Ad Notam Display Frame Unit DFU-0133 User Manual page 14

ProdUCt information - inPUt / oUtPUt overvieW
USB
2
1A
POWER
2
1B
14
1a Power input DC 12V for DFU-0133 up to DFU-0216
1b Power input DC 24V for DFU-0260 up to DFU-0840
2 USB input, 1 x USB terminal
TM
3 HDMI input, 3 x HDMI terminal
4 RS232, 1 x D-SUB 9pin male terminal
5 Component input (yPbPr), 3 x RCA terminal, green (y), blue (Pb), red (Pr)
6 Line audio input, 2 x RCA terminal, white (L), red (R)
7 Speaker output, 1 x Phoenix clip 4pin
8 IR input (Receiver)
9 IR output (Cable)
10 IR output (LED)
DISPLAy FRAME UNIT
RS232
3
HDMI
3
TM
LINE AUDIO
4 5 6
COMPONENT
IR INPUT IR OUTPUT
(RECEIVER) (LED)
10
7 8 9
SPEAKER OUT IR OUTPUT
(CABLE)
