VIVOTEK IP8152 Mini Box Series
Outdoor Enclosure
Using
AE-251/-252 Outdoor Enclosure,
AE-201/-202 Indoor Enclosure,
AM-114 Pendant Head (outdoor),
AM-116 and AM-117 Pendant Pipes,
AM-221 Gooseneck,
AM-212 Wall-mount bracket,
AM-311 Pole Mount,
AM-411 Corner Mount,
AM-711 Junction Box.
Installation Guide
Rev. 1.0
IP Sur veillance

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP8152 and is the answer not in the manual?

Questions and answers

Related Manuals for Vivotek IP8152

Summary of Contents for Vivotek IP8152

  • Page 1 VIVOTEK IP8152 Mini Box Series Outdoor Enclosure Using AE-251/-252 Outdoor Enclosure, AE-201/-202 Indoor Enclosure, AM-114 Pendant Head (outdoor), AM-116 and AM-117 Pendant Pipes, AM-221 Gooseneck, AM-212 Wall-mount bracket, AM-311 Pole Mount, AM-411 Corner Mount, AM-711 Junction Box. Installation Guide Rev. 1.0...
  • Page 2 Revison History: Rev. 1.0: Initial release. AE-251 and AE-252 Outdoor Enclosure Package Contents 1. Enclosure. 2. Dome cover. 3. Power supply with cable. 4. Camera Mount bracket. 5. Dome clearance measurement tool. 6. Screws. AE-201 and AE-202 Indoor Recess Mount Housing Package Contents 1.
  • Page 3 Compatible VIVOTEK Cameras IP8152 AE-201 AE-202 AE-251 AE-252 Mechanical Dimensions...

  • Page 5: Compatible Accessories

    Warning: 1. Select a suitable location where the camera is free from accidental damage, tampering, or harsh environmental conditions. 2. Locate a place for the installation where the camera can not be intentionally or unintentionally interfered. 3. Select a solid and flat mounting surface that can support the combined weight of the camera and associated hardware.
  • Page 6 Compatible Accessories (4): AM-711 Junction Box Compatible Accessories (5-1): AM-114 Pendant Head Compatible Accessories (5-2): AM-116 and AM-117 Pendant Pipe...
  • Page 7 Mounting & Cabling with Outdoor Enclosures 3-1. Installing Camera to AE-251 and AE-252 Housing Below is a general sample procedure using an outdoor enclosure: 1. Use a Phillips screwdriver to loosen the 2 screws on the sides of the camera bracket. 2.
  • Page 8 3. The IP8152 supports 4 different lens modules. If you are installing the larger lens [AL- 231(2.8-12mm), and AL-234(5-50mm)], you need to remove the inner bracket and install it in the opposite direction as shown below. Tighten the hand screws from the sides.
  • Page 9 5. Secure camera to the bracket assembly by driving a flathead screw. 6. Bend the included measurement tool into a rectangular arch. Attach the measurement tool to the top of camera lens to ensure your lens will not get in the way when the dome cover is installed.
  • Page 10 You should also swing the measurement tool and the camera back and forth to make sure there is enough clearance at different shooting angles. You can make adjustments by changing the camera's position along the bracket. 7. Secure the camera to the large base bracket by fastening the 4 thumb screws while you orient your camera's shooting direction.
  • Page 11 Make adjustments to the camera's shooting direction. 8. Feed power lines and other cables through a gooseneck bracket, a pendant head, or a pendant pipe.
  • Page 12 9. Insert and connect power cables and the Ethernet cable as shown below. The IP8152 can only be powered by a PoE Ethernet connection. camera DC 12V input for onboard Unused heater 10. Install the camera into the housing by driving 2 M6 screws.
  • Page 13 3-2. Installing AE-201 and AE-202 Housing Below is a general sample procedure using an outdoor enclosure: 1. Use a Phillips screwdriver to loosen the 2 screws on the sides of the camera bracket. 2. Detach the inner bracket by loosening the four thumb screws on the sides.
  • Page 14 3. For details about installing camera to the brackets, please refer to previous discussions on page 7, page 9, page 10, page 11, and page 12; from step 3 to 7, step 10, and step 4. Drill a hole on the ceiling that is 290mm in diameter. 5.
  • Page 15 7. Use a Phillips screwdriver to turn and to fit the stainless clamping plates against the ceiling board. Counter-clockwise: Increases the clearance Clockwise: Brings the clamping plate closer to ceiling...
  • Page 16 8. Install the trim ring to the housing by fastening 4 screws.
  • Page 17 3-3. Gooseneck Installation Below is a general, sample procedure using a gooseneck bracket: 1. Route power lines and other cables through the wall and the bracket. 2. Locate the position where you want to install the gooseneck bracket and camera. Drill holes on the wall for securing the bracket and for routing the cables.

  • Page 18: Pendant Mount Installation

    3-4. Pendant Mount Installation Below is a sample procedure using a Pendant pipe: 1. Determine a hard surface ceiling location, and use the mounting holes on the pendant head itself for marking where holes will be drilled to secure the pendant head. Drill holes 10mm in diameter and 60mm deep.
  • Page 19 3. Route power lines and other cables through the side opening and a 1-inch conduit (user-supplied), and through the pendant pipe. 4. Secure pendant pipe to the pendant head by rotating it clockwise until it is tightly fastened. Cables Pendant Head Pendant Pipe Outdoor Enclosure...
  • Page 20 5. Secure the connection using the included hex wrench. 6. Attach the outdoor enclosure to the pendant pipe by rotating it clockwise until it is tightly fastened. 7. Secure the connection using the included hex wrench. When cabling is done, proceed with initial setup such as enabling network access, focus tuning, or zooming.
  • Page 21 3-5. Corner Mount Installation Below is a general, sample procedure using a Corner mount bracket: 1. Combine the two brackets together using the included nuts and washers. 2. Align the assembled brackets with the desired position. Align screw holes on the brackets against the wall.

  • Page 22: Pole Mount Installation

    3-6. Pole Mount Installation Below is a general, sample procedure using a Pole mount bracket: 1. Route power lines and other cables through the included cable gland, pass them through conduits (separately purchased), and install the cable gland to the pole mount bracket.
  • Page 23 3-7. Junciton Box Installation Below are the package contents of the AM-711 junction box: 1. Junction box. 2. Screws for box type brackets. 3. Hex wrench. 4. Screws for speed dome type brackets or housings. A 3/4" conduit is required for the waterproof connector in the center, and another 1-inch conduit should be fitted to the bottom connector.
  • Page 24 Below is a general, sample procedure using a junction box: 1. Use the included hex wrench to remove the socket head cap screws, and then open the front panel. 2. Use a Phillips screwdriver to loosen and remove the middle plate in the junction box. Feed cables and install accessories, such as power adaptors, through the box and the waterproof connectors on the box.
  • Page 25 3. Use the included hex head bolts to secure a gooseneck bracket to the junction box. 4. cables should have been connected and routed through the waterproof connectors. Cable conduits should also be installed.
  • Page 26 5. Use the included hex wrench to fasten the socket head screws for the front door. 6. Use the 4 mounting holes on the back of the junction box to attach a pole mount or a corner mount bracket to the box. See previous discussions for details.
  • Page 27 7. You should then attach the junction box, along with the camera, to a pole-mount or corner-mount position. A pole-mount installation is shown below. You may also mount the junction box to a wall. The mounting holes on the right hand side is accessible when the front door is opened, and the anchors and screws are user- supplied.
