Model 341
Black Beauty Slimline
LIVE FUEL EFFECT GAS FIRE
(GC No. 32-032-30)
We trust that this guide gives
sufficient details to enable this
appliance to be installed and
maintained satisfactorily. However, if
further information is required, our
Baxi Fires Division Technical
Helpline will be pleased to help.
Telephone 08706 061 065 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 8706 061 065.
INSTALLER: Please leave this guide with the
©
Baxi Heating U.K. Limited 2007.
INSTALLER GUIDE
THIS APPLIANCE IS FOR USE WITH
NATURAL GAS (G20).
THIS APPLIANCE IS SUITABLE ONLY
FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC
OF IRELAND (IE).
600B690/13
owner
Advertisement
Table of Contents
Related Manuals for Baxi Fires Division 341 Black Beauty Slimline
Summary of Contents for Baxi Fires Division 341 Black Beauty Slimline
- Page 1 However, if THIS APPLIANCE IS SUITABLE ONLY further information is required, our FOR INSTALLATION IN THE UNITED Baxi Fires Division Technical KINGDOM (GB) AND THE REPUBLIC Helpline will be pleased to help. OF IRELAND (IE). Telephone 08706 061 065 (National call rates apply in the United Kingdom).
- Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Baxi Fires Division, Erdington, Birmingham B24 9QP www.firesandstoves.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication ©...
- Page 3 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Baxi Fires Division is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance. Careful Installation Baxi Fires Division is a CORGI registered company.
-
Page 4: Table Of Contents
INSTALLER GUIDE CONTENTS Section Heading Page 1 SAFETY 2 LIST OF ACCESSORIES 3 APPLIANCE DATA 4 GENERAL INSTALLATION REQUIREMENTS 4.11.2 Conventional fireplace. 4.11.3 Wall mounting to conventional or pre-cast flues. 4.11.4 Precast flues. 4.11.5 Metal flue box. 5 PRE-INSTALLATION PREPARATION 5.1 Unpacking. -
Page 5: Safety
INSTALLER GUIDE 1 SAFETY Installer Before continuing any further with the installation of this appliance please read the following guide to manual handling: The lifting weight of this appliance is 16.86 kg. One person should be sufficient to lift the fire. If for any reason this weight is considered too heavy then obtain assistance. -
Page 6: Appliance Data
INSTALLER GUIDE 3 APPLIANCE DATA Natural (G20) Inlet Pressure 20mbar Gross Heat Input Control Setting 5.05kW (17,200Btu/h) 3.45kW (11,800Btu/h) 1.80kW (6,100Btu/h) 1.55kW (5,300Btu/h) Burner Test Pressure (Cold) 17.2 + 0.75mbar (6.9 + 0.3in w.g.) Gas Connection 8mm pipe Burner Injectors Upper Bray Cat. - Page 7 INSTALLER GUIDE The convertion of net efficiency to gross was achieved by multiplying the net efficiency by the following conversion factor from Table E3 of SAP 2005, rounding down to the nearest whole number. Conversion factor from net to gross efficiency Natural Gas 0.901 This product uses a burner gasket and burner surface containing Refractory...
-
Page 8: General Installation Requirements
INSTALLER GUIDE 4 GENERAL INSTALLATION REQUIREMENTS The installation must be in accordance with these instructions. For the user’s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations. - Page 9 INSTALLER GUIDE Any chimney dampers or restrictors should be removed. If removal is not possible they must be fixed in the open position. Normal adventitious ventilation is usually sufficient to satisfy the ventilation requirements of this appliance. In GB reference should be made to BS 5871 Part 2 and in IE reference should be made to the current edition of IS 813 “Domestic gas Installations”...
- Page 10 INSTALLER GUIDE The minimum allowable distance from the outside of the appliance fascia to a corner wall having combustible material or any other combustible surface which projects beyond the front of the appliance is 100mm at either side (See figure 1). A clearance of 100mm should be maintained at the right side in all installations to allow satisfactory access to the control knob.
-
Page 11: Conventional Fireplace
4.11 In the United Kingdom, as supplied, this appliance can be installed in the following situations: - Note: A spigot extension is available (Baxi Fires Division part number 0595191). When fitted this shall extend through the closure plate for at least 15mm and have a minimum clearance of 50mm from the end to any surface. -
Page 12: Precast Flues
INSTALLER GUIDE finished floor covering. Any opening visible below the appliance may be closed in but the depth of the catchment space within the wall opening must be as shown in figure 2. 4.11.4 Precast flues. The appliance can be installed to a fireplace that has a properly constructed precast concrete or clay flue block system conforming to BS1289 or BS EN 1806. - Page 13 INSTALLER GUIDE * The total height of the closure plate is 660mm and will accommodate a maximum opening height of 650mm (This allows a 10mm overhang). Heights above 635mm (Inclusive of sealing tape) will leave the sealing tape and closure plate visible above the appliance.
- Page 14 INSTALLER GUIDE There must also be a minimum clearance of 165mm between the back of the closure plate and the back of the catchment space. On conventional flues the catchment space below the flue spigot must extend at least 250mm downward measured from the bottom of the flue spigot (See figure 2). 4.16 The front of the fireplace should be flat over an area sufficient to ensure a good seal with the closure plate.
-
Page 15: Pre-Installation Preparation
INSTALLER GUIDE 5 PRE-INSTALLATION PREPARATION 5.1 Unpacking. The carton contains the following:- 1off Fire assembly. 1off Ceramic fuel effect (In packaging inside firebox). 1off Closure plate. 1off Smoke match tube. 1off Olive & olive nut for gas line connection 1off Literature pack Remove all the items carefully to prevent damage. - Page 16 INSTALLER GUIDE fascia upward and forward to clear the top location (See figure 5). 5.3.6. The front of the fascia is secured by two screws as shown in figure 6. These screws have been tightened to avoid damage to the fascia during transit. These screws must be slackened to enable the customer to remove this section of the fascia.
- Page 17 INSTALLER GUIDE 5.4 Fitting the closure plate. (See figure 8). The closure plate has an opening at the bottom for a central gas feed pipe. The gap between the pipe and this opening should be sealed with tape after connection. If a central feed pipe is not required the opening should be completely sealed with tape.
-
Page 18: Appliance Installation
INSTALLER GUIDE Figure 10. Closure plate for wall mounting. 6 APPLIANCE INSTALLATION 6.1 Installing to a hearth. 6.1.1 Place the fire centrally on the hearth making sure that the spigot lines up with the spigot hole in the closure plate. Gently slide the appliance into place being careful not to scratch the hearth. -
Page 19: Gas Supply Connection
INSTALLER GUIDE with four no. 10 x 2in. woodscrews. 6.3 Gas supply connection. 8mm rigid tubing must be used to connect the gas supply to the appliance. An olive and nut are provided for connection to the inlet “T” connector on the appliance. The connector can be rotated to allow connection from either side or the rear. -
Page 20: Check Burner Pressure
INSTALLER GUIDE orifice is clear and that the thermocouple connections are sound. Replace the pilot unit if necessary (see servicing section of this manual). 7.1.6 Check all the control settings. These are:- Control Knob Burner appearance Position 1 / IGN Centre section on low. -
Page 21: Flame Supervision And Spillage Monitoring System
If the valve does not operate within this time limit do not allow the appliance to be used until the fault has been corrected. This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system must only be exchanged using Baxi Fires Division authorised parts. ©... -
Page 22: Final Assembly And Review
INSTALLER GUIDE 8 FINAL ASSEMBLY AND REVIEW 8.1 Fitting the fascia. 8.1.1 Detach the control knob and control bezel. 8.1.2 Refit the fascia. The fascia top rear strip should locate in front of, but touching, the side extensions of the engine back panel (See figure 14). -
Page 23: Servicing And Parts Repacement
INSTALLER GUIDE the flue is primed during the first 20 - 30 minutes of use. To do this, simply turn the control to its highest setting. This will also burn off any carbon deposits that may have formed during previous use. If using the appliance for long periods it is beneficial to change between settings. -
Page 24: To Remove The Window Unit
INSTALLER GUIDE 9.1 To remove the window unit. 9.1.1 Detach the window surround by sliding it upwards and then swinging the bottom forwards (See figure 6 in the installation section). Lift and store carefully. 9.1.2 Remove the window unit by removing the screws each side of the window frame and lifting the unit clear. -
Page 25: To Remove The Piezo Generator
INSTALLER GUIDE 9.5 To remove the piezo generator. 9.5.1 Remove the gas tap as section 9.4. 9.5.2 Make sure that the tap is in the off position. 9.5.3 Remove the circlip holding the piezo unit to the tap. Remove the piezo unit. 9.5.4 Replace in the reverse order. -
Page 26: To Remove The Complete Burner Module, Pipes And Pilot
INSTALLER GUIDE 9.8 To remove the complete burner module, pipes and pilot. 9.8.1 Remove the fascia as section 9.2. 9.8.2 Remove the ceramic fuel effect as section 9.3. 9.8.3 Support the inlet ‘T’ connector to avoid straining the pipework and disconnect the appliance.
