DREAMVISION Yunzi+ User Manual

Very high contrast video-projector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VERY HIGH CONTRAST VIDEO-PROJECTOR
IR
ACTIVE
RF
GLASSES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yunzi+ and is the answer not in the manual?

Questions and answers

Related Manuals for DREAMVISION Yunzi+

Summary of Contents for DREAMVISION Yunzi+

  • Page 1 VERY HIGH CONTRAST VIDEO-PROJECTOR ACTIVE GLASSES...
  • Page 2 Changes Dreamvision provides this manual ‘as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Dreamvision may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1.0  SAFETY INSTRUCTIONS ..................... Important Information ........................5 Regional Specific Information......................5 Important Safeguards ........................5 2.0  INSTALLATION GUIDELINES ................... Introduction ............................7 THX-3D Display Certification .......................7 Environment of Use........................8 Air-Flow and Space Requirements ....................8 Ceiling Mounting the Unit ......................8 Projection Distance.........................9 Setting the Lens and using Lens Memories..................9 3.0 ...
  • Page 4 10.5 Anamorphic (works with 3D signal) ....................26 10.6 High Altitude Mode ........................26 10.7 Environment Setting ........................26 11.0  DISPLAY SETUP ........................12.0  FUNCTION ..........................12.1 Trigger ............................27 12.2 Off-Timer............................27 12.3 ECO Mode ............................27 12.4 Network ............................27 12.5 Remote Code A or B ........................28 12.6 Lamp Reset ...........................28 13.0 ...

  • Page 5: Safety Instructions

    FCC Information (USA only) Changes or modification not approved by Dreamvision could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules.
  • Page 6 SAFETY INSTRUCTIONS HAZARD. In order not to defeat the safeguards incorporated into this product, observe the following basic rules for its installation, use and service. The power input is auto-ranging from 100 to 240 VAC. Please read these Important Safeguards carefully before use. •...

  • Page 7: Installation Guidelines

    2D and 3D images, and they are the proof of high definition and high quality, indicating that Yunzi+2&3 have cleared more than 400 rigorous image quality tests including accuracy of color reproduction, cross-talk, viewing angle and video processing performance.

  • Page 8: Environment Of Use

    Install at a safe place in case this unit or a part of it may drop. If the light-source lamp is broken, small pieces of glass from the mesh of the filter may appear outside the unit. • Regardless whether the unit is still under guarantee, Dreamvision R699840 - Yunzi+ User Manual...

  • Page 9: Projection Distance

    INSTALLATION GUIDELINES is not liable for any product damage caused by mounting the unit with third party ceiling mount or when the environment is not suitable for ceiling-mount. Dimensions • Distances between left and right holes is D = 337 mm. •...

  • Page 10: Adjust The Picture Zoom

    Using Lens Memories You can save the current picture position, zoom and focus in up to 5 different Lens Memories (10 for Yunzi+2&3). Each memory stores the current position, zoom, focus of the lens and you can also set a custom name of 10 characters or less.

  • Page 11: Remote Control Unit (Rcu)

    (MPC or Color Profile) [Hide] the current display Backlight button Confirm button [Back] to previous menu Display [Menu] Yunzi+1 Selects a Picture Mode Selects a Picture Mode PHOTO Selects [3D Format] Displays [3D Setting] menu CMD Clear Motion Drive...

  • Page 12: Getting Started

    4.1  General View Front side Optical Lens* Air Inlets Operating LEDs Front IR receiver (*) Optical Lens: On the Yunzi+2&3 models, the optical lens is protected by a motorized lens cover. Rear side Lamp trap Input Panel Navigation buttons Main Power Air Outlets •...

  • Page 13: Operating And Navigation Buttons

    CONNECTIONS 4.3  Operating and Navigation Buttons Power button STANDBY/ON Input source INPUT OK button Directional keys MENU BACK Menu Back Button Description Power To turn ON or OFF the projector. Input source To switch input source between HDMI 1 and HDMI 2. OK button To select or to confirm action.

  • Page 14: Connecting A Video Source To The Projector

    CONNECTIONS 5.2  Connecting a Video Source to the Projector HDMI 2 HDMI 1 3D syncro Emitter Audio/Video Connection Device to connect HDMI 1, HDMI 2 HDMI or DVI-D sources: Blu-ray Disc player, DVD-player equipped with HDMI (DVI compatible) output, Game Console, Computer with DVI-D output. 3D Synchro output 3D synchro emitter to control active shutter glasses.

  • Page 15: Menu Structure

    (Video programs) Natural (Concerts, theatrical rep.) Stage (available only for 4K50/60p input) 4k50/60p User1 User2 User3 User4 Picture Modes (Yunzi+2&3) (Movies) Film (total of 12 + 4 User) (Photos) Photos THX bright(*) THX dark(*) (*) for expert users, require ISF Day(*)
  • Page 16 -30 +30 -30 +30 Saturation -30 +30 Brightness -30 +30 Reset Confirm Color Temp. Xenon Modes (Yunzi+2&3) (Film projector) Xenon1 (DCI projector) Xenon2 (Cooler than DCI) Xenon3 Preset value: 5500K - 6000K - 6500K - 7000K 7500K - 8000K - 8500K - 9000K...
  • Page 17 On, Off Lock On, Off Lens Memory Select Lens Memory Save Lens Memory Name Edit 10 char. max Lens Center Confirm Lens Cover (Yunzi+2&3) Auto, Open Pixel Adjust Adjust Off, Memory1, Memory2 Adjust Area Whole, Zone Adjust Color Red, Blue...

  • Page 18: Picture Adjust

    7.1  Picture Modes and Color Profiles The preset Picture Modes are available and they can be applied to any input. A picture mode retains the picture adjustments. When adjusting the Picture Mode, you can also select pre-configured Color Profiles. Yunzi+1 picture modes Video Digital Cinema...

  • Page 19: Advanced Picture Mode

    PICTURE ADjUST There are 12 Color profiles for 2D inputs and 7 for 3D inputs, depending on the selected picture mode, you may choose an available color profile preset: • Film1 available with Film Picture Profile, uses the Xenon filter and adjusted to Eastman Kodak film tone •...

  • Page 20: Advanced Color Profile

    Accurate color temperature may require professional tools such as dedicated software and colormeter. Wait at least 15 minutes after startup before modifying the picture settings. (*) Xenon Modes are exclusive to Yunzi+2&3 models. 7.5  Advanced Color Temperature When selecting a Color temperature, you can set the Gains and Offsets of each primary color: red, green and blue to finely adjust the color balance.

  • Page 21: Advanced Gamma

    PICTURE ADjUST 7.7  Advanced Gamma Correction Value The Custom data can be set to: Correction Value: a unique value that will act as a gamma coefficient between 1.8 and 2.6, Normal, Brightness Priority, Contrast Priority, Gradation Priority, 1.8-2.6 or Import. Color Selection Select the color to which the Picture Tone, Dark / Bright Level settings would apply.

  • Page 22: Clear Motion Drive (400Hz)

    INPUT SIGNAL 7.9  Clear Motion Drive (400Hz) The Clear Motion function uses a 400Hz video processing to render a smooth and clear motion for movies shot at 24Hz or HD movies at 60Hz. Set the correct level between: • Off: Frame interpolation is disable.

  • Page 23: Aspect Ratio

    3D CONTENT AND 3D PROjECTION 8.4  Aspect Ratio When watching a movie or video program, you can manually set the desired aspect ratio to fill your screen. Select the correct aspect ratio depending on your source: For Video sources a) 4:3.

  • Page 24: Projector 3D Settings

    INSTALLATION 9.2  Projector 3D Settings 3D Formats Use this function to choose the correct 3D input format. Some input signals may contain 3D data such as 1080p Side-by-Side but encoded as if they were in 2D. This unit may treat them as standard 2D signals and will not project correctly.

  • Page 25: Pixel Adjust

    INSTALLATION Lens Memory Save Store into an available memory the lens focus, zoom and shift configuration. There are 5 memories for Yunzi+1 model and 10 memories for the Yunzi+2&3. Lens Memory Name Edit You can edit the Lens Memory Name within the limit of 10 characters. Same procedure as section “User Name Edit”, page 19.

  • Page 26: Keystone (Vertical)

    INSTALLATION Installation Style Flip the image to the left or right, up or down according to the projection state of the projector: Front, Ceiling Mount (F), Rear or Rear Ceiling mount (R) 10.3  Keystone (Vertical) Compensate for trapezoidal distortion caused by installation. Independently to the screen orientation, make sure that the projector is not tilt more than 5% up/down.

  • Page 27: Display Setup

    001 - 009: select a profile between 001 and 009 when watching 3D content with 3D shutter glasses. Profile 001 is recommended when using Dreamvision’s active IR 3D-glasses. b) 010 to 106: select the best compensation profile depending on your screen and environment.

  • Page 28: Remote Code A Or B

    INFORMATION MENU 12.5  Remote Code A or B Select in the projector menu the code A or B according to the code selected on the RCU. You can change the code used by the RCU to communicate with the projector from A to B. To do so, press and hold for 3 sec simultaneously [MENU]+[BACK] buttons on the RCU.

  • Page 29: Cinemascope Setup With Lens Zoom

    CINEMASCOPE SETUPS 14.2  Cinemascope setup with Lens Zoom Select “Menu => Installation => Lens Memory 1” Zoom in, until the left and right borders of the picture fits the 2.35:1 screen borders. Save the lens position in the lens memory 1. You can also edit the memory 1 name to “Cinemascope”. Select “Menu =>...

  • Page 30: Maintenance

    MAINTENANCE [Anamo]rphic modes Anamo Mode A Anamo Mode B When you press sequentially the [Anamo]rphic button, you change the mode from OFF, Mode A and Mode B. • Mode A is intended to be used with an anamorphic lens to watch 2.35:1 content on a 2.35:1 screen. •...

  • Page 31: Dirt On The Lens

    MAINTENANCE 15.2  Dirt on the Lens The lens shall be cleaned using commercial blowers or lens cleaning papers (for cleaning glasses and cameras). Do not use fluid-type cleaning agents. This may lead to peeling of the surface coating film. The lens surface is fragile.

  • Page 32: Troubleshooting

    MAINTENANCE • Pull out the lamp unit using the handle. • Insert the new lamp unit until it is firmly in place. • Tighten the screws of the lamp unit. • Attach the lamp cover and fasten the lamp trap screw. Resetting Lamp Time After installing a new lamp, reset the lamp time using the OSD menu Turn On the unit.

  • Page 33: Miscellaneous

    MISCELLANEOUS Operating LED WARNING LAMP STANDBY/ON Description (orange/red) (orange) (green or red) blinks 1 time: the lamp failed to ignite, restart the projector after a complete cooldown cycle. continuous blinking blinks 2 times: lamp has shut down during ptojection, orange restart the projector after a complete cooldown cycle.

  • Page 34: Available Operating Commands

    MISCELLANEOUS Commad: from 2 to 4 bytes length Command Data: variable length End of Data fixed to 0Ah Available Operating commands Function Command Command Data Description Connection RS-232 00h 00h none Check the serial connection Power 50h 57h Switch the unit On. Switch the unit in standby mode.
  • Page 35 MISCELLANEOUS Function Command Command Data Description Picture Mode 50h 4Dh 50h 4Dh 30h 35h User 3 30h 46h User 4 Color Profile 50h 4Dh 50h 52h 30h 30h 30h 31h Film1 30h 32h Film2 31h 33h Film3 30h 33h Standard 30h 34h Cinema1 30h 35h...
  • Page 36 MISCELLANEOUS Function Command Command Data Description Aspect Ratio 49h 53h 41h 53h Aspect Ratio set to 4:3 Aspect Ratio set to 16:9 Aspect Ratio set to Zoom (PC) Auto (PC) Just (PC) Full Anamorphic Modes 49h 4Eh 56h 53h Turn Off the Anamorphic mode Anamorphic mode set to Mode A Anamorphic mode set to Mode B Select 3D mode...

  • Page 37: Lan Protocol

    MISCELLANEOUS You want to... Command to send Switch this unit Off send: 21h 89h 01h 50h 57h 30h 0Ah receive: 06h 89h 01h 50h 57h 0Ah Change active Input to HDMI2. send: 21h 89h 01h 49h 50h 37h 0Ah send: 21h 89h 01h 52h 43h 37h 33h 37h 31h 0Ah Change Lens Memory1 name to send: 21h 89h 01h 49h 4Ch 4Dh 31h 0Ah “TV-size”...

  • Page 38: Infra Red, Long Hex-Pronto Compatible Rcu

    MISCELLANEOUS Examples You want to... Command to send Switch this unit On 1. open TCP connection 2. receive PJ_OK: 50h 4Ah 5Fh 4Fh 4Bh 3. send PJREQ: 50h 4Ah 52h 45h 51h 4. receive PJACK: 50h 4Ah 41h 43h 4Bh 5.

  • Page 39: Specifications

    Unit size (W x D x H) 46 x 51 x 22 cm - 18.1" x 20.1" x 8.7" (excluding feet) Net Weight 14,3 Kg - 31.5 lbs for Yunzi+1 15,1 Kg - 33.3 lbs for Yunzi+2&3 Box size (W x D x H) 58 x 61 x 41cm - 22.8"...
  • Page 40 MISCELLANEOUS Dimensions 22 cm 8.7” 46 cm 51 cm 18.1” 20.1” 51 cm 20.1” 46 cm 18.1” R699840 - Yunzi+ User Manual...
  • Page 41 Operating the 3D-Glasses (2) Power button Indicating LED (1) Optical lenses (4) (2) Power button Indicating LED (1) (3) 3-positions button Optical lenses (4) (5) micro-USB slot and rechargeable battery 1. Charging the 3D-Glasses The 3D-Glasses come with a USB-rechargeable battery (5) that is charged using the USB to micro-USB cable.
  • Page 42 R699840 - Yunzi+ User Manual...

Table of Contents
