User Manual for your
GEH6017 & GEH9017
Cooker Hood
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference.
Advertisement
Table of Contents
Related Manuals for Think Appliances GEH6017
Summary of Contents for Think Appliances GEH6017
- Page 1 User Manual for your GEH6017 & GEH9017 Cooker Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.
-
Page 2: Table Of Contents
CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….2 IMPORTANT SAFETY INFORMATION……………………………….…3-4 CARING FOR THE ENVIRONMENT…………………………………………5 USING YOUR COOKER HOOD………………………………..……………..6 MAINTAINING AND CLEANING YOUR COOKER HOOD ……….7-9 INSTALLATION INSTRUCTIONS ……………………….……...….10-11 ELECTRICAL CONNECTION……………10 INSTALLING THE COOKER HOOD……11 TROUBLESHOOTING ……………………………………………12 CONDITIONS OF GUARANTEE……………………………………………13 HT 21/09/11... -
Page 4: Your Cooker Hood's Specifications
Specifications of your GEH6017 & GEH9017 Cooker Hood To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual. You will also need this manual to ensure that your Cooker Hood has been installed properly. -
Page 5: Important Safety Information
Important Safety Information: Please read this before installing & using. Any installation work must be DO NOT SET YOUR * NOTE - carried out by a qualified COOKER HOOD LESS THAN electrician or competent person. 600MM ABOVE YOUR COOKER! The hood must be installed in o When installed between accordance with the installation adjoining wall cabinets,... -
Page 6: Important Safety Information
Important Safety Information: Please read this before installing & using. Ensure that proper o Ensure the ducting for ventilation measures are the extractor function being observed. Note has the same diameter as that it removes odours the outlet hole all the from your room, not way through. -
Page 7: Caring For The Environment
Never flambé cook under damaged in any way. Never attempt to use it this cooker hood . without the grease filters fitted or if the filters are excessively greasy! Environmental Note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. -
Page 8: Using Your Cooker Hood
Using your Cooker Hood: To use your cooker hood: 1) Make sure it has been properly installed. 2) Find the CONTROL PANEL. It is located centrally on the hood’s front surface, on the underside of the unit. 3) The CONTROL PANEL contains two rows of switches. These perform separate functions. -
Page 9: Maintaining And Cleaning Your Cooker Hood
Cleaning your Cooker Hood: Before cleaning, always ensure that you have IMPORTANT: switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable: Cleaning Clean the external parts with Be sure to replace the mild liquid detergents on a carbon filters at the damp cloth. - Page 10 Maintenance - Cleaning the Anti-grease Filters Please Read this before installing & using. First remove the grille by pulling down on it. Undo the side catches. You can now clean the anti-grease filter grilles. Soak them for about one hour in hot water with a grease-loosening detergent then rinse off thoroughly with hot water.
- Page 11 The active carbon filter must be replaced regularly, at least once every four months, to allow normal operation when in recirculation mode. Before starting to fit the carbon filter, turn the omni-polar switch OFF Changing the Carbon Filter – Note: carbon filters cannot be cleaned! 3) Place the new carbon filter (which has two fixing tongues), turning clockwise so that the tongues...
-
Page 12: Installation Instructions
o The power cable must be o The cooker hood’s power cable connected to the terminals must be fitted upstream from the marked L (live) and N (neutral) electrical connection using an in the hood and fixed with a omni-polar switch with a contact cable clamp. -
Page 13: Installing The Cooker Hood
Your Cooker Hood should only be fitted into the underside of a dedicated cabinet / kitchen unit. DO NOT position it any less than 700 mm (70 cm) above the hob or let other cabinets overhang the hob. Remove the metal anti-grease grille. Drill where indicated. -
Page 14: Troubleshooting
Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might prevent you from having to call for service. Symptom Solution Check that the hood is connected to the electricity supply. The cooker hood will not start! ... - Page 15 Think Appliances Pty Ltd. 416-424 Barry Rd Coolaroo VIC 3048 Sales Telephone 1300 132 824 Service Telephone 1800 444 357 Website www.thinkappliances.com Applico Ltd. P.O. 92900 Onehunga, Auckland, New Zealand 1061 Website www.applico.nz United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road,...
