Page 1 XC60 Owner's Manual WEB EDITION...
Page 3 Volvo, an automobile designed drive. with your safety and comfort in mind. We encour- Your Volvo is designed to meet all applicable fed- age you to familiarize yourself with the equipment eral safety and emission standards. If you have...
Page 4: Table Of Contents
Contents 00 Introduction 01 Safety 02 Locks and alarm Important information......... 6 Occupant safety........16 Remote key and key blade....... 58 Environment..........12 Reporting safety defects......17 Keyless drive..........67 Important warnings........13 Seat belts ..........18 Locks............70 Supplemental Restraint System (SRS) ..21 Alarm............
Page 5 03 Your driving environment 04 Driver support 05 Comfort and driving pleasure Instruments and controls......78 Stability system........142 Volvo Sensus.......... 198 Ignition modes.......... 88 Road sign information (RSI)* ....145 Menus and messages......199 Seats............90 Cruise control.......... 147 The MY CAR menus.......
Page 6 Contents 06 Infotainment 07 During your trip 08 Wheels and tires Introduction..........230 Driving recommendations....... 274 General information ....... 298 Radio............240 Refueling..........278 Tire inflation..........301 Media player........... 249 Loading........... 283 Inflation pressure ........303 AUX/USB sockets........254 Cargo area ..........287 Tire designations ........
Page 7 Contents 09 Maintenance and 10 Specifications 11 Index specifications Label information........366 Index............378 Volvo maintenance........328 Specifications......... 368 Maintaining your car....... 329 Overview of information and warning symbols........... 374 Hood and engine compartment....331 Volvo programs........377 Engine oil..........332 Fluids............
Page 8: Introduction
Before you operate your vehicle for the cle whose purpose is to provide important first time, please familiarize yourself with Volvo Cars of North America, LLC information in a clear and concise way. The the information found in the chapters...
Page 9 Introduction Important information Risk of damage to the vehicle Information Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual. If there is a series of illustrations associ- ated with step-by-step instructions, each step in the procedure is numbered in the...
Page 10 • Coolant or other reproductive harm. In addition, • Volvo reserves the right to make model • Engine oil certain fluids contained in vehicles and changes at any time, or to change certain products of component wear con-...
Page 11: Crash Event Data
The EDR in this vehicle is When your vehicle is parked, the gear selec- your Volvo not certifiable for legal opera- designed to record such data as: tor is locked in the P (Park) position. To tion in the U.S., Canada and other coun-...
Page 12 Volvo is responsi- Volvo has always been and continues to be a equipment, can read the information if they ble for ensuring that the information transmit- leader in automotive safety.
Page 13 License, regarding your rights under said available at www.volvocars.com. • busybox (based on version 1.13.2.) licenses. Volvo Car Corporation (VCC) offers to provide the source code of said free/open In order to read a QR code, a QR reader is GCC runtime library exception: http://...
Page 14: Environment
® trols and cleaner fuels are bringing us closer to our goal. In addition to continuous environ- Volvo is committed to the well being of its mental refinement of conventional gasoline- customers. As a natural part of this commit- powered internal combustion engines, Volvo...
Page 15: Important Warnings
Your new tested, or if you allow accessories to be your programmed presets to make radio Volvo is, or can be, equipped with many fea- installed by someone unfamiliar with your use quicker and simpler.
Page 16 Occupant safety..................16 Reporting safety defects................. 17 Seat belts ....................18 Supplemental Restraint System (SRS) ........... 21 Occupant Weight Sensor ............... 26 Side impact protection (SIPS) airbags ........... 30 Inflatable Curtain (IC) ................32 Whiplash Protection System – WHIPS........... 33 Rollover Protection System (ROPS) ............
Page 17 S A F E T Y...
Page 18: 01 Safety
If you are taking any medication, consult your vehicle, please contact your authorized your physician about its potential effects dates back to 1927 when the first Volvo rolled Volvo retailer. If your retailer is unable to on your driving abilities.
Page 19: Reporting Safety Defects
Trans- could cause injury or death, you port Canada in addition to notifying Volvo Volvo strongly recommends that if should immediately inform the Cars of Canada Corp.
Page 20: Seat Belts
The lap section of the belt must be posi- height. • if the vehicle is leaning excessively tioned low on the hips (not pressing Volvo also believes no child should sit in the • when driving in turns against the abdomen). front seat of a vehicle.
Page 21 Use water and a mild deter- work done by a trained and qualified gent for cleaning. Check seat belt mechanism Volvo service technician only. function as follows: attach the seat belt and • Any device used to induce slack into pull rapidly on the strap.
Page 22 01 Safety Seat belts Seat belt use during pregnancy Rear seats should strive to position the seat with as large a distance as possible between their belly The seat belt reminder in the rear seat has and the steering wheel. two additional functions: •...
Page 23: Supplemental Restraint System (Srs)
See also page 81 for more information about indicator and warning lights. Models with an digital instrument panel* As an enhancement to the three-point seat belts, your Volvo is equipped with a Supple- mental Restraint System (SRS). Volvo's SRS Option/accessory, for more information, see Introduction.
Page 24 (see below). This may cause airbag deployment which could result in serious injury. Have the vehicle towed to a trained and qualified Volvo service technician for repairs. Before attempting to tow the vehicle: Location of the passenger's side front airbag 1.
Page 25 SRS system, please contact a (e.g., a snow drift or bush), or a rigid, seating position, one may experience trained and qualified Volvo service technician fixed object at a low speed, the front air- abrasions, bruises, swellings, or other or Volvo customer support: bags will not necessarily deploy.
Page 26 Richmond Hill, Ontario L4B 0B9 fire. • 1-800-663-8255 Volvo's front airbags use special sen- Airbag decal on the outside of both sun visors sors that are integrated with the front www.volvocars.com/ca seat buckles. The point at which the...
Page 27 Feet must be on the floor, e.g., not on the steering wheel or the passenger's the dash, seat or out of the window. side dashboard. This should only be done by a trained and qualified Volvo service technician. • Failure to follow these instructions can result in injury to the vehicle occu- pants.
Page 28: Occupant Weight Sensor
Weight Sensor should be inspected by a of Federal Motor Vehicle Safety Standard front passenger's seat. trained and qualified Volvo service techni- (FMVSS) 208 and is designed to disable (will The OWS uses a PASSENGER AIRBAG OFF cian as soon as possible.
Page 29 Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. rear seat. Do not assume that the passenger's side front airbag is...
Page 30 OWS system. Failure to front passenger's seat. If a child is follow these instructions could Volvo Cars of North America, LLC seated in the front passenger's seat adversely affect the system's function Customer Care Center...
Page 31 01 Safety Occupant Weight Sensor WARNING • Do not place any type of object on the front passenger's seat in such a way that jamming, pressing, or squeezing occurs between the object and the front seat, other than as a direct result of the correct use of the Automatic Locking Retractor/Emergency Locking Retractor (ALR/ELR) seat belt (see...
Page 32: Side Impact Protection (Sips) Airbags
01 Safety Side impact protection (SIPS) airbags General information NOTE SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact. The airbags are not designed to deploy in all side impact situa- tions. Components in the SIPS airbag system This SIPS airbag system consists of a gas generator, the side airbag modules built into...
Page 33 Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat...
Page 34: Inflatable Curtain (Ic)
IC system. This should be restraint system. Only adults should sit in done only by a trained and qualified the front seats. Children must never be Volvo service technician. allowed in the front passenger seat, see page 39 for guidelines. Failure to follow •...
Page 35: Whiplash Protection System - Whips
Volvo service technician, support the occupant's head before moving even if the seats appear to be undam- slightly rearward.
Page 36 01 Safety Whiplash Protection System – WHIPS WARNING WARNING • Any contact between the front seat back- Boxes, suitcases, etc. wedged behind rests and the folded rear seat or a rear- the front seats could impede the func- facing child seat could impede the function tion of the WHIPS system.
Page 37: Rollover Protection System (Rops)
01 Safety Rollover Protection System (ROPS) Volvo’s Rollover Protection System utilizes the Roll Stability Control (RSC) function, which is designed to help minimize the risk of a rollover in emergency maneuvers or if a skid should occur. RSC uses a gyroscopic sensor that registers the amount of change in the lateral angle at which the vehicle is leaning.
Page 38: Crash Mode
Safety mode is a feature that is triggered if ing status should only be done by a one or more of the safety systems (e.g. front trained and qualified Volvo service or side airbags, an inflatable curtain, or one or technician.
Page 39 (pulled by another vehicle). There may be concealed damage that could make it difficult or impossible to control. The vehicle should be transported on a flatbed tow truck to a trained and qualified Volvo service technician for inspection/repairs.
Page 40: Child Safety
Volvo recommends the proper use of restraint of injuring or increasing the injury of a child. systems for all occupants including children.
Page 41: Automatic Locking Retractor
Volvo's recommendations When attaching the seat belt to a child WARNING seat: Why does Volvo believe that no child should • Do not use child safety seats or child 1. Attach the seat belt to the child seat sit in the front seat of a car? It's quite simple...
Page 42 01 Safety Child safety seat of any vehicle with a front passenger side airbag. • Drive safely! Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill out and return the registration card that comes with new child restraints.
Page 43: Child Restraint Systems
01 Safety Child restraint systems Child restraints Convertible seat Booster cushion Infant seat WARNING WARNING There are three main types of child restraint A child seat should never be used in the Always refer to the child restraint manufac- systems: infant seats, convertible seats, and front passenger seat of any vehicle with a turer's instructions for detailed information booster cushions.
Page 44 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil-...
Page 45: Infant Seats
01 Safety Infant seats Securing an infant seat with a seat WARNING belt A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated (on vehicles equipped with Occupant Weight Sensor).
Page 46 01 Safety Infant seats Pull out the shoulder section of the seat belt Ensure that the seat is securely in place 4. Pull the shoulder section of the seat belt 6. Push and pull the infant seat along the out as far as possible to activate the seat belt path to ensure that it is held belt's automatic locking function.
Page 47: Convertible Seats
• A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
Page 48 01 Safety Convertible seats this time and is normal. The seat belt should now be locked in place. Fasten the seat belt Ensure that the seat is securely in place 3. Fasten the seat belt by inserting the latch WARNING plate into the buckle (lock) until a distinct Pull out the shoulder section of the seat belt click is audible.
Page 49: Booster Cushions
01 Safety Booster cushions Securing a booster cushion Positioning the seat belt Position the child correctly on the booster cush- 4. Ensure that the seat belt is pulled taut and fits snugly around the child. Booster cushions are recommended for chil- WARNING dren who have outgrown convertible seats.
Page 50: Isofix/Latch Lower Anchors
4. Firmly tension the lower child seat straps according to the manufacturer's instruc- tions. WARNING Volvo's ISOFIX/LATCH anchors conform to FMVSS/CMVSS standards. Always refer to the child restraint system's manual for weight and size ratings. Fasten the attachment correctly to the ISOFIX/...
Page 51 01 Safety ISOFIX/LATCH lower anchors WARNING • Be sure to fasten the attachment cor- rectly to the anchor (see the illustra- tion). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a collision.
Page 52: Top Tether Anchors
• Child restraint anchorages are designed to withstand only those Your Volvo is equipped with child restraint loads imposed by correctly fitted child top tether anchorages in the rear seat. They restraints. Under no circumstances are are located on the rear side of the backrests.
Page 53: Integrated Booster Cushion
Volvo's optional integrated booster cushions the child's neck. If using a booster cushion are located in the outboard seating positions. does not result in proper positioning of the...
Page 54: Integrated Booster Cushion
01 Safety Integrated booster cushion* • That the seat belt is properly positioned and is taut. • The shoulder section of the seat belt is across the child's collarbone, not over the neck. • The lap section of the seat belt is across the child's hips and not the abdomen.
Page 55 This work should be per- formed by a trained and qualified Volvo service technician only. The booster cushion can be folded down completely (stowed) from either the stage 1 or stage 2 positions.
Page 56: Child Safety Locks
01 Safety Child safety locks Child safety locks Power child safety locks and the indicator light in the button will illu- disengaging rear door windows* minate when the function is activated. When the child safety locks are activated: • The rear door windows can only be opened from the driver's door control panel •...
Page 57 01 Safety...
Page 58 Remote key and key blade..............58 Keyless drive................... 67 Locks....................... 70 Alarm....................... 73...
Page 59 L O C K S A N D A L A R M...
Page 60: 02 Locks And Alarm
If either of the remote keys is lost, the other The PCCs have enhanced functionality com- • on the Volvo website at should be taken with the car to a Volvo pared with the standard remote key. http://www.volvocars.com/us/keys retailer. As an anti-theft measure, the code of •...
Page 61 02 Locks and alarm Remote key and key blade Key memory: door mirrors and driver's Confirmation when locking/unlocking FCC ID:KR55WK49266 + Siemens VDO 5WK49233 seat the vehicle The position of the side door mirrors, power Settings can be made in the menu system for FCC ID:KR55WK49233 driver's seat* and the selected instrument audible and visual confirmation when the...
Page 62 The vehicle cannot you misplace a key, take the other keys to a be started if the transponder is damaged. trained and qualified Volvo service technician The remote key's range is normally for reprogramming as an anti-theft measure.
Page 63 02 Locks and alarm Remote key and key blade Remote key/Personal Car After a short pause, press the Unlock button Communicator (PCC)* - common a second time within 10 seconds to unlock functions the other doors and the tailgate. This function can be changed so that all doors unlock at the same time by pressing My Car and going to Settings...
Page 64 02 Locks and alarm Remote key and key blade Unique functions—PCC* NOTE NOTE As an added safety precaution, the parking Buildings or other obstacles may interfere lights will come on automatically for a with the function of the remote key. The short period when the tailgate has been vehicle can also be locked or unlocked opened.
Page 65 5 minutes tion to the vehicle, contact an authorized If more than one PCC is used to lock/unlock Volvo service technician. ago. the vehicle, only the one used most recently will show the correct locking status.
Page 66 02 Locks and alarm Remote key and key blade Detachable key blade Reinserting the key blade in the remote "Removing the key blade" on page 64 for instructions). The key blade can be removed from the 1. Hold the remote key with the slot for the remote key.
Page 67 02 Locks and alarm Remote key and key blade key/PCC is pressed within approximately Replacing the batteries 60 ft (20 m) from the vehicle. CAUTION When handling batteries, avoid touching their contact surfaces as this could result in poor battery function in the remote key. Note the position of the battery's (+) or (–) sides.
Page 68 02 Locks and alarm Remote key and key blade 3. Carefully slide the key blade into its groove. 4. Gently press the key blade in the groove until it clicks into place. Old batteries should be properly recycled.
Page 69: Keyless Drive
02 Locks and alarm Keyless drive Keyless drive* (models with Personal See page 201 for a description of the menu NOTE Car Communicator only) system. • The gear selector must in the P posi- Unlocking the vehicle with the key tion before the vehicle can be locked Keyless locking and unlocking and the alarm can be armed.
Page 70 02 Locks and alarm Keyless drive • Locking the vehicle position of the driver's seat and door mir- A door has been opened and closed rors will be stored in the seat's memory. • The PCC has been inserted in the ignition •...
Page 71 02 Locks and alarm Keyless drive Location of the keyless drive CAUTION WARNING antennas Changes or modifications not expressly People with implanted pacemakers should approved by the manufacturer could void the not allow the pacemaker to come closer user's authority to operate the equipment. than 9 inches (22 cm) to any of the keyless drive system's antennas.
Page 72: Locks
02 Locks and alarm Locks Locking and unlocking the vehicle Locking unlocked with the detachable key blade. See • page 64. Press the lock button after the front From outside the vehicle doors have been closed. From inside the vehicle (central locking The remote key locks and unlocks all of the •...
Page 73 02 Locks and alarm Locks Automatic relocking Unlocking the tailgate with the remote The glove compartment can only be locked and unlocked using the detachable key blade If the doors are unlocked, the locks will auto- in the remote key. See page 64 for informa- matically reengage (re-lock) and the alarm will –...
Page 74 02 Locks and alarm Locks Unlocking the tailgate from the driver's The alarm indicator on the dashboard will CAUTION begin flashing to show that the vehicle is seat • When pressing the rubberized plate, locked and that the alarm has been armed. only light pressure is necessary to Opening the tailgate manually release the tailgate's electronic locking...
Page 75: Alarm
(2) this device must accept any slot and the ignition is put in mode I: the tem. Contact a trained and qualified Volvo interference, including interference that may alarm has been triggered.
Page 76 02 Locks and alarm Alarm Disarming the alarm Remote key not functioning If the remote key is not functioning properly, – Press the Unlock button on the remote the alarm can be turned off and the vehicle key. can be started as follows: >...
Page 77 02 Locks and alarm...
Page 78 Instruments and controls................ 78 Ignition modes..................88 Seats....................... 90 Steering wheel..................97 Lighting....................99 Wipers and washers................107 Windows....................110 Mirrors....................112 Digial compass*..................115 Laminated panoramic roof*..............117 ® HomeLink Wireless Control System*..........120 Starting the engine................123 Transmission..................128 Eco Guide* and Power Meter*..............
Page 79 Y O U R D R I V I N G E N V I R O N M E N T...
Page 80: 03 Your Driving Environment
03 Your driving environment Instruments and controls Instrument overview...
Page 81 03 Your driving environment Instruments and controls Function Page Function Page Function Page Controls for menus and 201, In-door control panels 110, Lighting panel, buttons messages, turn signals, 104, (power windows, mirrors, 112, 70, for opening fuel filler 280, 71 high/low beams, trip 99, 216 central locking button,...
Page 82 03 Your driving environment Instruments and controls Gauges and indicators: analog Gauges and indicators: digital instrument panel instrument panel* Different themes (display alternatives) can be selected for the digital instrument panel: • Elegance • • Performance To change themes, press the OK button on the left steering wheel lever and use the thumb wheel to scroll to Themes...
Page 83 03 Your driving environment Instruments and controls See also 216 and 278 for additional Tachometer (engine speed in thousands Power Meter (see page 132). information. of revolutions per minute (rpm)) Gear indicator: Shows the currently Coolant temperature gauge Gear indicator: Shows the currently selected gear selected gear Speedometer...
Page 84 If the engine does not start or if the function panel trained and qualified Volvo service technician check is carried out in ignition mode II, all as soon as possible. High beam indicator...
Page 85 The message can be should be driven to a trained and qualified erased and the symbol can be turned off by Warning symbols Volvo service technician for inspection, see pressing the OK button (see page 199 for page 134 for additional information. Symbol...
Page 86 MIN, the vehicle should be transpor- Low oil pressure 6 seconds if the driver has not fastened his or ted to an authorized Volvo workshop to have If the light comes on while driving, stop the her seat belt.
Page 87 199. The warning symbol can also driven, with great care, to an authorized come on in conjunction with other symbols. ing symbol illuminates, a graphic will be dis- Volvo workshop to have the brake system played in instrument panel and an explana- Action: checked.
Page 88 03 Your driving environment Instruments and controls Ambient temperature sensor The trip odometers are used to NOTE measure short distances. The distance is When the ambient temperature is between shown in the display. 23° and 36 °F (–5° and +2 °C), a snowflake symbol will be displayed next to the tem- Turn the thumb wheel on the left steering perature.
Page 89 03 Your driving environment Instruments and controls Clock the 24-hour format or the 12-hour format (AM/PM). 1. Go to Settings System options Clock, digital instrument panel* Time. Display 2. The hour box will be selected. Press OK to activate this box. Setting the clock 3.
Page 90: Ignition Modes
03 Your driving environment Ignition modes Inserting and removing the remote Removing the remote key Mode Function The remote key can be removed from the ignition slot by pulling it out. The odometer, clock and tem- perature gauge are illuminated. Power seats* can be adjusted Functions and the infotainment system can...
Page 91 03 Your driving environment Ignition modes Ignition modes Emergency towing See page 294 for important information Ignition mode 0 about the remote key when the vehicle is – The vehicle is unlocked. being towed. Ignition mode I – With the remote key fully pressed into the , press START/STOP ignition slot ENGINE briefly.
Page 92: Seats
03 Your driving environment Seats Front seats The front passenger seat backrest can be WARNING folded to a horizontal position to make room • Do not adjust the seat while driving. for a long load. Fold the backrest as follows: The seat should be adjusted so that Move the seat as far back and down as the brake pedal can be depressed...
Page 93 03 Your driving environment Seats Button for storing a position Power seat NOTE • M (memory) button Only one of the power seat's controls can be used at the same time. Programming the seat's memory • The power seats have an overload Three different seating and door mirror posi- protector that activates if a seat is tions can be stored in the driver seat's mem-...
Page 94 03 Your driving environment Seats 1. Insert a remote key in the ignition slot. > The positions of the power driver's NOTE seat and door mirrors are now stored 2. Go into the MY CAR menu and go to As a safety precaution, the seat will stop in the remote key's memory.
Page 95 03 Your driving environment Seats Heated seats* NOTE See page 211. • The seat will move to this position even if someone else has moved it to a Rear seats different position and locked the vehi- cle with a different remote key. Rear center head restraint •...
Page 96 03 Your driving environment Seats Automatically folding down the rear WARNING NOTE seat’s outboard head restraints • The center rear seat head restraint should The head restraint must be returned to only be in its lowest position when this the upright position manually. seat is NOT occupied.
Page 97 03 Your driving environment Seats ered. The outboard head restraints fold CAUTION CAUTION down automatically. The rear head restraints should not be To help avoid damage to the upholstery, Pull up the backrest release control on kept folded down for prolonged periods. there should be no objects on the rear seat This could result in pressure marks in and the seat belt should not be buckled...
Page 98 03 Your driving environment Seats WARNING • When one or more sections of the backrest is returned to the upright position, check that it is properly locked in place by pushing and pulling it. The red indicators should also not be visible.
Page 99: Steering Wheel
03 Your driving environment Steering wheel Adjusting Horn WARNING Never adjust the steering wheel while driv- ing. With the optional speed-dependent power steering the level of steering force can be adjusted, see page 223. Keypads and steering wheel paddles* Adjusting the steering wheel Horn Lever for releasing/locking the steering –...
Page 100 03 Your driving environment Steering wheel Electrically heated* steering wheel Button for steering wheel heating With the ignition in at least mode I (see page 89 for information about the ignition modes), press this button once to begin warming the steering wheel (press again to switch off).
Page 101: Lighting
In Canada: the daytime running lights will Rear fog lights (see page 103) be on Headlight switch With the headlight switch in the Volvo recommends using the posi- position: tion whenever possible. • The daytime running lights will be on (the...
Page 102 03 Your driving environment Lighting • High/low beam headlights Pull the lever toward the steering wheel to position 2 and release it to toggle between low and high beams. High beam flash Pull the lever toward the steering wheel to position 1.
Page 103 03 Your driving environment Lighting Models with an analog instrument panel CAUTION symbol will go out when these mes- In the following situations, it may be nec- When AHB is activated, the symbol sages are displayed. essary to switch between high and low will illuminate in the instrument panel.
Page 104 The factory default setting is on. The auxiliary lights must be connected to the vehicle's electrical system, which should only be done by a trained and authorized Volvo service technician. See page 201 for more information about the menu system.
Page 105 03 Your driving environment Lighting Canadian models: If the ignition is in position The intensity of the instrument lighting is The rear fog lights will only function in combi- adjusted with the thumb wheel. II or the engine is running, the daytime run- nation with the high/low beam headlights.
Page 106 03 Your driving environment Lighting Hazard warning flashers Turn signals NOTE • This automatic flashing sequence can be interrupted by immediately moving the lever in the opposite direction. • If the turn signal indicator flashes faster than normal, check for a burned-out turn signal bulb.
Page 107 03 Your driving environment Lighting The lighting in the front part of the passenger The lights are switched on or off by pressing The passenger compartment lighting can be compartment is controlled with the buttons each respective button. switched on and off manually within (1) and (2) in the roof console.
Page 108 03 Your driving environment Lighting Car settings Light settings Home safe light duration. See page 201 for a descrip- tion of the menu system. Approach lighting Approach lighting is activated by pressing the approach light button on the remote key (see the illustration on page 61).
Page 109: Wipers And Washers
03 Your driving environment Wipers and washers Windshield wipers/washers Windshield wipers off Rain sensor* Move the lever to position 0 to The rain sensor automatically regulates wiper switch off the windshield wipers. speed according to the amount of water on the windshield.
Page 110 03 Your driving environment Wipers and washers Deactivating Move the lever toward the steering wheel to CAUTION start the windshield and headlight washers. Deactivate the rain sensor by pressing the • Use ample washer fluid when washing After the lever is released the wipers make button or press the lever down to the windshield.
Page 111 If the tailgate wiper is in the normal (continu- ous) wiping mode, selecting different gears will not affect its function. Consult your Volvo retailer if you would like to have this function deactivated.
Page 112: Windows
03 Your driving environment Windows Power windows All power windows can be operated using the WARNING control panel in the driver's door. The control • Always remove the ignition key when panels in the other doors only operate the the vehicle is unattended to put the window in the respective doors.
Page 113 03 Your driving environment Windows Resetting If the battery has been disconnected, the auto open function must be reset so that it will work properly. 1. Gently raise the front section of the but- ton to close the window and hold it for one second.
Page 114: Mirrors
03 Your driving environment Mirrors Power door mirrors Retractable power door mirrors* the vehicle, for example when parallel park- ing. The mirrors can be retracted for parking/driv- ing in narrow spaces: To activate this function, select reverse gear and press the L or R mirror control button to 1.
Page 115 03 Your driving environment Mirrors Automatically tilting the door mirrors to the neutral position for electric retracting/ Press button (1) to defrost/de-ice the wind- extending to work. shield and/or button (2) to defrost the rear when parking window and door mirrors. The indicator lights The door mirrors can tilt down automatically •...
Page 116 03 Your driving environment Mirrors NOTE Obstructing the forward sensor with e.g., parking stickers, transponders, etc., or the rear sensor by loading the cargo compart- ment or the rear seat in such a way that light is prevented from reaching the sensor will reduce the auto-dim function in the interior rearview mirror and optional auto- dim function in the door mirrors.
Page 117: Digial Compass
03 Your driving environment Digial compass* Operation brated if the vehicle is driven into a new one 5. Press the button repeatedly until the (see the magnetic zones on the map in the number of the desired magnetic zone following section "Selecting a magnetic 1-15 ) is displayed.
Page 118 03 Your driving environment Digial compass* Selecting a magnetic zone Magnetic zones. The earth is divided into 15 magnetic zones. The correct zone must be selected for the compass to work correctly. 1. Put the ignition in mode II. 2. Using a pen or similar object, press and hold the button on the rear side of mirror for at least 3 seconds.
Page 119: Laminated Panoramic Roof
03 Your driving environment Laminated panoramic roof* Introduction Operation Both the laminated panoramic roof and the sun shade are operated by the controls in the The laminated panoramic roof is divided into ceiling console, near the rear-view mirror. The two sections. vehicle's ignition must be in mode I or II •...
Page 120 03 Your driving environment Laminated panoramic roof* Quick open/close Perform this procedure in reverse order to WARNING close the laminated panoramic roof and/or The laminated panoramic roof and the sun • During manual closing, if the laminated sun shade. shade can be opened/closed at the same panoramic roof is obstructed, immedi- time: ately open it again.
Page 121 03 Your driving environment Laminated panoramic roof* Tilt position laminated panoramic roof or sun shade will stop and reverse automatically approximately 2 in. (5 cm) from the point at which it was blocked (or will open fully to the tilt position). The auto-stop feature also functions when the laminated panoramic roof or sun shade is being opened.
Page 122: Homelink ® Wireless Control System
03 Your driving environment HomeLink ® Wireless Control System* Introduction Programming HomeLink WARNING • If you use HomeLink to open a garage NOTE door or gate, be sure no one is near the gate or door while it is in motion. Some vehicles may require the ignition to be switched on or be in the “accessories”...
Page 123 03 Your driving environment HomeLink ® Wireless Control System* 4. At the garage door opener receiver If you live in Canada or you are having diffi- NOTE (motor-head unit) in the garage, locate culties programming a gate operator or Some devices may require you to replace the “learn”...
Page 124 03 Your driving environment HomeLink ® Wireless Control System* Reprogramming a Single HomeLink NOTE NOTE Button If the ignition is switched off, HomeLink The transmitter has been tested and com- To program a device to HomeLink using a will function for 30 minutes after the driv- plies with FCC and IC rules.
Page 125: Starting The Engine
3 minutes these pedals is not impeded. before trying to start it again to give the • Volvo's floor mats are specially manu- battery time to recover its starting factured for your car. They must be capacity.
Page 126 03 Your driving environment Starting the engine WARNING NOTE CAUTION • • • Always remove the remote key from After a cold start, idle speed may be When starting in cold weather, the the ignition slot when leaving the vehi- noticeably higher than normal for a automatic transmission may shift up at cle and ensure that the ignition in...
Page 127 03 Your driving environment Starting the engine Engine Remote Start (ERS)* Information WARNING Introduction Keep the following in mind before using Approach lighting ERS is a feature that makes it possible to Starting the engine remotely start the engine to cool or heat the •...
Page 128 03 Your driving environment Starting the engine Switching off the engine Models with a Personal Car Switching off an engine started with Communicator (PCC) remote key* (see With the engine running, press the START/ page 62) Any of the following will switch off the engine STOP ENGINE button.
Page 129 03 Your driving environment Starting the engine jump starting instructions provided for the WARNING WARNING other vehicle. • PROPOSITION 65 WARNING! Do not connect the jumper cable to To jump start your vehicle: any part of the fuel system or to any Battery posts, terminals, and related moving parts.
Page 130: Transmission
03 Your driving environment Transmission Automatic transmission Hill Start Assist (HSA) HSA makes it easier to start or back up on a hill by retaining pressure on the brake pedal for several seconds after the pedal has been released in order to keep the vehicle at a standstill.
Page 131 03 Your driving environment Transmission • Neutral: position N Gear shift indicator* If you hold the gear selector toward "–", the transmission will downshift one gear No gear is engaged and the engine can be at a time and will utilize the braking power started with the gear selector in this position.
Page 132 03 Your driving environment Transmission Geartronic: starting on slippery Geartronic: Sport mode (S) surfaces This transmission mode provides sportier shifting characteristics and enables a more Selecting 3rd gear in Geartronic’s manual active driving style by making it possible to shifting mode can help provide better traction drive at higher rpm in each gear before shift- when starting off on slippery surfaces.
Page 133 Volvo service techni- cian. Your Volvo can be equipped with permanent If the vehicle cannot be driven, for example All Wheel Drive, which means that power is because of a dead battery, the gear selector...
Page 134: Eco Guide* And Power Meter
03 Your driving environment Eco Guide* and Power Meter* Introduction Power Meter Current (instantaneous) reading This is the current level of economical driving; These gauges help improve driving economy. This gauge indicates the engine power that the higher the reading, the more economically has been utilized and the amount of power To display or remove these functions from the the vehicle is being driven.
Page 135 03 Your driving environment Eco Guide* and Power Meter* higher the reading on the scale, the greater the amount of power that is being utilized. The larger the gap between the two indica- tors, the greater the amount of power remain- ing.
Page 136: Brakes
DO NOT DRIVE. Have the vehicle towed to a activated. This function causes an additional trained and qualified Volvo service techni- taillight on each side of the vehicle to illumi- cian and have the brake system inspected.
Page 137 03 Your driving environment Brakes The adaptive brake lights activate if: pedal is depressed. To avoid such a delay cle first reaches a speed of approximately when the brakes are needed, depress the 6 mph (10 km/h). The brake pedal will pulsate •...
Page 138 MIN mark in the reservoir or if a brake sys- tem-related message is shown in the infor- mation display: DO NOT DRIVE. Have the vehicle towed to a trained and qualified Volvo service technician and have the brake system inspected.
Page 139: Parking Brake
03 Your driving environment Parking brake Electric parking brake Applying the electric parking brake NOTE An electric parking brake has the same func- • In an emergency the parking brake can tion as a manual parking brake. be applied when the vehicle is moving by holding in the control.
Page 140 03 Your driving environment Parking brake Releasing the electric parking brake the passenger compartment on vehicles parking brake will release when the vehi with the optional keyless drive). cle begins to move. Heavy load uphill 3. Press firmly on the brake pedal. A heavy load, such as a trailer, can cause the 4.
Page 141 A fault is preventing the parking brake from being released. Try to apply the parking brake and release it sev- fully released eral times. If the problem persists, contact an authorized Volvo workshop. If you drive off with this error mes- sage showing, a warning signal sounds.
Page 142 Stability system..................142 Road sign information (RSI)* ..............145 Cruise control..................147 Adaptive Cruise Control (ACC)*............149 Distance Alert* ..................160 City Safety™ ..................163 Collision warning with Full Auto-brake and Pedestrian Detection*..169 Driver Alert System* ................177 Park assist*................... 183 Rear Park Assist Camera (PAC)* ............
Page 143 D R I V E R S U P P O R T...
Page 144: 04 Driver Support
Trailer Stability Assist helps stabilize a vehicle To switch to Sport mode: that is towing a trailer when the vehicle and This is one of DSTC's permanent functions and cannot be switched off. Included when a Volvo trailer hitch is installed...
Page 145 • Stop the vehicle in a safe place, turn off the engine and restart it. • If the message is still displayed when the engine has restarted, drive to an authorized Volvo work- shop to have the system inspected. "Message"...
Page 146 04 Driver support Stability system WARNING The stability system is intended to help improve driving safety. It supplements, but can never replace, the driver's judgment and responsibility when operating the vehi- cle. Speed and driving style should always be adapted to traffic and road conditions.
Page 147: Road Sign Information (Rsi)
04 Driver support Road sign information (RSI)* Introduction Operation Displaying the speed limit indication can be deactivated. To do so: • Deselect the alternative in MY CAR Settings Car settings Road Sign Information or cancel by pressing EXIT. Speed alert The driver can opt to be alerted if the vehicle exceeds the posted speed limit by more than 3 mph (5 km/h).
Page 148 04 Driver support Road sign information (RSI)* • Twisted or damaged signs • Obstructed signs • Signs that are partially covered by snow, ice, etc. Option/accessory, for more information, see Introduction.
Page 149: Cruise Control
04 Driver support Cruise control Operation Engaging the cruise control function Adjusting the set speed Before a speed can be set, the cruise control After a speed has been set, it can be system must be engaged (put in standby increased or decreased by using the mode).
Page 150 04 Driver support Cruise control Automatic deactivation WARNING Cruise control is automatically deactivated There may be a significant increase in temporarily if one of the following occurs: speed after the button has been • If the speed drops below approximately pressed.
Page 151: Adaptive Cruise Control (Acc)
When there are no longer Radar sensor in front grille only be performed by a trained and slower moving vehicles ahead, your vehi- qualified Volvo technician. Adaptive Cruise Control consists of: cle will accelerate to resume the set •...
Page 152 04 Driver support Adaptive Cruise Control (ACC)* 2-second interval will vary according the adaptive cruise control system. This is nor- driver will then have to maintain a safe dis- speed of the vehicles. mal. tance to the vehicle ahead. WARNING WARNING WARNING •...
Page 153 04 Driver support Adaptive Cruise Control (ACC)* Operation Putting ACC in standby mode WARNING Before ACC can be used to regulate speed Adaptive Cruise Control only warns of and/or the distance to a vehicle ahead, it vehicles detected by the radar sensor, see must first be put in standby mode.
Page 154 04 Driver support Adaptive Cruise Control (ACC)* pedal, the vehicle's speed when the but- When this symbol has changed col- Different time intervals can ton is pressed will be set. ors from white to green, ACC is in be selected and are shown in active mode and the vehicle will •...
Page 155 04 Driver support Adaptive Cruise Control (ACC)* • Standby mode (temporary deactivation) brake temperature is high NOTE To temporarily deactivate ACC (put it in • the radar sensor is obstructed by, for If the accelerator pedal is only depressed standby mode): example, wet snow or rain.
Page 156 04 Driver support Adaptive Cruise Control (ACC)* moving at speed below 18 mph WARNING WARNING (30 km/h)) Please be aware that this function will also Switching from ACC to CC means that: • Automatic standby mode when ACC cause the vehicle to accelerate briefly in •...
Page 157 04 Driver support Adaptive Cruise Control (ACC)* • The vehicle ahead must be within a rea- NOTE WARNING sonable distance (not farther away than ACC can remain active and keep your At speeds above 18 mph (30 km/h), ACC approx. 100 ft/30 meters) vehicle at a standstill for up to 4 minutes.
Page 158 WARNING The parking brake is applied sensor may be damaged in any way, contact a trained and qualified Volvo • automatically The radar sensor has a limited field of service technician as soon as possible.
Page 159 In certain situations, the radar sensor Fault tracing and actions only be performed by a trained and cannot detect vehicles at close quarters, qualified Volvo technician. Radar blocked See manual If the message for example a vehicle that suddenly is displayed, this means that the radar signals...
Page 160 04 Driver support Adaptive Cruise Control (ACC)* System with Auto-brake and Pedestrian The table lists possible causes for this mes- Detection will not function. sage being displayed, and suitable actions. Cause Action The surface of the radar in the grille is dirty or obstructed in some Clean the radar surface, or remove the object causing the obstruction.
Page 161 Cruise control Service ACC is not functioning. required Contact a trained and qualified Volvo service technician. Press Brake To hold The vehicle is at a standstill and ACC will release the brakes before the parking brake engages to keep the vehicle stopped but a problem with the parking brake means that the vehicle may begin to roll.
Page 162: Distance Alert
04 Driver support Distance Alert* Introduction Depending on the optional equipment NOTE selected, there may not be room for a Dis- Distance Alert is part of Adaptive Cruise Con- Distance Alert only monitors distance to tance Alert button in the center console. In trol and is a function that provides informa- the vehicle ahead while Adaptive Cruise this case, the function is controlled through...
Page 163 04 Driver support Distance Alert* Five different time intervals WARNING NOTE can be selected and are Only use a time interval that is suitable in Strong sunlight, reflections, extreme light shown in the display as 1–5 current traffic conditions. contrasts, the use of sunglasses, or if the horizontal bars.
Page 164 See page 156 for information on the radar sensor’s limitations. Collision warn. Serv- Distance Alert or Collision Warning with Full Auto-brake and Pedestrian Detection is not functioning prop- ice required erly. Contact a trained and qualified Volvo service technician. Option/accessory, for more information, see Introduction.
Page 165: City Safety
This is done in order to always give the driver’s actions highest priority. City Safety is a registered trademark of the Volvo Car Corporation...
Page 166 04 Driver support City Safety™ Function tion display to indicate that the system is/has WARNING been active. • City Safety™ only reacts to vehicles traveling in the same direction as your NOTE vehicle and does not react to small • vehicles or motorcycles or to people or When City Safety™...
Page 167: Troubleshooting
04 Driver support City Safety™ Press My Car in the center console control WARNING NOTE Settings Car settings panel and go to • The laser sensor has certain limitations Keep the windshield in front of the Driver support systems City Safety.
Page 168 (magnifiers) – Class • Before the windshield is replaced, 1M laser product. contact a Volvo retailer to ensure that The lower decal describes the laser beam's the correct windshield is ordered and physical data and contains the text: installed.
Page 169 NOTE Volvo service technician. The function of aftermarket laser detectors • Do not remove the laser sensor may be affected by City Safety's laser sen- (including removal of the lenses).
Page 170 Remove the obstruction and/or clean the windshield in front of the sensor(s). For more information on the sensor’s limitations, see page 165. City Safety Service City Safety™ is not functioning. required • If this message remains in the display, have the system checked by a trained and qualified Volvo service technician.
Page 171: Collision Warning With Full Auto-Brake And Pedestrian Detection
04 Driver support Collision warning with Full Auto-brake and Pedestrian Detection* Introduction The system should not be used in such a way WARNING that the driver changes his/her way of operat- Collision Warning with Full Auto-brake and • Collision Warning does not work in all ing the vehicle.
Page 172 Volvo technician. same direction as your vehicle. If there is a NOTE risk of collision with a vehicle or a pedestrian,...
Page 173 04 Driver support Collision warning with Full Auto-brake and Pedestrian Detection* Operation Activating/deactivating the audible WARNING warning signal only Settings are made by pressing MY CAR on • Short The setting should only be used The audible warning signal can be activated/ the center console control panel and using in situations where traffic is light and deactivated by pressing MY CAR on the cen-...
Page 174 04 Driver support Collision warning with Full Auto-brake and Pedestrian Detection* Limitations Settings console control panel and going to WARNING Car settings Driver support systems Strong sunlight, reflections, extreme light • In certain situations, the system can- contrasts, the use of sunglasses, or if the Collision Warning.
Page 175 04 Driver support Collision warning with Full Auto-brake and Pedestrian Detection* The camera’s limitations NOTE WARNING The camera is used by Collision Warning with • If warnings are given too frequently, the The camera has the same limitations Auto-brake, Driver Alert Control (see warning distance can be reduced (see as the human eye.
Page 176 04 Driver support Collision warning with Full Auto-brake and Pedestrian Detection* Fault tracing and actions Pedestrians The following conditions apply: Windscreen Sensors • If the message In order to detect a pedestrian, the sys- blocked is displayed, this means that the tem must have a full view of the person's camera is obscured and cannot detect entire body and the person must be at...
Page 177 Wait a short time. It may take several minutes for the camera to regis- display. ter visibility. The surface between the inside of the windshield and the camera is Contact an authorized Volvo retailer or service technician to have this dirty. surface cleaned. Symbols and messages in the display...
Page 178 156 for more information on the radar sensor’s limitations. Collision warn. Collision Warning and Auto-brake are partially or completely not functioning. Service required Contact a trained and qualified Volvo service technician if the message remains in the display. Option/accessory, for more information, see Introduction.
Page 179: Driver Alert System
04 Driver support Driver Alert System* Introduction Driver Alert Control (DAC)– DAC is designed to help detect a slowly introduction changing driving pattern. It is primarily The Driver Alert System is designed to help a intended to be used on main roads and is not driver who may be becoming fatigued or who meant for use in city traffic.
Page 180 04 Driver support Driver Alert System* Operating DAC 201 for more information on the menu sys- If the vehicle is being driven errati- tem. cally, the driver will be alerted by an audible signal and the message On/Off Driver Alert Time for a break To put Driver Alert in standby mode: displayed.
Page 181 See page 173 for information on the camera’s limitations. Driver Alert Sys Service The system is not functioning. Contact a trained and qualified Volvo service technician if the message required remains in the display.
Page 182 04 Driver support Driver Alert System* Lane Departure Warning (LDW)– Operation and function introduction LDW displayed in the instrument panel • The LDW symbol has white side marker LDW can be switched on or off by pressing lines: the function is active and "sees" This function is designed to help reduce the the button on the center console.
Page 183 04 Driver support Driver Alert System* Settings WARNING Settings for Lane Departure Warning can be The driver will only be warned once for made in the menu system by pressing My each time the wheels cross a marker line. Car. Go to Settings Car settings No alarm will be given if a marker line is...
Page 184 See page 173 for information on the camera’s limi- tations. Driver Alert Sys Service The system is not functioning. Contact a trained and qualified Volvo service technician if the required message remains in the display.
Page 185: Park Assist
04 Driver support Park assist* Introduction Function Activating/deactivating The system is activated automatically when The park assist system is designed to assist the vehicle is started. you when driving into parking spaces, garages, etc. It utilizes ultrasound sensors in – Press the Park assist button on the center the front bumper and rear bumper(s) to meas- console to temporarily deactivate the sys-...
Page 186 04 Driver support Park assist* Signals from the park assist system Audible signal Rear park assist The Park Assist system uses an intermittent tone that pulses faster as you come close to an object, and becomes constant when you are within approximately 1 ft (30 cm) of an object in front of or behind the vehicle.
Page 187 If a non- the system is not functioning properly and Volvo trailer hitch is being used, it may has been disengaged. Consult a trained and be necessary to switch off the system qualified Volvo service technician.
Page 188 04 Driver support Park assist* Cleaning the sensors with water and a suitable car washing deter- gent. Ice and snow covering the sensors may cause incorrect warning signals. NOTE If the sensors are obstructed by e.g., dirt, snow, or ice, this could result in false warning signals from the park assist sys- tem.
Page 189: Rear Park Assist Camera (Pac)
04 Driver support Rear Park Assist Camera (PAC)* Introduction Function Ambient lighting conditions The camera automatically monitors the ambi- The Park Assist Camera uses the display in ent lighting conditions behind the vehicle and the center console to show the area behind constantly adjusts sensitivity to light.
Page 190 R position 201 for a description of the menu system. or until the vehicle reaches a forward speed If the Volvo Navigation System (VNS) is in of 6 mph (10 km/h). The screen will then NOTE...
Page 191 04 Driver support Rear Park Assist Camera (PAC)* The dashed line (2) indicates the clear zone of markers in the display indicate which of the WARNING approximately 5 feet (1.5 m) behind the sensor(s) has detected the object. Keep in mind that the image on the screen bumper.
Page 192 04 Driver support Rear Park Assist Camera (PAC)* changed in the MY CAR menu) and the vated when the gear selector is moved to image is shown on the center console R. This setting can be changed in the MY CAR menu.
Page 193: Blind Spot Information System (Blis)
04 Driver support Blind Spot Information System (BLIS)* Introduction WARNING BLIS is an information system that indicates • BLIS and CTA are information sys- the presence of another vehicle moving in the tems, NOT warning or safety systems same direction as your vehicle on roads with and do not function in all situations.
Page 194 04 Driver support Blind Spot Information System (BLIS)* Activating/deactivating BLIS To erase the message: When BLIS detects a vehicle in zone 1 or a passing vehicle in zone 2, the indicator light in • Press the OK button on the left steering the door panel will glow steadily.
Page 195 04 Driver support Blind Spot Information System (BLIS)* When does CTA function your vehicle the approaching vehicle/ object has been detected. • CTA also provides a warning by illuminat- ing the BLIS indicator lights. • An icon will also illuminate in the Park assist graphic on the center console dis- play.
Page 196 Do not attach tape, decals, etc., on the only be done by a trained and qualified surface of the sensors (see the illustration Volvo service technician. in the following "Maintenance" section). • BLIS and CTA are deactivated if a trailer's wiring is connected to the vehicle's elec- trical system.
Page 197 • If this message recurs, the systems should be inspected by a trained and qualified Volvo service technician. Messages can be erased by pressing the OK button on the left steering wheel lever. Option/accessory, for more information, see Introduction.
Page 198 Volvo Sensus..................198 Menus and messages................199 The MY CAR menus................201 Climate system..................207 Trip computer..................216 Active chassis system–Four C*............. 223 Passenger compartment convenience..........224 Option/accessory, for more information, see Introduction.
Page 199 C O M F O R T A N D D R I V I N G P L E A S U R E...
Page 200: 05 Comfort And Driving Pleasure
Introduction systems as well as other options such as the park assist camera(s), etc. Volvo Sensus uses the screen in the center instrument panel to display information and selections are made using this panel’s con- trols and buttons. Certain features can also be controlled using the steering wheel key- pad.
Page 201: Menus And Messages
05 Comfort and driving pleasure Menus and messages Main instrument panel Menu overview The following menu alternatives may vary, depending on the equipment installed in the vehicle. Analog instrument panel Digital speed Trip comp. opt. Service status Messages (##) Digital Instrument panel* and menu controls Digital instrument panel* OK: access to the list of messages and Analog Instrument panel and menu controls...
Page 202 When a warning, information or indicator Service Mainte- Have the vehicle checked If the service intervals are symbol comes on, a corresponding message by an authorized Volvo nance over- not followed, the warranty urgent appears in the information panel. An error workshop immediately.
Page 203: The My Car Menus
05 Comfort and driving pleasure The MY CAR menus • Introduction Operation Reject and incoming phone call • The menu system provides access to The current function will be cancelled Center console controls menus for operating many of the vehi- •...
Page 204 • Settings wheel to put an X in the box. EXIT. My XC60 7. Finish by exiting the menu system either Paths one step at a time with short presses on The current menu level is displayed at the EXIT (2) or press and hold this button to return to the main menu.
Page 205 05 Comfort and driving pleasure The MY CAR menus Driver support systems Doors unlock 60 sec All doors 90 sec Driver door, then all See page 61 for more information. Keyless entry Home safe light duration All doors 30 sec Any door 60 sec Doors on same side...
Page 206 05 Comfort and driving pleasure The MY CAR menus Medium See page 180 for more information. See page 87 for more information. Road Sign Information Time format See page 223 for more information. 12 h Reset car settings 24 h This feature returns the "Car settings"...
Page 207 MY CAR Settings Voice settings pronunciation, no additional phrases will be Phone The menu alternatives under Only on vehicles with the optional Volvo Navigation System displayed. After completed voice training, commands show examples of the voice User 1 User 2...
Page 208 2. Test the setting by pressing OK Automatic rear defroster Map and software version 3. Store the setting and leave the menu by Interior air quality system Refer to the optional Volvo Navigation System pressing EXIT. manual for more information. Reset climate settings Voice POI list This feature returns the "Climate settings"...
Page 209: Climate System
Work of this type should only be condensation from the A/C system NOTE and is normal. done by a trained and qualified Volvo service Do not cover or block the sensors with technician. clothing or other objects. Sensor location Refrigerant •...
Page 210: Air Distribution
Air distribution Passenger compartment filter NOTE Replace the cabin air filter with a new one at Contact your Volvo retailer for IAQS air fil- the recommended intervals. Please refer to ter replacement intervals. your Warranty and Service Records Informa- tion booklet, or consult a trained and qualified Materials used in the cabin Volvo service technician for these intervals.
Page 211 05 Comfort and driving pleasure Climate system Air vents in the dashboard Air vents in the door pillars Open Closed Closed Open Horizontal airflow Horizontal airflow Vertical airflow Vertical airflow Direct the outer air vents toward the side win- Direct the outer air vents toward the side win- dows to defrost.
Page 212 05 Comfort and driving pleasure Climate system Electronic climate control, ECC Temperature control, driver's side Heated front passenger's seat* Heated driver's seat* Temperature control, passenger's side Defroster (maximum effect), electrically Recirculation heated windshield* AUTO Blower A/C on/off Manual air distribution—floor Manual air distribution—dashboard air vents Manual air distribution—defroster...
Page 213 05 Comfort and driving pleasure Climate system Climate system controls Blower control Seat heating will automatically switch off when the engine is switched off. Turn the control clockwise to Heated front seats* increase or counterclockwise Starting the seat heating automatically to decrease the blower This setting starts heating the driver's seat (at speed.
Page 214 05 Comfort and driving pleasure Climate system Air distribution Blower speed in automatic mode can be set Climate settings Automatic blower under adjustment. Choose between Normal High NOTE Selecting the lowest blower speed may increases the risk of fog forming on the windows.
Page 215 05 Comfort and driving pleasure Climate system A/C – ON/OFF Max. defroster and electrically heated front side windows. The indicator light (2) in the defroster button illuminates when When the indicator light in windshield* the function is active. the button is on, the air con- •...
Page 216 05 Comfort and driving pleasure Climate system Recirculation/air quality system Interior Air Quality System–IAQS* NOTE This system consists of a multifilter and an air Recirculation • quality sensor. The filter helps remove gases Triangular areas at the far sides of the This function can be used to and particles from the incoming air, thereby windshield are not heated electrically...
Page 217 05 Comfort and driving pleasure Climate system Air distribution table Air distribution Air distribution Air to windows. Some air To remove de-fog/de- Air to the floor and To ensure comfortable flows from the dashboard air ice the front side win- windows.
Page 218: Trip Computer
05 Comfort and driving pleasure Trip computer • Introduction Trip computer functions Functions To open and make settings in the trip com- • The content and appearance of the trip com- Trip computer information headings in the puter functions: instrument panel puter varies depending on whether the vehi- cle is equipped with an analog or digital 1.
Page 219 05 Comfort and driving pleasure Trip computer Function Description Digital speed This displays the vehicle's speed digitally in the center of the instrument panel • Open by pressing OK, scroll using the thumb wheel, confirm by pressing OK and exit by pressing –...
Page 220 05 Comfort and driving pleasure Trip computer Information headings in the instrument Description panel • T1 and total dist. Press and hold RESET to reset trip odometer T1. Trip odometer • T2 and total dist. Press and hold RESET to reset trip odometer T2. Trip odometer Distance to empty Distance to empty...
Page 221: Information Headings
05 Comfort and driving pleasure Trip computer 3. Use the thumb wheel to scroll among the 4. After completing your selection, exit by The following table lists the digital trip com- functions and select/confirm your choice pressing RESET twice. puter's functions: by pressing OK.
Page 222: Supplementary Information
05 Comfort and driving pleasure Trip computer Heading combinations Description • Press and hold RESET to reset trip odometer T1. Average fuel consumption Trip odometer T1 + mileage Average speed • Press and hold RESET to reset trip odometer T2. Current fuel consumption Trip odometer T2 + mileage Distance to empty...
Page 223 10 miles; the marker at the right will also bination of headings containing the trip in the Volvo Navigation System (VNS)*. odometer to be reset. change according to the scale selected. 2. Press and hold RESET until selected trip...
Page 224 05 Comfort and driving pleasure Trip computer See also the information about Eco Guide on page 132.
Page 225: Active Chassis System-Four C
05 Comfort and driving pleasure Active chassis system–Four C* Active chassis (Four C) Speed-dependent steering force* Advanced In this mode, body sway in curves is minimal Active chassis, Four-C (Continuously Con- Steering force increases with the speed of the and steering response is very direct. Gear trolled Chassis Concept), regulates the cha- vehicle to give the driver enhanced sensitivity.
Page 226: Passenger Compartment Convenience
05 Comfort and driving pleasure Passenger compartment convenience Storage spaces...
Page 227: Passenger Compartment Convenience
05 Comfort and driving pleasure Passenger compartment convenience Tunnel console Glove compartment Compartment in door panel Storage pocket on the front edge of the front seat cushions Glove compartment Storage compartment, 12-volt socket and AUX input/USB connector* Jacket holder Rear seat cup holders Storage pocket Jacket holder Storage compartment (for CDs, etc.)
Page 228 7.5A (90W). The auxiliary sockets can also be used to power a cigarette lighter. Accessory cigarette lighters and ashtrays can be purchased from your Volvo retailer. Vanity mirror with lighting 12-volt socket in the front tunnel console WARNING...
Page 229 05 Comfort and driving pleasure Passenger compartment convenience 12-volt socket in the cargo area* Fold down the cover to access the electrical socket. NOTE The 12-volt socket in the cargo area pro- vides electrical current even when the igni- tion is switched off. Using the socket while the engine is not running will drain the bat- tery.
Page 230 Introduction................... 230 Radio..................... 240 Media player..................249 AUX/USB sockets................. 254 ® Bluetooth media ................. 257 ® Bluetooth hands-free connection ............259 Cell phone voice control*..............268 Option/accessory, for more information, see Introduction.
Page 231 I N F O T A I N M E N T...
Page 232: 06 Infotainment
06 Infotainment Introduction General information Audyssey MultEQ NOTE The infotainment system consists of radio To help avoid excessive battery drain, and media player features and also makes it remove the remote key from the ignition possible to communicate via a cell phone. slot if the infotainment system is used The information is displayed on a 7"...
Page 233 06 Infotainment Introduction Infotainment system overview Basic infotainment functions Left/right arrow keys – short press moves between preset radio stations, tracks on a disc or chapters on a DVD. Press and hold to search within tracks or to tune to the next/previous available radio station.
Page 234 06 Infotainment Introduction Eject a disc. Keypad for entering text/numbers, storing radio stations, etc. OK/MENU – press the thumb wheel on * FAV – this button can be used to store a the steering wheel keypad or this button on the center console to confirm a menu selec- shortcut to a commonly used function in tion or accept an incoming phone call.
Page 235 06 Infotainment Introduction Menu navigation An example of menu navigation in MEDIA mode when a CD is playing...
Page 236 06 Infotainment Introduction Mode button (in this example, the MEDIA Scroll/search forward and back button). The number of buttons varies, Press briefly on (2) to scroll between CD depending on your vehicle’s specifica- tracks/audio files or to search for the next tions).
Page 237 06 Infotainment Introduction • * FAV—storing a shortcut Basic sound settings iPod • Press SOUND to display the basic sound set- Bluetooth ting menu ( Bass Treble , etc). Continue • pressing SOUND or OK/MENU to display the Favorites can also be stored for MY CAR, other setting alternatives.
Page 238 06 Infotainment Introduction • Subwoofer *: subwoofer volume level. Sound stage NOTE • The sound experience can be optimized for DPL II centre level 3 channel centre Sound quality may be affected if the MP3 the driver's seat, both front seats or the rear level : Volume for the center speaker.
Page 239 06 Infotainment Introduction Main FM1/FM2 menu There is also a dynamic calibration that takes View song memory into consideration the volume level, radio FM menu Channel list information reception, and the speed of the vehicle. Show radio text Station name The settings that are described in this man- Show presets Artist...
Page 240 06 Infotainment Introduction MEDIA menus Stop Change audio track Subtitles Scan Main CD Audio menu Disc menu Audio tracks Audio settings Random Advanced settings Main AUX menu Scan Angle AUX menu Audio settings DivX® VOD code AUX input volume Audio settings Audio settings Main CD/DVD Data menu...
Page 241 06 Infotainment Introduction ® Call options Main Bluetooth hands-free menu Phone menu Auto answer Call lists Voicemail number All calls Disconnect phone Missed calls Answered calls Dialled calls Call duration Phone book Search New contact Speed dials Receive vCard Memory status Clear phone book Change phone Remove Bluetooth device...
Page 242: Radio
06 Infotainment Radio General functions Menu navigation area. The currently tuned station will be indicated in the list by magnified text. RADIO menu selections can be made from the center console or the steering wheel key- 3. Turn TUNE again in either direction to pad, see page 231 for more information.
Page 243 06 Infotainment Radio the keypad on the center console to switch to > The sound will be muted for several NOTE manual tuning (or to switch back from manual seconds and when it returns, the sta- The radio is initially set to automatically tuning to the "list of stations"...
Page 244 06 Infotainment Radio Radio text More information about HD radio and IBOC NOTE can be found on Ibiquity's website, Some stations transmit information on pro- HD radio volume may fade in and out at www.hdradio.com and www.ibiquity.com. gram content, artists, etc. This information times due to coverage limitations.
Page 245 93.9 WNYC rial in extreme cases can be as much (Volvo uses the symbol ">" to indicate This will disable the radio's capability to as 8 seconds behind the analogue). there are sub-channels available) The receive digital broadcasts but it will continue This will noticeable as a "stuttering"...
Page 246 06 Infotainment Radio Sub-channels main channel, press and hold the left arrow Sub-channels can also be stored as presets, key on the center console or on the steering see page 241 for information on storing sta- wheel keypad for approximately 1 second. To tions.
Page 247 06 Infotainment Radio Selecting SiriusXM™ radio mode SiriusXM™ ID Selecting a channel There are three ways of tuning in a channel: 1. With the infotainment system switched The SiriusXM™ ID (sometimes referred to as on, press RADIO. the Electronic Serial Number or ESN) is •...
Page 248 06 Infotainment Radio Scanning Add current song to song the Song seek feature is activated, the lis- 3. Scroll to tener will be alerted by a text message and an memory and press OK/MENU. Scan automatically searches through the list audible signal.
Page 249 06 Infotainment Radio 5. Press OK/MENU to select All categories Locking a channel WARNING or turn TUNE to scroll to a category and 1. Press OK/MENU. Settings should be made when the vehicle press OK/MENU to select it. Advanced settings 2.
Page 250 3. The current code will be displayed. selection. Your Volvo retailer can also provide you with Temporarily unlock all channels assistance. This function will temporarily unlock all chan- nels and make them available for selection.
Page 251: Media Player
06 Infotainment Media player OK/MENU: Press to confirm your selec- Playing a disc CD/DVD functions tion or access the menus for the currently Press MEDIA ans scroll to Disc . Press OK/ Disc selected source (e.g., ) or press the MENU or the thumb wheel on the steering thumb wheel on the steering wheel key- wheel keypad.
Page 252 06 Infotainment Media player Navigating a disc and playing tracks When a file has been played, the player will NOTE continue to play the rest of the files (of the CD audio discs Some copy protected audio files or home- same type) in the current folder.
Page 253 06 Infotainment Media player Playing video DVDs Navigating in a DVD's menus Random This function plays the tracks in random order Play (shuffle). The random tracks/sound files can When playing a video DVD, a disc menu may be scrolled through in the normal way. To lis- appear on the display, giving you access to ten to tracks in random order: extra functions and settings such as choice of...
Page 254 06 Infotainment Media player Press EXIT to cancel and return to the normal See also www.divx.com/vod for more infor- view (without having made a selection). mation. It is also possible to change chapters by Screen settings pressing on the center console Screen settings can be made (when the vehi- control panel or on the steering wheel key- cle is not moving) for:...
Page 255 06 Infotainment Media player NOTE Dual format (double-sided discs) such as DVD Plus or CD-DVD are thicker than nor- mal discs and may not play in your info- tainment system. If a disc containing both CDDA and MP3 tracks is played, all MP3 tracks will be ignored.
Page 256: Aux/Usb Sockets
Sockets for auxiliary devices in the storage com- problem persists, contact a trained partment between the front seats and authorized Volvo service techni- When this information has been loaded, track ® cian. information will be displayed and a track can...
Page 257 06 Infotainment AUX/USB sockets sound is unmuted. Pause is also available via Scan buttons on the center console the menu system, select Play/Pause or steering wheel keypad can also be used to For information, see page 250. change tracks/files. External sound sources Random The following symbols are used in the dis- For information, see page 251.
Page 258 06 Infotainment AUX/USB sockets USB hub Compatible file formats via the USB A USB hub can be connected to the USB socket socket, making it possible to connect several The following audio and video files are sup- USB devices at the same time. To select one ported by the system when playing a device connected to the USB socket.
Page 259: Bluetooth ® Media
® When the Bluetooth function is active and mode's main view will display a shortcut Volvo retailer or at www.volvocars.us. the most recently used device is within range, menu. it is automatically connected. When the info- TUNE: Turn to navigate among menu...
Page 260 06 Infotainment ® Bluetooth media Switching to another device Disconnecting an external device Scanning audio files on an external device It is possible to switch among paired The external device is automatically discon- ® nected from the infotainment system if it is Bluetooth devices that are in the vehicle.
Page 261: Bluetooth ® Hands-Free Connection
Not all cell phones are fully compatible ance could void the user’s authority to oper- with the hands-free system. A list of com- ate the equipment. patible phones is available at your Volvo IC RSS-Gen retailer or at www.volvocars.us This equipment complies with FCC/IC radia-...
Page 262: Getting Started
06 Infotainment Bluetooth ® hands-free connection ® Pairing (connecting) external Bluetooth functions in the center steering wheel keypad can be used in the same way. console control panel Bluetooth ® devices OK/MENU: Press to answer an incoming A maximum of 10 cell phones or other devi- call, confirm your selection or access the ces can be paired with the hands-free sys- tem.
Page 263 Changing phones or devices phone’s display as My Volvo Car. directions provided. More than one device can be used in the 5. Turn the thumb wheel or TUNE to select vehicle as long as this device has been 5.
Page 264 06 Infotainment Bluetooth ® hands-free connection Making a call Auto answer The hands-free system is also deactivated when the ignition is switched off (or if the 1. Ensure that This function means that incoming calls will is shown at the top of driver’s door is opened).
Page 265 06 Infotainment Bluetooth ® hands-free connection Sound settings In phone mode, the various call lists can be Phone settings Sounds and volume Phone menu Call lists: displayed in Ring signals Ring signal 1, etc. Call volume • All calls Call volume can be only be adjusted during a NOTE •...
Page 266 06 Infotainment Bluetooth ® hands-free connection connected when the contact is saved. – Activate/deactivate this function in phone first letter of the contact's name. For exam- These contacts will be displayed regard- ple, pressing and holding button 6 would pro- Phone menu Phone settings mode in...
Page 267 06 Infotainment Bluetooth ® hands-free connection 1. Turn TUNE to the desired letter and press Press EXIT briefly to erase a single character. Button Function OK/MENU to confirm. The number/letter Press and hold EXIT to erase all of the char- keys on the center console can also be acters that have been entered.
Page 268 06 Infotainment Bluetooth ® hands-free connection Speed dial New contacts can be added in phone mode When all of the contact's information has Save contact been entered, select in the Speed dial numbers can be added in phone Phone menu Phone book menu to save.
Page 269 06 Infotainment Bluetooth ® hands-free connection Phone menu Phone book Clear phone book. NOTE Clearing the entries in the infotainment system's phone book does not delete entries in the cell phone's phone book. ® Bluetooth version information ® For information about the Bluetooth version Phone menu installed in the vehicle, go to...
Page 270: Cell Phone Voice Control
Voice commands offer convenience and help avoid distractions so that you can concen- trate on driving and focus your attention on road and traffic conditions. Available in vehicles equipped with the Volvo Navigation System* only Option/accessory, for more information, see Introduction.
Page 271: Getting Started
06 Infotainment Cell phone voice control* • Getting started When giving commands, speak at your This feature can be accessed by pressing the usual speed and in a normal tone of voice MY CAR button in the center console and after the tone turning TUNE.
Page 272 06 Infotainment Cell phone voice control* Voice output volume User action The following is a list of features that can be ® voice-controlled with a Bluetooth -connected Begin saying the digits in the phone number. Press MY CAR and go to Settings Voice cell phone.
Page 273 06 Infotainment Cell phone voice control* The user initiates the dialogue by saying: Phone dial voice mail Phone > call contact Continue by responding to the system's prompts. Phone call contact Continue by responding to the system's prompts. When calling contacts, keep the following in mind: •...
Page 274 Driving recommendations..............274 Refueling....................278 Loading....................283 Cargo area ................... 287 Towing a trailer..................290 Emergency towing................293...
Page 275 D U R I N G Y O U R T R I P...
Page 276: 07 During Your Trip
07 During your trip Driving recommendations General information 130 for additional information about Sport Some of the above mentioned items and oth- mode. ers are checked at the standard maintenance Economical driving conserves natural intervals. • Do not exceed posted speed limits. resources •...
Page 277 07 During your trip Driving recommendations Handling, roadholding WARNING CAUTION Vehicle load, tire design and inflation pres- • • Avoid driving through standing or Engine damage will occur if water is sure all affect vehicle handling. Therefore, rushing water. Doing so can be dan- drawn into the air cleaner.
Page 278: Conserving Electrical Current
Have a word with a trained and qualified operate (for up to 6 minutes) after the battery. Volvo service technician if you intend to engine has been switched off. drive in countries where it may be difficult Before a long distance trip to obtain the correct fuel.
Page 279 07 During your trip Driving recommendations • improves cold-weather starting as well as Use Volvo Teflon Lock Spray in the locks. decreasing fuel consumption while the • Avoid using de-icing sprays as they can engine is warming up. Full synthetic cause damage to the locks.
Page 280: Refueling
"oxygenated" fuel. Deposit control gasoline (detergent loss of emission warranty coverage. State Volvo allows the use of the following "oxy- additives) and local vehicle inspection programs will genated" fuels; however, the octane ratings...
Page 281 Typical pump octane label Many fuels contain benzene as a solvent. fire and injury. Unburned benzene has been strongly linked Volvo recommends premium fuel for best to certain forms of cancer. If you live in an performance, but using 87 octane or above...
Page 282 07 During your trip Refueling Opening/closing the fuel filler door central locking button does not lock the Manually opening the fuel filler door fuel filler door. • Be sure the fuel filler door is not obstruc- ted and is completely closed after refuel- ing.
Page 283: Emission Controls
If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.
Page 284 07 During your trip Refueling Heated oxygen sensors The heated oxygen sensors monitor the oxy- gen content of the exhaust gases. Readings are fed into a control module that continu- ously monitors engine functions and controls fuel injection. The ratio of fuel to air into the engine is continuously adjusted for efficient combustion to help reduce harmful emis- sions.
Page 285: Loading
07 During your trip Loading Introduction Power tailgate* WARNING The load carrying capacity of your vehicle is • Stop the engine, put the gear selector determined by factors such as the number of in P, and apply the parking brake passengers, the amount of cargo, the weight when loading or unloading long of any accessories that may be installed, etc.
Page 286 07 During your trip Loading Programming the tailgate opening CAUTION WARNING angle Be sure that there is adequate space Be sure that no one is near the tailgate The tailgate's maximum opening angle can above and behind the vehicle before open- when it is opened or closed automatically.
Page 287 07 During your trip Loading Grocery bag holder* tailgate will be released from the electrical The load anchoring eyelets on both sides of system. the vehicle are used to fasten straps, etc., to help anchor items in the cargo area. •...
Page 288 The vehicle's wind resistance and fuel consumption will increase with the size of Using load carriers the load. Load carriers are available as Volvo accesso- • Drive smoothly. Avoid rapid starts, fast ries. Observe the following points when in cornering and hard braking.
Page 289: Cargo Area
07 During your trip Cargo area Steel cargo grid* Installing the steel cargo grid Installing the cover For information about the necessary tools 1. Press the end piece on one side of the and procedures for installing/removing the cargo area cover into the retaining steel cargo grid, please refer to the assembly bracket in the side panel of the cargo instructions...
Page 290 07 During your trip Cargo area NOTE WARNING • On models equipped with this cover, it Be sure that the cargo net's upper should be removed before a child seat is attachment hooks are properly attached to the child restraint anchors. inserted in the brackets and that the lower straps are correctly attached and pulled taut.
Page 291 07 During your trip Cargo area Removing and storing the cargo net Cargo net in front position Mounting in the front position: With the Press the release buttons on the locks on net's rod attached to the front upper the straps and pull out a small section of brackets, hook the lower straps in the the strap.
Page 292: Towing A Trailer
Introduction watched when driving in hot climates or WARNING hilly terrain. Use a lower gear and turn off Volvo recommends the use of Volvo trailer • Bumper-attached trailer hitches must the air conditioner if the temperature hitches that are specially designed for the not be used on Volvos, nor should gauge needle enters the red range.
Page 293 07 During your trip Towing a trailer by Volvo. Make sure the cable does not drag 2. Slide the ball holder into the hitch assem- NOTE on the ground. bly. • When parking the vehicle with a trailer 3. Align the hole in the ball holder with the...
Page 294 07 During your trip Towing a trailer Trailer Stability Assist (TSA) be switched off (but will be on again the next time the engine is started) Trailer Stability Assist is a system designed to • TSA may not intervene when the vehicle help stabilize a vehicle that is towing a trailer and trailer begin to sway if the driver tries when the vehicle and trailer have begun to...
Page 295: Emergency Towing
07 During your trip Emergency towing Towing eyelet and may be partially concealed. This eye WARNING let must be screwed into the positions • When the vehicle is being towed, the provided on the right sides of either the ignition should be in mode II (in mode front or rear bumper (see illustration).
Page 296 Call for professional help from an authorized • Please check with state and local ENGINE for approximately 2 seconds to towing company.Volvo recommends the use authorities before attempting this type of flat bed equipment. activate ignition mode II. of towing, as vehicles being towed are 2.
Page 297 07 During your trip Emergency towing CAUTION • The vehicle should always be towed in the forward direction. • Vehicles with All Wheel Drive (AWD)* that are being towed with the front wheels off the ground should not be towed at a speed above approx. 45 mph (70 km/h) and should not be towed farther than 30 miles (50 km).
Page 298 General information ................298 Tire inflation................... 301 Inflation pressure ................. 303 Tire designations .................. 304 Glossary of tire terminology ..............306 Vehicle loading ..................307 Uniform Tire Quality Grading ............... 309 Snow chains, snow tires, studded tires ..........310 Temporary Spare ................. 311 Tire Sealing System*................
Page 299 W H E E L S A N D T I R E S...
Page 300: 08 Wheels And Tires
If the tires are rotated, they should a risk of altering the car's roadholding and only be moved from front to rear or Some Volvo models are equipped with an handling characteristics. vice versa. They should never be rota- Ultra High Performance tire and wheel ted left to right/right to left.
Page 301 08 Wheels and tires General information Summer and winter tires with less than 1/16" (1.6 mm) tread offer very process. The temporary spare should also poor traction. be replaced at 6-year intervals, even if it has never been used. When replacing worn tires, it is recommended that the tire be identical in type (radial) and A tire's age can be determined by the DOT size as the one being replaced.
Page 302 The tires with the most tread should WARNING always be at the rear (to reduce the risk of • The wheel and tire sizes for your Volvo skidding). are specified to meet stringent stability • Contact a Volvo workshop if you are and handling requirements.
Page 303: Tire Inflation
08 Wheels and tires Tire inflation Inflation placard NOTE WARNING • • The placards shown indicate inflation Under-inflation is the most common pressure for the tires installed on the cause of tire failure and may result in vehicle at the factory only. severe tire cracking, tread separation, or "blow-out,"...
Page 304 08 Wheels and tires Tire inflation Tire ratings After driving a distance of approximately 4. Visually inspect the tires to make sure 1 mile (1.6 km), the tires are considered to be there are no nails or other objects Speed ratings hot.
Page 305: Inflation Pressure
Tire inflation pressure table The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard (see page 301 for its location) for informa- tion specific to the tires installed on your vehicle at the factory.
Page 306: Tire Designations
08 Wheels and tires Tire designations Information on the sidewall 1. 215: the width of the tire (in millimeters) 7. M+S or M/S = Mud and Snow, AT = All from sidewall edge to sidewall edge. The Terrain, AS = All Season larger the number, the wider the tire.
Page 307 08 Wheels and tires Tire designations 10. Maximum Load: Indicates the maximum load in pounds and kilograms that can be carried by the tire. Refer to the vehicle's tire information placard located on the B- Pillar for the correct tire pressure for your vehicle.
Page 308: Glossary Of Tire Terminology
41 psi [43 psi (2.9 bar) for • Recommended tire inflation pressure: Metric tires]. Increasing the inflation pres- inflation pressure, established by Volvo, sure beyond this pressure will not which is based on the type of tires that increase the tire's load carrying capabil- are mounted on a vehicle at the factory.
Page 309: Vehicle Loading
08 Wheels and tires Vehicle loading Loads Permissible axle weight 2. Determine the combined weight of the driver and passengers that will be riding The maximum allowable weight that can be Properly loading your vehicle will provide in your vehicle. carried by a single axle (front or rear).
Page 310 Do not use replacement tires with lower load carrying capacities than the tires that were original equipment on the vehicle because this will lower the vehicle's GVW rating. Use only tires with the correct load carrying capacity. Consult your Volvo retailer for informa- tion.
Page 311: Uniform Tire Quality Grading
08 Wheels and tires Uniform Tire Quality Grading Quality grading information test surfaces of asphalt and concrete. A tire WARNING marked C may have poor traction perform- ALL PASSENGER VEHICLE TIRES MUST The temperature grade for this tire is ance. The traction grade assigned to this tire CONFORM TO FEDERAL SAFETY established for a tire that is properly infla- is based on braking (straight-ahead) traction...
Page 312: Snow Chains, Snow Tires, Studded Tires
Check local regulations regarding the • It is important to install winter tires on all use of snow chains before installing. Snow chains can be used on your Volvo with four wheels to help retain traction during the following restrictions: •...
Page 313: Temporary Spare
In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING Current legislation prohibits the use of the "Temporary Spare" tire other than as a temporary replacement for a punctured tire.
Page 314: Tire Sealing System
WARNING • The tire sealing system's compressor has After using the tire sealing system, the been tested and approved by Volvo. vehicle should not be driven farther than approximately 120 miles (200 km). The 12-volt sockets are located in the front •...
Page 315 08 Wheels and tires Tire Sealing System* • Tire sealing system–overview Inhalation: Move the exposed person WARNING to fresh air. If irritation persists, get Please keep the following points in mind medical attention. when using the tire sealing system: • Ingestion: Do NOT induce vomiting •...
Page 316 Once in place, clearly visible to the driver. the bottle cannot be unscrewed. This must be done by a trained and qualified Volvo Temporarily repairing a flat tire is done in two 2. Ensure that the on/off switch is in posi- service technician.
Page 317 In this occurs. Contact a towing service or case, the hole is too large to be sealed and WARNING Volvo On Call Roadside Assistance if the vehicle should not be driven. applicable. The vehicle´s engine should be running when the tire sealing system is used to 10.
Page 318 The compressor should not be used for to a Volvo retailer or a recycling station more than 10 minutes at a time to avoid that can properly dispose of harmful overheating.
Page 319 08 Wheels and tires Tire Sealing System* Inflating tires 9. Turn off the compressor (press the on/off WARNING switch to position 0) when the correct The tire sealing system can be used to inflate • The vehicle’s engine should be running inflation pressure has been reached.
Page 320: Changing A Wheel
08 Wheels and tires Changing a wheel Removing a wheel The other two blocks can remain in the spare WARNING wheel well. Current legislation prohibits the use of the After use “Temporary Spare” tire other than as a temporary replacement for a punctured The foam block and spare wheel must be tire.
Page 321 08 Wheels and tires Changing a wheel Jack attachment points 7. There are two jack attachment points on each side of the vehicle. Position the jack Lug wrench and towing eyelet 6. With the vehicle still on the ground, use correctly in the attachment (see the illus- 5.
Page 322 08 Wheels and tires Changing a wheel WARNING NOTE • The jack provided with your vehicle is The jack must correctly engage the intended to be used only in temporary sit- jack attachment. uations such as changing wheels in the •...
Page 323 08 Wheels and tires Changing a wheel 3. Install the wheel nuts and tighten hand- tight. Using the lug wrench, tighten cross- wise until all nuts are snug. 4. Lower the vehicle to the ground and alter- nately tighten the bolts crosswise to 103 ft.
Page 324: Tire Pressure Monitoring System (Tpms)
08 Wheels and tires Tire Pressure Monitoring System (TPMS) Introduction and may affect the vehicle's handling and NOTE stopping ability. If a fault occurs in TPMS, the tire pressure NOTE Please note that the TPMS is not a substitute warning light will flash for approximately for proper tire maintenance, and it is the driv- Tire press.
Page 325 • If the vehicle is equipped with a tempo- this chapter or consult your Volvo retailer. • After pumping the tires, always rein- rary spare tire, this tire does not have a stall the valve cap to help avoid dam- TPMS sensor.
Page 326 In certain cases, it may be necessary to reca- 1. Switch off the engine. Drive carefully; it may be difficult to determine librate TPMS to conform to Volvo's recom- which tire is damaged. To find the damaged 2. Put the ignition in mode I or II (see page...
Page 327 08 Wheels and tires Tire Pressure Monitoring System (TPMS) WARNING • SST tires should only be mounted by service technicians who are familiar with tires of this type. • SST tires may only be mounted on vehicles equipped with TPMS. •...
Page 328 Volvo maintenance................328 Maintaining your car................329 Hood and engine compartment............331 Engine oil....................332 Fluids..................... 334 Replacing bulbs..................336 Wiper blades and washer fluid.............. 343 Battery....................346 Fuses..................... 350 Vehicle care................... 359...
Page 329 M A I N T E N A N C E A N D S P E C I F I C A T I O N S...
Page 330: 09 Maintenance And Specifications
Refer to your Warranty and Service be performed by a qualified technician. To Canadian regulations, the following list of Records Information booklet for a keep your Volvo in top condition, specify warranties is provided. comprehensive service and mainte- time-tested and proven Genuine Volvo Parts nance schedule up to 150,000 miles •...
Page 331: Maintaining Your Car
OBD II will store a message about any end of its useful service life. Consult your fault. Volvo retailer for additional information. If a garage jack is used to lift the vehicle, the two jack attachments points should be used.
Page 332 OBD II to reach readiness. Your inspection? Volvo retailer can provide you with more Your vehicle can fail OBD II emission inspec- information on planning a trip. tion for any of the following reasons.
Page 333: Hood And Engine Compartment
09 Maintenance and specifications Hood and engine compartment Opening and closing the hood The appearance of the engine compartment WARNING may vary depending on engine model. Check that the hood locks properly when closed. WARNING The cooling fan (located at the front of the Engine compartment, overview engine compartment, behind the radiator) may start or continue to operate (for up to...
Page 334: Engine Oil
• Oil that is lower than the specified quality can damage the engine. • Volvo does not recommend the use of oil additives. • Always add oil of the same type and viscosity as already used.
Page 335 09 Maintenance and specifications Engine oil 3. Add oil if necessary. If the level is close to the MIN mark, add approximately 0.5 US quarts (0.5 liters) of oil. 4. Recheck the level and add more oil if necessary until the level is near the MAX mark.
Page 336: Fluids
MIN and changed. If the system must be drained, con- MAX marks. If it is not kept filled, there sult a trained and qualified Volvo service can be high local temperatures in the technician. engine which could result in damage.
Page 337 MIN and MAX marks. For display: DO NOT DRIVE. Have the car capacities and recommended fluid grade, see towed to a trained and qualified Volvo page 372. service technician and have the brake system inspected.
Page 338: Replacing Bulbs
The following bulbs should only be replaced fingers. Grease and oils from your fingers not mentioned in this section, please by a trained and qualified Volvo service tech- vaporize in the heat and will leave a contact your Volvo retailer or a trained...
Page 339 09 Maintenance and specifications Replacing bulbs Headlight housing 1. Plug in the connector until it clicks into CAUTION place. The entire headlight housing must be lifted When disconnecting the connector, pull on out when replacing all front bulbs. 2. Reinsert the headlight housing and lock- the connector itself and not on the wiring.
Page 340 09 Maintenance and specifications Replacing bulbs 1. Remove the headlight housing from the 1. Remove the headlight housing from the NOTE vehicle (see page 336). vehicle (see page 336). Before starting to replace a bulb, see 2. Remove the cover over the bulbs (see 2.
Page 341 09 Maintenance and specifications Replacing bulbs Extra high beam 7. Reconnect the wiring connector to the 5. Press the new bulb into the holder and bulb holder. turn it clockwise. 8. Put the cover back into position and rein- 6. Reinsert the bulb holder into the headlight stall the headlight housing.
Page 342 09 Maintenance and specifications Replacing bulbs Brake lights and taillights License plate lighting 3. Insert a new bulb, press it downward and turn it clockwise. 4. Reinsert the bulb holder and turn it clock- wise. Location of taillight bulbs The brake lights and taillights are replaced 1.
Page 343 09 Maintenance and specifications Replacing bulbs Cargo area lighting Vanity mirror lighting Bulb specifications Lighting func- Wat- Bulb Removing the mirror glass tion tage Extra high beam H7 LL (models with Active Bending Lights*) Low beam (hal- H11 LL ogen) High beam (hal- ogen) 1.
Page 344 09 Maintenance and specifications Replacing bulbs Lighting func- Wat- Bulb tion tage Backup lights P21W LL Brake lights P21W LL Cargo area SV8.5 lighting (length 43mm) NOTE Please consult a Volvo retailer’s Parts department for the most up-to-date speci- fications.
Page 345: Wiper Blades And Washer Fluid
09 Maintenance and specifications Wiper blades and washer fluid Wiper blades Replacing the windshield wiper blades 1. Insert the remote key into the ignition slot and press the START/STOP Service position ENGINE button briefly to put the ignition in mode I (see page 89 for detailed infor- mation about the ignition modes).
Page 346 09 Maintenance and specifications Wiper blades and washer fluid 4. Press the wipers back against the wind- 2. Grasp the inner section of wiper blade (at shield. the arrow). To return the wipers from the service position 3. Pull out the blade to release it from the to the normal position, fold the wipers back wiper arm.
Page 347 09 Maintenance and specifications Wiper blades and washer fluid filled with windshield washer solvent contain- ing antifreeze. For capacities, see page 372.
Page 348: Battery
A used battery should be disposed of in an and/or a message may be displayed if a environmentally responsible manner. Con- battery charger or jumper cables are not sult your Volvo retailer or take the battery See the owner's manual. connected properly. to a recycling station.
Page 349 09 Maintenance and specifications Battery • Never disconnect the battery when the WARNING CAUTION engine is running, or when the key is in • • Never expose the battery to open Always use distilled or deionized water the ignition. This could damage the vehi- flame or electric spark.
Page 350 09 Maintenance and specifications Battery WARNING WARNING Connect and disconnect the positive and PROPOSITION 65 WARNING! negative cables in the correct sequence. Battery posts, terminals, and related accessories contain lead and lead com- pounds, chemicals known to the state of Removal California to cause cancer and reproduc- Switch off the ignition, remove the remote key...
Page 351 09 Maintenance and specifications Battery 6. Connect the black negative cable. 7. Press in the rear cover. (See Removal). 8. Reinstall the molding. (See Removal). 9. Reinstall the front cover and secure it with the clips. (See Removal).
Page 352: Fuses
Cargo area If fuses burn out repeatedly, have the electri- cal system inspected by a trained and quali- fied Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the following pages. Doing so could seriously damage or overload the vehicle's electrical system.
Page 353 09 Maintenance and specifications Fuses Engine compartment...
Page 354 – relays/circuit breakers and should only Engine compartment box be removed or replaced by a trained ABS pump and qualified Volvo service technician. Auxiliary lights* ABS valves • There is a special fuse removal tool on the underside of the cover.
Page 355 09 Maintenance and specifications Fuses Function Relay coils Starter motor relay Ignition coils Engine Control Module Injection system, mass air meter, engine control module A/C compressor, engine valves, engine control mod- ule (6-cyl.), solenoids (6-cyl. non-turbo only) EVAP valve, heated oxygen sensor Fuel leakage detection –...
Page 356 09 Maintenance and specifications Fuses Under the glove compartment Positions: fuse box A Fold aside the upholstery covering the fuse Function boxes. Function 1. Press the cover's lock and fold it up. Circuit breaker for the info- 2. The fuses are accessible. 12-volt socket (cargo area) tainment system and for fuses 16-20,...
Page 357 09 Maintenance and specifications Fuses Function Function Function Keyless drive* Heated rear seat* (driver's Instrument panel side) Power driver's seat* Adaptive cruise control/colli- sion warning* Power front passenger's seat* Heated front passenger's Courtesy lighting, rain sensor* seat* Windshield washers Steering wheel module Tailgate window washer Heated driver's seat* Cental locking: fuel filler door...
Page 358 09 Maintenance and specifications Fuses Function Airbag system, occupant weight sensor Collision warning system* Accelerator pedal, auto-dim mirror function, heated rear seats* Brake lights Laminated panoramic roof* Immobilizer Option/accessory, for more information, see Introduction.
Page 359 Power tailgate* Trailer socket 1* Electric parking brake (left side) Electric parking brake (right NOTE side) Please consult a Volvo retailer’s Parts Heated rear window department for the most up-to-date speci- fications. Trailer socket 2* Option/accessory, for more information, see Introduction.
Page 360 Power tailgate* Trailer socket 1* Electric parking brake (left side) Electric parking brake (right NOTE side) Please consult a Volvo retailer’s Parts Heated rear window department for the most up-to-date speci- fications. Trailer socket 2* Option/accessory, for more information, see Introduction.
Page 361: Vehicle Care
Exterior components • Dry the car with a clean chamois and Volvo recommends the use of special clean- remember to clean the drain holes in the ing products, available at your Volvo retailer, doors and rocker panels.
Page 362 09 Maintenance and specifications Vehicle care CAUTION NOTE WARNING • • Condensation may form temporarily on the Avoid waxing or polishing plastic or When the vehicle is driven immediately inside of the lenses of exterior lights such rubber components after being washed, apply the brakes, as headlights, fog lights, or taillights.
Page 363 Staining, cracking, scuffing, and pitting, fading, oxidation, etc. These coat- towel, and allow the leather to dry com- fading can result. ings have not been tested by Volvo for pletely. compatibility with your vehicle's clear coat. Volvo offers an easy-to-use, non-greasy...
Page 364 09 Maintenance and specifications Vehicle care Volvo's Leather Care Kit 951 0251 and Cleaning floor mats CAUTION Leather Softener 943 7429. The floor mats should be vacuumed or • Under no circumstances should gaso- brushed clean regularly, especially during If there are stains on the steering wheel:...
Page 365 Paint repairs require special equipment and 3. When the primer surface is dry, the paint skill. Contact your Volvo retailer for any can be applied using a brush. Mix the extensive damage. paint thoroughly; apply several thin paint Minor scratches can be repaired by using coats and let dry after each application.
Page 366 Label information.................. 366 Specifications..................368 Overview of information and warning symbols........374 Volvo programs..................377...
Page 367: Specifications
S P E C I F I C A T I O N S...
Page 368: Label Information
10 Specifications Label information Location of labels...
Page 369 Vehicle Emission Control Information. to see it. Your Volvo is designed to meet all appli- cable emission standards, as evidenced Federal Motor Vehicle Safety Stand- by the certification label on the underside ards (FMVSS) specifications (USA) and of the hood.
Page 370: 10 Specifications
10 Specifications Specifications Dimensions Dimension In (mm) Wheelbase 109.2 (2774) Length 182.8 (4644) Load length, floor, seatback down 70.4 (1789) Load length, floor 38.3 (972) Height 67.4 (1713) Load height 31.6 (802) Track, front 64.3 (1632)
Page 371 10 Specifications Specifications Dimension In (mm) Track, rear 62.4 (1586) Load width, floor 42.9 (1090) Width 74.4 (1891) Width incl. door mirrors (folded out) 83.5 (2120) Width incl. door mirrors (folded in) 74.4 (1891) Weights Category Canada Gross vehicle weight 6-cyl.
Page 372 10 Specifications Specifications Category Canada Max. roof load 220 lbs 100 kg Max. trailer weights Without brakes: 1650 lbs Without brakes: 750 kg With brakes, 1 7/8” ball: 2,000 lbs With brakes, 1 7/8” ball: 900 kg With brakes, 2” ball: 3,300 lbs With brakes, 2”...
Page 373 10 Specifications Specifications Specification/Model 3.2 6-cyl. 3.2 6-cyl. 3.0T Displacement 3.19 liters (194.8 cu. in.) 3.19 liters (194.8 cu. in.) 2.95 liters (175 cu. in.) Compression ratio 10.8:1 10.3:1 9.3:1 This engine may not be available on all markets Oil specifications Oil additives must not be used.
Page 374 1.26 US qts (1.2 liters) Power steering fluid WSS M2C204-A2 or equivalent product. Washer fluid 6.8 US qts (6.5 liters) Use a washer antifreeze recommended by Volvo, mixed with water. 4.7 US qts (4.5 liters Fuel tank volume 3.0T/3.2 6 cyl.
Page 375 10 Specifications Specifications Electrical system CAUTION General information If the battery is replaced, replace it with a battery of the same cold start capacity and 12 volt system with a voltage-regulated alter- reserve capacity as the original (see the nator. Single pole system in which the chas- decal on the battery).
Page 376: Overview Of Information And Warning Symbols
10 Specifications Overview of information and warning symbols Introduction Symbols in the main instrument panel Indicator symbols in the instrument panel The symbols in the vehicle's various displays Warning symbols in the instrument are divided into three main categories: Symbol Description panel •...
Page 377 10 Specifications Overview of information and warning symbols Symbol Description Symbol Description Pg. no. Symbol Description Pg. no. Camera sensor, 173166 Driver Alert System* laser sensor (Lane Departure Left turn signal indicator Warning) Right turn signal indica- Collision Warning Driver Alert System* with Full Auto-brake (Lane Departure and Pedestrian...
Page 378 10 Specifications Overview of information and warning symbols Symbol Description Bluetooth hands-free HD radio Park Assist* Information symbols in the ceiling console Symbol Description Seat belt reminder Occupant Weight Sensor Option/accessory, for more information, see Introduction.
Page 379: Volvo Programs
10 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional infor- mation, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial: In the U.S.
Page 380: 11 Index
11 Index All Wheel Drive......... 131 Automatic transmission 1, 2, 3 ... Geartronic........... 129 Ambient temperature sensor..... 86 12-volt sockets........226 general description..... 128, 129 Anti-freeze........276, 334 oil............372 Anti-lock brake system shiftlock override........ 131 warning light........81, 83 Axle weight..........
Page 381 11 Index fluid............. 372 Check engine light........81 Collision warning system....169, 170 general information......134 Check Engine warning light....... 82 Compass in rearview mirror..... 115 Bulbs Child restraints Conserving electrical current....276 cargo area lighting......341 recalls and registration......40 Controls, center console......
Page 382 11 Index Disconnecting the front passenger’s air- Emission inspection readiness....329 Fog lights........... 83 bag............26, 27 rear..........103, 339 Engine Dome lighting........104, 105 overheating........... 84 Four C (active chassis system)....223 specifications........370 Door mirrors..........112 Front airbags..........22 starting..........
Page 383 11 Index Geartronic automatic transmission..129 High beams..........100 Infotainment active..........100 Menu navigation......... 233 Generator warning light......84 Hill Start Assist (HSA)......128 Infotainment system........ 230 Glossary of tire terminology..... 306 AUX/USB sockets....... 254 Hoisting the vehicle......... 329 Grocery bag holder........285 ®...
Page 384 11 Index Loading the vehicle......283, 307 retractable........... 112 roof loads..........286 vanity..........226 Jack Locking............70 Motor oil attaching..........318 tailgate..........71 checking..........332 location of........... 318 volumes..........372 Locking the vehicle........61 Jump starting........... 126 MY CAR........... 201 Locks, child safety........
Page 385 11 Index Outside temperature sensor...... 86 Power steering Rearview mirror fluid............. 335 auto-dim function....... 113 Overhead courtesy lighting....104, 105 speed-dependent....... 223 compass..........115 Overheating, engine........84 Power steering fluid......... 372 Rear window defroster......113 Oxygen sensors, heated......282 Power tailgate.......... 283 Recalls, child restraints......
Page 386 11 Index Roll Stability Control (RSC)......35 Shiftlock............9 Steering wheel override..........131 adjusting..........97 Roof loads..........286 heated........... 98 Side door mirrors........112 horn............97 Side impact airbags........30 keypad........97, 201, 231 Sign information (RSI)......145 Steering wheel paddles......97 SiriusXM™...
Page 387 Trip odometers.......... 86 Vehicle weights........369 speed ratings........302 Trips, long distance......... 276 Voice control storing..........300 Tunnel detection........102 cell phones......... 268 studded..........310 Turn signals..........104 Volvo and the environment......12 tire pressure monitoring system..322 indicator lights........83...
Page 388 11 Index Volvo maintenance........328 Windows power..........110 Volvo On Call Roadside Assistance..377 sun shade........... 110 Volvo programs........377 Windshield Volvo Sensus........... 198 heated......... 113, 213 rain sensor.......... 107 washers..........108 wipers/washers........107 Windshield washer fluid....344, 372 Warning flashers, hazard......104 Windshield wipers........

This manual is also suitable for:

Xc70

Volvo XC60 Owner's Manual

Quick Links

Related Manuals for Volvo XC60

Summary of Contents for Volvo XC60

This manual is also suitable for:

Table of Contents
