Page 3 Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual.
Page 4: Table Of Contents
Child safety locks........65 Occupant Weight Sensor ......22 Alarm............66 Side impact protection (SIPS) airbags ..26 Volvo Inflatable Curtain (VIC) ....28 Whiplash Protection System – WHIPS..29 Rollover Protection System (ROPS) ..31 Crash mode..........32 Child safety..........33 Child restraint systems......
Page 5 Contents 03 Your driving environment 04 Comfort and driving pleasure 05 During your trip Instruments and controls......72 Menus and messages......122 Driving recommendations....... 202 Ignition modes.......... 79 Climate system........126 Refueling..........206 Seats............81 Audio system.......... 133 Loading........... 210 Steering wheel..........
Page 6 Contents 06 Maintenance and 07 Index specifications Index............288 Volvo maintenance........224 Maintaining your car....... 225 Hood and engine compartment....227 Engine oil..........228 Fluids............230 Replacing bulbs........232 Wiper blades and washer fluid....240 Battery............. 242 Fuses............245 Wheels and tires........253 Vehicle care..........
Page 7: Contents
Contents...
Page 8: Introduction
• Do not export your Volvo to another coun- Optional or accessory equipment may not be render your Volvo not certifiable for try before investigating that country's available in all countries or markets.
Page 9 Important information this manual may not be available in all mar- kets. • Volvo reserves the right to make model changes at any time, or to change specifi- cations or design without notice and with- out incurring obligation. Vehicle event data (Black box)
Page 10: Important Warnings
Your new ted, or if you allow accessories to be instal- quicker and simpler. Volvo is, or can be, equipped with many fea- led by someone unfamiliar with your vehi- • Never use portable computers or personal ture-rich entertainment and communication cle.
Page 11: Environment
Volvo is committed to the well being of its cus- cycle. The metal content is about 75% of the •...
Page 12 Seat belts ....................14 Supplemental Restraint System (SRS) ........... 17 Occupant Weight Sensor ............... 22 Side impact protection (SIPS) airbags ........... 26 Volvo Inflatable Curtain (VIC) ..............28 Whiplash Protection System – WHIPS........... 29 Rollover Protection System (ROPS) ............31 Crash mode..................... 32 Child safety.....................
Page 13 S A F E T Y...
Page 14: 01 Safety
Safety is Volvo's cornerstone. Our concern If you are taking any medication, consult your physician about its potential effects dates back to 1927 when the first Volvo rolled on your driving abilities. off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy- •...
Page 15: Reporting Safety Defects
Trans- could cause injury or death, you ice campaign, safety or emission port Canada in addition to notifying Volvo Cars should immediately inform the recall or similar action, it should be of Canada Corp.
Page 16: Seat Belts
See page 34 for more infor- cause injury in the event of an accident. As Volvo also believes no child should sit in the mation regarding the Automatic Locking seat belts lose much of their strength when front seat of a vehicle.
Page 17 This message Volvo service technician only. will disappear after approximately 6 sec- • onds or can be erased by pressing the...
Page 18 01 Safety Seat belts Seat belt use during pregnancy a distance as possible between their belly and the steering wheel. Child seats Please refer to page 35 for information on securing child seats with the seat belts. The seat belt should always be worn during pregnancy.
Page 19: Supplemental Restraint System (Srs)
All work on to the neutral position: belts, your Volvo is equipped with a Supple- these systems should be performed by mental Restraint System (SRS). Volvo's SRS 1. Switch off the ignition for at least...
Page 20 01 Safety Supplemental Restraint System (SRS) Front airbags The passenger's side front airbag is folded behind a panel located above the glove com- partment. WARNING • The airbags in the vehicle are designed to be a SUPPLEMENT to–not a replace- ment for–the three-point seat belts.
Page 21 (e.g., a snow drift or bush), or a rigid, fixed nent in the SRS system, please contact a object at a low speed, the front airbags will trained and qualified Volvo service technician not necessarily deploy. or Volvo Customer Support: •...
Page 22 This is a normal characteristic and does not indicate fire. • Volvo's front airbags use special sen- sors that are integrated with the front Airbag decal on passenger's side dashboard seat buckles. The point at which the air-...
Page 23 The occupant's back must be as upright the steering wheel or the passenger's as comfort allows and be against the side dashboard. This should only be seat back with the seat belt properly done by a trained and qualified Volvo fastened. service technician. • •...
Page 24: Occupant Weight Sensor
• a child or a small person occupies the front fied Volvo service technician as soon as of Federal Motor Vehicle Safety Standard passenger's seat. possible.
Page 25 Volvo recommends that children always be properly This condition reflects limitations of the OWS restrained in appropriate child restraints in the rear seats. Do classification capability. It does not indicate not assume that the passenger's side front airbag is disabled unless the PASSENGER AIRBAG OFF indicator lamp is lit.
Page 26 01 Safety Occupant Weight Sensor In the USA WARNING WARNING Volvo Cars of North America, LLC • • No objects that add to the total weight Keep the following points in mind with on the seat should be placed on the respect to the OWS system.
Page 27 01 Safety Occupant Weight Sensor WARNING • Do not place any type of object on the front passenger's seat in such a way that jamming, pressing, or squeezing occurs between the object and the front seat, other than as a direct result of the correct use of the Automatic Locking Retractor/Emergency Locking Retrac- tor (ALR/ELR) seat belt (see page 34).
Page 28: Side Impact Protection (Sips) Airbags
01 Safety Side impact protection (SIPS) airbags General information SIPS airbag deployment SIPS decal on the front of the driver's door open- Location of the side impact (SIPS) airbags (front SIPS airbag deployment (one airbag) occurs seats only) only on the side of the vehicle affected by the NOTE impact.
Page 29 Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened.
Page 30: Volvo Inflatable Curtain (Vic)
It is designed to help protect the tion of the Volvo Inflatable Curtain. heads of the occupants of the front seats and the occupant of the outboard rear seating posi- tions in certain side impact collisions.
Page 31: Whiplash Protection System - Whips
Volvo service technician, even the backrest/head restraint to help support the if the seats appear to be undamaged.
Page 32 01 Safety Whiplash Protection System – WHIPS WARNING WARNING • Any contact between the front seat backr- Boxes, suitcases, etc. wedged behind ests and the folded rear seat or a rear-facing the front seats could impede the func- child seat could impede the function of the tion of the WHIPS system.
Page 33: Rollover Protection System (Rops)
01 Safety Rollover Protection System (ROPS) Volvo’s Rollover Protection System utilizes the Roll Stability Control (RSC) function, which is designed to help minimize the risk of a rollover in emergency maneuvers or if a skid should occur. RSC uses a gyroscopic sensor that registers the amount of change in the lateral angle at which the vehicle is leaning.
Page 34: Crash Mode
Restoring the vehicle to normal operat- than is absolutely necessary. ing status should only be done by a Driving after a collision trained and qualified Volvo service tech- If the vehicle has been involved in a collision, WARNING nician. SAFETY MODE SEE MANUAL the text •...
Page 35: Child Safety
A specially designed and tested booster cush- belts or the lap portion of a lap-shoulder belt. ion can be obtained from your Volvo retailer. It should have a label certifying that it meets Such child restraint systems can help protect applicable Federal Motor Vehicle Safety USA: for children weighing 33 –...
Page 36 Volvo's recommendations Drive safely! To make child seat installation easier, each Why does Volvo believe that no child should sit seat belt (except for the driver's belt) is equip- in the front seat of a vehicle? It's quite simple ped with a locking mechanism to help keep the really.
Page 37: Child Restraint Systems
01 Safety Child restraint systems Child restraints Convertible seat Booster cushion Infant seat WARNING WARNING There are three main types of child restraint A child seat should never be used in the Always refer to the child restraint manufac- systems: infant seats, convertible seats, and front passenger seat of any vehicle with a turer's instructions for detailed information booster cushions.
Page 38 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
Page 39: Infant Seats
01 Safety Infant seats Securing an infant seat with a seat belt WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated (on vehicles equipped with Occupant Weight Sensor).
Page 40 01 Safety Infant seats Pull out the shoulder section of the seat belt Ensure that the seat is securely in place 4. Pull the shoulder section of the seat belt 6. Push and pull the infant seat to ensure that out as far as possible to activate the belt's it is held securely in place by the seat belt.
Page 41: Convertible Seats
• A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
Page 42 01 Safety Convertible seats time and is normal. The seat belt should now be locked in place. Fasten the seat belt Ensure that the seat is securely in place 3. Fasten the seat belt by inserting the latch WARNING plate into the buckle (lock) until a distinct Pull out the shoulder section of the seat belt click is audible.
Page 43: Booster Cushions
01 Safety Booster cushions Securing a booster cushion Positioning the seat belt Position the child correctly on the booster cushion 4. Ensure that the seat belt is pulled taut and fits snugly around the child. Booster cushions are recommended for chil- dren who have outgrown convertible seats.
Page 44: Isofix Lower Anchors
01 Safety ISOFIX lower anchors Using the ISOFIX lower child seat 2. Kneel on the child restraint to press down anchors the seat cushion and locate the anchors by feel. 3. Fasten the attachment on the child restraint's lower straps to the ISOFIX lower anchors.
Page 45: Top Tether Anchors
An adult Your Volvo is equipped with child restraint top who uses a belt anchored in a child tether anchorages in the rear seat. They are restraint anchorage runs a great risk of located on the rear side of the backrests.
Page 46: Child Restraint Registration And Recalls
01 Safety Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill out and return the registration card that comes with new child restraints.
Page 47: Integrated Booster Cushion
(see page 35). The Volvo's optional integrated booster cushions shoulder belt must never be placed behind the are located in the outboard seating positions. child's back or under the arm.
Page 48 01 Safety Integrated booster cushion • That the seat belt is properly positioned and is taut. • The shoulder section of the seat belt is across the child's collarbone, not over the neck. • The lap section of the seat belt is across the child's hips and not the abdomen.
Page 49 This work should be performed by a trained and qualified Volvo service technician only. The booster cushion can be folded down com- pletely (stowed) from either the stage 1 or stage...
Page 50 Remote key and key blade..............50 Keyless drive................... 58 Locks....................... 61 Child safety locks..................65 Alarm....................... 66...
Page 51 L O C K S A N D A L A R M...
Page 52: 02 Locks And Alarm
02 Locks and alarm Remote key and key blade Introduction This code is available at an authorized Volvo Canada-5WK49264 retailer. Two remote keys or optional Personal Car IC:267T-5WK49264 + Siemens VDO Communicators (PCC) are provided with your 5WK49236 Loss of a remote key vehicle.
Page 53 When the vehicle is locked with a remote key, drive only. Remote qualified Volvo service technician for reprog- the turn signals will flash once to confirm that key not recognized ramming as an antitheft measure.
Page 54 02 Locks and alarm Remote key and key blade Canada–IC: 3659A-WFS125VO Common functions – Remote key/ Personal Car Communicator (PCC) Operation is subject to the following condi- tions: (1) this device may not cause interfer- ence, and (2) this device must accept any inter- ference, including interference that may cause undesired operation of the device.
Page 55 02 Locks and alarm Remote key and key blade Approach lighting – As you approach the Panic alarm – This button can be used to Functions – PCC vehicle, press the button on the remote control attract attention during emergency situations. to light the interior lighting, parking lights, To activate the panic alarm, press and hold this license plate lighting and the lights in the door...
Page 56 Outside of the PCC´s range eral times from different places in relation to the vehicle, contact an authorized Volvo If the PCC is more than approximately 300 ft service technician. (100 m) from the vehicle when the information...
Page 57 02 Locks and alarm Remote key and key blade Heartbeat Sensor Unlocking the doors with the detached Removing the key blade key blade The heartbeat sensor function is a comple- Insert the key blade as far as possible in the ment to the vehicle's standard alarm, and indi- driver's door lock.
Page 58 02 Locks and alarm Remote key and key blade Replacing batteries in the remote key/ Replacing the batteries CAUTION When handling batteries, avoid touching their contact surfaces as this could result in poor battery function in the remote key. Note the position of the battery's (+) or (–) sides.
Page 59 02 Locks and alarm Remote key and key blade 4. Gently press the key blade in the groove until it clicks into place. Old batteries should be properly recycled.
Page 60: Keyless Drive
02 Locks and alarm Keyless drive Keyless drive (models with Personal Both of the PCCs provided with the vehicle Locking the vehicle Car Communicator only) have the keyless function, and additional ones The doors and the tailgate can be locked by can be ordered.
Page 61 02 Locks and alarm Keyless drive Tested To Comply With FCC Standards NOTE CAUTION For Automobile Use • If several people carrying PCCs approach Keyless drive remote controls should the vehicle at the same time, the driver's never be left in the vehicle. In the event Canada –...
Page 62 02 Locks and alarm Keyless drive Location of the keyless drive antennas WARNING People with implanted pacemakers should not allow the pacemaker to come closer than 9 inches (22 cm) to any of the keyless drive system's antennas. This is to help pre- vent interference between the pacemaker and the keyless drive system.
Page 63: Locks
02 Locks and alarm Locks Locking and unlocking the vehicle Unlocking Glove compartment Press the unlock (left) section of the button. From outside the vehicle Locking The remote key locks all of the doors and the Press the lock (right) section of the button after tailgate.
Page 64 02 Locks and alarm Locks Locking/unlocking the tailgate Unlocking the tailgate from the NOTE passenger compartment • If the doors are locked while the tailgate is open, the tailgate will remain unlocked until the vehicle is relocked by pressing the Lock button on the remote control.
Page 65 02 Locks and alarm Locks Power tailgate* Interrupting automatic opening/closing CAUTION Automatic opening or closing the tailgate can Be sure that there is adequate space above be interrupted in four ways: and behind the vehicle before opening the • tailgate automatically. By pressing the button on the lighting panel.
Page 66 02 Locks and alarm Locks Operating the tailgate manually The power tailgate can be disconnected from the vehicle’s electrical system by quickly pull- ing the outer handle twice. The tailgate can then be opened/closed manually.
Page 67: Child Safety Locks
02 Locks and alarm Child safety locks Child safety locks NOTE There are no manual child safety locks on vehicles equipped with the optional power child safety locks. WARNING Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the controls in position A (manual child safety locks) or if the power child safety lock function is activated.
Page 68: Alarm
– the alarm is armed This device complies with part 15 of the FCC Contact an authorized Volvo service techni- • The indicator light flashes rapidly before rules. Operation is subject to the following con- cian.
Page 69 02 Locks and alarm Alarm Turning off (stopping) the alarm Reduced alarm function 1. Go into the menu under Car settings If the alarm is sounding, it can be stopped by 2. Select Reduced guard (Press Enter to Turning off the accessory alarm sensors pressing the Unlock button on the remote con- choose).
Page 70 02 Locks and alarm Alarm ment alarm sensors, do not make a choice in the menu or press EXIT and lock the vehicle.
Page 71 02 Locks and alarm...
Page 72 Instruments and controls................ 72 Ignition modes..................79 Seats....................... 81 Steering wheel..................86 Lighting....................87 Wipers and washers................93 Power windows..................96 Mirrors..................... 98 Power panorama moonroof*..............100 HomeLink® Wireless Control System*..........102 Starting the engine................105 Transmission..................109 Brakes....................112 Hill Descent Control (HDC)..............
Page 73 Y O U R D R I V I N G E N V I R O N M E N T...
Page 74: 03 Your Driving Environment
03 Your driving environment Instruments and controls Instrument overview...
Page 75: Instruments And Controls
03 Your driving environment Instruments and controls Information displays Function Page Function Page Menus and mes- 122 , 90, Hazard warning 122 , 136 sages, turn signals, 87, 153 flashers high/low beams, Audio system con- trip computer trols Cruise control Climate system controls Horn, airbag...
Page 76 03 Your driving environment Instruments and controls Gauges Indicator, information, and warning for faults in the vehicle's emissions system and symbols the symbol for low oil pressure. Certain symbols may not have their functions illustrated, depending on the vehicle's equip- ment.
Page 77 When this happens, please have your vehicle one of the vehicle's systems. The message can checked by a trained and qualified Volvo serv- should be driven to a trained and qualified be erased and the symbol can be turned off by ice technician as soon as possible.
Page 78 Volvo service technician. This is normal, tensioner, a front airbag, side impact airbag, provided it goes off when the engine speed is and/or an inflatable curtain.
Page 79 " COOLANT LEVEL LOW " will also be with great care, to an authorized Volvo safety and/or drivability of the vehicle. An displayed. If your engine does overheat so that workshop to have the brake system...
Page 80 03 Your driving environment Instruments and controls ance with the message in the display. Clear Trip odometers Clock the message using READ. Reminder – doors not closed If one of the doors, the hood or tailgate is not closed properly, the information or warning symbol comes on together with an explanatory text message in the instrument panel.
Page 81: Ignition Modes
03 Your driving environment Ignition modes Functions CAUTION Posi- Function tion Foreign objects in the ignition slot can impair function or damage the lock. Odometer, clock and tempera- ture gauge are illuminated. Steer- Ignition mode 0 ing lock is deactivated. The audio Insert the remote key in the ignition slot.
Page 82 03 Your driving environment Ignition modes NOTE Use the POWER button for the audio sys- tem when the engine is not running to avoid discharging the battery.
Page 83: Seats
03 Your driving environment Seats Front seats Lift the catches on the rear of the backrest. WARNING • Do not adjust the seat while driving. The Without releasing the catches, push the seat should be adjusted so that the backrest forward. brake pedal can be depressed fully.
Page 84 03 Your driving environment Seats Operation Seat with memory function* 1. Move the seat (and door mirrors) to the desired position using the seat and mirror The seats can be adjusted for a short period adjustment controls. after unlocking the door with the remote con- trol without the key in the ignition slot.
Page 85 03 Your driving environment Seats The position of the driver's seat is now stored Emergency stop Rear seats in the remote control's memory. If the seat accidentally begins to move, press Folding down the rear seat backrests one of the buttons to stop the seat. Automatic seat adjustment To move the seat to the position in which you WARNING...
Page 86 03 Your driving environment Seats • The right (passenger's side) section can be Rear center head restraint WARNING folded down together with the center sec- • When the backrest(s) are returned to the tion. upright position, check that it is properly •...
Page 87 03 Your driving environment Seats Manually lowering the rear seat's WARNING outboard head restraints For safety reasons, no one should be allowed to sit in the outboard rear seat posi- tions if the head restraints are folded down. If these positions are occupied, the head restraints should be in the upright (fixed) position.
Page 88: Steering Wheel
03 Your driving environment Steering wheel Adjusting Horn WARNING Never adjust the steering wheel while driv- ing. With speed-dependent power steering* the level of steering force can be adjusted, see page 157. Keypads Adjusting the steering wheel Horn Lever for releasing/locking the steering Press the steering wheel hub to sound the –...
Page 89: Lighting
03 Your driving environment Lighting Lighting panel High/low beam headlights Daytime running lights can be deactivated by a trained and qualified Volvo service techni- cian. NOTE • The use of daytime running lights is mandatory in Canada. • Continuous high beams cannot be acti-...
Page 90 03 Your driving environment Lighting > Brake lights NOTE The symbol illuminates in the The brake lights come on automatically when instrument panel to indicate that the This function is only active in twilight or dark the brakes are applied. conditions, and only when the vehicle is in high beams are on.
Page 91 03 Your driving environment Lighting Front fog lights Rear fog light NOTE The rear fog light is considerably brighter than the normal tail lights and should be used only when conditions such as fog, rain, snow, smoke or dust reduce visibility for other vehicles to less than 500 ft.
Page 92 03 Your driving environment Lighting When turning Interior lighting, front NOTE Move the lever as far up or down as possi- • Regulations regarding the use of the ble to start the turn signals. The turn signals will hazard warning flasher may vary, be cancelled automatically by the movement of depending on where you live.
Page 93 03 Your driving environment Lighting Interior lighting, rear The lights are switched on or off by pressing The passenger compartment lighting can be each respective button. switched on and off manually within 30 minutes after the vehicle has been unlocked. Courtesy lights/door step lighting* If the lighting is switched on manually and the The courtesy lights/door step lighting switch...
Page 94 03 Your driving environment Lighting Approach lighting Approach lighting is activated by pressing the approach light button on the remote key (see page 52). When the function has been activated, the parking lights, indicator lights, door mirror lights, license plate lighting, dome lighting and door step lighting come on.
Page 95: Wipers And Washers
03 Your driving environment Wipers and washers Windshield wipers/washers Windshield wipers off NOTE Move the lever to position 0 to switch The wipers will make an extra sweep each off the windshield wipers. time the thumb wheel is adjusted upward. Single sweep Move the lever upward from position When the rain sensor is activated, the symbol...
Page 96 If the windshield wipers are on and the trans- eral extra sweeps. tion. mission is put into reverse gear, the tailgate wiper will go into intermittent wiping function Consult your Volvo retailer if you would like to have this function deactivated. Option/accessory, for more information, see Introduction.
Page 97 03 Your driving environment Wipers and washers This function is deactivated when a different gear is selected. NOTE On vehicles with the optional rain sensor, the tailgate wiper will be activated when reverse is selected, if the rain sensor is acti- vated and it is raining.
Page 98: Power Windows
03 Your driving environment Power windows Power windows Operating NOTE • Movement of the windows will stop if they are obstructed in any way. • To reduce buffeting wind noise if the rear windows are opened, also open the front windows slightly. Manual up/down Move one of the controls up/down slightly.
Page 99 03 Your driving environment Power windows Laminated glass* This glass is reinforced to help pro- vide protection against break-ins and improved sound insulation in the passenger compartment. The wind- shield and other windows have laminated glass. Option/accessory, for more information, see Introduction.
Page 100: Mirrors
03 Your driving environment Mirrors Power door mirrors Retractable power door mirrors* To acitvate this function, select reverse gear and press the L or R mirror control button to tilt The mirrors can be retracted for parking/driving the mirror down. in narrow spaces: The door mirror will reset to its normal position: 1.
Page 101 03 Your driving environment Mirrors to the neutral position for electric retracting/ Press the button once to start simultaneous extending to work. rear window and door mirror defrosting. The light in the button indicates that the function is • Retract the mirrors with the L and R but- active.
Page 102: Power Panorama Moonroof
03 Your driving environment Power panorama moonroof* Introduction CAUTION WARNING The panorama moonroof is divided into two • • Remove ice and snow before opening During manual closing, if the moonroof sections. the moonroof. is obstructed, immediately open it • The rear glass section is fixed in place and again.
Page 103 03 Your driving environment Power panorama moonroof* • Open - pull the control back (to the auto panorama moonroof is opened to the tilt posi- NOTE open position) twice in quick succession tion. For manual opening, the sun shade must and release it.
Page 104: Homelink® Wireless Control System
03 Your driving environment HomeLink® Wireless Control System* Introduction Programming HomeLink WARNING • If you use HomeLink to open a garage NOTE door or gate, be sure no one is near the gate or door while it is in motion. Some vehicles may require the ignition switch to be turned on or to the second •...
Page 105 03 Your driving environment HomeLink® Wireless Control System* found where the hanging antenna wire is cedures, replace “Programming HomeLink” NOTE step 2 with the following: attached to the motor-head unit. Some devices may require you to replace • 5. Firmly press and release the “learn” or Continue to press and hold the HomeLink this Programming Step 2 with procedures button while you press and release -...
Page 106 03 Your driving environment HomeLink® Wireless Control System* Erasing HomeLink Buttons This device complies with FCC rules part 15 and Industry Canada (IC) RSS-210. Operation To erase programming from the three Home- is subject to the following two conditions: (1) Link buttons (individual buttons cannot be This device may not cause harmful interfer- erased but can be “reprogrammed”...
Page 107: Starting The Engine
03 Your driving environment Starting the engine Starting the engine 1. Insert the remote key into the ignition slot 3. Depress the brake pedal . Press and with the buttons upward and the metallic release the START/STOP ENGINE button. key blade pointing outward (not inserted The autostart function will operate the into the slot) starter motor until the engine starts.
Page 108 03 Your driving environment Starting the engine WARNING NOTE CAUTION • • • Always remove the remote key from the The idling speed can be noticeably When starting in cold weather, the auto- ignition slot when leaving the vehicle, higher than normal during cold starts. matic transmission may shift up at especially if there are children in the This is to enable emission control sys-...
Page 109 03 Your driving environment Starting the engine 1. Switch off the ignition (set the ignition to NOTE WARNING mode 0, see page 79). For the vehicle to start, one of the vehicle's PROPOSITION 65 WARNING! 2. First connect the red jumper cable to the remote keys must be in the passenger com- Battery posts, terminals, and related acces- partment.
Page 110 03 Your driving environment Starting the engine WARNING • Do not connect the jumper cable to any part of the fuel system or to any moving parts. Avoid touching hot manifolds. • Batteries generate hydrogen gas, which is flammable and explosive. •...
Page 111: Transmission
03 Your driving environment Transmission Automatic transmission Shiftlock Neutral position (N) When P has been selected, the transmission is No gear is engaged and the engine can be mechanically blocked in this position. The started with the gear selector in this position. brake pedal must be depressed before the Apply the parking brake if the vehicle is sta- tionary with the gear selector in position N.
Page 112 03 Your driving environment Transmission • the right to M (or to S on models equipped If you slow to a very low speed, the trans- Shiftlock override with Sport mode). mission will automatically shift down. • To return to the D position from M or S, Shiftlock –...
Page 113 03 Your driving environment Transmission All Wheel Drive – AWD Your Volvo can be equipped with permanent All Wheel Drive, which means that power is distributed automatically between the front and rear wheels. Under normal driving condi- tions, most of the engine's power is directed to the front wheels.
Page 114: Brakes
DRIVE . Have the vehicle towed to a trained may result in delayed brake function. This delay and qualified Volvo service technician and is minimized by cleaning the brake linings. Severe strain on the brake system have the brake system inspected.
Page 115 MIN mark in the reservoir or if a brake system-related message is shown in the information dis- DO NOT DRIVE play: . Have the vehicle towed to a trained and qualified Volvo serv- ice technician and have the brake system inspected.
Page 116: Hill Descent Control (Hdc)
03 Your driving environment Hill Descent Control (HDC) Introduction Function Using HDC Normally, when the accelerator pedal is HDC allows the car to roll forward at a maxi- released while driving down hills, the vehicle's mum speed of 6 mph (10 km/h), and 4 mph speed slows as the engine runs at lower rpm (7 km/h) in reverse.
Page 117 03 Your driving environment Hill Descent Control (HDC) NOTE Engine response to pressure on the accel- erator pedal may be slightly slower than normal when HDC is activated.
Page 118: Parking Brake
03 Your driving environment Parking brake Electric parking brake Applying the electric parking brake NOTE An electric parking brake has the same func- • In an emergency the parking brake can tion as a manual parking brake. be applied when the vehicle is moving by holding in the control.
Page 119 Parking brake not fully released 1. Start the engine. – A fault is after the vehicle begins to move. preventing the parking brake from being released. Contact an authorized Volvo work- Option/accessory, for more information, see Introduction.
Page 120 Parking brake not applied – A fault is pre- venting the parking brake from being applied. Try to apply and release. Contact a Volvo work- shop if the message remains. Parking brake Service required – A fault has arisen.
Page 121 03 Your driving environment...
Page 122 Menus and messages................122 Climate system..................126 Audio system..................133 Bluetooth® hands-free connection............147 Trip computer..................153 Compass....................154 Stability system..................155 Active chassis system–Four C.............. 157 Cruise control..................158 Collision warning with Auto-brake*............160 City Safety™ ..................166 Adaptive Cruise Control (ACC)*............172 Distance alert ..................
Page 123 C O M F O R T A N D D R I V I N G P L E A S U R E...
Page 124: 04 Comfort And Driving Pleasure
04 Comfort and driving pleasure Menus and messages Center console ENTER – leads back one step in the menu Search paths to the menu system functions are structure. A long press exits the menu sys- listed as follows: Car settings Lock Certain functions are controlled from the cen- tem.
Page 125 04 Comfort and driving pleasure Menus and messages City Safety Main menu FM Main instrument panel FM settings Light settings Radio text Lock settings Advanced radio settings Reduced guard Audio settings Parking camera settings* Steering force level* Main menu CD Random Information Climate settings...
Page 126 Serious Time for regular Time for regular risk of damage. maintenance service at an author- Contact an author- ized Volvo work- ized Volvo work- shop. The timing is shop. determined by the number of miles Stopping the Stop and switch off...
Page 127 Maintenance over- If the service inter- vals are not fol- lowed, the warranty does not cover any damaged parts. Contact an author- ized Volvo workshop for service. Temporarily OFF A function has been temporarily switched off and is reset automatically while driving or after starting again.
Page 128: Climate System
Work of this type should only be done when it has been parked. This water is condensation from the A/C system and by a trained and qualified Volvo service tech- NOTE is normal. nician. Do not cover or block the sensors with Refrigerant clothing or other objects.
Page 129 NOTE The incoming air is distributed from 20 different Contact your Volvo retailer for IAQS air filter vents in the passenger compartment. replacement intervals. Air distribution is fully automatic in AUTO mode.
Page 130 04 Comfort and driving pleasure Climate system Air vents in the door pillars Electronic climate control, ECC Blower control Turn the control clockwise to increase or counterclockwise to decrease the blower speed. Pressing the AUTO switch will automatically reg- ulate blower speed and over- ride manual adjustment.
Page 131 04 Comfort and driving pleasure Climate system Heated rear seats* Auto Temperature control The function automatically The temperatures on the regulates cooling, heating, driver and passenger sides blower speed, recirculation, can be set independently. and air distribution to main- When the vehicle is started, tain the chosen temperature.
Page 132 04 Comfort and driving pleasure Climate system Defroster Recirculation/air quality system Interior Air Quality System–IAQS* This function defrosts/de-ices This system consists of a mul- Recirculation the windshield and front side tifilter and an air quality sen- This function can be used to windows.
Page 133 04 Comfort and driving pleasure Climate system • • The left orange light comes on – the air If the insides of the windows start fog- NOTE quality sensor is disengaged. ging, disengage the air quality sensor. • The air quality sensor should always be Use the defroster function to increase •...
Page 134 04 Comfort and driving pleasure Climate system Air distribution Air distribution Airflow to windows and To ensure good com- Air to floor. Some air flows to To warm or cool the feet. from dashboard air vents. fort in warm, dry the dashboard air vents and weather.
Page 135: Audio System
04 Comfort and driving pleasure Audio system Introduction Control panel with headphone socket* NOTE The audio system is available in two versions: Rear seat control panel To prevent unnecessary drain on the vehi- High Performance and Premium Sound. The cle's battery, remove the remote key from system version is shown in the display when the ignition slot if the audio system is used Steering wheel keypad...
Page 136 04 Comfort and driving pleasure Audio system Please note that these functions are also avail- A sound source must be chosen, depending on The arrow keys on the steering wheel key- pad can also be used in the same way. able through the audio system controls on cen- the device that has been connected: ter console.
Page 137 04 Comfort and driving pleasure Audio system tem must be set to USB Removable device/ presses are used to fast-wind CD tracks or to Mass Storage Device. search for the next available radio station. iPod Limitations An iPod receives current and its battery is The audio source (FM, AM, CD, etc.) being charged through the connecting cord.
Page 138 04 Comfort and driving pleasure Audio system 1. Select the function in the menu to be Track information (on/off) Audio volume and automatic volume stored. Only certain functions can be control Car settings stored. The audio system compensates for disrupting Fold mirror when locking noises in the passenger compartment by 2.
Page 139 04 Comfort and driving pleasure Audio system Sound settings 1. Go to Audio settings and select Equalizer Front Equalizer Rear Press the control (3) repeatedly to toggles among the sound settings. Adjustments are The sound level for the frequency band is made by turning the control (3).
Page 140 04 Comfort and driving pleasure Audio system intended to enable the user to adapt sound Automatic tuning 2. Hold in AUTO until Autostoring… reproduction to his/her personal tastes. appears on the display. 1. Select a wave band using FM or AM. Autostoring…...
Page 141 04 Comfort and driving pleasure Audio system 1. Select a wave band using AM or FM. radio reception will remain analog (“normal” HD Radio™reception (U.S. reception) if you are not within digital range of 2. Press SCAN. models only) a station's transmitter. Digital range is slightly >...
Page 142 04 Comfort and driving pleasure Audio system Sub-channels frequency's main channel, pressing the left Digital Audio Broadcasting (DAB) - Canadian models only arrow key will tune to the next lower radio fre- quency. Introduction Digital Audio Broadcasting (DAB) is a digital NOTE radio broadcasting system.
Page 143 04 Comfort and driving pleasure Audio system Wavebands Scanning Selecting Sirius radio mode DAB is broadcast on two wavebands Band SCAN automatically searches through the list 1. Press Power to switch on the audio sys- of available channels tem (see page 136 for information on the LBand standard audio and radio functions).
Page 144 04 Comfort and driving pleasure Audio system • actions. The SIRIUS ID is sometimes referred Using the left and right arrow keys Storing a channel to as the Electronic Serial Number (ESN). • A total of 20 satellite channels can be stored; By turning the tuning control 10 channels each for Sirius 1 and 2, see •...
Page 145 04 Comfort and driving pleasure Audio system If a new song is selected when the memory is Radio text Skip options full, you will be prompted to press ENTER to The text that is displayed about the song that This function is used to remove a channel from delete the last song on the list.
Page 146 Button for changing CD tracks 3. The current code will be displayed. selection. Scan CD Your Volvo retailer can also provide you with Temp. unlock all ch. assistance. Select disc (optional CD changer only) This function will temporarily unlock all chan- nels and make them available for selection.
Page 147 04 Comfort and driving pleasure Audio system Eject individual discs by pressing the eject but- scanned before the CD begins playing. The Playing a CD (CD player ton. length of time that this takes depends on the If a music CD is in the player when CD is quality of the disc.
Page 148 04 Comfort and driving pleasure Audio system Scan CD If a disc with sound files is being played, acti- This function plays the first ten seconds of vate/deactivate under Random Folder. each CD track/sound file. Press SCAN to acti- CD changer vate.
Page 149: Bluetooth® Hands-Free Connection
NOTE Not all cell phones are fully compatible with the hands-free system. A list of compatible phones is available at your Volvo retailer or at www.volvocars.us WARNING Never use the hands-free feature or any other device in your vehicle in a way that System overview distracts you from the task of driving safely.
Page 150 04 Comfort and driving pleasure Bluetooth® hands-free connection function is also available on the steering Alternative 1–using the vehicle's menus disconnect it from the hands-free system (by pressing PHONE in the center console wheel keypad. 1. Activate the cell phone’s Bluetooth® func- for several seconds).
Page 151 04 Comfort and driving pleasure Bluetooth® hands-free connection 3. Press ENTER. Handling calls NOTE End the call by pressing EXIT. • Incoming calls On certain cell phones, the connection is broken when the mute function is Press ENTER to answer a call, even if the audio Disconnecting the cell phone used, which is normal.
Page 152 04 Comfort and driving pleasure Bluetooth® hands-free connection Ringing volume More information about registering A connection can also be established in the and connecting cell phones menu system under Bluetooth Connect Go to Phone settings Sounds and volume phone Change phone.
Page 153 04 Comfort and driving pleasure Bluetooth® hands-free connection Searching for contacts phone number has been stored, press and hold Button Function 1 to dial this number. The easiest way to search for a contact in the phone book is to press and hold any of the Space .1-? ! , : "...
Page 154 04 Comfort and driving pleasure Bluetooth® hands-free connection Bluetooth® menus Missed calls Received calls Dialed calls Phone book 4.1. Search 4.2. Copy fr. mobile phone Bluetooth... 5.1. Change phone 5.2. Connect phone 5.3. Disconnect phone 5.4. Connect fr. mobile phone Phone settings 6.1.
Page 155: Trip Computer
The calculation is based on average fuel distance and speed, contact an authorized consumption during the last 20 miles (30 km) Volvo workshop. of driving and the amount of fuel remaining in the tank when the reading was taken. When the...
Page 156: Compass
04 Comfort and driving pleasure Compass Operation 1. Stop the vehicle in a large open area, safely Selecting a magnetic zone out of traffic and away from steel structures and high-tension electrical wires. 2. Start the vehicle. NOTE For best results from calibration, switch off all electrical equipment in the vehicle (cli- mate system, windshield wipers, audio sys- tem, etc.) and make sure that all doors are...
Page 157: Stability System
This is one of DSTC's permanent functions and 2. Restart the engine. cannot be switched off. If the message remains when the engine is restarted, drive to an authorized Volvo work- Active Yaw Control (AYC) shop to have the system inspected. This function helps maintain directional stabil-...
Page 158 04 Comfort and driving pleasure Stability system If the symbol appears alone, it may appear as follows: • If the symbol flashes, this indicates that the stability system is actively functioning to help counteract wheel spin and/or a skid. • If the symbol remains on for approximately 2 seconds after the engine has been started, this indicates that the system is...
Page 159: Active Chassis System-Four C
04 Comfort and driving pleasure Active chassis system–Four C Active chassis (Four C)* Operation NOTE Active chassis, Four-C (Continuously Con- This steering force level menu function can- trolled Chassis Concept), regulates the cha- not be accessed when the vehicle is in racteristics of the shock absorbers so that the motion.
Page 160: Cruise Control
04 Comfort and driving pleasure Cruise control Operation > The symbol illuminates and the text NOTE (---) mph (5) indicates that cruise con- • A temporary increase in speed by trol is in standby mode. pressing the accelerator pedal, for less than 1 minute (e.g.
Page 161 04 Comfort and driving pleasure Cruise control Temporary deactivation The driver can temporarily deactivate cruise control by pressing 0. The saved speed is shown in brackets in the information display. Resume set speed If cruise control has been deactivated tempo- rarily, it can be reactivated by pressing .
Page 162: Collision Warning With Auto-Brake
The radar sensor and the camera work system components must only be per- together to detect stationary vehicles and vehi- WARNING formed by a trained and qualified Volvo cles that are moving in the same direction as technician. The auto-brake function connot prevent a your vehicle.
Page 163 04 Comfort and driving pleasure Collision warning with Auto-brake* support is activated. Brake support prepares On and off WARNING the brake system to react quickly, and the To switch Collision Warning on or off, go into • The setting Short should only be used brakes are applied slightly.
Page 164 04 Comfort and driving pleasure Collision warning with Auto-brake* Limitations WARNING NOTE Strong sunlight, reflections, extreme light con- • If warnings are given too frequently, the In certain situations, the system cannot trasts, the use of sunglasses, or if the driver is warning distance can be reduced (see provide warnings or warning may be not looking straight ahead may make the visual...
Page 165 04 Comfort and driving pleasure Collision warning with Auto-brake* Fault tracing and actions WARNING If the message Windshield sensors • The camera has the same limitations as blocked is displayed, this means that the cam- the human eye. In other words, its era is obscured and cannot detect vehicle or “vision is impaired”...
Page 166 Wait a short time. It may take several minutes for the camera to register display. visibility. The surface between the inside of the windshield and the camera is dirty. Contact an authorized Volvo retailer or service technician to have this surface cleaned. Symbols and messages in the display Symbol...
Page 167 175 for more information on the radar sensor’s limitations. Collision warn. Collision Warning and Auto-brake are partially or completely not functioning. Service required Contact a trained and qualified Volvo service technician if the message remains in the display. Option/accessory, for more information, see Introduction.
Page 168: City Safety
City Safety™ activates in situations where the ing effect. driver has not applied the brakes in time, which • Never wait for City Safety™ to intervene in a potential collision situation. The City Safety is a registered trademark of the Volvo Car Corporation...
Page 169 04 Comfort and driving pleasure City Safety™ driver is always responsible for main- Safety™ can help prevent a collision from Using City Safety™ taining a safe distance to the vehicle taking place. ahead. • NOTE If the difference in speed is between approximately 10-18 mph (16-30 km/h), The City Safety™...
Page 170 04 Comfort and driving pleasure City Safety™ 1. Use the thumb wheel to scroll until City City Safety™ will be automatically switched on faces may not be detected. Normally, the Safety is displayed. the next time the engine is started, even if it was license plate and taillight reflectors give the off when the engine was switched off.
Page 171 1/50 x 1/10 in. (0.5 x 3 mm) or larger, contact a trained and qualified The area of the Clean the wind- Volvo service technician to repair or replace windshield in front of shield or remove the the windshield (see the illustration showing the sensor is dirty or ice/snow.
Page 172 NOTE Volvo service technician. The function of aftermarket laser detectors • Do not remove the laser sensor (includ- may be affected by City Safety's laser sen- ing removal of the lenses).
Page 173 City Safety Service required City Safety™ is not functioning. • If this message remains in the display, have the system checked by a trained and qualified Volvo service technician. City Safety ON/OFF City Safety™ can be switch on or off manually.
Page 174: Adaptive Cruise Control (Acc)
Maintenance of cruise control compo- tain a suitable speed or suitable dis- nents must only be performed by an Controls tance. authorized Volvo workshop. Radar sensor in front grille Adaptive cruise control consists of: • A cruise control system to maintain a set speed •...
Page 175 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* of the vehicle ahead exceeds the speed that Warning light-driver braking required WARNING you have set. Adaptive cruise control has a braking capacity • Adaptive cruise control is not a collision that is equivalent to approximately 30% of the The adaptive cruise control system is designed avoidance system.
Page 176 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* Operation illuminates in the display and (---) indicate NOTE that ACC is in standby mode. • If one of the adaptive cruise control but- tons is pressed for more than approxi- Setting a speed mately one minute, ACC will be deacti- Use the...
Page 177 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* trol. The set speed is then cleared and cannot must then intervene and adapt the vehicle's WARNING be resumed. speed to the surrounding traffic. • Only use a time interval that is suitable When ACC is activated, the vehicle’s speed Automatic deactivation may be caused if: in current traffic conditions.
Page 178 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* • if the radar sensor is obstructed and can- lanes between your vehicle and the one not detect other vehicles, for example in that the system has already detected. heavy rain, or if snow or other objects are Small vehicles, such as motorcycles, or obscuring the radar sensor.
Page 179 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* Cause Action Swirling water or snow from the surface of the road may interfere with No action possible. A very wet or snow-covered road surface may affect the radar signals. the function of the radar. The surface of the radar is clean but the message remains in the display.
Page 180 ACC has been temporarily disconnected because the radar is obstructed in some way and cannot detect other vehicles. See manual See page 175 for information on the radar sensor’s limitations.. Cruise control ACC is not functioning. Service required Contact a trained and qualified Volvo service technician. Option/accessory, for more information, see Introduction.
Page 181: Distance Alert
04 Comfort and driving pleasure Distance alert Introduction > The indicator light in the button illumi- NOTE nates when the function is on. Distance Alert is part of Adaptive Cruise Con- Distance Alert is in active mode while Adap- trol and is a function that provides information tive Cruise Control is active.
Page 182 04 Comfort and driving pleasure Distance alert A smaller version of the symbol is then shown Limitations WARNING to the right in the display. The same symbol is The Distance Alert function uses the same • Bad weather or winding roads may also displayed when Adaptive Cruise Control is radar sensor used by Adaptive Cruise Control affect the radar sensor’s capacity to...
Page 183 Distance Alert has been temporarily disconnected because the radar is obstructed in some way and cannot detect other vehicles. See page 175 for information on the radar sensor’s limitations. See manual Collision warn. Distance Alert or Collision Warning with Auto-brake is not functioning properly. Contact a trained and qualified Volvo service technician. Service required...
Page 184: Driver Alert System
04 Comfort and driving pleasure Driver Alert System* Introduction Driver Alert Control (DAC)–general DAC is designed to help detect a slowly chang- information ing driving pattern. It is primarily intended to be The Driver Alert System is designed to help a used on main roads and is not meant for use in driver who may be becoming fatigued or who city traffic.
Page 185 04 Comfort and driving pleasure Driver Alert System* Operating DAC Driver If the vehicle is being driven erratically, the Thumb wheel. Turn this wheel until Alert is displayed. The second line shows driver will be alerted by an audible signal and Certain settings can be made from the menu Off, Unavailable the message Driver Alert, Time for a break is...
Page 186 See page 162 for information on the camera’s limitations. See manual Driver Alert Sys The system is not functioning. Contact a trained and qualified Volvo service technician if the message remains in the display. Service required...
Page 187 04 Comfort and driving pleasure Driver Alert System* Lane Departure Warning (LDW)– Operation and function If the camera can no longer monitor the road’s general information side marker lines, or if the vehicle’s speed falls below 37 mph (60 km/h), LDW will return to standby mode and Lane Depart Warn Unavailable...
Page 188 See page 162 for information on the camera’s See manual limitations. Driver Alert Sys The system is not functioning. Contact a trained and qualified Volvo service technician if the message remains in the display. Service required Settings started.
Page 189: Park Assist
04 Comfort and driving pleasure Park assist* Introduction Function Activating/deactivating The system is activated automatically when the The park assist system is designed to assist vehicle is started. you when driving into parking spaces, garages, etc. It utilizes four ultrasound sensors located –...
Page 190 Rear park assist is deactivated automati- Display in a vehicle with rear park assist cally when towing a trailer if Volvo genuine only. Here, an object has been detected by trailer wiring is used.
Page 191 Assist syst Service required is shown on the Location of the front sensors information display, this indicates that the sys- tem is not functioning properly and has been disengaged. Consult a trained and qualified Volvo service technician. Option/accessory, for more information, see Introduction.
Page 192: Park Assist Camera (Pac)
122. WARNING mals that are close to the vehicle. If the Volvo Navigation System (VNS) is in use, Objects seen on the screen may be closer PAC will automatically override the navigation than they appear to be.
Page 193 04 Comfort and driving pleasure Park Assist Camera (PAC)* Deactivation see path the vehicle will take, even if he/she The sidelines indicate approximately 4 inches turns the steering wheel while backing up. (10 cm) of free space from the outer edge of the Move the gear selector from R to another posi- door mirrors to the inside of the sideline.
Page 194 04 Comfort and driving pleasure Park Assist Camera (PAC)* Activating the system Marker (color) Distance to • Automatic Mark to activate PAC each object time reverse gear is selected. Green > 5 ft (1.5 m) • Mark to turn off PAC completely. Yellow 5–1 ft (0.3–1.5) Limitations...
Page 195: Blind Spot Information System
CAUTION The BLIS system should only be repaired by a trained and qualified Volvo service tech- nician. Areas monitored by BLIS Distance A = approx. 31 ft. (9.5 meters), Distance B = approx. 10 ft.
Page 196 04 Comfort and driving pleasure Blind Spot Information System* When does BLIS function Darkness WARNING BLIS reacts to the headlights of surrounding The system functions when your vehicle is • BLIS does not react to cyclists or vehicles. In order to be detected by BLIS, a moving at speeds above 6 mph (10 km/h).
Page 197 04 Comfort and driving pleasure Blind Spot Information System* Limitations CAUTION In certain situations, the BLIS indicator light(s) • Clean the lenses carefully to avoid may illuminate even when there are no other scratching. vehicles in the area monitored by the system. •...
Page 198 The camera will reset itself when Blind spot syst. BLIS not functioning service required properly. Contact an these conditions have changed. have authorized Volvo been function service technician. reduced Blind spot syst. BLIS camera camera blocked obscured. Clean the lenses.
Page 199: Passenger Compartment Convenience
04 Comfort and driving pleasure Passenger compartment convenience Storage spaces...
Page 200 It is only intended for hanging light manually with the key blade, see page 61. ger, 12-volt socket and small storage com- garments. partment. Cigarette lighter and ashtray* Your Volvo retailer has lighters and ashtrays available as accessories. Option/accessory, for more information, see Introduction.
Page 201: Passenger Compartment Convenience
04 Comfort and driving pleasure Passenger compartment convenience Vanity mirror 12-volt sockets socket to supply current, the ignition must be in at least mode I, see page 79. WARNING Always keep the sockets covered when not in use. 12-volt socket in the cargo area* Vanity mirror with lighting 12-volt socket in the front tunnel console The light comes on automatically when the...
Page 202 Driving recommendations..............202 Refueling....................206 Loading....................210 Cargo area.................... 213 Towing a trailer..................217 Emergency towing................220...
Page 203 D U R I N G Y O U R T R I P...
Page 204: 05 During Your Trip
05 During your trip Driving recommendations • General information Remove snow tires when threat of snow or WARNING ice has ended. Economical driving conserves natural Driving with the tailgate open: Driving with • Note that roof racks, ski racks, etc, the tailgate open could lead to poisonous resources increase air resistance and also fuel con-...
Page 205 05 During your trip Driving recommendations Driving through water CAUTION WARNING • The vehicle can be driven through water up • The cooling fan may start or continue to Engine damage will occur if water is to a depth of approximately 10 in. (25 cm), operate (for up to 6 minutes) after the engine drawn into the air cleaner.
Page 206 It is always worthwhile to have your vehicle Synthetic oil is not used when the oil is are likely to occur, consider snow tires. checked by a trained and qualified Volvo serv- changed at the normal maintenance inter- ice technician before driving long distances.
Page 207 Driving recommendations 2 parts water Down to –18 °F (–28 °C): 1 part washer solvent and 1 part water. • Use Volvo Teflon Lock Spray in the locks. • Avoid using de-icing sprays as they can cause damage to the locks.
Page 208: Refueling
State the use of "oxygenated" fuel. Deposit control gasoline (detergent and local vehicle inspection programs will Volvo allows the use of the following "oxygen- additives) make detection of misfueling easier, possibly ated" fuels; however, the octane ratings listed...
Page 209 Typical pump octane label injury. Many fuels contain benzene as a solvent. Volvo engines are designed to run on unleaded Unburned benzene has been strongly linked to gasoline with an octane rating of 87 or above.
Page 210 05 During your trip Refueling • Opening/closing the fuel filler door Be sure the fuel filler door is not obstructed If necessary, the fuel filler door can be opened and is completely closed after refueling. manually: • Open the fuel filler cap slowly during hot 1.
Page 211 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.
Page 212: Loading
• anchor items in the cargo area. Stop the engine and apply the parking tion of the Volvo Inflatable Curtain. brake when loading or unloading long objects. The gear selector can be knocked out of position by long loads, which could set the vehicle in motion.
Page 213 Using load carriers Cover sharp edges on long loads to help prevent injury to occupants. Secure the Load carriers are available as Volvo accesso- load to help prevent shifting during sud- ries. Observe the following points when in use: den stops.
Page 214 05 During your trip Loading • The vehicle's wind resistance and fuel con- sumption will increase with the size of the load. • Drive smoothly. Avoid rapid starts, fast cornering and hard braking.
Page 215: Cargo Area
05 During your trip Cargo area Steel cargo grid* Installing the steel cargo grid Do the same on the opposite side of the vehicle. In order to install the steel grid, the rear seat backrests must be completely folded down, see page 83 for instructions.
Page 216 05 During your trip Cargo area Cargo area cover* Removing the cover Cargo net* 1. Press one of the end pieces of the cover inward. 2. Pull the cover carefully upward and out- ward. The other end will release automati- cally from its retaining bracket.
Page 217 05 During your trip Cargo area WARNING • Be sure that the cargo net's upper attachment hooks are properly inserted in the brackets and that the lower straps are correctly attached and pulled taut. • A damaged cargo net should never be used.
Page 218 05 During your trip Cargo area Removing and storing the cargo net Press the release buttons on the locks on the straps and pull out a small section of the strap. Press in the catches on the straps' hooks and remove the hooks from the eyelet. Fold up the net's rod at the center and roll up the net.
Page 219: Towing A Trailer
Introduction when driving in hot climates or hilly terrain. WARNING Use a lower gear and turn off the air con- Volvo recommends the use of Volvo trailer • Bumper-attached trailer hitches must ditioner if the temperature gauge needle hitches that are specially designed for the vehi- not be used on Volvos, nor should enters the red range.
Page 220 3. Align the hole in the ball holder with the one Volvo. Make sure the cable does not drag on overloaded or if the load is unevenly distributed in the hitch assembly.
Page 221 05 During your trip Towing a trailer in the trailer, there is risk of swaying at speeds How TSA works between approximately 45-55 mph Once swaying has begun, it can be very diffi- (70-90 km/h). cult to stop, which makes it difficult to control the vehicle and trailer.
Page 222: Emergency Towing
05 During your trip Emergency towing Towing eyelet on the right sides of either the front or rear Press the cover for the attachment point back bumper (see illustration). into position. CAUTION WARNING If the vehicle is being towed on a flat bed If the vehicle has no electrical current and truck, the towing eyelets must not be used must be towed, the power steering and...
Page 223 Towing vehicles with front wheel drive/ NOTE All Wheel Drive During towing, ignition mode II should be Volvo recommends the use of flat bed equip- used so that the lighting can be switched on. ment. • If wheel lift equipment must be used,...
Page 224 Volvo maintenance................224 Maintaining your car................225 Hood and engine compartment............227 Engine oil....................228 Fluids..................... 230 Replacing bulbs..................232 Wiper blades and washer fluid.............. 240 Battery....................242 Fuses..................... 245 Wheels and tires..................253 Vehicle care................... 274 Label information.................. 279 Specifications..................
Page 225 M A I N T E N A N C E A N D S P E C I F I C A T I O N S...
Page 226: 06 Maintenance And Specifications
To keep your Volvo in top is provided. with each other, information about your vehi- condition, specify time-tested and proven cle's operation.
Page 227: Maintaining Your Car
Corrosion may indicate a loose ter- minal connector, or a battery near the end How do states use OBD II for emission of its useful service life. Consult your Volvo inspections? retailer for additional information. Many states connect a computer directly to a If a garage jack is used to lift the vehicle, the vehicle's OBD II system.
Page 228 06 Maintenance and specifications Maintaining your car inspection has replaced the tailpipe emission way driving is typically needed to allow OBD II to reach readiness. Your Volvo test. retailer can provide you with more infor- How can my vehicle fail OBD II emission mation on planning a trip.
Page 229: Hood And Engine Compartment
06 Maintenance and specifications Hood and engine compartment Opening and closing the hood Battery WARNING Relay and fuse box Check that the hood locks properly when closed. Washer fluid reservoir Air cleaner Engine compartment, overview WARNING The cooling fan may start or continue to operate (for up to 6 minutes) after the engine has been switched off.
Page 230: Engine Oil
The car should be parked on a level sur- the oil level. The level must be between the • face when the oil is checked. Volvo does not recommend the use of MIN and MAX marks. oil additives. • If the engine is warm, wait for at least •...
Page 231 Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces. NOTE Synthetic oil is not used when the oil is changed at the normal maintenance inter- vals except at owner request and at addi- tional charge. Please consult your Volvo retailer.
Page 232: Fluids
MIN and changed. If the system must be drained, con- MAX marks. If it is not kept filled, there sult a trained and qualified Volvo service tech- can be high local temperatures in the nician.
Page 233 Check the level frequently. The fluid does not require changing. The fluid level must be Always entrust brake fluid changing to a between the MIN and MAX marks. For capaci- trained and qualified Volvo service technician. ties and recommended fluid grade, see page 285. WARNING...
Page 234: Replacing Bulbs
For information regarding any other bulbs not mentioned in this section, please con- tact your Volvo retailer or a trained and The entire headlight housing must be lifted out authorized Volvo service technician. when replacing all front bulbs (except for the fog lights).
Page 235 The headlight wiring must be connected and Volvo service technician. the housing must be securely in place before 5. Replace the defective bulb(s). the ignition is switched on.
Page 236 06 Maintenance and specifications Replacing bulbs Removing the cover to access the Low beam, Halogen High beam, Halogen headlights 1. Remove the headlight housing from the 1. Remove the headlight housing from the vehicle (see page 233). vehicle (see page 233). NOTE 2.
Page 237 06 Maintenance and specifications Replacing bulbs 8. Reconnect the wiring connector to the bulb 5. Insert a new bulb in the holder until it snaps 3. Pull out the holder to access the bulb. holder. in place. It can only be inserted in one way. 4.
Page 238 06 Maintenance and specifications Replacing bulbs 1. Remove the headlight housing from the Remove the fog light lens by pulling out the The rear fog light (located on the driver's side vehicle (see page 233). upper corner that is closest to the grille. of the vehicle) can be reached from behind the bumper 2.
Page 239 3. Remove the burned out bulb by pressing it after a faulty bulb has been replaced, con- in and turning it counterclockwise. tact an authorized Volvo workshop. 4. Insert a new bulb, press it in and turn it clockwise. Brake lights and Taillights 5.
Page 240 06 Maintenance and specifications Replacing bulbs Cargo area lighting Vanity mirror lighting 2. Press the three lower lugs back into posi- tion. Removing the mirror glass Specification, bulbs Lighting Output/volt- Bulb function age (W) Active Dual Xenon (extra high beam) Low beam (halogen) High beam...
Page 241 06 Maintenance and specifications Replacing bulbs Lighting Output/volt- Bulb function age (W) Front side marker lights Glove com- Festoon partment bulb lighting SV8.5...
Page 242: Wiper Blades And Washer Fluid
06 Maintenance and specifications Wiper blades and washer fluid Wiper blades The wipers will return to the normal position when the vehicle is started. Replacing the windshield wiper blades With the wipers in the service position, fold out the wiper arm from the windshield. Press the button on the wiper blade attach- ment and pull the wiper blade straight out, parallel with the wiper arm.
Page 243 06 Maintenance and specifications Wiper blades and washer fluid Replacing the tailgate wiper blade Filling washer fluid Location of the washer fluid reservoir 1. Fold the wiper arm outward. The windshield and headlight washers share a 2. Grasp the inner section of wiper blade (at common reservoir.
Page 244: Battery
A used battery should be disposed of in an Never expose the battery to open flame environmentally responsible manner. Con- or electric spark. sult your Volvo retailer or take the battery to • Do not smoke near the battery. a recycling station.
Page 245 06 Maintenance and specifications Battery CAUTION WARNING • Connect and disconnect the positive and Always use distilled or deionized water negative cables in the correct sequence. (battery water). • Never fill above the level mark in the cell. Removal Switch off the ignition and wait at least Changing 5 minutes before disconnecting the battery so that all information in the vehicle's electrical...
Page 246 06 Maintenance and specifications Battery 6. Connect the black negative cable. WARNING 7. Press in the rear cover. (See Removal). PROPOSITION 65 WARNING! 8. Reinstall the cold section moulding. (See Battery posts, terminals, and related acces- Removal). sories contain lead and lead compounds, chemicals known to the state of California 9.
Page 247: Fuses
(written on the fuse). If fuses burn out repeatedly, have the electrical system inspected by a trained and qualified Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the follow- ing pages.
Page 248 06 Maintenance and specifications Fuses Engine compartment...
Page 249 Moonroof*, ceiling console/ – circuit breakers and should only be ECC* removed or replaced by a trained and ABS pump qualified Volvo service technician. Engine compartment box • There is a special fuse removal tool on ABS valves Auxiliary lights* the underside of the cover.
Page 250 06 Maintenance and specifications Fuses Function Starter motor relay Ignition coils Engine Control Module (ECM), throttle Injection system Engine valves EVAP/heated oxygen sensor/ Injection Crank case ventilation heater Fuel leakage detection – Cooling fan...
Page 251 06 Maintenance and specifications Fuses Under the glove compartment 1 2 3 4 6 7 8 9 10 11 12 13 14 24 25 26 27 28 Fold aside the iupholstery covering the fuse Function Function box. Accelerator pedal, heated Moonroof* 1.
Page 252 06 Maintenance and specifications Fuses Function Overhead courtesy lighting, Control panel driver's door/ Power passenger seat* Information display Power driver's seat* Tailgate wiper Remote key receiver, Alarm sensors Fuel pump Electric steering column lock – Lock, tank/tailgate Alarm siren. ECC START/STOP ENGINE button Brake light switch Option/accessory, for more information, see Introduction.
Page 253 06 Maintenance and specifications Fuses Cargo area Located behind the upholstery on the left side of the cargo area Positions Module (black). Func- Module (black). Func- Module (black). Func- tion tion tion – Power driver's seat* Switches in driver's door 12-V socket in cargo area Trailer socket 1* Switches in passenger's door...
Page 254 06 Maintenance and specifications Fuses Module (white). Func- Module (blue). Func- tion tion Park assist, Park assist cam- Navigation system display* era* – Control module Four C* Subwoofer* Heated driver's seat* SIRIUS satellite radio* Heated passenger's seat* Audio amplifier* Rear seat heater, passenger's side* Audio system AWD control module...
Page 255: Wheels And Tires
Some Volvo models are equipped with an ristics. Ultra High Performance tire and wheel com- A tire's age can be determined by the DOT bination designed to provide maximum dry stamp on the sidewall (see the illustration).
Page 256 The tires with the most tread should always WARNING during hard braking. be at the rear (to reduce the risk of skid- • The wheel and tire sizes for your Volvo ding). • Hitting curbs or potholes can damage the are specified to meet stringent stability •...
Page 257 When Check tire inflation pressure regularly. approximately 1/16" (1.6 mm) is left on the Your Volvo retailer can also provide guidance Tables listing the recommended inflation pres- tread, these strips become visible and indicate...
Page 258 06 Maintenance and specifications Wheels and tires the vehicle's tire information placard or certifi- NOTE WARNING cation label. • • The placards shown indicate inflation Under-inflation is the most common Checking tire pressure pressure for the tires installed on the cause of tire failure and may result in vehicle at the factory only.
Page 259 06 Maintenance and specifications Wheels and tires To check inflation pressure: Tire specifications Load ratings 1. Remove the cap from the valve on one tire, Speed ratings then firmly press the tire gauge onto the 1365 lbs (615 kg) The speed ratings in the table translate as fol- valve.
Page 260 Wheels and tires Tire inflation pressure table – U.S. models The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory.
Page 261 06 Maintenance and specifications Wheels and tires Tire designations 5. 95: The tire's load index. In this example, a 7. M+S or M/S = Mud and Snow, AT = All Terrain, AS = All Season load index of 95 equals a maximum load of 1521 lbs (690 kg).
Page 262 Recommended tire inflation pressure: grades: see page 262 for more informa- load at 41 psi [43 psi (2.9 bar) for Metric inflation pressure, established by Volvo, tion. tires]. Increasing the inflation pressure which is based on the type of tires that are 12.
Page 263 06 Maintenance and specifications Wheels and tires Vehicle loading Permissible axle weight 2. Determine the combined weight of the driver and passengers that will be riding in The maximum allowable weight that can be Properly loading your vehicle will provide maxi- your vehicle.
Page 264 (straight-ahead) traction Snow chains cable, on the tire sidewall between the tread tests and is not a measure of cornering Snow chains can be used on your Volvo with (turning) traction. shoulder and maximum section width. For the following restrictions: example: •...
Page 265 300 – 600 miles (500 – 1000 km) during no circumstances should you exceed which the vehicle should be driven as Consult your Volvo retailer for additional snow 31 mph (50 km/h). smoothly as possible to give the studs the chain information.
Page 266 Spare” in use. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. CAUTION The vehicle must never be driven with more WARNING than one temporary spare wheel.
Page 267 06 Maintenance and specifications Wheels and tires After use nuts 1/2 – 1 turns by exerting downward pressure. The foam block and spare wheel must be replaced in the reverse order. Note the arrow 5. Turn the nuts counterclockwise to loosen. on the upper foam block.
Page 268 06 Maintenance and specifications Wheels and tires Tire Sealing System WARNING • The jack must correctly engage the jack attachment. • Be sure the jack is on a firm, level, non- slippery surface. • Never allow any part of your body to be extended under a vehicle supported by a jack.
Page 269 • Have the tire inspected by a trained and 2. Open the floor hatch. qualified Volvo service technician as soon as possible to determine if it can 3. Remove the retaining screws. be permanently repaired or must be 4.
Page 270 06 Maintenance and specifications Wheels and tires • • Inhalation: Move the person to fresh air. Stage 1: The hole is sealed by pumping WARNING If irritation persists, get medical atten- sealing compound into the tire. The car is Please keep the following points in mind tion.
Page 271 Once in place, the bot- compressor should not be used for more tle cannot be unscrewed. This must be done than 10 minutes at a time to avoid over- by a trained and qualified Volvo service heating. technician.
Page 272 If the pressure remains below 22 psi holder. Consult a trained and qualified (1.8 bar) after approximately seven minutes, Volvo service technician to have the turn off the compressor. In this case, the bottle removed and properly disposed WARNING hole is too large to be sealed and the vehicle should not be driven.
Page 273 12-volt socket. place, or outdoors, before using the sys- ration date has passed, please take it to tem. a Volvo retailer or a recycling station Tire Pressure Monitoring System • that can properly dispose of harmful Children should never be left unattended (TPMS)–U.S models only...
Page 274 Tire inflation pressure tables or sure, even if under-inflation has not reached If a fault occurs in TPMS, the tire pressure consult your Volvo retailer. the level to trigger illumination of the TPMS low warning light will flash for approximately tire pressure telltale.
Page 275 TPMS system must be recalibrated to these tires. This must be done by a trained and qualified Volvo service tech- Changing wheels with TPMS nician. Please note the following when changing or •...
Page 276: Vehicle Care
When washing the car, remember to remove Exterior components as soon as possible. Otherwise the finish dirt from the drain holes in the doors and Volvo recommends the use of special cleaning sills. may be permanently damaged. products, available at your Volvo retailer, for •...
Page 277 06 Maintenance and specifications Vehicle care fully. Solvents or stain removers should not be headlights, fog lights, or taillights. This is nor- CAUTION used. mal and the lights are designed to withstand • Before driving into an automatic car moisture. Normally, condensation will dissi- wash, turn off the optional rain sensor pate after the lights have been on for a short CAUTION...
Page 278 4. Dry the stain with soft paper towels or a CAUTION protection. Staining, cracking, scuffing, and towel, and allow the leather to dry com- Volvo does not recommend the use of long- fading can result. pletely. life or durable paint protection coatings,...
Page 279 06 Maintenance and specifications Vehicle care gent. For best protection in winter, Volvo rec- Paint repairs require special equipment and CAUTION ommends the use of Volvo rubber floor mats. skill. Contact your Volvo retailer for any exten- • Under no circumstances should gaso- Consult your Volvo retailer.
Page 280 06 Maintenance and specifications Vehicle care Minor scratches on the surface 4. If there is a longer scratch, you may want to protect surrounding paint by masking it If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touch-up paint can be applied as 5.
Page 281: Label Information
06 Maintenance and specifications Label information Location of labels...
Page 282: Label Information
06 Maintenance and specifications Label information List of labels Vehicle Emission Control Information. Your Volvo is designed to meet all appli- Model plate. Vehicle Identification Num- cable emission standards, as evidenced by ber (VIN). Codes for color and upholstery, the certification label on the underside of etc.
Page 283: Specifications
06 Maintenance and specifications Specifications Dimensions Dimension In. (mm) Wheelbase 109.2 (2774) Length 182.2 (4628) Load length, floor, seatback down 70.4 (1789) Load length, floor 38.3 (972) Height 67.4 (1713) Load height 31.6 (802) Track, front 64.3 (1632)
Page 284: Specifications
06 Maintenance and specifications Specifications Dimension In. (mm) Track, rear 62.4 (1586) Load width, floor 42.9 (1090) Width 74.4 (1891) Width, incl. door mirrors 84.3 (2142) Weights Category Canada Gross vehicle weight 5380 lbs 2440 kg Capacity weight 950 lbs 430 kg Permissible axle weights, front 2840 lbs...
Page 285 Displacement 2.95 liters (175 cu. in.) Compression ratio 9.3:1 Engine oil omy and engine protection. Consult your Volvo Oil viscosity retailer for recommendations on premium or Incorrect viscosity oil can shorten engine life Engine oil must meet the minimum ILSAC synthetic oils.
Page 286 06 Maintenance and specifications Specifications recommended for driving in areas of sustained The API Service Symbol "donut" is divided into temperature extremes (hot or cold), when tow- three parts: ing a trailer over long distances, and for pro- • The upper section describes the oil's per- longed driving in mountainous areas.
Page 287 Power steering fluid WSS M2C204-A2 or equivalent product. Washer fluid 6.8 US qts (6.5 liters) Use a washer antifreeze recom- mended by Volvo, mixed with 4.7 US qts (4.5 liters water. Fuel tank volume 18.5 US gallons (70 liters) Under normal driving conditions the transmission oil does not need changing during its service life. However, it may be necessary under adverse driving conditions.
Page 288 06 Maintenance and specifications Specifications Electrical system General information 12 volt system with a voltage-regulated alter- nator. Single pole system in which the chassis and engine block are used as conductors. The negative terminal is connected to the chassis. Performance, battery Engine 3.0T Voltage (V)
Page 289: Volvo Programs
06 Maintenance and specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment.
Page 290: 07 Index
07 Index 1, 2, 3 ... Approach lighting......... 52, 92 Audio system 12-volt sockets........199 Battery audio functions........136 changing........242, 243 CD player/changer...... 144, 145 maintenance........242 Digital Audio Broadcasting (DAB)..140 remote control, replacing..... 56 HD digital radio........139 specifications........
Page 291 07 Index introduction......... 232 Child restraint systems......35 Coolant..........230, 285 license plate lights......237 booster cushions........41 Cooling system, general information..203 side marker lights....... 235 convertible seats........39 Courtesy lighting........90, 91 specifications........238 infant seats........... 37 Crash mode..........32 taillight..........
Page 292 07 Index Dual Xenon headlights....... 88 specifications........283 Fuel level warning light......75 volumes..........284 Fuel requirements......206, 207 Environment..........9 Fuel tank volume........285 Eyelets for anchoring loads..... 210 Fuses....... 245, 246, 249, 251 ECC..........129, 130 Economical driving........202 Electric parking brake......
Page 293 07 Index Headlights Infant seats..........37 changing bulbs........234 Inflatable Curtain........28 Dual Xenon........... 88 Key blade..........50, 55 Inflation pressure......255, 256 high/low beams........87 Keyless drive Inflation pressure tables......258 high beam flash........87 starting the engine......106 Information lights......
Page 294 07 Index Parking lights..........88 changing bulbs........234 Main instrument panel......123 Occupant safety........12 Personal Car Communicator, unique func- Maintenance..........224 Occupant weight sensor...... 22, 23 tions............53 hoisting the vehicle......225 Octane recommendations....... 207 Polishing..........276 performed by the owner..... 225 Odometer, trip...........
Page 295 07 Index Registering child restraints......44 Seat belts Automatic locking retractor/Emergency Remote control.......... 50 Radio locking retractor........34 approach lighting........52 Sirius satellite radio.... 141, 143, 144 buckling..........14 common functions........ 52 maintenance......... 14 Radio functions........138 immobilizer........... 50 pretensioners........14 Digital Audio Broadcasting (DAB)..
Page 296 07 Index Stability system........155 tire pressure monitoring system..271 indicator light........75 tread wear indicator......255 Tailgate uniform tire quality grading....262 Starting the engine........105 driving with it open......202 with keyless drive....... 106 Top tether anchors (child restraint sys- power operated........
Page 297 Volvo Inflatable Curtain......28 Windows changing bulbs........235 power..........96, 97 Volvo maintenance........224 indicator lights........75 Windshield Volvo On Call Roadside Assistance..287 Two-stage booster cushion....... 45 rain sensor..........93 Volvo programs........287 washers..........94 wipers/washers........93 Windshield washer fluid....241, 285 Windshield wipers........

Volvo XC60 Owner's Manual

Contents

Introduction

1 Safety

2 Locks and Alarm

3 Your Driving Environment

4 Comfort and Driving Pleasure

5 During Your Trip

6 Maintenance and Specifications

7 Index

Quick Links

Need help?

Questions and answers

Related Manuals for Volvo XC60

Summary of Contents for Volvo XC60

Table of Contents
