Lewitt DGT 260 Quick Start Manual

// DOWNLOAD THE DGT 260 DRIVER AND FULL MANUAL
www.lewitt-audio.com/dgt260/downloads
//

Getting started

1 Install Lewitt Control Center software.
2
Follow the on screen installation instructions.
3 Connect your microphone to your computer's USB port using the supplied micro-usb cable.
4 Open the Control Center software.
5 Choose your settings.
6 You are ready to go!
//

How to operate your microphone

Standard mode // Status Indicator (1) is illuminated in white. This is the default state of the device - you can quickly access the
headphone volume by turning the jog dial (9) and check metering on the LED graph (6).
Settings mode //
Enter Settings mode by pushing the jog dial (9) - the status indicator's (1) illumination will turn off.
In Settings mode you can change all the settings on your DGT 260 including: I/O metering, monitoring options (3),
low-cut filter (4), attenuation (5) and gain (7/8).
Rotate the jog dial (9) to change the selected value.
Push the jog dial (9) to jump to the next setting.
After 10 seconds your device automatically switches back to Standard mode.
2
3 3
1
4 5
6
7 8
9
11
Figure 1
//

User interface

1 Status indicator
occurs. Off: in Settings mode.
2 Metering
3 Monitoring
input signal of your microphone.
Return
Direct
of the DGT 260. This way you can monitor the signal without
any latency.
4 Low-cut filter
e.g. structure-borne noise.
5 Pre-attenuation
clipping.
6 LED Graph
10
input gain and others.
7 Output gain
8 Input gain
9 Jog Dial
10 Headphone jack
11 Micro-USB port
connect your DGT 260 to your computer.
// DGT 260
QUICKSTART GUIDE
// White: normal operation. Red: clipping
//
Select IN for input or OUT for output metering.
// Mix the playback of your computer with the
// Monitor the output of your PC, e.g. playback signal.
// The signal of the input is sent directly to the output
//
Use to get rid of unwanted low frequencies,
// Use for loud input signals to prevent
// Displays values for settings like headphone gain,
// Set headphone volume.
// Set microphone gain.
// Turn and push to change settings.
// Connect your 3.5mm headphone plug.
// Use the provided USB cable to
