Think Appliances BAH61 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual for your
BAH61&BAH91
BAH60&BAH90
BAH93CG&BAH93CGIS
BAH94FG&BAH94FGIS
Cooker Hood
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAH61 and is the answer not in the manual?

Questions and answers

Related Manuals for Think Appliances BAH61

Summary of Contents for Think Appliances BAH61

  • Page 1 User Manual for your BAH61&BAH91 BAH60&BAH90 BAH93CG&BAH93CGIS BAH94FG&BAH94FGIS Cooker Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.

  • Page 2: Table Of Contents

    CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….3 IMPORTANT SAFETY INFORMATION……………………………….…4-5 CARING FOR THE ENVIRONMENT…………………………………………6 USING YOUR COOKER HOOD …………………..………….…..7-10 MAINTAINING AND CLEANING YOUR COOKER HOOD …….11-14 INSTALLATION INSTRUCTIONS ……………………….……...….15-25 ELECTRICAL CONNECTION……………15 INSTALLING THE COOKER HOOD………16-18 FITTING THE CHIMNEY…………………19-21 INSTALLATION NOTES – EXTRACTION / PURIFYING VERSION .….21 NOTE ON INSTALLING THE VERSION WITH LOWER BRACKET.…22-25 TROUBLESHOOTING ……………………………………………26 CONDITIONS OF GUARANTEE……………………………………27-28...
  • Page 3 We also carry a complete range of spare parts for all Think products. For all your spare parts enquiries please contact our team at Pronto Parts on: 1300 306 973 Again, thank you for choosing an appliance brought to you by Think Appliances and we look forward to being of service to you. Kind regards...

  • Page 4: Specifications Of Your Cooker Hood

    Please see the installation section of this manual for details. Model Width control light Extraction Carbon (mm) Capacity filter BAH61 Electronic 2*3W button BAH91 Electronic 2*3W button BAH60 Push button 2*20W halogen...

  • Page 5: Important Safety Information

    Important Safety Information: Please Read this before installing & using. Any installation work must be Electric cookers: carried out by a qualified 600 mm electrician or competent person. Gas cookers: 600 mm The hood must be installed in accordance with the installation instructions and all measurements DO NOT SET YOUR * NOTE -...
  • Page 6 Important Safety Information: Please read this before installing & using. Always put lids on pots and pans when cooking o If other types of flue or on a gas cooker. appliances are fitted, ensure that there is an The manufacturer adequate supply of air in refuses to accept any the room.

  • Page 7: Environmental Note

    ventilation system which Do not attempt to use is being used for any the cooker hood if it is other purpose. damaged in any way. Never attempt to use it Do not install above a without the grease filters cooker with a high level fitted or if the filters are grill.

  • Page 8: Using Your Cooker Hood

    Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E.
  • Page 9 Make sure it has been properly installed. Find the CONTROL PANEL. It is located at the front of the canopy, to the right. The CONTROL PANEL contains buttons as shown in the Figure below. These perform separate functions. You will need to understand what these buttons do before you attempt to use your cooker hood.
  • Page 10 Before operating the hood, make sure that it has been installed by a suitably qualified person, as per the information contained in installation instructions. 1) Find the control panel, which is located in the front middle of the canopy. 2) There are several buttons on the control panel, which perform separate functions.
  • Page 11 7) Use the same buttons as before to adjust the number shown on the LED display. 8) Press the timer button for a third time and this will confirm the time of day setting. Setting the fan speed 1) Press the ON/OFF button to switch the hood on; the LED display backlight will switch on.
  • Page 12 4) It is useful to use this feature when you have finished cooking. You can press the timer button and the hood will run on to extract any remaining odours and then switch itself off without you needing to return to the kitchen. To use your cooker hood (Electronic button) o You should use a good quality stainless steel cleaner and polish on ALL of the stainless steel areas of your cooker hood, before it is used...

  • Page 13: Cleaning Your Cooker Hood

    PLEASE NOTE THAT YOUR COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE THE HOOD IN RECIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FILTERS. Cleaning your Cooker Hood: Before cleaning, always ensure that you have IMPORTANT: switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable:...
  • Page 14 days and at least once a month in hot water with normal washing-up detergent. DO NOT USE A DISHWASHER TO ACHIEVE THIS. Maintenance - Cleaning the Anti-grease Filters First remove the grille by pulling down on it. Undo the side catches. You can now clean the anti-grease filter grilles.
  • Page 15 discolouration of the grille –its performance won’t be affected. Let the filter grilles dry thoroughly before refitting them. Maintenance – Changing the Light Bulb and Carbon Filter Changing the light bulb a) Changing the light bulb 1) Before changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off at the omni- polar switch on...

  • Page 16: Installing / Changing The Carbon Filter

    Installing / Changing the Carbon Filter. Your Cooker Hood uses a pair of CARBON FILTERS to purify the air for the air recirculation function. You will find that the filters will attach to both sides of the fan motor (please see figures at bottom of page).
  • Page 17 INSTALLATION INSTRUCTIONS Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home.
  • Page 18 NOTE: WARNING – THIS APPLIANCE MUST BE EARTHED. It should only be connected by a competent person using the 10A plug and a suitable switched 10A GPO. See the bottom picture on right – wire diagram. We recommend that the appliance is connected by a qualified electrician who will comply with loca regulations.
  • Page 19 2) Position the hood against the wall and mark the position of the support holes that are to be drilled as shown in the figure below. These support holes can be found on Fig. 4 on next page marked as ‘D’ with the anchoring holes marked as ‘E’...
  • Page 20 INSTALLATION INSTRUCTIONS – Attaching the Hood Rear view of your cooker hood. -------------------------------------------------------------------------- 3) Using a drill bit with a 6 mm diameter, make holes in the wall where you have marked these positions (see below).

  • Page 21: Installation Instructions – Attaching The Hood

    INSTALLATION INSTRUCTIONS – Attaching the Hood 4) Insert the expansion fixings (rawlplugs) in the holes and then screw the support screws halfway in (see below figure, at right). 5) Hook the hood onto the screws (see above figure) and fasten it onto the wall, tightening the support and anchoring screws the rest of the way in (next page, at top.) -------------------------------------------------------------------------------------------...
  • Page 22 INSTALLATION INSTRUCTIONS – Fitting the Chimney specifications shown in the notes on Extraction / Air Purifier (Recirculation) Modes on p.18. FITTING THE PIPE – Once your Cooker Hood has been installed, you can now fit the pipe.

  • Page 23: Installation Instructions

    1) Take the two casings ‘A’ and ‘B’: 2) Rest the bottom of the casing ‘A’ on the top of the hood, taking care to position the tabs of the casing correctly on the back of the hood as shown as part ‘X’ in Figure 4 at right.
  • Page 24 contact with the ceiling, and then mark the anchoring holes (‘H’). 7) Using a drill bit with a 6mm diameter, make two holes on the fixing marks you previously made (see below). 8) Insert the expansion fixings (rawlplugs) provided, put bracket ‘G’...
  • Page 25 Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig. 1 – on right). Using a 125 mm diameter pipe, connect the union (N) on the upper part of the hood (see Fig.
  • Page 26 Please note that your cooker hood may include a lower bracket. If this is the case, you will need to have it installed as such. This will mean a slight change in how the cooker hood is to be installed from the process shown on page 13. In Fig.
  • Page 28 1) Position the hanging plate on the ceiling and then mark the position of the screw holes. o The hanging plate should be securely fixed to the ceiling, using the 12 x ST6 (40 mm) screws. o Depending on the surface of the ceiling that you are fixing the hanging plate to, you may need to use 8 x expansion bolts (for concrete).
  • Page 29 3) Extend the angle bars to the required height and then fix them in position using the 16 x M4 nuts and bolts with metal washers. o IMPORTANT: The angle bars must have an overlap of AT LEAST 100 mm. 4) If your cooker hood is going to be used in extraction mode, then you should connect the ducting hose to the ceiling adaptor at this point.
  • Page 30 7) Lift the main body of the cooker hood onto the angle bar and then fix it into position using the 16 x M4 bolts. o IMPORTANT: This stage of the installation process MUST be completed by two people. o IMPORTANT: The 16 x M4 bolts MUST be securely tightened.

  • Page 31: Troubleshooting

    Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom Solution • Check that the hood is connected to the electricity supply. The cooker hood will not start! •...
