Summary of Contents for DREAMVISION Dreamy geek II
- Page 2 Changes Dreamvision provides this manual ‘as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Dreamvision may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1.0 IMPORTANT SAFEGUARDS ....................2.0 INSTALLATION GUIDELINES ................... Introduction ............................7 Packaging ............................7 Environment of Use........................7 Attaching the Unit ..........................8 Projection Distance.........................8 Lens Offset, Picture Zoom and Focus ....................9 3.0 REMOTE CONTROL UNIT (RCU) ................. General View ..........................10 Loading and Replacing Batteries ....................10 4.0 ... - Page 4 14.2 Unexpected Behavior ........................23 15.0 SPECIFICATIONS ........................ R699854 - Dreamy Geek 2 User Manual...
-
Page 5: Important Safeguards
FCC Information (USA only) Changes or modification not approved by Dreamvision could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. -
Page 6: Important Notice
Important SafeguardS Slots and openings are provided for ventilation must not be blocked or covered. Do not place this unit on a bed, sofa, rug or other similar surface. • Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltages and other hazards. -
Page 7: Installation Guidelines
InStaLLatIon guIdeLIneS 2.0 INSTALLATION GUIDELINES 2.1 Introduction This product is powered by a single HD-Ready DLP® chip with a native resolution of 1280 x 800 pixels. It supports both Standard and HD video formats. Thanks to the use of a 1200 lumens color LED system, the Dreamy Geek 2 can sustain a continuous projection of 20,000 hours (30,000 hours in eco mode). -
Page 8: Attaching The Unit
• Install at a safe place in case this unit or a part of it may drop. • Regardless whether the unit is still under guarantee, Dreamvision is not liable for any product damage caused by improper installation. 1/4”-20 thread 2.5 ... -
Page 9: Lens Offset, Picture Zoom And Focus
InStaLLatIon guIdeLIneS 2.6 Lens Offset, Picture Zoom and Focus Lens Offset The optimum image can be obtained when this projector is place perpendicular to the projection screen. The lens offset is fixed to 50%, that means that the projector can be placed either at the top or at the bottom of the picture as shown in the below picture. -
Page 10: Remote Control Unit (Rcu)
remote ControL unIt (rCu) 3.0 REMOTE CONTROL UNIT (RCU) 3.1 General View [Mute] sound [Power] On / Standby [3D] menu [Picture Menu] [OK] to confirm selection [Custom] button Directionnal Keys [Home] button [Back] to previous screen [Menu] Volume setting [-] or [+] •... -
Page 11: General View
generaL VIeW 4.0 GENERAL VIEW 4.1 Top view and Touch Pad [Mouse] mode [Back] to previous screen [Home] button [OK] button Directionnal Keys Touch Pad buttons Description Mouse Set the Mouse pointer and use the directional keys to move the pointer Back Go back to previous screen Home... -
Page 12: Getting Started
gettIng Started 5.0 GETTING STARTED 5.1 Connecting the Power Cord Power Outlet 110 - 240 V Connecting the Power cord to this unit CAUTION AGAINST FIRE AND ELECTRIC SHOCK . Since the power consumption of this unit is high, insert the power plug directly into a wall outlet. Do not use a power voltage different from that which is indicated. -
Page 13: Connections
ConneCtIonS 6.0 CONNECTIONS 6.1 Caution when connecting a Device to HDMI Input Prior to connecting any device to this unit, switch the projector in standby mode. Never connect a HDMI source to this unit when the projector is in operate mode. The HDMI termination is a self-powered connection and can cause electric discharges. -
Page 14: Menu Structure
menu StruCture 7.0 MENU STRUCTURE SCREENS MENUS SUB MENUS AND OPTIONS Recommend Screen Hulu plus Youtube Netflix Online TV Local Screen Media Player HDMI 1 HDMI 2 A/V Input Settings Screen Apps Manager Settings All Applications SD Card Internal Storage Space Sdcard Storage Network Status... -
Page 15: Recommend Screen
reCommend SCreen Others Scan for devices System Upgrade System Update System Information Restore to Factory Default Language and keyboard settings About Games Screen Turn your phone and tablet into a remote Angry Birds Epic Defense Smash Hit Apps Screen All the other Apps Picture Menu (*) Mute / Hide Picture Menu Auto 3D... -
Page 16: Local Screen
LoCaL SCreen 9.0 LOCAL SCREEN 9.1 General View Use this screen to select the current active input. Select desired input between: • Media Player, browses and reads any supported format files on TF-Card, USB disc, USB key, LAN or WLAN. •... -
Page 17: Basic Operations During Playback
LoCaL SCreen Select the correct input where is located the multimedia file: “TF card” or “USB”, then select the correct type of file between: Photo (JPG or BMP), Music (WMA, MP3 or M4A) or Movie (AVI, MKV, MP4, MOV or MPEG). Browse into the folders where is located the file then press the [OK] button to read the file. -
Page 18: Settings Screen
SettIngS SCreen 10.0 SETTINGS SCREEN 10.1 General View 10.2 Apps Manager Settings Install Applications from App Store: allow or disable the installation of new Apps from the App Store. Default Installation Location: select where the new Apps will be installed, select between Default, Internal or External. -
Page 19: Image Settings
SettIngS SCreen PPoE To set an internet connection using the Point-to-Point protocole. PPoE protocole is generally used to establish an internet connection when using DSL. Use the login and password given by your ISP to fill the empty fields Proxy Setting To set a proxy if needed for your internet connection. -
Page 20: Others
Scan for Devices: confirm to scan and to establish a connection with a Bluetooth device. System Upgrade System update: use only if recommended by an official Dreamvision reseller. System Information: current system revision. Restore to Factory Default: use to restore the Dreamy Geek 2 settings to default. Note that all the custom picture and system settings will be lost. -
Page 21: Apps Screen
appS SCreen 12.0 APPS SCREEN 12.1 General View The All Apps screen lets you browse the entire set of Apps that are installed on your device. You can add more App, to do so please launch the “Play Store App” and login with your account (or create a new account) then browse and choose an App to install between the thousands App available on the Play Store. -
Page 22: Picture Menu
pICture menu 13.0 PICTURE MENU Enter the Picture Menu by pressing the Remote Control Unit button. Press the [Picture Menu] button to adjust the picture quality. 13.1 Auto 3D Confirm to Auto detect the 3D format. Note that most 3D sources contains the 3D format description but in a few cases, the 3D format has to be manually selected. -
Page 23: Clean Memory
maIntenanCe 13.6 Clean Memory Confirm to close all the running Apps and to release used memory. 13.7 Focus Figure Confirm to display a Focus test pattern. 13.8 ScreenShot Confirm to take a screenshot of the current screen. The picture is stored in the TF-Card (sda1/Pictures/ Screenshots/). -
Page 24: Specifications
SpeCIfICatIonS 15.0 SPECIFICATIONS Overview The Dreamy Geek 2 projection device is based on a DLP WXGA DarkChip 3 Emission method Darkchip 3 DLP Display panel size 0.45” Darkchip 3 Native Resolution 1280 x 800 pixels Contrast ratio 20,000:1 Projection lens Fixed Zoom: throw ratio of 1.2:1 with manual Focus Brightness 1,200 ANSI Lumens... - Page 25 SpeCIfICatIonS Dimensions 134 mm 232 mm 45 mm 45 mm 232 mm R699854 - Dreamy Geek 2 User Manual...
- Page 26 R699854 - Dreamy Geek 2 User Manual...
- Page 27 R699854 - Dreamy Geek 2 User Manual...
