of the computer is sent to the monitor and synchronized. • If the main power switch is turned off or the power cord is unplugged for one week or longer, the monitor’s time and date display will no longer be displayed accurately.

  • Page 62: Network Settings

    ● Network Settings Set network information. Attention • When any one of the IP address settings / IP address / subnet mask / gateway is changed and “Apply” is selected, the warning message “The network settings will be changed” is displayed. Select “OK”. Also, when you select “OK”...

  • Page 63: Communication Settings

    ● Communication Settings The communication settings are used to configure the web interface function, detection of communication errors, and so on. 1. In “System”, select “Communication Settings”. The “Communication Settings” screen is displayed. 2. Configure the items. Item Detail Setting range 100Mbps Half duplex / Communication Set the communication speed between the monitor and...

  • Page 64: Other System Settings

    Remote lock Locks operations from remote control. On / Off Logo Set whether to display / hide the EIZO logo when the On / Off power is turned on Power Indicator Set whether to turn of or off the power indicator (blue) On / Off while the monitor is on.

  • Page 65: Maintenance

    ● Maintenance Perform system initialization, restarts, software updates, and settings data migration. 1. In “System”, select “Maintenance”. The “Maintenance” screen is displayed. Initialization and Restart Initialize the system 1. Select “Execute” for “Initialization”. All settings are returned to default setting except for system logs, operation logs, the current time, time zone and summer time settings.
  • Page 66 Restart the system 1. Select “Start” at “Restart”. Restart the system. 2. The following message appears. Select “OK”. Chapter 3 Configuring from a Web Browser...
  • Page 67 Software Update You can both upgrade or downgrade the software version. 1. In “System”, select “Maintenance”. The screen transitions to “Software Update”. 2. Select “Browse”. A file selection dialog box opens. Select the applicable file. Attention • The software will not be updated if a file is not selected, or a file other than an update file has been selected.
  • Page 68 Settings Data Migration You can save and load the settings data to the PC. Saving Settings Data 1. Select “Save Settings Data” on the “Settings Data Migration” screen. The “Save Settings Data” dialog box is displayed. 2. Enter the password. The password is blank by default.
  • Page 69 Loading Settings Data 1. Select “Load Settings Data” on the “Settings Data Migration” screen. The “Load Settings Data” dialog box is displayed. 2. Select the settings data file. 3. Enter the password that was set when saving the settings data. 4.
  • Page 70 6. The following message appears. Select “OK”. Attention • If the environment where settings data was stored is different from the environment where settings data is being loaded with respect to network settings or communication settings, you may not be able to display the Web control screen from the Web browser.

  • Page 71: Setting User Information

    3-7. Setting User Information Register, change or delete information (username, user level, and password) on users that access this product, and configure Auto Login settings. Note • For details, see “2-7. Setting User Information” (page 36). ● Adding User Information Procedure 1.

  • Page 72: Changing User Information

    ● Changing User Information Procedure 1. Select “User”. 2. Select the user to be changed from the “User List”. 3. Select “Change”. A dialog box for entering user information appears. 4. Set user information. 5. Select “OK”. The setting complete screen is displayed. Select “OK”. ●...

  • Page 73: Configuring Auto Login Settings

    ● Configuring Auto Login Settings Procedure 1. Select “User”. 2. On the “Auto Login” screen, select users to whom the Auto Login is to be applied. 3. Select “Apply”. The setting complete screen is displayed. Select “OK”. Chapter 3 Configuring from a Web Browser...

  • Page 74: Displaying Operation Logs

    3-8. Displaying Operation Logs Operations of this product are recorded on logs. Past operation results can be checked by displaying operation logs. You can also display system logs. Note • The following data are recorded on the log: - Login information: The names of users who logged in to the system - Camera operation results: Name of operated camera, operation details, operation results - Date, time and details of changes confirmed by selecting “Apply”...

  • Page 75: Setting The Live Image Screen

    3-9. Setting the Live Image Screen The live image screen settings are used for changing the live image screen layout, or the present monitor status. Procedure 1. In “Live Image Screen”, select “Live Image Screen Settings”. A link for each setting item that can be configured in the live screen settings is located at the top of the screen.

  • Page 76: Live Image Screen Settings

    ● Live Image Screen Settings The live image screen settings are used for configuring the display, such as changing the live image screen layout. 1. Select each setting item from the list box. Item Detail Setting range Full Screen Display Displays / hides the menu of the live image screen.

  • Page 77: System Status Settings

    ● System Status Settings Sets the current monitor screen display status and brightness. Current Status Adjusts the current monitor screen display status. 1. Click ▼ next to “Current Status” to select the status from the displayed list. The following statuses are displayed. Item Status Live Image Screen...

  • Page 78: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting 4-1. Imaging problems Problem Possible cause and remedy 1. The display images are not smooth / • Reduce the resolution and / or bit rate set for the network camera images are not displayed (when camera (see “Video Settings”...
  • Page 79 Problem Possible cause and remedy 8. A “** Camera Control Error” message is • The network camera may not be equipped with the displayed at the message display area function operated. Check the specifications of the camera. 9. The screen is whitish or blackish (for HDMI •...

  • Page 80: Setting Problems

    4-2. Setting Problems Problem Possible cause and remedy 1. Network camera is not detected automati- • In some cases, automatic discovery and camera IP cally address setting become inoperable when 20 or more minutes have passed since the network camera was started up.

  • Page 81: Chapter 5 Reference

    Chapter 5 Reference 5-1. List of setting items Note • Some settings may not be available depending on the firmware version of the monitor. • The setting items and values differ according to the camera. Setting item Setting Default setting Easy Easy Setup Date and Time Date/Time...
  • Page 82 Setting item Setting Default setting Easy Easy Setup Camera Auto Camera Discovery Panasonic / AXIS / ONVIF (None) Setup Discovery Display Position Settings Camera Auto Camera Discovery Panasonic / AXIS / ONVIF (None) Discovery Camera Name Alphanumeric characters (None) Manual (0 to 24 characters) Registration IP Address...
  • Page 83 Setting item Setting Default setting Camera Function Video Settings Bit Rate (Max.) According to the camera According to the camera Settings (When using a specification (Maximum specification) AXIS network possible values 8192 kbps) camera) Priority None / Frame Rate / Quality (According to the camera specification) Transmission Mode...
  • Page 84 Setting item Setting Default setting System System Date and Time Date/Time Date Format yyyy/mm/dd yyyy/mm/dd Settings Display Settings Mmm/dd/yyyy dd/Mmm/yyyy mm/dd/yyyy dd/mm/yyyy Time Format Time Zone GMT-12:00 GMT-11:00 GMT-10:00 GMT-09:30 GMT-09:00 GMT-08:00 GMT-07:00 GMT-06:00 GMT-05:00 GMT-04:30 GMT-04:00 GMT-03:30 GMT-03:00 GMT-02:00 GMT-01:00 GMT+01:00 GMT+02:00...
  • Page 85 Setting item Setting Default setting System System Network DNS Settings Auto / Manual Manual Settings Primary 0.0.0.0 to 255.255.255.255 (None) Server Address Secondary 0.0.0.0 to 255.255.255.255 (None) Server Address NTP Settings On / Off Server Alphanumeric characters and (None) Address symbols 100Mbps Half duplex / Communication...
  • Page 86 Setting item Setting Default setting System User Auto Login Auto Login On / Off Username (Registered user) (None) UserLevel ADMIN / CAMERA (None) CONTROL / LIVE Log Display Date (GMT) Display Save to USB Storage Remove USB Storage *1 This can only be set from the monitor screen. This is not available through your web browser. *2 Can only be set and confirmed from the web browser.

  • Page 87: Chapter 6 Glossary

    Chapter 6 Glossary Bit Rate Displays the volume of data flowing across the network. Generally, the volume is expressed with the unit “bps” (bits per second) which indicates the number of data bits transmitted per second. DNS (Domain Name Server) A server used to convert addresses such as “www.eizoglobal.com”...
  • Page 88 ping A command used to check the connection status with other network devices. Generally, it is judged that there is a problem in the network route when there is no response to ping requests, and the ping command is used for finding out the cause of the problem. PoE (Power over Ethernet) A technology to supply electricity using an Ethernet cable.

  • Page 89: Appendix

    Ethernet is a registered trademark of Fuji Xerox Co., Ltd. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorEdge Tablet Controller, ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i•Sound, Quick Color Match, RadiLight, Re/Vue, Screen Administrator,...

  • Page 90: License

    If the open source software contains a product for which usage us granted under a GPL (GNU GENERAL PUBLIC LICENSE) license, Eizo Corporation will, in line with the GPL usage license conditions, provide the source code for corresponding GPL software via a medium, such as CD-ROM, at a cost to individuals and organizations who make contact via the following contact information for a minimum period of three years after purchase of the product.

  • Page 91: Limited Warranty

    The period of this Warranty is two (2) years from the date of purchase of the Product (hereinafter referred to as the “Warranty Period”). EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty.

  • Page 92: Recycling Information

    Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizoglobal.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale.
  • Page 93 Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizoglobal.com...
  • Page 94 Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizoglobal.com Ringlussevõtu alane teave...
  • Page 95 03V25999D1 IM-FDF4627WIP Copyright © 2016-2019 EIZO Corporation. All rights reserved. 4th Edition-October, 2019...
