- Page 1 User Manual for your BAH6019 Cooker Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.
- Page 2 CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….2 IMPORTANT SAFETY INFORMATION……………………………….…3-4 CARING FOR THE ENVIRONMENT…………………………………………5 USING YOUR COOKER HOOD………………………………..……………..6 MAINTAINING AND CLEANING YOUR COOKER HOOD ……….7-9 INSTALLATION INSTRUCTIONS ……………………….……...….10-11 ELECTRICAL CONNECTION……………10 INSTALLING THE COOKER HOOD……11 TROUBLESHOOTING ……………………………………………12...
- Page 3 CONDITIONS OF GUARANTEE……………………………………………13 HT 09/03/08 Specifications of your GEH6019 Cooker Hood Congratulations on purchasing a Cooker Hood! To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual.
-
Page 4: Important Safety Information
NOTE: PLEASE NOTE THAT YOUR COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE THE HOOD IN RE- CIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FILTER. IF YOU WANT TO USE YOUR COOKER HOOD IN EXTRACTOR MODE, YOU WILL NEED TO FIT DUCTING (DIAMETER OF 125MM) TO THE SPIGOT (SEE INSTALLATION DIAGRAM) AND WORK IT THROUGH A HOLE OF 130MM SO THAT IT IS EXPELLING FUMES THROUGH A DEDICATED FLUE SYSTEM THAT ISN’T... -
Page 5: Important Safety Information
function, ensure that the observe fire safety advice ducting is fire retardant in these instructions. and that there are no o Remember that when in bends sharper than 90 extraction mode, your degrees as this will cooker hood is removing reduce the efficiency of air from your room. -
Page 6: Environmental Note
overheated fats and oils damaged in any way. might catch fire. Never attempt to use it without the grease filters Do not leave naked fitted or if the filters are flames under the cooker excessively greasy! hood. Never flambé cook under ... -
Page 7: Using Your Cooker Hood
Using your Cooker Hood: To use your cooker hood: 1) Make sure it has been properly installed. 2) Find the CONTROL PANEL. It is located centrally on the hood’s front surface, on the front of the unit. 3) The CONTROL PANEL contains buttons as shown in the Figure below. These perform separate functions. -
Page 8: Cleaning Your Cooker Hood
‘U’ – Light ‘on/off’ button-This button controls the light Cleaning your Cooker Hood: Before cleaning, always ensure that you have IMPORTANT: switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable: Cleaning Clean the external parts with ... - Page 9 days and at least once a month in hot water with normal washing-up detergent. DO NOT USE A DISHWASHER TO ACHIEVE THIS. Maintenance - Cleaning the Anti-grease Filters Please Read this before installing & using. First remove the grille by pulling down on it. Undo the side catches.
- Page 10 Let the filter grilles dry thoroughly before refitting them. Maintenance – Changing the Light Bulb and Carbon Filter Changing the LIGHT BULB Disconnect the hood from the power supply. Access the lamp area. Please note that you will have to take off the ...
-
Page 11: Installation Instructions
up with the ‘Y’ on the Position the filter P in order conveyor. Then turn to cover the motor clockwise. Reverse to protection grille, ensuring dismount that the ‘X’ on the filter lines INSTALLATION INSTRUCTIONS - Electrical Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home. -
Page 12: Installation Instructions
2) The BROWN coloured RED WIRE must be (Fig. 7 – at left ) connected to the terminal marked ‘L’ (‘Live’), or INSTALLATION INSTRUCTIONS – installing your Cooker Hood The cooker hood must not PLEASE NOTE THAT YOU WILL HAVE be fitted above stoves with a TO DECIDE BEFORE INSTALLING YOUR radiant top plate. - Page 13 65cm 75cm Way two:Mounting under a wall unit 1. Drill 6 holes of 4mm diameter at the bottom of the hanging cupboard 2. Put the one way valve on the cooker hood, then install the cooker hood on the bottom of the cupboard, tighten the hood with enclosed 6 screws.
-
Page 14: Troubleshooting
Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom Solution Check that the hood is connected to the electricity supply. The cooker hood will not start! Check that the fan speed control is set properly. - Page 15 Think Appliances will provide free of charge the parts required to repair the appliance during the warranty period,only if they are fitted by a qualified technician(for this phone Think appliances),for any...
- Page 16 In the course of the work carried out it may be necessary to remove the appliance from its operating position.Whilst all reasonable care will be taken,Think Appliances cannot accept responsibility for damage sustained to any property whatsoever in this process.
- Page 17 This guarantee is in addition to and does not diminish your statutory or legal rights. If you have any further questions please contact Think Appliances Pty Ltd: SERVICE DEPARTMENT Phone:1800 444 357 Fax:1300 133 279 Email:service@thinkappliances.com SALES DEPARTMENT Phone:1300 132 824 Fax:1300 660 188 Web:www.thinkappliances.com...
