- Page 1 ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual GSM/GPRS/GPS Vehicle Tracker GPS106A/B User Manual ZY INTERNATIONAL LIMITED ADD:RM 1202,12/F,TUNG CHUN COMMERCIAL CENTRE,438-444 SHANGHAI STREET,KOWLOON,HONGKONG TEL: 86-755-26783978 , 852-21375268 FAX:86-755-26787909 , 852-21375270 http://www.zhyichina.com...
-
Page 2: Table Of Contents
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual Preface Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual. - Page 3 ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.16.6 Over Speed Alarm..........................12 6.17 Cut off the Oil and Power System ......................12 6.18 Resume the Oil and Power System ....................... 12 6.19 Fuel alarm ............................. 12 6.20 Arm ............................... 13 6.21 Disarm ..............................13 6.22 Function of Remote Control (Option for model B) ................
-
Page 4: Function Introduction
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 1. Function Introduction 1.1 This tracker is a new product based on the GSM / GPRS network and GPS satellite positioning system, which set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety. It can track and monitor remote target by SMS or internet. -
Page 5: Acessories
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual ⑵. J4 Monitor microphone jack. ⑻. GPS antenna connector ⑶. LED indicator ⑼. Remote control receiver antenna（model B） ⑷. SIM card slot ⑽. J1 12PIN harness port ⑸. SIM card slot Pop-up switch ⑾. J2 Camera port ⑹.SD card slot... -
Page 6: Specifications
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual Optional for Model A and B Camera Optional for Model A and B and different type depends Fuel sensor on vehicles 5．Specifications Content Specifications 85*71*26mm Weight 170g Network GSM/GPRS Band 850/900/1800/1900Mhz GSM/GPRS Simcom900B Module GPS Module... -
Page 7: Sim Card Installation
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.1.3 Pay attention to make installation location preventing water and dust. 6.1.4 Find the 12 PIN harness and insert it into the corresponding holes of the products, and connect the wires with the original car circuit showing below: Wiring diagram 6.1.5 Note: The orange wire can be connected to the original car siren;... -
Page 8: Turn On The Tracker Device
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.2.1 Use a tweezers or a sharp thing to touch the SIM CARD popup switch, the SIM CARD slot will pop up, take out the SIM card slot to load the SIM card, and then put the SIM card slot back to its original position after confirm the SIM card in the right place. -
Page 9: Authorization
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.7 Authorization There are 5 numbers to be allowed to authorize in the tracker at most. 6.7.1 Call and track the tracker device for 10 times from cell phone in success, it will make the cell phone number as the authorized number automatically, and reply “add master ok”. -
Page 10: Location Base Station (Lbs)
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.9.4 When the GPS signal is not good, the latitude and longitude you received is the last position before going into GPS blind areas, if any bias with the location, pay attention to the time stamp in the message. -
Page 11: Data Load
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual will reply “save ok”, and will store the lat, long locations every 30 seconds for 5 times. (S: second, m: minute; h: hour). 6.14.3 Multi-Storage：Send sms:”save030s***n+password” to tracker device, it will reply “save ok”. 6.14.4 Storage Clearance: send SMS: “clear+password” to tracker device, it will reply “clear ok”. -
Page 12: Movement Alarm
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual tracker to set the restricted district. In case of breach, it will send SMS “stockade!+latitude/longitude.” to the authorized numbers. Note: The first latitude & longitude is coordinate of the top left corner of the Geo-fence, while the second latitude & longitude is the coordinate of the bottom right corner, it will alarm SMS in 3 minutes interval. -
Page 13: Arm
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual If the tracker device detects the fuel decrease by 8% in three minutes, then it will send oil leak or theft alarm “oil: xx%+latitude/longitude” to authorized numbers in 3 minutes interval. Siren beeps 30 seconds. Cancel fuel alarm: Send SMS command “nooil+password” to tracker. -
Page 14: Door Alarm
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.23.1 Door alarm The tracker will send SMS “Door alarm+lat/long” to the authorized numbers in 3 minutes interval when the door of the car opens in arm status; Siren will sound for 30 seconds, send disarm command “disarm+password” to stop it. -
Page 15: Alarms In Gsm Blind Area
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual Quite silent mode Press “A+B” together in disarm state for 0.5 second again, siren will beep four times. Siren will sound after alarm is triggered. And tracker will also send SMS alarm to authorized numbers. 6.25 Alarms in GSM Blind Area... -
Page 16: Setting Up Apn
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual 6.31 Setting up APN 6.31.1 APN standards for Access Point Name and differs from country to country. For more information about your local APN, please inquire with your local GPRS network operator. 6.31.2 Send SMS command “APN123456+Space+your local APN” to tracker via a cell phone and if succeeded, the tracker will reply “APN OK”. -
Page 17: Cautions
ZY INTERNATIONAL LIMITED GPSTrackerTK106ABManual the package box. [Software Platform User Manual] 7. Cautions Please comply with the instructions to extend the unit life: 1. Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry.
