INSTRUCTION MANUAL Ver 2.0 Mini Speed Dome Camera (x12)
Page 2
This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Page 3
NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.
CONTENTS ○ Introduction Features Product & Accessories Parts Name & Functions ○ Installation DIP Switch Setup Installation using Surface Mount Bracket Installation using Ceiling Mount Bracket Installation using Wall Mount Bracket Cabling ○ Operation Checking Before Operation Preset and Pattern Function Pre-Check Start OSD Menu Reserved Preset Preset...
INTRODUCTION Features Camera Specifications CCD Sensor : Sony 1/4" Super-HAD CCD (12T model) Sony 1/4" ExView-HAD PS CCD (12W model) Zoom Magnification : × 12 Optical Zoom, × 12 Digital Zoom (Max × 144 Zoom) Day & Night Function Various Focus Mode : Auto-Focus / Manual Focus / Semi-Auto Focus. Independent &...
Page 6
INTRODUCTION OSD(On Screen Display) Menu OSD menu is provided to display the status of camera and to configure the functions interactively. The information such as Camera ID, Pan/Tilt Angle, Alarm Input and Preset can be displayed on screen. Alarm I/O Functions 4 alarm sensor Inputs are available.
INTRODUCTION Product & Accessories Product & Accessories Accessory Main Body (Terminal Block, BNC Cable, Wrench, Screws) Options Surface Mount Bracket Wall Mount Bracket Ceiling Mount Bracket 7/42 Speed Dome Camera Instruction Manual...
INTRODUCTION Parts Name & Functions Assemble Reference Line Mount Bracket Mounting Hole Drop Prevention Drop Prevention Spring Spring Hook Cabling Terminal Block Lockup Screw DIP Switch Main Body Dome Cover Main Unit / Surface Mount Bracket Back of Main Unit Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust.
INSTALLATION DIP Switch Setup Before you install the camera, you should set the DIP switches to configure the camera ID, communication protocol. Communication Camera ID Protocol OPTIONS ADDRESS (ID) 16 32 64 128 Refer to the Manual NTSC Camera ID Setup ID number of camera is set using binary number.
Page 10
INSTALLATION Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol (Pin 1) (Pin 2) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps If you want to control using DVR or P/T controller, their protocol must be identical to camera.
Page 11
INSTALLATION Terminal resistor Setup Terminal resistor is used if your system is one of following two cases. Case1: Control cable between camera and controller is relatively very long (1:1 connection) If communication cable is very long, the electrical signal will bound in the terminal point.
INSTALLATION Installation using Surface Mount Bracket ① To pass cables through to upside of ceiling, make ② After assembling Rubber Gasket to Mount a hole whose diameter is about 50~60mm on the Cover, install Mount Cover on surface of ceiling ceiling panel.
INSTALLATION Installation using Ceiling Mount Bracket ① To pass cables through to upside of ceiling, make Turn camera housing axis ② a hole whose diameter is about 50~60mm on the CW(Clockwise) direction until it stops. ceiling panel. Then attach the Ceiling Mount Bracket ③...
INSTALLATION Installation using Wall Mount Bracket ① To pass cables through to inside of wall, make a ② Hook up “Drop Prevention Spring” on main body hole whose diameter is about 50~60mm on the to prevent camera from unexpected drop and wall.
INSTALLATION Cabling Power PWR(+) IrDA PWR(-) Sensor IN COM+ RS-485(+) RS-485(-) Door Controller/ DVR VIDEO(+) Switch VIDEO(-) Sensor Moinitor Cabling Terminal Block Power Connection Please, check the voltage and current capacity of rated power carefully. Rated power is indicated in the back of main unit.
Page 16
INSTALLATION Video Connection Connect with BNC coaxial cable. Alarm Input Connection Sensor Input Internal +5V~12V IN COM+ Sensor 1 Output IN 1- Sensor 4 Output IN 4- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.
OPERATION Check points before operation Before power is applied, please check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading DIP switch of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.
OPERATION Starting OSD Menu Function Using the OSD menu, Preset, Pattern, Swing, Group and Alarm Input function can be configured for each application. Enter Menu <Go Preset> [95] Reserved Preset Description Some Preset numbers are reserved to special functions. Function <Go Preset>...
OPERATION Preset Function Max. 127 positions can be stored as Preset position. The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics (i.e. White Balance, Auto Exposure) can be set up independently for each preset.
OPERATION Pattern Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern.
OPERATION Group Function The group function allows running sequence of Presets, Pattern and/or Swings. Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or swing. Preset speed can be set up and the repeat number of Pattern & Swing can be set up in Group setup.
OPERATION Other Functions Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, Swing and Group are available for this function but Jog actions are not available to resume. Auto Flip In case that tilt angle arrives at the top of tilt orbit (90°), zoom module camera keep moving to opposite tilt direction (180°) to keep tracing targets.
OPERATION OSD Display of Main Screen Action Title Preset Label LABEL12345 PRESET1 Image Flip Alarm Information I:1--4 Camera ID CAM 1 15/4/x1/N P/T/Z Information P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction. Camera ID Current Camera ID(Address). Action Title Followings are possible Action Titles and their meaning.
HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu. For all menu level, to go into sub menu, press NEAR key. To go to up-one-level menu, press FAR key. To move from items to item in the menu, use joystick in the Up/Down or Left/Right.
HOW TO USE OSD MENU Display Setup This menu defines Enable/Disable of OSD display on Main Screen. If an DISPLAY SETUP item is set to be AUTO, the item is displayed only when the value of it is ------------------------ CAMERA ID changed.
HOW TO USE OSD MENU PRIVACY ZONE MASK Setup Select area in image to mask. Select area in image to mask. PRIVACY ZONE ------------------------ Mask No [1~8] Mask No [1~8] MASK NO UNDEFINED Select Mask number. If the selected mask has DISPLAY Select Mask number.
HOW TO USE OSD MENU CAMERA SETUP Setup the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO Focus Mode [AUTO/MANUAL/SEMIAUTO] DIGITAL ZOOM IMAGE FLIP Sets camera focus mode. SHARPNESS STABILIZATION SEMIAUTO Mode <WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP>...
Page 28
HOW TO USE OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL ------------------------ In Manual mode, Red and Blue level can be set WB MODE AUTO ADJUST up manually BLUE ADJUST Red Adjust [0~255] Blue Adjust [0~255] BACK EXIT Auto Exposure Setup...
Page 29
HOW TO USE OSD MENU [OFF/LOW/MIDDLE/HIGH/MANUAL(0~15)] Enhances image brightness automatically in case that luminance level of image signal is too low. This function is fixed High value when Day/Night is Auto mode. SSNR [OFF/LOW/MIDDLE/HIGH] Enhances images by deducting noises when gain level of images is too high.
HOW TO USE OSD MENU Motion Setup Setup the general functions of Pan/Tilt motions. MOTION SETUP ------------------------ Motion Lock [ON/OFF] MOTION LOCK PWR UP ACTION If Motion Lock is set to ON, it is impossible to AUTO FLIP set up and delete Preset, Swing, Pattern and JOG MAX SPEED 120/SEC JOG DIRECTION...
Page 31
HOW TO USE OSD MENU Parking Action Setup If Park Enable is set to ON, camera runs assigned function automatically PARKING ACTION SETUP ------------------------ if there is no PTZ command during assigned "Wait Time". PARK ENABLE WAIT TIME 00:10:00 Park Enable [ON/OFF] PARK ACTION HOME...
Page 32
HOW TO USE OSD MENU Alarm Input Setup Sets alarm function. ALARM INPUT SETUP ------------------------ ALARM NO. Alarm No [1~4] TYPE N.OPEN Selects a sensor number to set up. ACTION NOT USED HOLD TIME ENDLESS POST ACTION HOME Type [Normal OPEN/Normal CLOSE] Sets sensor operation type.
HOW TO USE OSD MENU PRESET Setup Preset Number [1~128] PRESET SETUP ------------------------ If a selected preset is already defined, camera PRESET NO. moves to pre-defined position and preset CLR PRESET CANCEL characteristics such as Label and Relay Outputs <EDIT SCENE> <EDIT LABEL>...
Page 34
HOW TO USE OSD MENU Edit Preset Scene Using Joystick, move camera to desired position. ○ EDIT SCENE - PRESET 1 ------------------------ By pressing NEAR key, save current PTZ data. ○ Press FAR key to cancel. ○ MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL] Edit Preset Label...
HOW TO USE OSD MENU Swing Setup Swing Number [1~8] SWING SETUP ------------------------ Selects Swing number to edit. If a selected Swing SWING NO. 1ST POS. NOT USED has not defined, "NOT USED" is displayed in 1st 2ND POS. NOT USED Position and 2nd Position SWING SPEED 30/SEC...
HOW TO USE OSD MENU Pattern Setup Pattern Number [1~4 ] PATTERN SETUP ------------------------ Selects Pattern number to edit. PATTERN NO. UNDEFINED If a selected pattern number is not defined, CLR PATTERN CANCEL RUN PATTERN "UNDEFINED" will displayed under <EDIT PATTERN> selected pattern number.
HOW TO USE OSD MENU Group Setup Group Number [1~8] GROUP SETUP ------------------------ Selects Group number to edit. GROUP NO. UNDEFINED If a selected Group number is not defined, CLEAR GROUP CANCEL RUN GROUP "UNDEFINED" will be displayed under selected <EDIT GROUP>...
Page 38
HOW TO USE OSD MENU ④ Set up items such as Action, ###, Dwell and OPT. EDIT GROUP 1 ------------------------ NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ SAVE :MOVE CURSOR] CANCEL [...
HOW TO USE OSD MENU System Initialize Clear All Data Deletes all configuration data such as display, SYSTEM INITIALIZE camera, motion setup and so on. ------------------------ CLEAR ALL DATA CLR DISPLAY SET Clear Display Set Initializes Display Configuration CLR CAMERA SET CLR MOTION SET CLR EDIT DATA Clear Camera Set...
SPECIFICATIONS Specifications Appearance Model 12T model (×12) Video Signal System NTSC Sony 1/4'' Super-HAD CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. Min. 560 TV Line(Color), 600 TV Line(B/W) S/N Ratio 52 dB (AGC Off) Zoom ×12 Optical Zoom, ×12 Digital Zoom Focal length...
Page 41
SPECIFICATIONS Specifications Appearance Model 12W model (×12, WDR) Video Signal System NTSC Sony 1/4'' ExView-HAD PS CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. Min. 560 TV Line(Color), 600 TV Line(B/W) S/N Ratio 52 dB (AGC Off) Zoom ×12 Optical Zoom, ×12 Digital Zoom...
SPECIFICATIONS Dimension Main Unit & Surface Mount Bracket Ceiling Mount Bracket 158.2 56.4 56.4 3/4" NPT 1.5" NPT 3/4" NPT Wall Mount Bracket 118.6 Unit (mm) 42/42 Speed Dome Camera Instruction Manual...
