ZY International MT-200 User Manual

Automatic vehicle locator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ZY INTERNATIONAL LIMITED
GPSTrackerManual_MT200
MT-200
Automatic Vehicle Locator User Manual
Version 2.0
ZY INTERNATIONAL LIMITED
ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI
STREET,KOWLOON,HONGKONG
TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270
http://www.zhyichina.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-200 and is the answer not in the manual?

Questions and answers

Related Manuals for ZY International MT-200

Summary of Contents for ZY International MT-200

  • Page 1 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 MT-200 Automatic Vehicle Locator User Manual Version 2.0 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...

  • Page 2: Table Of Contents

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 Table of Contents Version 2.0 ..........................1 A Working Directions ......................3 B. System Introduction ......................4 C. Wiring Installation......................6 1. Product Parts List ......................6 2. Precaution before Installation ................... 7 3.INSTALLATION ........................ 81 3.1 Step 1: Install SIM Card .................... 81 3.2 Step 2: Connect power charging ................

  • Page 3: A Working Directions

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 A Working Directions Thank you for your purchase of MT200 Automatic Vehicle Tracker. In order to realize the full functions of this product, please read this manual carefully before starting to use the product. 1. This product can only be maintained and repaired by qualified professional service personnel.

  • Page 4: System Introduction

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 B. System Introduction MT200 is a high-tech product through cooperation with mobile operators. It combines GPS Global Positioning System and GSM/GPRS communication system, which can clearly inform you the position & situation of your car. GPS is the abbreviation for Global Positioning System, which based on 24 position location satellites around the earth orbit.
  • Page 5 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 Following are the major function descriptions for the MT200 products. GPS Position Tracking Function IP66 water resistance Build-in GPS antenna and GSM antenna, easy for installation Build-in 850mAh battery ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI...

  • Page 6: Wiring Installation

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 C. Wiring Installation 1. Product Parts List AVL Unit Car Charger Lighter Socket ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...

  • Page 7: Precaution Before Installation

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 GPS Antenna(optional) 2. Precaution before Installation Check if all the parts are included. Prepare a SIM card for GSM communication. Use some other mobile phone to confirm that the PIN code has not been set, and that it can dial out and receive telephone calls without problem.

  • Page 8: Installation

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 the AVL unit to the power source. 3.INSTALLATION 3.1 Step 1: Install SIM Card (1) Unscrew and remove the front cover of your locator. (2) Insert the SIM card by sliding it into the card holder slot, with the chip module facing to the connectors on PCB, as direction shown in the picture.
  • Page 9 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 (3)Switch the tracker on ,as following picture shows.After switch on,the red and blue led will blink ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...

  • Page 10: Step 2: Connect Power Charging

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 (4) Put back the front cover and screw it up. ※ Make sure to turn off the power before installing the SIM card. ※ Make sure to deactivate the PIN code, so that the SIM card can operate without PIN protection.
  • Page 11 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 Car Battery PIN description for MT200 socket: Colour function DC IN ( power input ) Input voltage : (important) 9V~25V Suggested : Black white No usage now Blue No usage now Green No usage now Yellow...
  • Page 12 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 4. Wiring Description Connect the wiring correctly. The AVL unit should be connected to power source, after all the wiring work has been completed and checked. Build-in GPS antenna and GSM antenna is used in this unit to make installation easy.GPS antenna is used to receive satellite signals in the...

  • Page 13: Operating Instructions

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 D. Operating Instructions 1. Position Report Function by SMS No matter where you are, when you want to know the position of your vehicle, send a SMS message or make a telephone call to the MT200; it will report its location back to you by SMS .

  • Page 14: Hardware Specifications

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 information Position Data means : Longitude = 114 degree - 04 cent - 57.74 second Latitude = 22 degree - 32 cent - 40.05 second Tips: Apply for one position service by another easier way: (a) Make a cell phone call to MT200...
  • Page 15 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 Range Humidity Up to 75% non-codensing External Antenna Connected via the 50Ω coax connector External SIM Card Connected via SIM Card connector SIM card type Transmit Power Class 4(2W) for E-GSM 900 and 850 Class 1(1W) for DCS 1800...

  • Page 16: More Professional Sms Instruction

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 G More Professional SMS Instruction ****** is user password , and init password is 000000 SMS Instruction Format Note Request one position W******,000 ****** is old password Modify user password W******,001,###### ###### is new password XXX(3 digital)
  • Page 17 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 =08 2000m Extend setting W******,008,ABCDEFG### A=0 , Close position report function which get position SMS (note: by Calling MT200 Please use this instruction A=1 , Open position report function carefully) which get position SMS by Calling MT200 B=0, position SMS format be analyzed in order to read easily.

  • Page 18: Gprs Communication Setting

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 GPS signal is weak ###, end character (Default value should be : ABCDEFG=1011110 ) Set sleep mode for saving W******,021,XX### power. XX=00 close sleep mode XX=01 sleep XX=02 deep sleep GPRS setting Set the phone number for...
  • Page 19 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 H GPRS communication setting Step1: Make sure that your SIM card in MT200 support the GPRS function Step2: Set tracker ID of MT200 by send one SMS: SMS Format: W******,010, Tracker ID For example : W000000,010,123456 GT30 will response one SMS to confirm the setting.
  • Page 20 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 Step4: Set APN String SMS format : W*****,011, APNString For example : W000000,011, CMNET GT30 will response one SMS to check it For Example “set APN OK /CMNET” Step5: Set time interval of sending GPRS package SMS format: W******,014 , XXXXX XXXXX：means times interval, (Unit: 10s)
  • Page 21 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 For example: W00000, 013, 1 W00000, 013, 0 (tip: About the detail of Protocol B or Protocol A pls contact with our support teams: info@zhyichina.com ) Step7 : According to the document of our our GTP communication protocols , the server can analyses the GPRS data.

  • Page 22: K Trouble Shooting

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 K Trouble shooting If you find some trouble in using MT200, please refer the following: (1) Check GPS signal is normal, please check following issue: (a) Working outdoor,MT200 can get better GPS signal; (b) Check the front side is placed toward sky;...

  • Page 23: Attachment :Worldwide Apn (Access Point Name) List

    ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 (a) Whether the GSM network is strong enough to make the track unit work. You can judge it by calling someone thorough your cell phone. (b) Whether the SIM card is installed correctly or not ,and try to pull out and insert SIM card as following picture shows to ensure it;...
  • Page 24 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
  • Page 25 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
  • Page 26 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
  • Page 27 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
  • Page 28 ZY INTERNATIONAL LIMITED GPSTrackerManual_MT200 ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-30717728 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
