D-Link 2×1000BASE-T User Manual

Gigabit & fast ethernet switch.
Hide thumbs

Advertisement

Gigabit & Fast
Ethernet Switch
2×1000BASE-T
plus
8×10/100BASE-TX
User's Guide

Advertisement

   Related Manuals for D-Link 2×1000BASE-T

   Summary of Contents for D-Link 2×1000BASE-T

  • Page 1

    Gigabit & Fast Ethernet Switch 2×1000BASE-T plus 8×10/100BASE-TX User’s Guide...

  • Page 3: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE..................1 ......................1 ERMS ’ ............1 VERVIEW OF THIS UIDE INTRODUCTION...................3 ............3 IGABIT THERNET ECHNOLOGY ..............4 THERNET ECHNOLOGY ...............5 WITCHING ECHNOLOGY ....................6 EATURES Ports ......................6 Performance features................6 UNPACKING AND SETUP ................7 ....................7 NPACKING ......................7 ETUP .................8 ESKTOP NSTALLATION )............9...

  • Page 7: Terms

    BOUT UIDE This user’s guide tells you how to install your 10-port 10/100/1000Mbps Gigabit Ethernet Switch, how to connect it to your network. Terms For simplicity, this documentation uses the terms “Switch” (first letter upper case) to refer to the 10-port 10/100/1000Mbps Gigabit Ethernet Switch, and “switch”...

  • Page 9: Introduction

    NTRODUCTION This section describes the features of the 10-port 10/100/1000Mbps Gigabit Ethernet Switch, as well as giving some background information about Gigabit Ethernet, Fast Ethernet and Switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol, full duplex, flow control, and management objects, but with a tenfold increase in theoretical throughput over 100-Mbps Fast Ethernet and a...

  • Page 10: Fast Ethernet Technology

    Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to perform 10 times the number of operations in the same amount of time. In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective method to take advantage of today and tomorrow’s rapidly improving switching and routing internetworking technologies.

  • Page 11: Switching Technology

    provides a straightforward upgrade and takes advantage of the existing investment in hardware, software, and personnel training. Switching Technology Another key development pushing the limits of Ethernet technology is in the field of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or fast Ethernet LAN segments.

  • Page 12: Features

    Features The 10-port 10/100/1000Mbps Gigabit Ethernet Switch was designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously. Switch features include: Ports ♦ Two 10/100/1000Mbps Gigabit Ethernet port (port 9 ~ 10). ♦...

  • Page 13: Unpacking And Setup

    NPACKING AND ETUP This chapter provides unpacking and setup information for the Switch. Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: ♦ One 10-port 10/100/1000Mbps Gigabit Ethernet Switch ♦...

  • Page 14: Desktop Installation

    ♦ Make sure that there is proper heat dissipation from and adequate ventilation around the Switch. Do not place heavy objects on the Switch. Desktop Installation When installing the Switch on a desktop, the rubber feet included with the device must be first attached. Attach these cushioning feet on the bottom at each corner of the device.

  • Page 15: Rack Installation (optional)

    Rack Installation (optional) The 10-port 10/100/1000Mbps Gigabit Ethernet Switch can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the switch’s front panel (one on each side) and secure them with the screws provided.

  • Page 16: Connecting Network Cable

    Connecting Network Cable The Gigabit Ethernet Switch supports two 10/100/1000Mbps Gigabit Ethernet ports and eight 10/100Mbps Fast Ethernet ports. Port 1 to port 8 supports 10Mbps Ethernet or 100Mbps Fast Ethernet. Port 9 and port 10 are Gigabit Ethernet port, it supports 10Mbps, 100Mbps and 1000Mbps.

  • Page 17: Identifying External Components

    DENTIFYING XTERNAL OMPONENTS This chapter describes the front panel, rear panel and LED indicators of the Switch Front Panel The front panel of the Switch consists of 8 10/100Mbps Ethernet ports, 2 10/100/1000Mbps Gigabit Ethernet ports, and LED indicators. 10-Port 10/100/1000Mbps Gigabit Ethernet Switch Off=10M Green=100M Amber=1000M...

  • Page 18: Rear Panel

    Rear Panel The rear panel of the Switch consists of an AC power connector. The following shows the rear panel of the Switch. Figure 3-2. Rear panel view ♦ AC Power Connector This is a three-pronged connector that supports the power cord. Plug in the female connector of the provided power cord into this connector, and the male into a power outlet.

  • Page 19

    1 0 - P o r t 1 0 / 1 0 0 / 1 0 0 0 M b p s G i g a b i t E t h e r n e t S w i t c h O f f = 1 0 M G r e e n = 1 0 0 M A m b e r = 1 0 0 0 M...

  • Page 21: Technical Specifications

    ECHNICAL PECIFICATIONS General IEEE 802.3 10BASE -T Ethernet IEEE 802.3u 100BASE -TX Fast Ethernet Standards: IEEE 802.3ab 1000BASE -T Gigabit Ethernet ANSI/IEEE 802.3 Auto-negotiation IEEE 802.3x Full duplex Flow Control Protocol: CSMA/CD Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex) Data Transfer Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex) Rate: Gigabit Ethernet: 2000Mbps (full-duplex) Topology...

  • Page 22: Physical And Environmental

    Physical and Environmental AC inputs: 100-240 VAC, 50-60 Hz Power 9 watts maximum Consumption: Operating 0 ~ 40 degrees Celsius Temperature: Storage -10 ~ 70 degree Celsius Temperature: Humidity: 10% ~ 90% RH, non-condensing Dimensions: 280 mm x 180 mm x 44 mm EMI: FCC Class A, CE Mark Class A, VCCI Class A Safety:...
