User manUal

DISPLAy FRAME UNIT

subject to modifi cation, errors and omissions excepted * V3.1 * 2014-04

Table of Contents

Need help?

Do you have a question about the Display Frame Unit DFU-0133 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ad Notam Display Frame Unit DFU-0133

Page 1 User manUal DISPLAy FRAME UNIT subject to modifi cation, errors and omissions excepted * V3.1 * 2014-04...
Page 3: Table Of Contents
SUMMARy GENERAL INFORMATION INSTALLATION IN WET ROOMS PRODUCT INFORMATION GETTING STARTED TROUBLESHOOTING TECHNICAL SPECIFICATION WARRANTY TERMS...
Page 4: General Information
general information - safety CaUtion • Only qualifi ed specialist staff may carry out service tasks. Service work is necessary, if the unit has been damaged, e.g. if the mains plug or mains cable have been damaged, if liquid or items are present inside the device, if it has been exposed to water or moisture, if it does not work properly or if it has fallen down.
Page 5 general information - Cleaning Do not clean the screen surface with a coarse item or tissues! These can damage the display surface. A clean, dry cloth is suffi cient; never use aggressive cleaners or solvent such as alcohol, thinner or cleaning petrol to clean the Display Frame Unit .
Page 6 CaUtion ad notam does not offer any guarantee for the screws and dowels delivered with the product. These may need to be replaced on site when considering the weight and quality of the load-bearing wall, since ad notam is not familiar with the construction environment.
Page 7 Have this product installed by qualifi ed staff only. Use the mounting systems which are specifi ed or recommended by ad notam. Install the product in a way that it is fi xed properly and take care that children are not exposed to danger.
Page 8 installation of Power adapters The device may only be operated with the provided power adapter. The rated voltage is indicated on the product label. The device is factory-set to the optimal operating voltage (see Technical Specifi cation). Use only power cords and plugs that are suitable for your local electrical outlets.
Page 9 note The power adapter should be adequately secured to prevent it from becoming unstable and/or falling. Make sure the power source circuits are properly grounded. Use the supplied power cord in order to connect it to the power source. If your installation requires a different power cord, be sure to use an offi cially approved power cord displaying the mark of the safety agency that defi nes the regulations for power cords in your country.
Page 10 ® , MIRROR IMAGE , MAGIC MIRROR AD NOTAM, MIRROR IMAGE and MAGIC MIRROR are licensed trademarks of ad notam. Hdmi HDMI, HDMI CEC (HDMI Consumer Electronics Control), the HDMI logo and HIGH-DEFINITION MULTIMEDIA INTERFACE are trademarks of HDMI Licensing LLC.
Page 11 general information - disPosal of old eQUiPment and batteries european Union The following symbol indicates that electrical resp. electronic equipment and batteries signed with this symbol should not be disposed of as general household waste at its end of life. Instead, the products should be handed over to the applicable collection points for the recycling of electrical and electronic equipment as well as batteries for proper treatment, recovery and recycling in accordance with your national legislation and the Directive 2002/96/EC and 2006/66/EC.
Page 12: Installation In Wet Rooms
DIN VDE 0100 T.701. According to this standard, ad notam monitor systems with DC 12V (Limited Power Source Class II, SELV) can be installed at each position (incl. Zones “0” and “1”) in harsh environments, also in showers and above a bath tub as long as the monitor system is shielded from a sealed glass surface and the (external) power adapter is installed beyond these protection zones.
Page 13: Product Information
ProdUCt information - sCoPe of delivery Before using the device please check the following contents of the box for completeness: Display Frame Unit monitor system..........monitor system..........• IR remote control......................... IR remote control......................... IR remote control......................... • WATERPROOF for DFU-0133 up to DFU-0216 SLIMLINE for DFU-0260 up to DFU-0840 Low voltage power adapter................
Page 14 ProdUCt information - inPUt / oUtPUt overvieW IR INPUT IR OUTPUT RS232 LINE AUDIO (RECEIVER) (LED) POWER HDMI COMPONENT SPEAKER OUT IR OUTPUT (CABLE) 1a Power input DC 12V for DFU-0133 up to DFU-0216 Power input DC 24V for DFU-0260 up to DFU-0840 2 USB input, 1 x USB terminal 3 HDMI input, 3 x HDMI terminal...
Page 15: Getting Started
getting started - HoW to ConneCt external video and audio sources The DFU features one Component (5) and three HDMI (3) inputs. We recommend using the HDMI inputs for best video and sound quality. Connect an HDMI cable to the HDMI output terminal of your STB, VCR, DVD player, BluRay player or the like and one of the three HDMI (3) inputs of the DFU.
Page 16 Open / close OSD menu of DFU Dimmer scene 1 recall Switch between TV and radio Favorite list Sleeptimer Aspect ratio Select audio mode / audio track functions used for ad notam Set Top Box solutions functions used for ad notam lighting solutions DISPLAy FRAME UNIT...
Page 17 The LED indicator is off. In order to reset all keys to ad notam “factory default” IR commands, please follow the next steps: In order to reset all keys to ad notam “factory default” IR commands, please follow the next steps: In order to reset all keys to ad notam “factory default”...
Page 18 Open / close OSD menu of DFU Sleeptimer Aspect ratio Select audio mode and audio track Dimmer on / off Dimmer scene 1 recall functions used for ad notam Set Top Box solutions functions used for ad notam lighting solutions DISPLAy FRAME UNIT...
Page 19 getting started - inPUt soUrCe Input Source Within the input source list you can select the available Within the input source list you can select the available key on your remote control input sources. Press the HDMI 1 to open the input source list. HDMI 2 •...
Page 20 getting started - osd menU OSD Settings Image Settings OSD Language English Picture Mode Standard OSD Time Out 180 s Brightness OSD Transparency In the on screen display menu (OSD) you can adapt the Contrast Saturation Sharpness characteristics of the monitor system based on personal Color Temperature Medium Noise Reduction...
Page 21 image settings image settings Press the key to open the osd menu. Navigate to key to open the key to open the Image Settings image settings with the keys. Picture Mode Standard • Picture mode: defi ne the picture mode, choose from Brightness Standard, Dynamic, Mild, User.
Page 22 audio settings audio settings Press the key to open the osd menu. Navigate to key to open the key to open the Audio Settings audio settings with the keys. Sound Mode Standard • sound mode: define the sound mode according Bass to your preferences, choose from Standard, Music, Treble...
Page 23 setup settings setup settings Press the key to open the osd menu. Navigate to key to open the key to open the Setup Settings setup settings with the keys. DFU Model „Model Number“ • save Current settings: save your current device Firmware Version „Version Number“...
Page 24 If the OSD menu is deactivated, users are not able to access the OSD menu without password. Service Settings Input HDMI 1 • start logo: (de)activate the ad notam start-up logo Input HDMI 2 while booting. Input HDMI 3 •...
Page 25 • signal loss timer: set a timespan, how long the input scan should be performed, choose from 5, 10, Service Settings 30, 60, 120 seconds. The DFU switches to standby HDMI CEC mode if no alternative signal was found within the RS-232 Access chosen time.
Page 26 • input Hdmi 1: (de)activate the HDMI 1 input port. • input Hdmi 2: (de)activate the HDMI 2 input port. Service Settings • input Hdmi 3: (de)activate the HDMI 3 input port. Input HDMI 1 • input Component: (de)activate the Component Input HDMI 2 (yPbPr) input port.
Page 27: Troubleshooting
troUblesHooting If the product is not working properly, please check the following troubleshooting hints before you contact customer service: symptoms Possible solution Check the status LED. If the status LED is red, the DFU is in standby and the monitor is black, this is normal.
Page 28: Technical Specification
teCHniCal sPeCifiCation - dfU dimensions IR eye Status LED dfU size 354.0mm 239.0mm 30.5mm 30.5mm 28.5mm 293.0mm 165.0mm 177.0mm 301.5mm 227.0mm 7.0mm 30.0mm 80.0mm 159.0mm 13.0mm 13.3" 13.94" 9.41" 1.20" 1.20" 1.12" 11.54" 6.50" 6.97" 11.87" 8.94" 0.28" 1.18" 8.94" 6.26"...
Page 29 teCHniCal sPeCifiCation - dfU featUres features dfU-0133 up to dfU-0840 0° - 50°Celsius / 32° - 122°Fahrenheit Operating Temperature 20 - 80% Humidity Deutsch, English, Español, Français, Italiano, Português, 中文 (Chinese) OSD Languages UL 60950-1, CAN / CSA 22.2 - 60950-1, CB, FCC, EN 60950-1, EMC 55022, EN 6100-3-2 Certifi cations For model specific parameters please refer to our website: www.ad-notam.com/techinfo...
Page 30 teCHniCal sPeCifiCation - dfU Ports Ports dfU-0133 up to dfU-0840 Line Audio Input 1 x RCA terminal, white, red Component Input 3 x RCA terminal, green, blue, red HDMI Input 3 x HDMI terminal Input Ports 1 x USB terminal RS232 1 x D-SUB 9pin male IR Input (Infrared)
Page 31 teCHniCal sPeCifiCation - dfU sPeCial featUres special features dfU-0133 up to dfU-0840 Multimedia Player Software Update CI (Common Interface) Autostart Signal Scan Hotel Mode RS-232 FM Radio Teletext Weak Signal Enhancement Noise Reduction...
Page 32 teCHniCal sPeCifiCation - Usb media sUPPort Usb media support file extension video audio .avi DivX, XviD, MPEG-4 .mpg MPEG-1, MPEG-2 Movie MP3, WMA, AAC .dat MPEG-1 .mov / .mkv H.264 .mp3 Music .wma .m4a /.aac Progressive JPEG .jpg / .jpeg Baseline JPEG Photo .bmp...
Page 33 teCHniCal sPeCifiCation - remote Control art.no. transmission type model dimensions l x W x H 60 x 150 x 11mm ET_555 Infrared WATERPROOF 2.36“ x 5.91“ x 0.43“ 45 x 225 x 16mm ET_556 Infrared SLIMLINE 1.77“ x 8.86“ x 0.63“ teCHniCal sPeCifiCation - PoWer adaPter Art.No.
Page 34: Warranty Terms
(h) When any alterations whatsoever are made to the Warranty persons or unauthorized dealers as well as in case of removed, be repaired, or at ad notam´s option replaced free of charge. To Certificate regarding the year, month and date of purchase, the...
Page 36 This worldwide Warranty Certificate and proof of purchase must be presented at an authorized ad notam repair service or dealer station before any repair can be made under the conditions of warranty. In addition to the one year Worldwide Warranty issued by ad notam AG, Germany, the European Warranty is valid for two years from the date of purchase.
Page 37 retUrn to faCory In case of a defect, please fill out the form and enclose to the package. rma no. Company Name Contact Address Place, date ZIP, City Country Phone signature E-Mail Please provide below a detailed description of the encountered problem or defect. With this you avoid time consuming inquiries and speed up the repair process considerably.
Page 39 In case of a defect, please contact the ad notam service department in order to receive a RMA number. Returns without indicated valid RMA number cannot be processed and will be refused. ad notam service and support...
Page 40 MAGIC MIRROR ® ® ® are licensed trademarks of ad notam. This product, parts, components and the assembly are protected by or might be part of one or more of the following intellectual property rights: US 7455412 B2 - US 7589893 B2 E-Mail: info@ad-notam.com...

This manual is also suitable for:

Display frame unit dfu-0840
