User Manual for your
BH600&BH700&BH900
Cooker Hood
Chimney Hood in Stainless Steel
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference.
06/05/11
Advertisement
Table of Contents
Related Manuals for Think Appliances BH600
Summary of Contents for Think Appliances BH600
- Page 1 User Manual for your BH600&BH700&BH900 Cooker Hood Chimney Hood in Stainless Steel NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.
-
Page 2: Table Of Contents
CONTENTS SPECIFICATIONS OF YOUR COOKER HOOD ………………………….3 IMPORTANT SAFETY INFORMATION……………………………….…4-5 CARING FOR THE ENVIRONMENT…………………………………………6 USING YOUR COOKER HOOD……………………………………………….7 MAINTAINING AND CLEANING YOUR COOKER HOOD ……. 8-12 Cleaning the anti-grease filter………………………... 9-10 Changing the Light Bulb…………………………………. Changing & Installing Carbon Filter………………… 11-12 INSTALLATION INSTRUCTIONS ……………………….……...….12-20 Electrical Connection………………………………………... -
Page 4: Specifications Of Your Cooker Hood
Please see the installation section of this manual for details. Model Width control light Extraction Carbon (mm) Capacity filter BH600 Electronic Button 2*3W (AYD-001) BH700 Electronic Button 2*3W (AYD-001) BH900 Electronic Button 2*3W (AYD-001) -
Page 5: Important Safety Information
IMORTANT SAFETY INFORMATION: Please read this before installing Any installation work must be o The edges of the cooker carried out by a qualified hood are sharp – be electrician or competent person. mindful of this as you handle your appliance, The hood must be installed in especially during accordance with the installation... - Page 6 Older children and infirm o If the supply cord is persons should be damaged it must be supervised if they are replaced by the using the cooker hood. manufacturer or service agent in order to avoid Please dispose of the hazard.
-
Page 7: Caring For The Environment
CARING FOR THE ENVIRONMENT THE MANUFACTURER DECLINES ALL RESPONSIBILITY IN THE EVENT OF FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR INSTALLATION, MAINTENANCE AND SUITABLE USE OF THE HOOD Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. -
Page 8: Using Your Cooker Hood
USING YOUR COOKER HOOD To use your cooker hood: Make sure it has been properly installed. Find the CONTROL PANEL. It is located at the front of the canopy. You have a Pushbutton control panel that looks like the one pictured below. The CONTROL PANEL’s buttons all perform separate functions. -
Page 9: Maintaining And Cleaning Your Cooker Hood
MAINTAINING AND CLEANING YOUR COOKER HOOD PLEASE NOTE THAT YOUR COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE THE HOOD IN RECIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FILTERS (SEE PAGE 10-11) Before cleaning, always ensure that you IMPORTANT!: have switched your cooker hood OFF at the omni-polar... - Page 10 Maintenance – Cleaning the Anti-grease Filters First remove the grille by pulling down on it. Undo the side catches. You can now clean the anti-grease filter grilles. Soak them for about one hour in hot water with a grease-loosening detergent then rinse off thoroughly with hot water.
-
Page 11: Changing The Light Bulb
Maintenance – Changing the Light Bulb and Carbon Filter Changing the light bulb Before changing the light bulb, ensure that the appliance is not live (i.e. ensure that you have switched it off at the wall switch). Remove the metal anti-grease filters (see Figure 2 on the next page) and find the old bulb located in the light fixture up inside the exposed canopy. - Page 12 Changing the Carbon Filters 1) Press the handle of the metal grease filter towards the rear part of the unit until it is released from the front housing, and remove it by pressing downwards (Fig. 2 - above). 2) Remove the old carbon filters by twisting them anticlockwise until they unlatch from the sides of the motor.
- Page 13 INSTALLATION INSTRUCTIONS – Electrical Connection. Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home.
-
Page 14: Installation Instructions
INSTALLATION INSTRUCTIONS – Installing your Cooker Hood PLEASE NOTE THAT YOU WILL HAVE The cooker hood must not TO DECIDE BEFORE INSTALLING YOUR be fitted above stoves with a COOKER HOOD THAT YOU CAN ADAPT radiant top plate. IT AS AN EXTRACTION FAN. We recommend that at least two people install this hood. -
Page 15: Attaching The Hood
INSTALLATION INSTRUCTIONS – Attaching the Hood Rear view of your cooker hood. -------------------------------------------------------------------------- 3) Using a drill bit with an 8 mm diameter, make holes in the wall where you have marked these positions (see next page). - Page 16 -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 4) Insert the expansion fixings (rawlplugs) in the holes and then screw the support screws halfway in (see below figure, at right). 5) Hook the hood onto the screws (see above figure) and fasten it onto the wall, tightening the support and anchoring screws the rest of the way in (next page, at top.) -------------------------------------------------------------------------------------------...
- Page 17 INSTALLATION INSTRUCTIONS – Attaching the Hood ------------------------------------------------------------------------------------------- 6) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the cooker hood (see below). Then connect the discharge pipe to the coupling as shown below. Remember that your ducting will have to match the specifications shown in the notes on Extraction / Air Purifier (Recirculation) Modes on p.20.
-
Page 18: Installation Instructions - Fitting The Chimney
INSTALLATION INSTRUCTIONS – Fitting the Chimney FITTING THE PIPE – Once your Cooker Hood has been installed, you can now fit the pipe. 1) Take the two casings ‘A’ and ‘B’: 2) Rest the bottom of the casing ‘A’ on the top of the hood, taking care to position the tabs of the casing correctly on the back of the hood as shown as part ‘X’... - Page 19 6) Take the fixing bracket ‘G’ (Fig. 4 – previous page), centre it with respect to the mark you previously made, keeping it in contact with the ceiling, and then mark the anchoring holes (‘H’). 7) Using a drill bit with an 8mm diameter, make two holes on the fixing marks you previously made (see below).
- Page 20 8) Insert the expansion fixings (rawlplugs) provided, put bracket ‘G’ (see Fig. 4 on previous page) in position and secure it with the screws provided. 9) Lift casing ‘B’ up to the ceiling and secure it to the bracket ‘G’, inserting the screws provided in the holes ‘M’...
- Page 21 AIR PURIFIER (RECIRCULATION) OPERATION - Installation Instructions Extraction / Air Purifier Modes of Operation EXTRACTION OPERATION – Installation Instructions Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig.
-
Page 22: If Your Cooker Hood Comes With A Lower Bracket
* Note on what to do if your Cooker Hood is the version that comes with a BRACKET. If your Cooker Hood comes with a Lower Bracket Please note that your cooker hood may include a lower bracket. If this is the case, you will need to have it installed as such. This will mean a slight change in how the cooker hood is to be installed from the process shown on pages 13-15. -
Page 23: Troubleshooting
Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom Solution • Check that the hood is connected to the electricity supply. The cooker hood will not start! •... - Page 24 Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance. This guarantee is in addition to and does not diminish your statutory or legal rights. If you have any further questions please contact Think Appliances Pty Ltd:...
- Page 25 SERVICE DEPARTMENT Phone: 1800 444 357 Fax: 1300 133 279 Email:service@thinkappliances.com SALES DEPARTMENT Phone: 1300 132 824 Fax: 1300 660 188 Web: www.thinkappliances.com SPARE PARTS DEPARTMENT Phone: 1300 306 973 Fax: 1300 887 306...
