Summary of Contents for Hunt Electronic Outdoor Day/Night Speed Dome

  • Page 2 Notes on Safety ◎Please read the instructions thoroughly before installing or operating the unit. Please do not mount the machine on an unstable surface or bracket. Please prevent all liquids or other material from entering the dome housing. When connecting the power source, please follow all electric safety standards and only use the power supply designated for this device.
  • Page 3: Table Of Contents

    Ⅰ. Introduction Ⅱ. Technical Data 2.1. Technical Parameters of the Intelligent High-speed Dome 2.2. Camera Parameter for High-speed Dome: (Built in SONY Camera). Ⅲ. Settings 3.1 Dome Address, Transmission Speed, Protocol Setting 3.2 Speed Dome Camera Address Setting 3.3 Speed Dome Camera Communication Protocol Setting 3.4 Speed Dome Camera Transmission Speed Setting (Baud Rate Setting) 3.5 RS-485 Bus Matching Resistance IV.
  • Page 4: Ⅰ. Introduction

    . Introduction Congratulations on purchasing our speed dome, an intelligent, high-speed dome with a high-performance DSP camera and sophisticated zoom lens. It is an advanced technological surveillance product combining an all-direction variable speed dome and digital decoder all in one unit. It can aim quickly and scan continuously, making omni-directional and non-blind-spot monitoring into reality.
  • Page 5: Camera Parameter For High-Speed Dome: (Built In Sony Camera)

    2.2. Camera Parameter for High-speed Dome: (Built in SONY Camera). Model Outdoor Day/Night Speed Dome Indoor Speed Dome ¼”Sony Exview (Day/Night) CCD ¼” Sony Exview CCD Mode Sync Internal/ external Scan 2:1 Interlace Resolution >480 lines Minimum illumination 0.7lux/0.01lux (b/w mode) 0.7lux...
  • Page 6: Speed Dome Camera Address Setting

    3.2 Speed Dome Camera Address Setting The address code for the speed dome should be properly set before use to ensure accurate addressing of the dome at the control center and to control several dome cameras. The address code is made up of SW2 (8 bits) on PCB board.
  • Page 7: Speed Dome Camera Communication Protocol Setting

    3.3 Speed Dome Camera Communication Protocol Setting The 1st, 2nd and 3rd bits in SW3 are used to set communication protocol (see following figure) Please ensure that the controlling device and the camera are using the same protocol. 3.4 Speed Dome Camera Transmission Speed Setting (Baud Rate Setting) The 4th and 5th bits of SW3 on the PCB board are used to set the baud rate (see following figure).
  • Page 8: Basic Function Of Dome Camera

    IV. Basic Function of Dome Camera Use the keyboard controller to utilize the complete potential of the speed dome. (The keyboard control protocol is set as the default protocol for the speed dome.) 4.1 Preset Position The Preset function is the dome’s default level angle, lean angle and camera focal length in EMS memory.
  • Page 9: 360° Scanning

    2. In the Main Menu enter a dwell time for Point A. Example: If Dwell time is 2 seconds the control keyboard displays: 3. Press PAN A. 4. To set Point B. Move the joystick to the desired position. 5. In the Main Menu enter a Dwell time for Point B. 6.
  • Page 10: Alarm Linkage Function

    once, control keyboard displays: Displays Current Speed dome address 3. Press Enter to Confirm. 4. Press the FUN key three times, control keyboard displays: 5. Input the desired waiting time using the number keys: Example: After inputting time: 05, press Enter. Setting the Guard Location 1.
  • Page 11: Focus/Rotation Speed Auto Match Technology

    using the control keyboard. In addition, a user can adjust focal length to change the angle of view or the size of the objects. When in auto-iris and auto-zoom mode, the camera adjusts automatically to get a clear picture with changing image environments. Focus/Rotate Auto Speed Controls When manually adjusting the zoom length or focal distance at longer ranges, a typical PTZ dome may move too quickly resulting in the loss of important images.
  • Page 12: Auto Backlight Compensation

    4.9.4 Auto Backlight Compensation Camera is divided into six areas to realize auto backlight compensation. In lighting conditions where a strong backlight exists, the speed dome will adjust the light levels relative to the foreground and background objects in order to achieve the highest resolution image. The camera is divided to 6 zones to best handle unique lighting conditions.
  • Page 13: Present Position Char Over Lap Function (Multi-Function Series Only)

    VI. Present Position Char Over lap Function (Multi-Function Series Only) Through 232-845 adapter, speed dome camera can transfer the PC deferent 232 signal to RS-485 signal which speed dome can recognize and can be communicated by the attached software. This enables the speed dome display multi-language and images in every present position.
  • Page 14: Camera Menu Of Available Models

    input 51, then input SHIFT + CALL, will enter starting point of line scanning (i.e. point 1). If another control device is used to control the speed dome camera, Some of the special functions of Intelligent high speed dome can’t be realized because of protocol limitation. When another control device is used to control the speed dome camera, you will need to set the protocol, address and baud rate correctly.
  • Page 15: Lg Camera

    15)BRIGHT: (Brightness Adjustment) Press down LIST key, showing “up” means brightness increase, “Down” means brightness decrease. Press List key to cycle for 12 times. Press “LIST” for gain increase, press “Enable” for gain decrease 16)GAIN: Press down LIST key, showing “up” means gain increase, “Down” means gain decrease. Press List key to cycle for 12 times.
  • Page 16 4. Auto keyboard control: Nonuse 5. Default setup: Press List key to restore the default setup 6. Back: Press List key to exit the sub menu. Automatic exposure setting: Press ACK key to enter the sub menu 1. Exposure mode: optional: “Auto” “Iris manual” “Gain manual” “Manual” 2.
  • Page 17: Cnb Camera Menu

    continue selecting. 4. Zoom status display: optional: “ON” “OFF”: Press ACK or List key to select, if selected, press Enable key to continue selecting. 5. User’s name display: optional: “ON” “OFF”: Press ACK or List key to select, if selected, press Enable key to continue selecting.
  • Page 18 Address-Binary code chart Binary SAMSUNG PELCO-D Binary System SAMSUNG PELCO-D Hunt CCTV Hunt CCTV System Code KALATEL PELCO-P Code KALATEL PELCO-P 00000000 00000001 00000010 00000011 00000100 00000101 00000110 00000111 00001000 00001001 00001010 00001011 00001100 00001101 00001110 00001111 00010000 00010001 00010010 00010011 00010100 00010101...
  • Page 19 Binary SAMSUNG PELCO-D Binary System SAMSUNG PELCO-D Hunt CCTV Hunt CCTV System Code KALATEL PELCO-P Code KALATEL PELCO-P 01010100 01010101 01010110 01010111 01011000 01011001 01011010 01011011 01011100 01011101 01011110 01011111 01100000 01100001 01100010 01100011 01100100 01100101 01100110 01100111 01101000 01101001 01101010 01101011 01101100...
  • Page 20 SAMSUNG SAMSUNG Binary PELCO-D Binary System PELCO-D Hunt CCTV Hunt CCTV KALATEL KALATEL System Code PELCO-P Code PELCO-P 10101100 10101101 10101110 10101111 10110000 10110001 10110010 10110011 10110100 10110101 10110110 10110111 10111000 10111001 10111010 10111011 10111100 10111101 10111110 10111111 11000000 11000001 11000010 11000011 11000100...
  • Page 21: Ⅹ. Exception Handling

    Ⅹ. Exception Handling Issue Possible Reason Solution Power on, no movement, Power line connected wrong Correct it no image, indicator light Power damaged Replace does not light Blowout Replace Power line be connected bad Check it Power on, self check, has The machine’s address code or Reset image, can’t control,...
