Lewitt DGT 650 Quick Start Manual

10 Data Connector
11 Headphone jack
12 MIDI in
13 line-in
OS X (10.6 and up) //
Connect the DGT 650 to the breakout box and the breakout box to the USB port.
Open "system preferences" in the  menu at the top of the screen.
1
"DGT 650." // Click the "Input" tab and also select "DGT 650."
windows
// Connect the DGT 650 to the breakout box and the breakout box to the USB
Center for changing the settings of your DGT 650 from your computer at
– please follow the onscreen instructions.
iOS
// Just plug and play. But do make sure that the internal battery is charged or that a charger is connected to the dedicated
charging port. If no audio signal is sent to or coming from the DGT 650, iOS will turn it off after a few seconds.
Made for iPhone 5, iPhone 5s, iPhone 5c, iPad (4th generation),
iPad Air, iPad mini, iPod touch (5th generation)
// User Interface
1 Input indicator //
Displays active recording mode
Stereo Mode // Cardioid Mode
Line-In Mode
2 Monitoring modes // Mix the output signal of your device with the
input signal of your microphone
Return // Monitor the Output of your PC, Mac or iOS device
Direct // Monitor the input of the DGT650 without any latency
3 Charging port // Use a dedicated USB charger as power supply for
the DGT 650 on mobile devices to charge the internal battery
4 High-pass fi lter // Use to get rid of unwanted low frequencies.
5 Pre-attenuation // Use for loud input signals to prevent clipping.
6 leD Graph // Displays a value for some settings like headphone
gain, input gain, and others
7 battery Status // Indicates if the device is powered from the
internal battery or connected to a charger
8 I/O Gain // Input and output gain settings
9 Jog Dial // Turn and push to change settings.
// Setup
Connect the breakout box to your microphone. Connect the data
connector cable to the breakout box (10) and the USB connector to
your computer or the lightning connector to your iOS device.
// Click on the "Sound" icon.
port. //
www.lewitt-audio.com/DGT-Series/DGT-650/Downloads
// DGT 650
QUICkSTART GUIDe
// Singer/Songwriter Mode //
// Click the "Output" tab and select
Download the drivers and Control
Stereo
