Summary of Contents for DREAMVISION R699848 Dreamy Cinema
- Page 2 Changes Dreamvision provides this manual ‘as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Dreamvision may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1.0 IMPORTANT SAFEGUARDS ....................2.0 INSTALLATION GUIDELINES ................... Introduction ............................7 Packaging ............................7 Environment of Use........................7 Attaching the Unit ..........................8 Projection Distance.........................8 Lens Offset, Picture Zoom and Focus ....................9 3.0 REMOTE CONTROL UNIT (RCU) ................. General View ..........................10 Loading and replacing Batteries ....................11 4.0 ... - Page 4 R699848 - Dreamy Cinema User Manual...
-
Page 5: Important Safeguards
FCC Information (USA only) Changes or modification not approved by Dreamvision could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. -
Page 6: Important Notice
Important SafeguardS points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. Slots and openings are provided for ventilation must not be blocked or covered. Do not place this unit on a bed, sofa, rug or other similar surface. -
Page 7: Installation Guidelines
InStaLLatIon guIdeLIneS 2.0 INSTALLATION GUIDELINES 2.1 Introduction This product is powered by a single HD-Ready DLP® chip with a native resolution of 1280 x 800 pixels. It supports both Standard and HD video formats. Thanks to the use of a 1600 lumens color LED system, the Dreamy Cinema can sustain a continuous projection of 30,000 hours. -
Page 8: Attaching The Unit
• Install at a safe place in case this unit or a part of it may drop. • Regardless whether the unit is still under guarantee, Dreamvision is not liable for any product damage caused by improper installation. 1/4”-20 thread 2.5 ... -
Page 9: Lens Offset, Picture Zoom And Focus
InStaLLatIon guIdeLIneS 1.3x Zoom projection Distance Chart The Dreamy Cinema Zoom comes with an adjustable zoom ranging from 1.07:1 to 1.39:1. Projection Screen Projection Screen Projection Screen Dreamy Cinema Zoom Diagonal Size Base Size Height (Aspect Ratio 16:10) (Aspect Ratio 16:10) (Aspect Ratio 16:10) Projection Distance 20”... -
Page 10: Remote Control Unit (Rcu)
remote ControL unIt (rCu) Picture Focus Adjust the picture focus with the focus adjustment tab located on the top cabinet of this unit as shown below. Picture Zoom The 1.3x Zoom is only available on the Dreamy Cinema Zoom. The manual tab for zoom adjustments is located next to the focus tab as shown in the picture below. -
Page 11: Loading And Replacing Batteries
generaL VIeW 3.2 Loading and replacing Batteries a) Push the cover tab with the fingernail a little backwards and pull upwards the cover top. Slide the cover forward to remove. b) Push the battery body towards the spring and lift up to remove. Insert two AAA - LR03 size batteries, making sure the polarities match the + and - marks inside the battery compartment. -
Page 12: Rear View
ON by pressing the Power button on the Control Panel for 3 seconds or by pressing the Power button on the IR- RCU. The projector should turn ON and display the Dreamvision startup screen. R699848 - Dreamy Cinema User Manual... -
Page 13: Power Off
ConneCtIonS Power button Press the Power button to power ON this unit. 5.3 Power OFF To turn OFF this unit, press and hold for 3 seconds the Power button on the Control Panel or on the IR-RCU. You may also press the Power OFF icon in the Status and Navigation Bar located at the bottom of the screen. WAIT UNTIL COOLING CYCLE IS COMPLETE . -
Page 14: Connecting A Video Source To The Projector
menu StruCture 6.2 Connecting a Video Source to the Projector Video Composite HDMI 1 Audio Right Audio Left HDMI 2 VGA/PC Audio/Video Connection Device to connect HDMI 1, HDMI 2 HDMI or DVI-D sources: Blu-ray Disc player, DVD-player equipped with HDMI (DVI compatible) output, Game Console, Computer with DVI-D output. - Page 15 menu StruCture Sound Set Sound Mode Standard Music Movie Sports User Treble 0 - 100 Bass 0 - 100 Radio FM TX On, Off 76.0 - 108.0 Surround Sound Off, SRS, Surround Spdif Mode Auto, PCM Volume 0 - 100 Auto Volume On, Off Brightness...
-
Page 16: Settings Menus
SettIngS menuS 8.0 SETTINGS MENUS 8.1 Picture Setting Menu Picture Mode Select one of the pre-configured video profile between: Dynamic, Standard, Mild or User. Brightness The brightness function is used to adjust the overall light output. Adjust the Brightness value between 0 and 100. Contrast The contrast function is used to adjust the contrast between the light and dark areas of the displayed image. -
Page 17: Brightness Mode
Select the correct language for the OSD between French or English. 8.10 System Upgrade, Instruction and Reset Factory System update: use only if recommended by an official Dreamvision reseller. System instruction: use with the MicroSD card. Reset Factory: use to restore the Dreamy Cinema settings to default. Note that all the custom picture and system settings will be lost. -
Page 18: Menu
3d menu 9.0 3D MENU Shortcut button on the RCU to this menu: 9.1 General Information about 3D playback Comfort and Caution with 3D Content 3D content has the spectator to focus on extruding objects on the screen. The visual perception of the image and the real focus distance cause a great contradiction, this strain contributes to fatigue and discomfort. -
Page 19: Select A File From A Microsd Card Or From An Usb Disc
openIng a muLtImedIa fILe • Video file compatibility: Format Codec Maximum resolution MPEG1, MPEG2 MPG, MPEG 1920x1080/30P (20 Mbps) AVI, MP4 DVIX, XVID 1920x1080/30P (20 Mbps) MKV, MOV H.264 1920x1080/30P (20 Mbps) MJPEG AVI H.264 640x480/30P (10 Mbps) • Audio file compatibility: Format Maximum bandwidth WMA, MP3, M4A... -
Page 20: Maintenance
maIntenanCe 11.0 MAINTENANCE 11.1 Clean Dirt Dirt on the Cabinet Always use a soft cloth. In case of heavy soiling, soak a cloth in neutral detergent diluted with water, wring dry and wipe, followed by wiping again using a dry cloth. Pay attention to the following as the cabinet may deteriorate in condition, get damaged or paint may come off: - Do not wipe with a stiff cloth. -
Page 21: Specifications
SpeCIfICatIonS 12.0 SPECIFICATIONS Overview The Dreamy Cinema projection device is based on a DLP WXGA DarkChip 3 Emission method Darkchip 3 DLP Display panel size 0.45” Darkchip 3 Native Resolution 1280 x 800 pixels Contrast ratio 12 000:1 Projection lens -Fixed Zoom: throw ratio of 1.45:1 -1.3x Zoom: throw ratio of 1.07:1 to 1.39:1 Manual focus... - Page 22 SpeCIfICatIonS Dimensions 171 mm 171 mm 274 mm 48 mm 48 mm R699848 - Dreamy Cinema User Manual...
