セッ トアップマニュアル 重要 : ご使用前に必ずこのセッ トアップマニュアルおよび取扱説明書 (CD-ROM内) をよくお読みになり、 正しくお使いください。 このセッ トアップマニュアルは大 切に保管してください。 Setup Manual Important: Please read this Setup Manual and the User’s Manual stored (on the CD- ROM) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. 设定手册...
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
Page 14
PRECAUTIONS IMPORTANT • This product is intended for applications such as ship engine monitoring. This product is not developed for applications which would require higher reliability, and safety such as those listed below. - Safety devices (Disaster prevention system, security control system, etc.) - Equipment with direct effect on human life (Life support systems, Medical equipment or devices used in the operating room, etc.) - Nuclear energy control devices (Nuclear energy control systems, security control systems of nuclear...
Page 15
WARNING To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock. The equipment must be connected to a grounded main outlet. Failure to do so may result in fire or electric shock. Use the correct voltage.
● How to assemble Fasten the M6 screws (8 locations) through the monitor into the assembly enclosure. Attention • The mounting screws are not supplied. Prepare screws (8 pcs.) for the assembly enclosure. • Install the monitor away from the compasses. Otherwise, an error may occur in the compasses. The safe distance between the monitor and compass is shown below.
● How to connect Connect the signal cables to the input signal connectors and PC. Check the shape of the connectors, and connect the cables. After connecting the signal cable, tighten the screws of the connectors to secure the coupling. Analog connection MD-C87 (D-Sub)
Page 20
Installing the Touch Panel Driver (FDU2101T) Attention • The user account to be used for installing the touch panel driver must have the “Administrators” privilege. • When reinstalling the touch panel driver to update the driver, etc., restart the PC after uninstalling the driver and then install Uninstall the other touch panel driver, if it is installed.
Troubleshooting ● No picture If a problem still remains after applying the suggested remedies, contact your local dealer. Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light. •...
