WPA-1000
802.11g Wireless Projector Adapter

Quick Start Guide

Version 1.00
3/2007
Edition 1
Copyright © 2007. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPA-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZyXEL Communications WPA-1000

  • Page 1: Quick Start Guide

    WPA-1000 802.11g Wireless Projector Adapter Quick Start Guide Version 1.00 3/2007 Edition 1 Copyright © 2007. All rights reserved.
  • Page 2: Setup Overview

    WEP security. This Quick Start Guide shows how to connect to the WPA-1000 with an Ethernet cable in order to set it up and secure the wireless connection. (If the wireless connection is not secure, people in adjacent rooms may be able to view your presentation.) It also shows...
  • Page 3: Hardware Connections

    • Restart your device. 5 Look at the LEDs (lights). • The STATUS LED shows orange while the WPA-1000 is starting up, and green when it is ready. • The LAN LED blinks while sending/receiving data, then shows a steady green when it has a successful connection.
  • Page 4: The Standby Screen

    • Check the projector is turned on and working properly. • Check your grey VGA cable is securely attached to the WPA-1000 and to the projector. Write down the Server IP on the screen for use when connecting to the web configurator.
  • Page 5 WPA-1000 Quick Start Guide 1 Open an Internet browser such as Internet Explorer on your computer. 2 Type the Server IP address displayed on the standby screen in the web address field of your Internet browser (the default IP address is 192.168.1.10). Press [ENTER].
  • Page 6 7 Set the ESSID that you want every user to see when they scan for available wireless devices. The ESSID identifies a wireless network. The ESSID is WPA-1000 by default. 8 Type a Key in the screen. Make sure the key is the correct length and type of character according to the type of Key you choose.
  • Page 7 WPA-1000’s wireless network. When the WPA-1000 restarts, check the standby screen displayed on the projection screen. To connect to the WPA-1000, participants must use the same ESSID, channel and security settings as the WPA-1000. Write down the following details for use when connecting wirelessly to the WPA-1000 and using the WPA-1000 utility.
  • Page 8 2 Type the Server IP address displayed on the standby screen in the web address field of your Internet browser (the default IP address is 192.168.1.10). Press [ENTER]. 3 Click Download in the screen below to download the WPA-1000 utility file and save it to a location on your computer.
  • Page 9 ) on your desktop or click Start > Programs > WPA- 1000 to start the WPA-1000 utility. A control panel appears. 2 Press the play button ( 3 The WPA-1000 utility searches for available projectors. Choose the projector with the Device Name shown in the standby screen.
  • Page 10 4 Type the Login Code that appeared in the standby screen. Then press [ENTER]. . 5 The projector displays the content on your computer monitor. The PLAY LED blinks when your WPA-1000 is successfully projecting. 6 Control your presentation using the WPA-1000 utility’s functions described below. BUTTON DESCRIPTION...
  • Page 11 2 Ask the network administrator whether you have permission to join the network. For example, check you are not “kicked” out. 3 Check your operating system (OS). The WPA-1000 utility is only compatible with Windows XP and Windows 2000. Viewing Your Product’s Certifications 1 Go to http://www.zyxel.com.
