How to Realize Single Image Switching

CP 3096H can realize seamless effects switch between two channels, choose the signal in PREVIEW
area, then push the [TAKE] button, the signal will be switched to LED display.
For example, switch VGA to LED display, first push the [VGA] button in PREVIEW area, then push the
[TAKE] button or T-bar in effects switch control area, the LED display will show VGA signal.
System default the switch time is 1 seconds for [TAKE] button, if need to adjust the fade time, turn the
knob in transition time control area, and set according to actual need, push the [TAKE] button again, the
signal will be switched to the LED display with the adjusted time.
User can also switch the signal by pushing the signal button in PROGRAM area, but the signal in
monitor will not change.

How to Scale the Image

1. Push the [SCALE] button in function area and enter to the scale function menus.
2. Turn the knob, choose H SIZE or V SIZE and set according to actual need, user can adjust the items
by knob or number buttons, after setting, push the knob to confirm.
3. If image quality distorts by improper operation, it can be recover by reset.

How to Crop the Image

1. Push the [CROP] button in function area and enter to the crop function menus.
2. Turn the knob, choose H SIZE, V SIZE, H POS or V POS, and set according to actual need, user
can adjust the items by knob or number buttons, after setting, push the knob to confirm.
3. If image quality distorts by improper operation, it can be recover by reset.
Note: The setting is only for the selected input signal.
