SYSTEM OVERVIEW

About the Display and Indicators

Display Definitions
Alarm:
Armed Away:
Armed Stay:
Exit Now:
Disarmed Ready to Arm:
Disarmed Ready:
Disarmed NotReady:
AwayInst or StayInst:
Fire:
LowBat:
No AC:
Chime:
Test in Progress:
Record Press Off to Stop: Displayed when the system is in Recording mode.
Msg:
Bypass:
Fault:
PH Speakerphone:
PC Remote Phone:
LED Meanings
ARMED LED:
(Red)
READY LED:
(Green)
(for other displays, see Trouble Messages)
Displayed when the system is armed and an intrusion has been detected
(also appears during a fire alarm or audible emergency alarm).
Accompanied by the protection zone that is in alarm.
All burglary zones, interior and perimeter, are armed.
Perimeter burglary zones (i.e.: protected windows and doors) are armed.
Displayed during exit delay
Displayed immediately after system has been disarmed.
Displayed when the system is disarmed and is ready to be armed.
Displayed when the system is disarmed but is not ready to be armed
Entry delay is turned off.
Displayed when a fire alarm or fire fault is present. Accompanied by a
display of the zone that is in alarm.
Low battery condition exists in a wireless sensor (if zone number is
displayed) or low system battery (if no zone number is displayed). If 00 is
displayed, a wireless keypad (5827) has a low battery condition.
Displayed when AC power is NOT present. If displayed, the system is
operating on backup battery power.
Displayed when the Chime feature is enabled and the system is disarmed.
Displayed when the system is in Test mode, blinks during the last 5
minutes of test.
Displayed when a recorded message has not yet been played back.
Displayed when one or more burglary protection zones are bypassed.
Displayed at any time a malfunction is discovered in the system; or any
time an open is detected in a fire zone; or when a fault in a day/night
burglary zone is discovered during a disarmed period. It will be
accompanied by a display of the zone number in trouble.
Displayed in place of the clock when the speaker phone mode is active.
Displayed during a remote phone control session.
ON = System armed
OFF = System disarmed
Blinking = System armed, but a fault exists
Blinking alternately with READY LED = AVM (VOX or Talk) or
speaker phone mode is active
ON = System disarmed, ready to arm
OFF = System armed
Blinking = System disarmed, not ready to arm (a fault exists)
Blinking alternately with ARMED LED = AVM (VOX or Talk) or
speaker phone mode is active.
– 12 –
