Think Appliances Venini_VCH92G User Manual

Cooker hood chimney hood in stainless steel
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual for your
Cooker Hood
Chimney Hood in Stainless Steel
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference.
24/05/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Venini_VCH92G and is the answer not in the manual?

Questions and answers

Related Manuals for Think Appliances Venini_VCH92G

Summary of Contents for Think Appliances Venini_VCH92G

  • Page 1 User Manual for your Cooker Hood Chimney Hood in Stainless Steel NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.

  • Page 2: Table Of Contents

    CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….3 IMPORTANT SAFETY INFORMATION……………………………….…4-5 CARING FOR THE ENVIRONMENT…………………………………………6 USING YOUR COOKER HOOD………………………………..………..7-8 MAINTAINING AND CLEANING YOUR COOKER HOOD …….…….9 MAINTAINING CLEANING THE ANTI GREASE FILTER……..10-11 INSTALLING / CHANGING THE CARBON FILTER ……………12-13 INSTALLATION INSTRUCTIONS ……………………….……...….14-25 ELECTRICAL CONNECTION……………14 INSTALLING THE COOKER HOOD………15-18 FITTING THE CHIMNEY…………………19-20...

  • Page 4: Your Cooker Hood's Specifications

    Specifications of your Cooker Hood Congratulations on purchasing a Cooker Hood! To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual. You will also need this manual to ensure that your Cooker Hood has been installed properly.

  • Page 5: Important Safety Information

    Important Safety Information: Please Read this before installing & using. Any installation work must be o The edges of the cooker carried out by a qualified hood are sharp – be mindful electrician or competent person. of this as you handle your appliance, especially during The hood must be installed in installation and cleaning.
  • Page 6 Important Safety Information: Please read this before installing & using. Please dispose of the packing material carefully – children are especially Do not connect the vulnerable to it. ducting system of this appliance to any existing ventilation system which Always put lids on pots and is being used for any pans when cooking on a gas other purpose.

  • Page 7: Caring For The Environment

    Environmental Note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E.

  • Page 8: Using Your Cooker Hood

    Using your Cooker Hood: To use your cooker hood: 1) Make sure it has been properly installed. 2) Find the CONTROL PANEL. It is located centrally on the hood’s front surface, on the underside of the unit. 3) The CONTROL PANEL contains two rows of switches. These perform separate functions.
  • Page 9 The other is to control the light. LIGHT ON/OFF switch – Slide the ‘C-1’ switch in figure above from ‘0’ to ‘1’. Make sure it has been properly installed. * Note: The hood should be switched on at least as soon as you start cooking.

  • Page 10: Maintaining And Cleaning Your Cooker Hood

    Cleaning your Cooker Hood: PLEASE NOTE THAT YOUR COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE THE HOOD IN RECIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FILTERS (SEE PAGE 12) Before cleaning, always ensure that you IMPORTANT!: have switched your cooker hood OFF at the omni-polar switch, et at the wall from the cable:...

  • Page 11: Maintaining Cleaning The Anti Grease Filter

    Maintenance - Cleaning the Anti-grease Filters Anti-Grease Grille Your cooker hood includes an anti-grease grille which helps absorb vapour-suspended grease particles to protect your kitchen & furniture from greasy residues. The metal grille may become flammable if it becomes saturated with greasy residue. To prevent this fire hazard, the grille should be cleaned regularly (depending on use) every 10-15 days and at least once a month in a dishwasher or in...
  • Page 12 You can now clean the anti-grease filter grilles. Soak them for about one hour in hot water with a grease-loosening detergent then rinse off thorough with hot water. Repeat the process if needed. Refit the grease grille once it has dried. To clean the grease filter gr illes in your dishwasher:...

  • Page 13: Installing / Changing The Carbon Filter

    Maintenance – Changing the Light Bulb and Carbon Filter Changing the light bulb Be o f re changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off at the wall switch). Remove the metal anti-grease filters and find the old bulb l ocated in the light fixture up inside the exposed canopy.
  • Page 14 Changing the Carbon Filters 1) Press the handle of the metal grease filter towards the rear part of the unit until it is released from the front housing, and remove it by pressing downwards (Fig. 2 - above). 2) Remove the old carbon filters by twisting them anticlockwise until they unlatch from the sides of the motor.

  • Page 15: Electrical Connection

    INSTALLATION INSTRUCTIONS – Electrical Connection ELECTRICAL CONNECTION fitted with a power cord & plug for connection to a fitted with a power cord & plug for connection to a 10A power outlet . 10A power outlet . o The power cable must be o The cooker hood’s power cable connected to the terminals must be fitted upstream from the...

  • Page 16: Installation Instructions

    INSTALLATION INSTRUCTIONS – Installing your Cooker Hood PLEASE NOTE THAT YOU WILL HAVE The cooker hood must not TO DECIDE BEFORE INSTALLING YOUR be fitted above stoves with a COOKER HOOD THAT YOU CAN ADAPT radiant top plate. IT AS AN EXTRACTION FAN. We recommend that at least two people install this hood.

  • Page 17: Installation Instructions – Attaching The Hood

    INSTALLATION INSTRUCTIONS – Attaching the Hood Rear view of your cooker hood.
  • Page 18 3) Using a drill bit with an 8 mm diameter, make holes in the wall where you have marked these positions (see next page). 4) Insert the expansion fixings (rawlplugs) in the holes and then screw the support screws halfway in (see below figure, at right). 5) Hook the hood onto the screws (see above figure) and fasten it onto the wall, tightening the support and anchoring screws the rest of the way in (next page, at top.)
  • Page 19 ------------------------------------------------------------------------------------------- 6) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the cooker hood (see below). Then connect the discharge pipe to the coupling as shown below.

  • Page 20: Installation Instructions - Fitting The Chimney

    INSTALLATION INSTRUCTIONS – Fitting the Chimney FITTING THE PIPE – Once your Cooker Hood has been installed, you can now fit the pipe. 1) Take the two casings ‘A’ and ‘B’: 2) Rest the bottom of the casing ‘A’ on the top of the hood, taking care to position the tabs of the casing correctly on the back of the hood as shown as part ‘X’...
  • Page 21 6) Take the fixing bracket ‘G’ (Fig. 4 – previous page), centre it with respect to the mark you previously made, keeping it in contact with the ceiling, and then mark the anchoring holes (‘H’). 7) Using a drill bit with an 8mm diameter, make two holes on the fixing marks you previously made (see below).

  • Page 22: Installation Notes - Extraction / Purifying Version

    Extraction / Air Purifier Modes of Operation EXTRACTION OPERATION – Installation Instructions Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig. 1 – on right).

  • Page 23: Note On Installing The Version With Lower Bracket

    If your Cooker Hood comes with a Lower Bracket Please note that your cooker hood may include a lower bracket. If this is the case, you will need to have it installed as such. This will mean a slight change in how the cooker hood is to be installed from the process shown on page 15.
  • Page 24 Island Hood Installation 1) Position the hanging plate on the ceiling and then mark the position of the screw holes. o The hanging plate should be securely fixed to the ceiling, using the 12 x ST6 (40 mm) screws. o Depending on the surface of the ceiling that you are fixing the hanging plate to, you may need to use 8 x expansion bolts (for concrete).
  • Page 25 2) Fix the angle bars to the hanging plate, using the 8 x M4 nuts and bolts with metal washers. 3) Extend the angle bars to the required height and then fix them in position using the 16 x M4 nuts and bolts with metal washers.
  • Page 26 6) If the glass canopy has not been pre- assembled by the factory, then it should be fixed to the top of the main body of the cooker hood at this stage. 7) Lift the main body of the cooker hood onto the angle bar and then fix it into position using the 16 x M4 bolts.

  • Page 27: Troubleshooting

    Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom Solution • Check that the hood is connected to the electricity supply. The cooker hood will not start! •...

  • Page 28: My Appliance Isn't Working Correctly

    Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance. This guarantee is in addition to and does not diminish your statutory or legal rights. If you have any further questions please contact Think Appliances Pty Ltd SERVICE DEPARTMENT SALES DEPARTMENT...
