ZY INTERNATIONAL LIMITED
GPSTrackerManual_TK107
GPS TRACKER TK-107
USER MANUAL
Preface
U
Thank you for purchasing GPS Vehicle Tracker. This manual shows how to operate the device
smoothly and correctly. Make sure to read this manual carefully before using this product. Please note
that specification and information are subject to changes without prior notice in this manual. Any
change will be integrated in the latest release. The manufacturer assumes no responsibility for any
errors or omissions in this document.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ZY International TK-107
Summary of Contents for ZY International TK-107
- Page 1 ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 GPS TRACKER TK-107 USER MANUAL Preface Thank you for purchasing GPS Vehicle Tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.
-
Page 2: Table Of Contents
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Content 1 Summary ------------------------------------------------------------------------------------------------- 2 Application ------------------------------------------------------------------------------------------------ 3 Hardware Description -------------------------------------------------------------------------------- 3.1 Front Face ------------------------------------------------------------------------------------ 3.2 Rear Face -------------------------------------------------------------------------------------- 3.3 Interior --------------------------------------------------------------------------------------- 4 Specifications ---------------------------------------------------------------------------------------- 5 SIM Card Installation ------------------------------------------------------------------ 6 Startup ------------------------------------------------------------------------------------- ----------- 7 Usage... -
Page 3: Application
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Monitoring Mode ------------------------------ --------- -------- 10 Talking Mode ------------------------------ --------- -------- 11 GPRS Setting -------------------------------------------------------------------- 12 Cautions --------------------------------------------------------------------- 13 Faults & Solutions --------------------------------------------------------------------- 14 commands ------------------------------------------------------------------------ 1 Summary Working based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or GPRS,and guard against theft of Vehicle. -
Page 4: Rear Face
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Speaker SOS Button USB Port,for charging and upgrade the firmware For call GPS indicator light GSM indicator light Microphone Working modes indicator light Rear Face Battery back cover SIM Card SD Card... -
Page 5: Interior
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Interior Battery 4 Specs. Content Specs. Dim. 80MM*56MM*22MM Weight Network GSM/GPRS Band 850/ 900/1800/1900Mhz GPS chip SIRF3 chip GSM/GPRS Simcom900 module GPS sensitivity -159dBm GPS accuracy Reacquisition 0.1s Cold status 45s Time To First Fix Warm status 35s... -
Page 6: Sim Card Installation
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Battery DC5V input Battery Chargeable changeable 3.7V 800mAh Li-ion battery Standby 100hours Storage Temp. -40°C to +85°C Operation Temp. -20°C to +55°C Humidity 5%--95% non-condensing 5 SIM card installation Make sure that there is no call transfer and call display is on, and PIN code off. -
Page 7: Startup
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 After SD card is mounted， Fasten downwards ,make sure the SD card is mounted Fasten the simcard rightwards Fasten the cover Put the battery upwards 6 Startup Put the SIM card and SD card in place,install batteries locator will automatically boot. -
Page 8: Usage
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 is you can play the following Settings. (note: blue lights on time with the current GPS signals about, the current not GPS signals blue lamp will not bright. 7 Usage The tracker has three working modes: Tracking mode，Monitor mode , Double-way Commnication mode ,Modes switch between “Tracking”, “Monitor”... -
Page 9: Authorization
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.3 Authorization 8.3.1 Send SMS “admin+ password+ space+ cell phone number”to set the first authorized number, it will reply “admin ok”, The other authorized numbers should be set by the first authorized number.(PS: There are only 5 numbers able to be authorized) 8.3.2 Send SMS noadmin+password+space+authorized number to cancel the... -
Page 10: Auto-Track
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 1 == charging 0 means no charging Signal:F ==== Full GPS signal 0 means weak GPS signal 354776031555474== IMEI号 05=quantity of satellites ( from 3 to 12 ) 43.5=Altitude 460 = MCC Mobile Country Code 01 == MNC... -
Page 11: Tlimit Function
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 From:13188888888 T030s***n ok 8.4.2 Send SMS t030s***n+password to the unit, it will reply SMS heaps of times. You will receive a reply as “t030s005n OK” ( t030s***n ok ) if the setting is successful. 8.4.3 Cancel: Send notn+password to delete the “ auto track “,it will reply “notn ok”。... -
Page 12: Gps Refurbish Setting
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.6 GPS-refresh setting Send SMS “GpsAutoSearch123456 120”，it will reply “GpsAutoSearch ok”. The tracker will search gps signal in 120s interval after setting this. The refreshing time is between 120-600 seconds(120<interval <600) (note: Longer standby time for longer refreshing time and shorter standby time for shorter refreshing time.) -
Page 13: Movement Alert
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.8.2 Cancel:Send SMS “nostockade+password” to deactivate this function.It will reply “nostockade ok”。 From:13188888888 TO:13188888888 nostockade ok nostockade123456 This function will be out of effect after the unit moves outside the district. 8.8.3 Response SMS format: stockade!+geo-info. It will alarm one time in each setting. -
Page 14: Overspeed Alert
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 TO:13188888888 From:13188888888 move123456 move ok 8.9.2 Cancel: Send SMS nomove+password to deactivate the movement alert,it will reply move ok This function will be invalid after getting one movement alert Response SMS format: :move!+geo-info. It will alarm one time in each setting. - Page 15 ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 TO:13188888888 From:13188888888 speed123456 080 speed ok 8.10.2 Cancel: Send SMS”nospeed+password “to deactivate the overspeed alert,it will reply” nospeed ok。” TO:13188888888 From:13188888888 nospeed123456 nospeed ok Response SMS format: speed+080!+Geo-info (suppose the speed is 80km/h). The tracker will check the speed in 3 minutes interval and alarm if it is overspeed.
-
Page 16: Imei Checking
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Remark: It is recommended that the speed alarm is set at not less than 80km/h. in order to make this function accurate 8.11 IMEI Checking: Send SMS” imei+password: to the unit,it will reply imei350001122222222 ok. TO:13188888888... -
Page 17: Smslink
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.13 SOS Button Press the SOS for 3 second, it will send “help me !+ Geo-info” to all the authorized numbers every 3 minutes. It will stop sending such a SMS when one of the authorized number reply SMS ”... -
Page 18: Smsone
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.15 SMS ONE Send “smsone+password”.The tracker will reply one SMS to admin number or gprs server. The same function with real-time tracking, but no need to call just send this command 8.16 Low Battery Alert When the battery inside is less than 3.7 V, it will send low battery alert to admin number 8.17 SMS Center ( or appointed number) -
Page 19: Motion Sensor
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.19 Motion Sensor（This function is used to protect the vehicel or tracker when it is touched.） 8.19.1 Setup: Send shake+password+space+1-10 to the tracker to set up this function.(1-10 means the level of intensity) 8.19.2 Send SMS shake+password+space+1 is the least sensitivity . Have to shake the tracker strongly to get the alert. -
Page 20: Monitoring Mode
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 8.21.1 Switch off Press TALK button and SOS button for three seconds, the green indicator will flash quickly until it is off. 8.21.2 Switch on Press TALK button and SOS button for three seconds, the green indicator will flash quickly until it is on. - Page 21 ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 stop calling if any authorized number picks up the calling. 10.4 Press TALK button for 3 seconds to cancel the double-communication or authorized number-calling 111 GPRS setting APN(access point name), IP, PORT have to be set up for gprs function. Apn user, apn password have to be set up also if there are.
-
Page 22: Gprs Setting
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Cancel: The old APN will be invalid automatically when a new APN is set. 11.4 Set APN’s User Name Setup: Send SMS apnuser+123456+space+the sim card’s user name. Send SMS apnuser+123456+space+the APN's user name If setup successful, the tracker will reply SMS “apnuser ok”. -
Page 23: Cautions
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 12 Cautions Please comply with the instructions to extend the unit life: 1. Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry. 2. Don’t use & store the unit in dusty places. -
Page 24: Commands
ZY INTERNATIONAL LIMITED GPSTrackerManual_TK107 Don’t use it in the place beyond reach of signals. Place the Location report in unit outdoors, especially when starting it up. digits of zeros. (Remark: There are two ways for the times of sending alarm in each setting.one time and heap of times,which is according to the customer’s requirements, this... - Page 25 Setup APN username apnuser+123456+space+The APN'S USER NAME apnpasswd+123456 +space+THE APN'S Setup APN password PASSWORD Setup IP address & Port adminip+password+space+ip address+space+port Cancel IP address & Port noadminip+password ZY INTERNATIONAL LIMITED (Alibaba Gold Supplier) Website: http://www.zhyichina.com http://www.zhyichina.cn E-Mail: info@zhyichina.com MSN: sales@zhyichina.com Wholesale:...
