Hunt Electronic HTZ-3701WBH Instruction Manual

High speed dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Ver 1.2
High Speed Dome Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTZ-3701WBH and is the answer not in the manual?

Questions and answers

Related Manuals for Hunt Electronic HTZ-3701WBH

Summary of Contents for Hunt Electronic HTZ-3701WBH

  • Page 1 INSTRUCTION MANUAL Ver 1.2 High Speed Dome Camera...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 3 NOTICE Important Safety Guide 1. Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. 2. Keep this manual Keep this manual for reference in future. 3. Attachments / Accessories Use only the attachments or accessories specified by the manufacturer. 4.
  • Page 4 NOTICE Caution Operating Before using, make sure that the power supply and others are properly installed. While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. Handling Do not disassemble or tamper with the parts inside the product. Do not drop or subject the product to shock and vibration as this can damage the product.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS ① Introduction Model Code Features Package Components Main Part Description ② Installation DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Installation with In-Ceiling Mount Bracket Wiring and Cabling ③ Operation Check Point before Operation Check Points for Preset and Pattern Function before Operation OSD Menu Reserved Preset (Hot Keys)

  • Page 6: Model Code

    Model Code Speed Dome Camera Instruction Manual 6/82...

  • Page 7: Features

    Features Powerful Zoom Camera & Setup Options Image Sensor : 1/4" Interline Transfer CCD (HTZ2701 & HTZ3701 model) Zoom : ×27 Optical Zoom, ×16 Digital Zoom (HTZ2701 model) ×37 Optical Zoom, ×16 Digital Zoom (HTZ3701 model) Day & Night, Privacy Mask and WDR (WDR Possible Models Only) DNR (Digital Noise Reduction) Function Various Focus Mode : Auto-Focus, Manual Focus, Semi-Auto Focus Various Setup Options in OSD Menu.
  • Page 8 INTRODUCTION Preset, Pattern, Swing, Group, Schedule, Privacy Mask and More… MAX. 209 Presets are programmable and each preset can have its own parameter values independently from the other presets. For an example, refer to the below table. Preset No. White Balance Auto Exposure Label Remarks...
  • Page 9 INTRODUCTION Alarm In/Out Function 3 alarm sensor inputs and 1 alarm sensor outputs are available. Alarm sensor input is decoupled with photo-couplers to avoid external electric noise and shock perfectly. Both of N.O.(Normal Open) sensors and N.C.(Normal Close) sensors can be used and the signal range of the sensor input is from DC 5.0V to 12.0V for various applications.

  • Page 10: Package Components

    INTRODUCTION Package Component Product & Accessories Main Body & Dome Cover (Wall/Ceiling model) Main Body & Dome Cover (In-ceiling model) Manual Default Accessories [Main Cable, I/O Cable ,Wrench, Owner’s Manual] Speed Dome Camera Instruction Manual 10/82...
  • Page 11 INTRODUCTION Brackets (Optional) Wall Mount Bracket Ceiling Mount Bracket [Screws : , Hex Lag [Screws : , Anchor Bolt TORX Machine M4×L18 TORX Machine M4×L18 #14×50] 3/8"×70] In-Ceiling Mount Bracket [Screws : Tapping FH Ø4×L20, Machine Sams M3×L8] Speed Dome Camera Instruction Manual 11/82...

  • Page 12: Main Part Description

    INTRODUCTION Main Part Description Mounting Screw Hole Drop Prevention Spring DIP Switch Main Connector Sensor I/O Port Dome Cover Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust.

  • Page 13: Dip Switch Setup

    INSTALLATION DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol. Camera ID Setup ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10...
  • Page 14 INSTALLATION Communication Protocol Setup Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Others Reserved Match the camera protocol with the camera protocol in the setting of your DVR or controller to control the camera.
  • Page 15 INSTALLATION Terminal Resistor Setup The terminal resistor is used for the following cases. Case 1 : In case that the control cable length between a camera and a controller is relatively very long (1:1 Connection) If the communication cable length is very long, the electrical signal will bound in the terminal point.

  • Page 16: Installation With Ceiling Mount Bracket

    INSTALLATION Installation with Ceiling Mount Bracket ① Remove the ceiling tile from the ceiling ② Hook up “Drop Prevention Spring” on and cut a hole whose diameter is main body to prevent camera from 30~40mm on the ceiling tile to pass the unexpected drop and pull the wire(s) and wire(s) and cable(s) through to the upside cable(s) for the system as below.

  • Page 17: Installation With Wall Mount Bracket

    INSTALLATION Installation with Wall Mount Bracket ① Make a hole whose diameter is 30~40mm ② Hook up “Drop Prevention Spring” on on the mounting surface to pass the main body to prevent camera from wire(s) and cable(s) through the mounting unexpected drop and pull the wire(s) and surface.

  • Page 18: Installation With In-Ceiling Mount Bracket

    INSTALLATION Installation with In-ceiling Bracket ① Assemble the dome cover and the braket ② Cut a hole whose diameter is 215mm on with the main body the ceiling tile and insert the camera into the hole. Open the cover and make all the connections.

  • Page 19: Wiring And Cabling

    INSTALLATION Wiring and Cabling POWER MAIN CABLE MONITOR RS-485 CONTROLLER / DVR I/O CABLE SENSOR I/O DOOR SENSOR SWITCH Port Description Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal Video + BNC Connector Video − RS-485 + Yellow RS-485 −...
  • Page 20 INSTALLATION Power Description Carefully check the voltage and current capacity of the rated power. Current Model Input Voltage Range Consumption Without F/H ECI Series 1.0 A DC12V Input DC 11V ~ 18V With F/H ECO Series 1.8 A Without F/H ECI Series 0.8 A AC24V Input...
  • Page 21 INSTALLATION Video Use BNC coaxial cable only. Alarm Input Internal +5V~12V IN COM+ IN 1- Sensor 1 IN 3- Sensor 3 Before connecting sensors, check driving voltages and output signal types of the sensors. Since output signal types of the sensors are divided into Open Collector type and Voltage Output type in general, the wiring must be done properly after considering those types.

  • Page 22: Check Point Before Operation

    OPERATION Check Points before Operation Before turning on the system, check if the wire(s) and cable(s) are connected properly. Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera. The camera ID can be checked by reading the DIP switch of the camera or on OSD.

  • Page 23: Osd Menu

    OPERATION OSD Menu Function With OSD menu, the system can be properly configured for each application. Entering into OSD Go Preset [95] Reserved Presets (Hot Keys) Description Some Preset numbers are reserved to change some parameters without entering into OSD menu. Hot Keys Go Preset [95] : Entering into OSD menu...

  • Page 24: Preset

    OPERATION Preset Function MAX. 209 presets can be configured except the Reserved Presets (Hot Camera parameters such as White Balance, Auto Exposure and Keys). others can be set up independently and each preset can have its own parameter values independently from the other persets. When setting up presets with a controller, Label should be blank and "Camera Adjust"...

  • Page 25: Pattern

    OPERATION Pattern Function This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. Patterns programmable Maximum communication commands can be programmed in a pattern. Setting Patterns A Pattern can be created by the following methods.

  • Page 26: Group

    OPERATION Group Function This function is that the camera memorizes the combination of Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 40 actions which are the combination of Preset, Pattern and Swing.
  • Page 27 OPERATION Alarm Input 3 Alarm Inputs are available. When external sensors activate, the camera runs pre-defined actions such as Preset, Pattern, Swing and Group. After the pre-defined time period passed, “Post Alarm” activates, which is pre-defined. Note that only the latest alarm input is effective when multiple sensors are activated at the same time.

  • Page 28: Osd Display

    OPERATION OSD Display Action Title Preset Label LABEL12345 PRESET1 Date(Day/Month/Year) 01/JAN/2013 Time(Hour/Min./Sec.) Alarm Information 01:15:35 I:-2- O:1 CAM 1 15/4/x1/N Camera ID P/T/Z Information P/T/Z Information Displays the amount of pan from zero degree vertical, the amount of tilt from zero degree horizontal and current compass direction. Also identifies the amount of the zoom magnification.

  • Page 29: ④ Osd Menu

    OSD MENU Quick Programming Guide The menu items with < > always have sub-menus. To go to submenus or make the cursor move to the right, press NEAR key. To go to the previous-upper level menus, press FAR key. To make a selection, press NEAR key To cancel a selection, press FAR key To move the cursor in the menu, use the joystick to the Up/Down direction or Left/Right direction.

  • Page 30: Display Setup

    OSD MENU Display Setup Display setup allows you to program how labels are DISPLAY SETUP displayed on the monitor. In case of AUTO, the labels are ------------------------ displayed on the monitor when there are any changes in CAMERA ID parameters. PTZ INFORMATION AUTO ACTION TITLE...

  • Page 31: Privacy Zone Mask Setup

    OSD MENU Compass Direction Setup Move the camera to a target position and press NEAR SET NORTH DIRECTION button to save the direction as North. The direction is the ------------------------ reference direction to assign other compass directions. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL Privacy Zone Mask Setup...
  • Page 32 OSD MENU Privacy Zone Mask Area Setup Move your camera to an area to mask. Then a mask and the EDIT MASK 1 menu to adjust the mask size will be displayed. ------------------------ MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL] Privacy Zone Mask Size Setup Adjusts the mask size.

  • Page 33: Clock Setup

    OSD MENU Clock Setup Configures current time and how to display in OSD CLOCK SETUP ------------------------ [ON/OFF] Display Date DISPLAY DATE Configures whether Date will be displayed DISPLAY TIME in OSD or not SET CLOCK 01/JAN/2013 TUE [ON/OFF] Display Time 00:01:02 [hh:mm:ss] Configures whether Time will be displayed in OSD or not...

  • Page 34: Camera Setup

    OSD MENU Camera Setup (HTZ2701 & HTZ3701 model) Sets the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ Focus Mode [AUTO/MANUAL/SEMIAUTO] FOCUS MODE SEMIAUTO Sets camera Focus mode. DIGITAL ZOOM IMAGE FLIP SEMIAUTO Mode SHARPNESS This mode automatically exchanges focus STABILIZATION modes between Manual Focus mode and <WHITE BALANCE SETUP>...
  • Page 35 OSD MENU Stabilization [ON/OFF] Compensates image vibrations by wind or others. The images with vibrations are compensated by Digital Zoom function and the image resolution with this function should be lower than normal image resolution when this function is turned on. Also this function may not work properly in the following cases.
  • Page 36 OSD MENU Auto Exposure Setup Backlight [OFF/WDR/BLC/HLC] or [OFF/BLC/HLC] AE SETUP - GLOBAL Sets Backlight Compensation. If a bright ------------------------ backlight is present, the subjects in the BACKLIGHT picture may appear dark or as a DAY/NIGHT AUTO silhouette. Backlight compensation BRIGHTNESS IRIS AUTO...
  • Page 37 OSD MENU Shutter Speed [ESC/A.Flicker/Manual(×512~1/120000 sec)] Sets Shutter Speed. Shutter Speed is the duration of the electronic shutter. If Iris is set to Manual and Shutter Speed is set to ESC, Shutter Speed has higher priority. If Shutter Speed is set to A.Flicker, to remove Flicker, Shutter Speed should be set to 1/100 sec.
  • Page 38 OSD MENU WDR (Wide Dynamic Range) Setup Limit [LOW/MIDDLE/HIGH] ------------------------ Level [1~100] LIMIT MIDDLE LEVEL BACK EXIT HLC (High Light Compensation) Setup Limit [LOW/MIDDLE/HIGH] When there are too bright lights, this ------------------------ function blocks light sources on images LIMIT COLOR to have better images.
  • Page 39 OSD MENU Camera Setup (281L, 371L model) Sets the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ Focus Mode [AUTO/MANUAL/SEMIAUTO] FOCUS MODE SEMIAUTO Sets camera Focus mode. DIGITAL ZOOM IMAGE FLIP SEMIAUTO Mode SHARPNESS This mode automatically exchanges focus STABILIZATION modes between Manual Focus mode and <WHITE BALANCE SETUP>...
  • Page 40 OSD MENU Stabilization [ON/OFF] Compensates image vibrations by wind or others. The images with vibrations are compensated by Digital Zoom function and the image resolution with this function should be lower than normal image resolution when this function is turned on. Also this function may not work properly in the following cases.
  • Page 41 OSD MENU Auto Exposure Setup Backlight [OFF/WDR/BLC/HLC] AE SETUP-GLOBAL Sets Backlight Compensation. If a bright ------------------------ backlight is present, the subjects in the BACKLIGHT picture may appear dark or as a DAY/NIGHT <AUTO> BRIGHTNESS silhouette. Backlight compensation IRIS AUTO enhances objects in the center of the SHUTTER AUTO picture.
  • Page 42 OSD MENU Shutter Speed [×512~×2, AUTO,OFF,A.FLK, 1/60~1/120000 ] Sets Shutter Speed. Shutter Speed is the duration of the electronic shutter. In the Auto mode, the shutter is set automatically according to the brightness of subject. In the Off mode, the shutter is fixed to 1/60 in case of NTSC and 1/50 in case of PAL.
  • Page 43 OSD MENU WDR (Wide Dynamic Range) Setup Level [LOW/MIDDLE/HIGH] ------------------------ [ON/OFF] LEVEL MIDDEL In case of extreme contrast between light and shade, ACE even more brighten the dark portion of the image with the WDR function. BACK BLC Setup Level [LOW/MIDDLE/HIGH] ------------------------ LEVEL...
  • Page 44 OSD MENU Camera Setup (280S, 281S, 361S model) Sets the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ Focus Mode [AUTO/MANUAL/SEMIAUTO] FOCUS MODE SEMIAUTO Sets camera Focus mode. DIGITAL ZOOM FLICKERLESS SEMIAUTO Mode COLOR This mode automatically exchanges focus IMAGE FLIP modes between Manual Focus mode and <WHITE BALANCE SETUP>...
  • Page 45 OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL Retains color balance over a color ------------------------ temperature range. In auto mode, this WB MODE AUTO feature automatically processes ADJUST BLUE ADJUST viewed image. In Manual mode, Red and Blue level can be set up manually.
  • Page 46 OSD MENU Auto Exposure Setup Backlight [ON/OFF] AE SETUP-GLOBAL Sets Backlight Compensation. If a bright ------------------------ backlight is present, the subjects in the BACKLIGHT picture may appear dark or as a silhouette. DAY/NIGHT AUTO Backlight compensation enhances objects AE MODE AUTO in the center of the picture.
  • Page 47 OSD MENU Shutter [1/1 ~ 1/10000] If AE mode is set to SHUTTER mode or MANUAL mode, this can be set up. Brightness [0 ~ 31] If AE mode is set to BRIGHTNESS mode, this can be set up. Special Setup Auto DSS [ON/OFF] SPECIAL...
  • Page 48 OSD MENU Camera Setup (281W, 331W, 361W model) Sets the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ Focus Mode [AUTO/MANUAL/SEMIAUTO] FOCUS MODE SEMIAUTO Sets camera Focus mode. DIGITAL ZOOM FLICKERLESS SEMIAUTO Mode COLOR This mode automatically exchanges focus IMAGE FLIP modes between Manual Focus mode and <WHITE BALANCE SETUP>...
  • Page 49 OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL Retains color balance over a color ------------------------ temperature range. In auto mode, this WB MODE AUTO feature automatically processes ADJUST BLUE ADJUST viewed image. In Manual mode, Red and Blue level can be set up manually.
  • Page 50 OSD MENU Auto Exposure Setup Backlight [ON/OFF] AE SETUP-GLOBAL Sets Backlight Compensation. If a bright ------------------------ backlight is present, the subjects in the BACKLIGHT picture may appear dark or as a silhouette. DAY/NIGHT AUTO Backlight compensation enhances objects AE MODE AUTO in the center of the picture.
  • Page 51 OSD MENU Special Setup Auto DSS [ON/OFF] SPECIAL When set to ON, ensure that the ------------------------ slow shutter is set to automatically AUTO DSS NIGHT>DAY LEVEL when the brightness drops. APERTURE Night > Day Level [0 ~ 28] STABILIZATION Adjust the sensitivity to change Night mode to Day mode.

  • Page 52: Motion Setup

    OSD MENU Motion Setup Sets the general functions of Pan/Tilt motions. MOTION SETUP Motion [ON/OFF] ------------------------ MOTION LOCK Lock If Motion Lock is set to ON, it is impossible to PWR UP ACTION set up and delete Preset, Swing, Pattern and AUTO FLIP Group.
  • Page 53 OSD MENU Parking Action Setup This feature allows the camera to begin a specified action PARKING ACTION SETUP after a programmed time of inactivity. ------------------------ PARK ENABLE Park Enable [ON/OFF] WAIT TIME 00:10:00 If Park Enable is set to ON, the camera PARK ACTION HOME runs an assigned function automatically if...
  • Page 54 OSD MENU Alarm Input Setup Defines Alarm Function. When an alarm is receive, an ALARM INPUT SETUP input signal to the camera triggers the user-defined action ------------------------ programmed for the alarm. ALARM NO. Alarm No [1~3] TYPE N.OPEN Selects a sensor number to set up. ACTION NOT USED HOLD TIME...

  • Page 55: Preset Setup

    OSD MENU Preset Setup Preset [1~255] MAX. Presets except PRESET SETUP Reserved Presets (Hot Keys) Number ------------------------ Selects a preset number to set up. If a PRESET NO. selected preset is already defined, the CLR PRESET CANCEL camera moves to the pre-defined position <EDIT SCENE>...
  • Page 56 OSD MENU Preset Scene Setup ○ 1 Use the Joystick to move the camera to a desired EDIT SCENE - PRESET 1 position. ------------------------ ○ 2 Save the preset position by pressing NEAR key. ○ 3 Press FAR key to cancel targeting the preset position. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL]...

  • Page 57: Swing Setup

    OSD MENU Swing Setup Swing [1~10] SWING SETUP Number Selects a Swing number to edit. If the ------------------------ selected Swing is not defined, "NOT USED" SWING NO. is displayed in the 1st Position and the 2nd 1ST POS. NOT USED 2ND POS.

  • Page 58: Pattern Setup

    OSD MENU Pattern Setup Pattern Number [1~8] PATTERN SETUP Selects a Pattern number to edit. If the ------------------------ selected pattern number is not PATTERN NO. defined, "UNDEFINED" will UNDEFINED CLR PATTERN CANCEL displayed under the selected pattern RUN PATTERN number. <EDIT PATTERN>...

  • Page 59: Group Setup

    OSD MENU Group Setup Group Number [1~8] GROUP SETUP Selects a Group number to edit. ------------------------ If the selected Group number is not GROUP NO. UNDEFINED defined, "UNDEFINED" will CLEAR GROUP CANCEL displayed under the selected Group RUN GROUP number. <EDIT GROUP>...
  • Page 60 OSD MENU ③ Define Action, Dwell time and Option. Note that the dark EDIT GROUP 1 rectangular is the cursor. Move the cursor Left/Right to ------------------------ select an item and move cursor Up/Down to change NO ACTION ### DWELL OPT each parameter.
  • Page 61 OSD MENU ⑥ After finishing setting up, press FAR key to exit. Then the EDIT GROUP 1 cursor will move to “SAVE”. Press Near key to save the ------------------------ data. NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE...

  • Page 62: Schedule Setup

    OSD MENU Schedule Setup Schedule No [1~8] SCHEDULE SETUP Selects a Schedule to be configured. ------------------------ SCHEDULE NO Action [NOT USED/PRESET/PATTERN/SWING ACTION NOT USED /GROUP] HOLD TIME ENDLESS POST ACTION HOME Consigures a function to be run for a CYCLE ONCE configured time period.

  • Page 63: Password Setup

    OSD MENU Password Setup Password Setup [ON/OFF] PASSWORD SETUP Configures whether OSD menu will be ------------------------ protected with a password. A password CHECK PASSWORD configured [EDIT <EDIT PASSWORD> PASSWORD]. BACK EXIT [Caution] It is mandatorily recommended that a user must take a memo for a password before a user applies a password to a system.
  • Page 64 OSD MENU Edit Password A password should be made up with a 4 Alphanumeric EDIT PASSWORD combination ------------------------ ---------- 1234567890 ABCDEFGHIJ CANCEL KLMNOPQRST Current Cursor Position UVWXYZabcd efghijklmn opqrstuvwx ① With Left/Right/Up/Down of the joystick, move to a yz<>-/:. desired Alphabet or a desired number in the ---------- Alphanumeric set.

  • Page 65: System Initialize

    OSD MENU System Initialization Clear All Data Deletes all configuration data and the system SYSTEM INITIALIZE is set to the factory default. ------------------------ Clear Display Set Initializes all the configuration data for Display. CLEAR ALL DATA CLR DISPLAY SET Clear Camera Set Initializes all the configuration data for CLR CAMERA SET Camera.
  • Page 66 OSD MENU Camera Parameters (HTZ2701 & HTZ3701 model) Focus Mode SemiAuto Day&Night AUTO Digital Zoom Brightness Image Flip Iris AUTO Sharpness 12 or 16 Shutter Stabilization MIDDLE White Balance AUTO SSNR MIDDLE Backlight SENS-UP AUTO (x2) Camera Parameters (281L, 371L model) Focus Mode SemiAuto Day&Night...

  • Page 67: ⑤ Specifications

    SPECIFICATIONS Specifications CAMERA PART (HTZ-3701 Model) Video Signal Format NTSC Image Sensor 1/4'' Interline Transfer CCD Total Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 600 TV Lines(Color), 700 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) ×37 Optical Zoom, ×16 Digital Zoom Zoom Forcal Length...
  • Page 68 SPECIFICATIONS CAMERA PART (370T Model) Video Signal Format NTSC Image Sensor 1/4'' Interline Transfer CCD Total Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 600 TV Lines(Color), 700 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) Zoom ×37 Optical Zoom, ×16 Digital Zoom Forcal Length...
  • Page 69 SPECIFICATIONS CAMERA PART (331T Model) Video Signal Format NTSC Image Sensor 1/4'' Interline Transfer CCD Total Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 600 TV Lines(Color), 700 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) Zoom ×33 Optical Zoom, ×16 Digital Zoom Forcal Length...
  • Page 70 SPECIFICATIONS CAMERA PART (330T Model) Video Signal Format NTSC Image Sensor 1/4'' Interline Transfer CCD Total Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 600 TV Lines(Color), 700 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) Zoom ×33 Optical Zoom, ×16 Digital Zoom Forcal Length...
  • Page 71 SPECIFICATIONS CAMERA PART (HTZ-2701 Model) Video Signal Format NTSC Image Sensor 1/4'' Interline Transfer CCD Total Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 600 TV Lines(Color), 700 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) Zoom ×27 Optical Zoom, ×16 Digital Zoom Forcal Length...
  • Page 72 SPECIFICATIONS CAMERA PART (281L Model) Video Signal Format NTSC Image Sensor 1/4'' 960H Dual Scan CCD Total Pixels 520K 610K Effective Pixels 480K 570K Horizontal Resolution 600 TV Lines(Color) Video Signal-to-Noise 50 dB Zoom ×28 Optical Zoom, ×12 Digital Zoom Forcal Length F1.5~3.7, f=3.5~98.0mm SensUp Off : 0.2 Lux (Color) / 0.
  • Page 73 SPECIFICATIONS CAMERA PART (371L Model) Video Signal Format NTSC Image Sensor 1/4'' 960H Dual Scan CCD Total Pixels 520K 610K Effective Pixels 480K 570K Horizontal Resolution 600 TV Lines(Color) Video Signal-to-Noise 50 dB Zoom ×37 Optical Zoom, ×12 Digital Zoom Forcal Length F1.5~4.1, f=3.5~129.5mm SensUp Off : 0.2 Lux (Color) / 0.
  • Page 74 SPECIFICATIONS CAMERA PART (280S Model) Video Signal Format NTSC Image Sensor 1/4'' EX-view HAD CCD Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 550 TV Lines Video Signal-to-Noise 50 dB Zoom ×28 Optical Zoom, ×12 Digital Zoom Forcal Length F1.35~3.7, f=3.5~98.0mm Angle of View (H) 55.8°(Wide)~2.1°(Tele) Zoom Speed...
  • Page 75 SPECIFICATIONS CAMERA PART (281S Model) Video Signal Format NTSC Image Sensor 1/4'' EX-view HAD CCD Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 550 TV Lines Video Signal-to-Noise 50 dB Zoom ×28 Optical Zoom, ×12 Digital Zoom Forcal Length F1.35~3.7, f=3.5~98.0mm Angle of View (H) 55.8°(Wide)~2.1°(Tele) Zoom Speed...
  • Page 76 SPECIFICATIONS CAMERA PART (361S Model) Video Signal Format NTSC Image Sensor 1/4'' EX-view HAD CCD Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Resolution 550 TV Lines Video Signal-to-Noise 50 dB Zoom ×36 Optical Zoom, ×12 Digital Zoom Forcal Length F1.6~4.5, f=3.4~122.4mm Angle of View (H) 57.8°(Wide)~1.7°(Tele) Zoom Speed...
  • Page 77 SPECIFICATIONS CAMERA PART (281W Model) Video Signal Format NTSC Image Sensor 1/4'' Sony Super HAD II (Double Scan) CCD Total Pixels 1028(H)×508(V) 520K 1028(H)×596(V) 610K Horizontal Resolution 700 TV Lines (Color), 750 TV Lines (B/W) @ HR 7 mode Video Signal-to-Noise 50 dB Zoom ×28 Optical Zoom, ×32 Digital Zoom...
  • Page 78 SPECIFICATIONS CAMERA PART (331W Model) Video Signal Format NTSC Image Sensor 1/4'' Sony Super HAD II (Double Scan) CCD Total Pixels 1028(H)×508(V) 520K 1028(H)×596(V) 610K Horizontal Resolution 700 TV Lines (Color), 750 TV Lines (B/W) @ HR 7 mode Video Signal-to-Noise 50 dB Zoom ×33 Optical Zoom, ×32 Digital Zoom...
  • Page 79 SPECIFICATIONS CAMERA PART (361W Model) Video Signal Format NTSC Image Sensor 1/4'' Sony Super HAD II (Double Scan) CCD Total Pixels 1028(H)×508(V) 520K 1028(H)×596(V) 610K Horizontal Resolution 700 TV Lines (Color), 750 TV Lines (B/W) @ HR 7 mode Video Signal-to-Noise 50 dB Zoom ×36 Optical Zoom, ×32 Digital Zoom...
  • Page 80 SPECIFICATIONS MECHANISM PART 360°(Endless) Movement Range Tilt 90° Preset 500°/sec. Speed 0.05 ~ 360°/sec. (Proportional to Zoom) Swing 1~ 180°/sec. Preset 209 Presets (Label, Independent Camera Parameter Setting) Pattern 8 Patterns [880 Commands(Approx. 4 Minute) / Pattern] Swing 10 Swings 8 Groups (MAX.
  • Page 81 SPECIFICATIONS MECHANICAL Ceiling Mount Wall Mount In-Ceiling Mount Dome Polycarbonate Material Internal Polycarbonate, ABS External Aluminium Polycarbonate Dome Size ∅150mm / ∅ 5.9” Dimension ∅200×407.8 mm 300×309.1 mm ∅253×259 mm Weight Approx 3.6 Kg Approx 3.4 Kg Approx 2.3 Kg [Note] 1) Specification and features are subject to change without prior notice.

  • Page 82: Dimension

    SPECIFICATIONS Dimension Main Body Ceiling Mount Type 56.4 56.4 1.5" NPT 158.2 Wall Mount Type In-Ceiling Mount Type 118.6 4- 8 [Unit : mm] Speed Dome Camera Instruction Manual 82/82...
