Back Panel

Input Interface
5~10 Audio input port
14 USB input USB-B port
15 HDMI input HDMI-A port
16 DVI input DVI-I port
17 VGA input DSUB15 port
18 CVBS input BNC port
19~21 S.H.D.U.V.C optional module
Other Interface
1 Dial Switch
2 USB Interface
3. 4 RS-232 Interface
13 Switch
19 Power IEC-3
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Output Interface
11. 12 Audio output port
22 DVI preview output DVI-I port
23 DVI output DVI-I port
24 DVI+VGA output DVI-I port
25. 26 3G-SDI output BNC port
27. 28 CVBS output BNC port
